USER'S MANUAL

Please keep the instruction manual properly.
1
2
3
4
1
All parameters of this vehicle have been permanently set according to the national standard before leaving factory. The company is not
responsible, if the original electrical or circuit has been changed and caused excess, such as increase of the speed, change of the voltage,
change the battery capacity, or change the pedal riding ability
USER INSTRUCTION
To ensure your safety,please read this manual carefully before riding and make sure you are
always following the requirements below:
Fully understand the information in this manual, include but not limited to the relevant instruction, precautions
and warnings.
Fully understand the operation and contingency measures of RU smart electric bike.
Be fully aware of warning labels of RU smart electric bike.
Don’t disassemble vehicle or any parts, if need replacement, please contact your local dealer.

To ensure the safety of you and others, please make sure to observe the following matters:
1
2
3
4
5
6
7
8
9
SAFETY INSTRUCTION
2
Don’t lend your vehicle to someone who can’t operate it in order to prevent any injuries.
No minors under 16 years old are allowed riding on the road.
Do not ride after you take medications which may affect your riding ability, drink alcohol, or when you are
unwell.
Observe traffic regulations and traffic signs, according to the provisions of laws and regulations to carry people
and cargo. Confirm the surrounding road conditions and bike conditions any time, so as to actively avoid
injuries.
In rainy and snowy weather braking distance will be extended, please slow down; avoid traveling in bad
weather such as storms and typhoons.
Wear safety equipment, such as helmet, and appropriate protective clothing if necessary, such as gloves and
mask.
In order to guarantee safety of you and others , please turn on lights timely in the case of poor visibility.
Please turn off the power and remove the key immediately after use. Do not allow children to play, so as to
avoid accidents.
Perform a basic check each time before riding, and regularly go to SOCO Service Center for maintenance.

3
10
11
Please make sure that the electric bicycle is save to ride
a. Electric bike should not be parked in building foyers, evacuation staircases, walkways, and safety exits.
b. Electric bike should not be charged and parked in residential buildings, should be far away from combus-
tible when charging, do not exceed the recommended charging time.
c. Please pay attention to the correct use of the battery and warnings; Old battery should be recycled properly.
d. Please pay attention to the safe use method and warnings for the charger;When changing the charger, it
should match the model of the battery.
e. Please pay attention to the matters concerning washing.
Check before riding. If there is any abnormality, please timely carry out maintenance or seek professional
maintenance.
a. Check the status of power circuit, lighting circuit, etc.
b. Check whether the front and rear brakes work normally:
c. Check for proper alignment of handlebars, front and rear
wheels:
d. Check the tire pressure:
e. Check the reflector for damage or contamination.
SAFETY INSTRUCTION

Battery type: lithium battery
Capacity: 20Ah
Nominal voltage: 48V
Motor type: brushless dc motor
Motor power: 700W
rated rotatespeed: 400r / min
rated voltage: 48V
Controller undervoltage protection value: 36±0.5V
Main technical parameters of the vehicle
L*W*H mm: 1643X725X1044
Front and rear wheel center distance: 1160 mm
Weigh: 54.5kg
Max speed: 32km/h
Range ≥50km（@20km/h）
Power consumption of every hundred kilometers: 1.2kW·h/100km
load weight: 85kg
Specific cations
Main technical parameters and performance index
RU Main technical parameters
Quick Start
4
Controller overcurrent protection value: 20±0.5A

01
QUICK START
Check accessories items
2
X1
X1
X
1
X1 X
2
X
Intelligent remote control
key
Left&right rearview mirror
Rearview mirror wrench
Instruction manual
Charger
5

02
Install rear-view mirror
6
QUICK START

Open seat cushion/
battery compartment.
03
Install battery pack
1Put in the battery pack. Plug in the main plug. 2 3 Drop the seat cushion. 4
7
QUICK START

04
Start the vehicle
1Wear helmet. 23Gently turn the handle
to ride on the road.
4
a b c d
Pack up the main stand
and ride RU
8
Press the "unlock key"
of the intelligent
remote control key,
and then press the
"pass-key" to enter the
"energized state" of
the vehicle.
QUICK START

Parts description
Operational guidelines
Cycling guidelines
Battery instructions
The maintenance
Common problems
10
13
15
18
22
23
CONTENTS
9

10
SIDE VIEW
a. Complete vehicle parts schematic diagram
headlamps
The vehicle codeRear view mirror
Disc brake
Battery compartment
FOC vector controller
The motor
Main stand
PARTS DESCRIPTION
Nameplate position
Lighting and
reflector position

The saddle
Rear brake handle Left hand switch set
Throttle
instrumentpanel
PARTS DESCRIPTION
a. Complete vehicle parts schematic diagram
TOP VIEW
Front brake handle
11

Speed display/error code
Percentage of electricity display
Headlight status display
Signal of headlights on/off
NOTE:
Charging status light indicates/low power status
Charging status display
Quantity indicator bar
Total VMT/single VMT
b. Instrument diagram
1
1
6
2
2
3
5 6
4
3
4
PARTS DESCRIPTION
Display the current battery percentage Display current battery level
Display total vehicle mileage/single trip mileage
5
12
Displays the current speed, and displays the
error code when the error prompt is on
Troubleshooting tips When the charge indicator light power ≤10% flashes

1
2
OPERATIONAL GUIDELINES
a. Left combination switch
Press and hold the horn to sound, release and stop.
The horn button
Headlight switch
One touch to switch on/off.
1
2
13

b. Intelligent remote control operation c. Open battery compartment
1
2
3
Unlock
Lock
On/off key
14
RU adopts the second generation of intelligent remote control of
SOCO, which can easily lock or unlock the vehicle by pressing the
key within the effective distance.
When the vehicle is in a static
state, press the ‘lock’ button
lightly, and the vehicle enters the
locked state.
Press the ‘unlock button’ to
unlock the vehicle.
When unlocking the vehicle, press
the button lightly, the vehicle
enters the energized state, and
the vehicle can be started with a
light twist.
When the vehicle is electrified and
remains in a static state, press the
button gently and the vehicle
enters the state of power failure.
Insert and turn the
key to the right to
open the battery
compartment.
OPERATIONAL GUIDELINES

tire, it needs to be
Whether the handlebar is stable and whether it's rotating freely.
Whether the switches of the left and right on the handlebar work properly.
Whether the throttle works properly.
Ensure normal tire pressure, recommended for front wheels 175-225kpa\ rear wheels 200-250kpa.
There are no cracks, damage, wear, foreign body puncture or adhesion on tire surface.
Whether the tread pattern depth is enough, if it is worn to the black shadow mark of the schematic
replaced.
If there is any fault warning light on the instrument panel after power on.
Whether the battery is fully charged.
Whether the head and tail lights, brake lights and direction lights are working properly.
Check if the horn is working properly.
The rear view mirror is clean and adjusted to an appropriate angle.
Whether the handlebar and brake system work properly.
1
2
3
4
5
6
7
8
9
10
11
12
For any exceptions or operational concerns, please contact SOCO customer service center.
a. Check items before riding
CYCLING GUIDE
15
6
Before riding RU smart electric vehicle, please make sure to check the following items, which will guarantee your safety on the
road.

b. Start the vehicle
12
3Gently turn the handle to
ride on the road.
4
Lift up the main stand
and ride RU.
Press the “unlock"
button of the intelligent
remote control, and
then press the
“On/Off" button to
enter the "energized
state" of the vehicle.
The vehicle must be in a completely stationary state before starting. If the vehicle is on the road, please push the vehicle to a safe area carefully. Do
not attempt to restart the vehicle on the road or lane to avoid danger.
Before riding, make sure that the main stand is in a stowed state
16
CYCLING GUIDE
Wear helmet.

c.
1
2
3
4
5
For any exceptions or operational concerns, please contact SOCO customer service center.
Riding notes
When starting the bike, accelerate slowly to avoid increase of energy consumption caused by instanta-
neous rapid acceleration.
In order to ensure safety, the riding speed should be kept as steady as possible to reduce the energy
consumption caused by frequent starting, braking, instantaneous acceleration and other
operations.
The maximum load of this bike is 85KG. Do not overload the bike.
Press the "On/Off" button of the intelligent remote control when carrying out the vehicle to ensure that the
vehicle is in a state of power failure, so as to prevent accidental turning of the handle, resulting in sudden
start of the bike and accident.
Open the main stand when parking and press the “lock”button of the intelligent remote control.
17
CYCLING GUIDE

BATTERY INSTRUCTIONS
Open the battery
compartment
Charging method 1: directly charge the battery:
Disconnect the
battery pack main
plug.
1 2 3 4 5 Indicator light is
red when charging
normally, and green
when full.
18
Remove the battery
from the battery
compartment
(or not).
Insert the main
plug of the charger
into the charging
port of the battery
pack, and then
insert the ac plug
of the charger into
the socket.

TIPS：
Serious warning: avoid the battery to rain or flush, do not soak the battery in water, the vehicle must not wade into the water
above the bottom height of the battery compartment, otherwise it may cause the battery water, internal short circuit, battery
permanent failure.Under such circumstances, it is strictly forbidden to charge the vehicle or the battery again, otherwise it will
cause the danger of battery fire, combustion and explosion. Please immediately hand over the battery to the network for
maintenance.In extreme cases, internal fire, spontaneous combustion, explosion.
Open the battery compartment.
Disconnect the battery pack main plug.
Insert the main plug of the charger into the charging port of the battery pack, and then insert the ac
plug of the charger into the socket.
Indicator light is red when charging normally, and green when full.
1
2
3
4
BATTERY INSTRUCTIONS
Charging mode 2: charge the battery on-board
19
