Super SOCO TC-MAX User manual
USER INSTRUCTIONS
Welcome to the family of SUPER SOCO owners! We will guide you to know every function for the right and safe use of
TC-MAX smart electric bikes.To ensure your safety, please read this manual carefully before riding and make sure you
are always following the requirements below:
1Fully understand the information in this manual, including but not limited to the relevant instructions, precautions and warnings.
2Fully understand the operation and contingency measures of TC-MAX smart electric bikes.
3Be fully aware of warning labels of TC-MAX smart electric bikes.
4Do not disassemble the electric bike and parts without permission, Please contact customer service department and dealers if you need any replacement or
do further purchase.
5Please keep this User Manual properly
Warning
All parameters have been permanently set according to national standards before delivery, our company is not responsible for anything change like the original electrical circuit
,wire harness and maximum speed.
Please contact the SUPER SOCO Customer Service Center 400-021-2008 if you have any questions about this bike. We are at our service at any time. Wi sh you safe and pleasant riding
experience!
1
To ensure the safety of you and others, please make sure to observe the following matters:
1Please do not lend your vehicle to someone who can not control it to avoid injury
2Minors under 16 years old is not allowed to ride our bike on the road.
3Please ride your bike in the bicycle lane, do not exceed the maximum speed (Keep right on the road if there is no bicycle lane)
4Do not ride after you take medications which may effect your riding ability, drink alcohol or when you feel physically
upset.
5Observe traffic regulations and traffic signs,manned and loaded in accordance with local laws and regulations and confirm the surrounding road conditions and
bike’s conditions at any time, so as to actively avoid danger.
6In case of rain and snow, the braking distance shall be increased. Pay attention to slowing down the speed.Try to avoid traveling as much as possible in
inclement weather condition.
7Wear safety equipment, such as helmet, and appropriate protective clothing if necessary, such as gloves and boots.
8In order to ensure the safety of you and others, please DO NOT use high beam in good lighting conditions.The continuous use of high beam will cause the
visual disturbance to vehicles and pedestrians on the opposite side, affecting normal driving.
9Please turn off the power ,remove the key immediately after riding.Keep away from the children, avoid the loss of
your family and property.
10 Perform abasic check each time before riding, so as to confirm the light, brake, tread and tire pressure and check other parts for looseness or abnormal noise,
and regularly go to official dealer’s service center for maintenance.
2
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
11 Check before riding. In case of any abnormality, please timely repair or go to official dealer’s service center.
a. Check the power circuit, lighting circuit statues etc.
b. Check whether the front and rear brakes work properly
c. Check the handlebar and the front and rear wheels fixing
d. Check the tire pressure
e. Check the belt whether loose or damaged
f. Check the belt wheels whether it is damaged
g. Check the belt whether belt wheel tooth groove
3
2 1 1
1
Spanner for mirrors
12
Quick Start
Keys
Mirrrors User manual
Charger
QUICK START
01
PARTS INSPECTION
4
02
INSTALL BATTERY PACK
1 Open storage,take out cover. 2 Put battery package in. 3 Connect power plug. 4 Switch off kill switch,put seat
back.Put storage cover back and
close storage.
5
QUICK START
03
IGNITE TC-MAX
1 Press ‘UNLOCK’ on remote
control, “POWER” button on.
Put helmet on.
4 Press ‘Power’ , power on.
23 Get on TC-MAX, kick side stand
out.
5 Press ‘Parking’ button,
unpacking TC-MAX, parking
symbol off.
6 Turn accelerator gently, TC-
MAX run.
QUICK START
6
04
DOWNLOAD APP
TC-MAX smart electric bikes has GPRS function,can connect with your smart phone.
By APP,you can use smart phone to manage and query your TC-MAX. Only IOS and Android
are currently available now,
please confirm your smart phone operating system in advance.
IOS system:APP only support Apple ISO 9.0 system and above. Android system: APP onl y
support Android 4.4 system and above.
Download and install the SUPER SOCO APP by QR code in this manual or key box.
SOCO APP
QUICK START
7
Description of Components and Parts Operation
guide 12
Riding guider
09
17
Battery use instruction 20
App instruction 23
Maintenance 24
FAQ & Trouble shooting 25
CONTENTS
8
A. SCHEMATIC DIAGRAM OF COMPONENTS AND PARTS
TOP VIEW
Headlamp
compartment
Storage box Front brake
lever
Tall lamp
Left-handlebar switch assy
Battery Winker
SIDE VIEW
Rear mirror
Brake disc
Motor
Electronic side stand
FOC vector controller Rear brake Spoke-type
aluminum rim lever
Brake cylinder
Accelerator
Right-handlebar switch assy
Speedometer assy
Saddle
DESCRIPTION OF COMPONENTS AND PARTS
9
B. DIAGRAM OF SPEEDOMETER
2
6
5
1
1Speed
Display current speed
2 Temperature & distance Distance per
charge/ trip distance/ rotating speed, ambient
temperature
3 Total mileage
Display the total mileage
3
4
4 Controller temperature
Display the temperature under current
operating conditions
7
7 Gear Display
Display current driving gear.
5 Power display bar 6 Battery percentage display
Display current battery power Display the current battery power level percentage
DESCRIPTION OF COMPONENTS AND PARTS
10
B. DIAGRAM OF SPEEDOMETER
M M bottom instruction
Displacement switching Range/Temperature
Innormal mode，press the switch for one second, turned into
force switch and keep the status.
Manually start the back light of Speedometer (Back light for Letters +LCD back
light)
In normal mode, press it longer than two seconds but shorter than 8seconds, start
the back light for speedometer and head light.
Change between KM/Mile and KM/P &MPH
In normal mode, press it longer than 8 seconds, then release.
Press it less than 2 seconds, change indications, and keep the status.
Press it longer than 2 seconds but shorter than 8 seconds, start the back light for
speedometer and head light.
Press it longer than 8 seconds, then release.
NORMAL Mode ECO ModeData connecting
Charging
High beam indicator
Winker indicator light on
Battery error
Prompt fault code
Parking Light
M
DESCRIPTION OF COMPONENTS AND PARTS
11
1 High/low beam switch
Up position, high beam on; Down
position, low beam on.
3 Right switch
Press, horn on; release, horn off.
2 Winker switch
2
A.LEFT SWITCH
Turn to left, left winker on; Turn to right,
right winker on.
3
1
OPERATION GUIDE
12
1 Front Light switch
Up position, front light on;Down position, front light
automatically on.(Front light adjust the lightness
automatically according to environment) Remark:The
front light always on at EEC state.
B. RIGHT SWITCH 1
3 Parking switch
Press,light on, TC-MAX at parking position;
Press again, TC-MAX ready to ride.
2 Mode switch
TC-MAX is set with 3modes:
1: ECO mode 2: NORMAL mode 3: SPORT mode.
Position at left, mode 1; position in the
middle, mode 2; position at right, mode 3.
2
3
OPERATION GUIDE
13
E.UNLOCK
UNLOCK, When TC-MAX in lock state,press “UNLOCK”, “POWER”
continuously on,TC-MAX unlocked.
F.POWER
After unlocking TC-MAX via remote control, press the
“POWER”, power on, press again, power off.
“POWER” flash, locked status.
“POWER” continuously on, stand-by status
Red circle continuously on, TC-MAX ready to ride.
C.REMOTO CONTROL
TC-MAX use second generation smart remote control, within 50 meter radius, press the button, can lock or unlock your TC-MAX.
D.LOCK
LOCK, when TC-MAX in resting state, press
“LOCK”, “POWER” flash, TC-MAX locked.
OPERATION GUIDE
14
g.HANDLEBAR LOCK
1TC-MAX in parking position, turn handlebar to the extreme left position, put key in handlebar lock, and turn the key to right position, handlebar locked.
2Put the key in handlebar lock, turn the key to left position, handlebar unlocked.
h.STORAGE &SEAT
1Put key in storage&seat lock, turn key to right direction, when hear sound “click”, storage open.
2Put key in storage&seat lock, turn key to left direction, seat open.
OPERATION GUIDE
15
g.KILL SWITCH
Kill switch, protect power, when current over than set range cause by abnormal situation or short circuit, kill switch will stop the connection between battery and TC-MAX
automatically, for safety reason.
TIPS: For your own safety, please put kill switch at “OFF” position:
A. Before taking out batt ery pack;
B. Before cleaning and washing;
C. Long time storage.
16
OPERATION GUIDE
ON OFF
6
7Whether the belt has abrasion, cracks, broken teeth or not.
8Whether there are stones or other foreign bodies in the belt teeth or not.
9Whether any error warning light in the speedometer with power on or not.
10 Whether the battery capacity is enough for your trip.
11 Whether all light work properly or not.
12 Whether the horn work properly or not.
13 Whether the mirrors are clean and adjust them to the appropriate angle.
a. CHECKING LIST BEFORE RIDING
Make sure to check the following items before riding your TC-MAX
1Whether the handlebar is stable and flexible when turning.
2Whether the right and left switches on the handlebar can work properly or not.
3Whether the accelerator can work properly or not.
4Make sure the tyre pressure is connect. The recommended tire pressure is 200Kpa for front wheel, 225Kpa for rear with rider only and 200Kpa for front
wheel,250Kpa for rear when 1 rider with 1passenger.
5Check tyre surface, make sure no cracks, damage, and foreign matter puncture or attachment.
6Whether the tread depth is enough,such as worn to the black shadow position on the sketch ,tyre need to be replaced.
14 Whether the brake oil is enough, whether the brake lever and brake system work properly or not.
Any exceptions or operational doubts, please contact Super SOCO official dealer’s service center.
RIDING GUIDE
17
b. POWER ON
1 Press “UNLOCK” on remote control,
“POWER” continuously on.
2 Put on helmet. 3 Riding TC, kick out side stand.
4 Press “POWER”, power on. 5 Press ‘Parking’ button, unpacking TC-
MAX, parking symbol off.
6 Turn throttle gently, TC-MAX run
RIDING GUIDE
18
RIDING GUIDE
TIPS：
1Before riding, make sure side stand is kicked out, handlebar is unlocked.
2DON’T press “PARKING” during riding, in case any dangerous due to motor power off and in parking
status.
3DON’T put side stand at standing position, in case any dangerous due to motor power off and in
standing status.
4TC-MAX need to power on under steady standing status. In case any unusual situation, please move the bike to side of the road, in case any
dangerous,please don’t restart the bike when it still running or in the middle of the road.
c. NOTICE
1After the riding start, it should accelerate slowly to avoid excessive starting current caused by instanta-neous rapid acceleration and increase
energy consumption
2Under the premise of ensuring safety, try to keep a constant speed on the way you are driving, reduce frequent starts, brake, instant
acceleration, etc.
3The maximum load of TC-MAX is 150KG. Overload is strictly prohibited
4Press “Parking” switch while pushing the bike, in order to prevent the unintentional handlebar rotation causing an accident.
5Please turn off the power while packing and remove the key
19
