Super Vision International IGP231 User manual

8210 Presidents Drive
Orlando,Florida 32809
svision.com
WARNING!
PERMANENT
DAMAGETOTHE
12VAC LAMPWILL
OCCUR IF IT
INSTALLED IN A
120VAC SOCKET.
The IGS54 and the IGS321
are available in either
12VAC(low volatge) model
and a 120VAC mode.
The 120VAC light has a
gold or brass colored
Edison screw base.
The 12VAC Edison screw
base is a silver or aluminim
color.
DANGER!
RISK OF ELECTRICAL
SHOCK OR
ELECTROCUTION
Always disconnect power
to the pool or spa light at
the circuit breaker before
servicing the light. Failure
to do so could result in
death or serious injury to
the installer, servicemen.
pool and spa users or
others due to electrical
shock.
Refer to the original
manufacturer’s installation
manual before proceeding.
This device is not intended
for use with emergency
exit fixtures or emergency
exit lights.
IGS54
Spa LED Lamp
DELIVERTO HOMEOWNER
IGP231/IGS54
Galaxy LED Lamp
Installation/Operation/Warranty
This guide contains important information on installing
and using your Galaxy LED Lamp. Please read it
carefully and save it for future reference.
Rated Lamp Life
The illumination generated by the Galaxy LED Lamp is
based on Light Emitting Diodes (LED) whose predicted
source life is rated at 100,000 elapsed time hours under
normal operating conditions.
[Temperature: -4° to 104°F (-20°C to 40°C), Humidity:
0-95% non-condensing humidity]. This equates to 11.4
years of continuous 24-hour a day usage.
Safety Precautions
Do not open, alter or tamper with the product. This
will void the manufacturer’s warranty. Follow all
instructions in the user guide,and observe all warnings
carefully.
• Do not allow the LED unit to get wet. It is conformal
coated to protect it from moisture.
• Keep the unit dry.
• Handle the Galaxy LED Lamp as you would any
delicate product. Be careful not to drop the unit.
IGP231
Pool LED Lamp

Installation for IGP231/IGS54
Galaxy LEDPool & Spa Lamps
NOTE: Galaxy LED Lamp fits most 12VAC and 120VAC wedge-based lighting
sockets. Galaxy LEDLamparenot for usewithspasthathavedimming systems or
electronic controllers.
STEP 1
Access the old lamp according to your spa
manufacturer’s instructions. Remove the locking
ring. (Fig.1)
STEP 2
Remove the existing lamp.(Fig.2),
WARNING: Always install a new lens gasket
wheneverdisassembling the light. Failure to doso
may permit water to leak into the assembly,
whichcouldcause:anelectricalhazardresulting in
death or serious injury to pool and spa users,
installers or others due to electrical
shock; or breakage of the lamp or lens
which could result in serious injury to
pool and spa users, installers,
bystanders,or in property damage.
STEP 3
Replace the existing gasket with a new
one. (Fig.3)
STEP 4
ScrewintheGalaxy
LED Lamp into the
socket.
(Fig.4A,4B)
(Fig.1)
(Fig.2)
(Fig.3)
(Fig.4A) (Fig.4B)

Installation for IGP231/IGS54
Galaxy LEDPool & Spa Lamps
WARNING: Some housings use a special
pilot screw. This screw mounts and electrically
groundsthehousing securelytothe mounting
rings and wet niche. Failure to use the screw
could create an electrical hazard which could
resultindeathorserious injurytopoolandspa
users, installers or others due to electrical
shock.
(Fig.5)
Controlling the IGP231/IGS54
Galaxy LEDPool & Spa Lamps
Use the pool or spa’s existing light switch to control the effects.
CHOOSING EFFECTS
Galaxy LED Lamps are pre-programmed with an assortment of lighting effects.
• When you turn the Galaxy LED Lamp off and then on again within three
seconds,it advances to the next effect.
• When you turn the Galaxy LED Lamp off and leave it off for more than five
seconds,it returns to the first mode“white”.
DESCRIPTION OF EFFECTS
1. White only
2. Color Change- Colors transition from color to color,cycling through the
color spectrum. Each color cycle take approximately 1 minute.
3. Yellow
4. Blue
5. Orange
6. Green
7. Hot Pink
8. Cyan
9. Blue/Green Mix
10.Party Mode™ - Multiple Colors transition quickly,cycling through the
color spectrum.

Warranty
Super Vision® International, Inc. warranties its products to be free from defects in
material and/or workmanship,under normal use,conditions and service,for a period
of ONEYEAR from the date of original purchase.In the event of a defect in material or
workmanship during the warranty period, Super Vision® will repair or replace (at its
discretion) its products under the conditions of theWarranty. SuperVision® will do so
at its expense for the materials but not for shipping. This remedy is the sole and
exclusive remedy for any and all claims relating to any breach of warranty by Super
Vision®.Limitations,exclusions and other rights:
1.) Except as provided herein,Super Vision® makes no other warranties,expressed or
implied, including but not limited to the implied warranties of merchantability or
fitness for a particular purpose,as all such warranties are expressly disclaimed. Some
states do not allow the exclusion of an implied warranty,so the above exclusion may
not apply to you.
2.) Super Vision® is not responsible for defects or malfunctions in and/or damage to
lighting systems where a sale is specifically made without warranty. In such sales the
disclaimers of warranty and liability;set forth above,shall continue to apply.
3.) The Warranty covers normal consumer use and does not cover damage which
occurs in shipment or damage or failure which results from alteration,accident,theft,
misuse,abuse, abnormal use,negligent installation, improper maintenance or where
adequate care has not been taken to prevent damage to the lighting system.
4.) This Warranty gives you specific legal rights, and you may also have other rights
which vary from state to state. If you discover a defect or malfunction during the
period towhichthisWarrantyapplies,writeorphone SuperVision® forinformationon
receiving warranty service.
IGPINSTALL-01
4.22.02
