LED Strobe Light Head
WIFI-CON
User Manual
Important: Read all instructions prior to installation. STSC-x6
Safety and Notes
Installation and Operation
Parts Included
Accessories
Specications
1 - LED strobe light head
1 - mounting bracket
1 - hardware kit (to attach strobe head to mounting bracket)
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
STSC-x6
Voltage 12-24 VDC
Current Draw 600 mA (0.6 A) @12 VDC
IP Rating IP67
Wire Length 15 in. (381 mm)
Recommended Fuse Rating 1A /Light Head
Operating Temperature -22°–122° F(-30°–50° C)
Strobe Switch (AMSB-2M-PT)
Fuse Holder (WMFH)
Fuse (MAF-x)
• To reduce risk of electric shock, ensure that battery is
disconnected before performing any installation procedures.
• When linking multiple lights with a common wire, make sure
to select wire appropriately sized for intended load and run
of the wire.
• Avoid looking directly into lamp when illuminated.
Setting Group
Strobes can be set in two groups, so they ash in an alternating
pattern. Strobes in same group will ash together.
1. Prior to installation and with strobe grounded, apply power to red
and yellow wire simultaneously. Light will ash once for group 1
and twice for group 2.
2. Remove yellow wire from power and then momentarily reapply
power to change group. Light will remain in its set group until the
process is repeated.
Changing Flash Patterns
1. Once each light is set to desired group, complete main power
and ground wiring.
2. Connect common wire that runs from yellow wire on each light
to a momentary switch.
Note: Supply side of switch should only be connected to
fused power.
3. Apply main power to turn strobes on, then use momentary
switch to cycle through patterns.
Flash Patterns
Rev Date: V1 04/05/2019
Pattern Pattern Name
1Six Flash
2Quad Flash
3Double Flash
4Six Flash (Speed)
5Single Flash-R65
6Triple Flash
7Double Flash (Speed)
8Quad Flash (Speed)
9R/L Flash
10 Double Flash (R/L)
11 Six Flash (R/L)
12 Riple Flash (R/L –Speed)
15.33in
389.46mm
6.56in
166.69mm
3.50in
88.90mm
1.69in
43.01mm
1.13in
28.59mm
7.06in
179.39mm
1.41in
35.73mm
3.18in
80.77mm
6.31in
160.34mm
BRACKET
FOAM GASKET
4X HEX NUT
4X WASHER
4X LOCK WASHER
2X M5 X 15mm
2X M5 X 20mm
WIFI-CON
Important: Read all instructions prior to installation.
Wiring
LED Strobe Light Head
Dimensional Diagram
Ground
Power Switch
(SWK-PM
or similar)
Momentary Switch
(SWK-PM or similar)
to brown wire(s) (+)white wire(s) (+) to black wire(s) (-)
battery
ground
chassis
ground
or
oror
Fuse Holder (WMFH)
Fuse (MAF-x)
Multiple Synced Light Systems
Strobe Light Switch and Power Supply DiagramWiring Diagram
to momentary switch
for pattern control (+)
to battery (+)
to battery ground (-)
to chassis ground (-)to chassis ground (-)
to additional lights
to additional lights
to additional lights
Black (-)
chassis (or battery)
ground
Red (+)
12–24 VDC
(1A fuse recommended)
Yellow (momentary +)
used during installation to set group
and after connected syncs lights in
and selects pattern
STSC-x6 STSC-x6
STSC-x6
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V1 04/05/2019
User Manual
STSC-x6
