Superior TF18NV User manual

For use with log sets
LTF18MM LTF18RS LTF18WT
LTF24MM LTF24RS LTF24WT
LTF30MM LTF30RS LTF30WT
Installation and Operation Instructions
Unvented (Vent-Free) Gas Log Heater
Models
PFS
®
US
Report No. F11-017
P/N 126817-01 Rev. D 04/2017
P126817-01
TF18NV TF18PV TF2430NV TF2430PV
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home,
where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases.
WARNING: This appliance is for installation only in a solid-fuel burning masonry or UL127 factory-built
fireplace or in a listed ventless firebox enclosure. It is design-certified for these installations in accordance
with ANSI Z21.11.2. Exception: DO NOT install this appliance in a factory-built fireplace that includes
instructions stating it has not been tested or should not be used with unvented gas logs.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Air for Combustion and Ventilation
section on Page 6 of this manual.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.

SuperiorFireplaces.us.com 126817-01D2
TABLE OF CONTENTS
Safety .................................................................. 2
Product Identification........................................... 5
Local Codes......................................................... 5
Unpacking............................................................ 5
Product Features................................................. 6
Air For Combustion and Ventilation..................... 6
Installation ........................................................... 8
Operation........................................................... 25
Inspecting Burners............................................. 29
Cleaning and Maintenance................................ 30
Troubleshooting................................................. 31
Replacement Parts............................................ 35
Service Hints ..................................................... 35
Technical Service............................................... 35
Specifications .................................................... 35
Wiring Diagram.................................................. 35
Accessories....................................................... 36
Parts.................................................................. 37
Warranty............................................................ 43
SAFETY
WARNING: FIRE, EXPLOSION, AND ASPHYXIATION HAZARD
Improperadjustment,alteration,service,maintenance,orinstallationofthis
heater or its controls can cause death or serious injury.
Read and follow instructions and precautions in User’s Information Manual
provided with this heater.
WARNING:Thisapplianceisfor
installationonlyinasolid-fuelburn-
ing masonry or UL127 factory-built
fireplace or in a listed ventless fire-
boxenclosure.Itisdesign-certified
fortheseinstallationsinaccordance
with ANSI Z21.11.2. Exception:
DO NOT install this appliance in a
factory-built fireplace that includes
instructions stating it has not been
tested or should not be used with
unvented gas logs.
WARNING: This is an unvented
gas-firedheater.Itusesair(oxygen)
fromtheroominwhichitisinstalled.
Provisionsforadequatecombustion
andventilationairmustbeprovided.
Refer to Air for Combustion and
Ventilation section on Page 6 of
this manual.
Thisappliancemaybeinstalledinan
aftermarket,* permanently located,
manufactured(mobile)home,where
not prohibited by local codes.
This appliance is only for use with
the type of gas indicated on the
rating plate. This appliance is not
convertibleforusewithothergases.
* Aftermarket: Completion of sale, not for
purpose of resale, from the manufacturer
WARNING:Thisproductcontains
and/or generates chemicals known
to the state of California to cause
cancer or birth defects or other re-
productive harm.
DANGER: Carbon monoxide
poisoning may lead to death!
WARNING:Vent-freeproductsare
prohibitedforbedroomandbathroom
installation in the Commonwealth of
Massachusetts.

SuperiorFireplaces.us.com
126817-01D 3
SAFETY
Continued
Carbon Monoxide Poisoning: Early signs of
carbon monoxide poisoning resemble the flu,
with headaches, dizziness or nausea. If you
have these signs, the fireplace may not be
working properly. Get fresh air at once! Have
fireplace serviced. Some people are more af-
fected by carbon monoxide than others. These
include pregnant women, people with heart
or lung disease or anemia, those under the
influence of alcohol and those at high altitudes.
NaturalandPropane/LP gasesare odorless.An
odor-making agent is added to these gases.
The odor helps you detect a gas leak. How-
ever, the odor added to the gas can fade. Gas
may be present even though no odor exists.
Make certain you read and understand all
warnings. Keep this manual for reference. It
is your guide to safe and proper operation of
this appliance.
IMPORTANT: Read this owner’s
manual carefully and completely
before trying to assemble, operate
or service this appliance. Improper
use of this appliance can cause
serious injury or death from burns,
fire,explosion,electricalshockand
carbon monoxide poisoning.
WARNING: Any change to this
heater or its controls can be dan-
gerous.
WARNING: Do not use a blower
insert,heatexchangerinsertorother
accessorynotapprovedforusewith
this heater.
WARNING: Do not allow fans to
blow directly into the heater. Avoid
any drafts that alter burner flame
patterns. Ceiling fans can create
drafts that alter burner flame pat-
terns. Altered burner patterns can
cause sooting.
Due to high temperatures, the ap-
pliance should be located out of
traffic and away from furniture and
draperies.
Do not place clothing or other
flammable material on or near the
appliance. Never place any objects
on the heater.
Appliancebaseassemblybecomes
very hot when running appliance.
Children and adults should be
alertedtothehazardofhighsurface
temperature and should stay away
to avoid burns or clothing ignition.
Appliance will remain hot for a time
after shutdown. Allow surface to
cool before touching.
WARNING: Do not place log
scraps or volcanic stone on burner.
Young children should be care-
fully supervised when they are in
the same room with the appliance.
When using the hand-held remote
accessory, keep selector switch in
theOFFpositiontopreventchildren
fromturningonburnerswithremote.
You must operate this appliance
with the fireplace screen and hood
inplace.Makesurefireplacescreen
andhoodareinplacebeforerunning
appliance.Thefireplacescreenshall
have openings for introduction of
combustion air.
Keep the appliance area clear and
free from combustible materials,
gasoline and other flammable va-
pors and liquids.
Solid-fuels shall not be burned in a
fireplaceinwhichanunventedroom
heater is installed.

126817-01D
4SuperiorFireplaces.us.com
SAFETY
Continued
2. Do not place propane/LP supply tank(s)
inside any structure. Locate propane/LP
supplytank(s)outdoors (propane/LPunits
only).
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touchany electrical switch; do not
use any phone in your building
• immediately call your gas supplier from
aneighbor’s phone.Followthegassup-
plier’s instructions
• if you cannot reach your gas supplier,
call the fire department
4. This heater shall not be installed in a
bedroom or bathroom. This gas log set
may not be installed as a vented appli-
ance in a bedroom or bathroom in the
Commonwealth of Massachusetts.
5. WARNING: Before installing in a solid
fuel-burningfireplace, thechimney flue
and firebox must be cleaned of soot,
creosote, ashes and loose paint by a
qualified chimney cleaner.Creosote will
igniteifhighlyheated.Adirtychimneyflue
may create and distribute soot within the
house. Inspect chimney flue for damage.
Ifdamaged,repairflueandfireboxbefore
operating appliance.
6. Do not burn solid-fuel in a fireplace in
which a vent-free appliance is installed.
7. If appliance has glass doors, never oper-
atethisappliance withglassdoorsclosed.
Any glass doors shall be fully opened
when the appliance is in operation. If you
operateappliancewith doors closed,heat
Installation and repair should be
done by a qualified service person.
The appliance should be inspected
before use and at least annually by
aprofessionalserviceperson.More
frequent cleaning may be required
duetoexcessivelintfromcarpeting,
beddingmaterial,etc.Itisimperative
thatcontrolcompartments,burners,
and circulating air passageways of
the appliance be kept clean.
1. WARNING: This appliance isonly for
use with the type of gas indicated on
the rating plate.This appliance isnot
convertible for use with other gases.
buildupinsidefireplace will causeglassto
burst.Make surethereare noobstructions
across openings of fireplace.
8. To prevent the creation of soot, follow the
instructionsinCleaningandMaintenance,
Page 30.
9. Beforeusingfurniturepolish,wax, carpet
cleaner or similar products, turn appliance
off. If heated, the vapors from these prod-
ucts may create a white powder residue
within burner box or on adjacent walls and
furniture.
10. This appliance needs fresh, outside air
ventilation to run properly. This appliance
has an Oxygen Depletion Sensing (ODS)
safety shutoff system. The ODS shuts
down the appliance if enough fresh air is
not available. See Air for Combustion and
Ventilation, Page 6. If appliance keeps
shuttingoff,seeTroubleshooting,Page 31.
11. Do not run appliance
• where flammable liquids or vapors are
used or stored
• under dusty conditions
12. Do not use this appliance to cook food or
burn paper or other objects.
13. Do not use this room heater if any part
has been under water. Immediately call
a qualified service technician to inspect
the room heater and to replace any part
of the control system and any gas control
which has been under water.
14. Do not operate appliance if any log is
broken. Do not operate appliance if a log
is chipped (dime-sized or larger).
15. Turn appliance off and let cool before
servicing, installing or repairing. Make
sure the selector switch is in the OFF
position. Only a qualified service person
shouldinstall,serviceor repair appliance.
16. Make sure the selector switch is in the
OFF position when you are away from
home for long periods of time.
17. Remote-ready appliances must not be
connected to any external electrical
source.
18. Operating appliance above elevations of
4,500 feet may cause pilot outage.
19. To prevent performance problems, do
not use propane/LP fuel tank of less than
100 lb. capacity (propane/LP units only).
20. Provide adequate clearances around air
openings.
21. Follow the clearance requirements within
this manual to assure adequate clear-
ances for accessibility for purposes of
servicing and proper operation.

SuperiorFireplaces.us.com
126817-01D 5
PRODUCT IDENTIFICATION
Figure 1 - Product Identification
Glowing
Embers
Chassis
Control
Knob
Flame
Adjustment
Knob
Left
Side
Right
Side
Front
LOCAL CODES NOTE:Donotpickupappliancebaseas-
semblyby burners.Thiscould damagethe
appliance.Alwayshandlebaseassembly
by grate.
2. Remove all protective packaging applied
to logs and appliance for shipment.
3. Check appliance for any shipping dam-
age. If appliance is damaged, promptly
inform dealer where you purchased the
appliance.
Install and use appliance with care. Follow all
localcodes.Intheabsenceoflocalcodes,use
the latest edition of The National Fuel Gas
Code, ANSI Z223.1/NFPA 54*.
*Available from:
American National Standards Institute, Inc.
25 West 43rd Street, 4th floor
New York, NY 10036
National Fire Protection Association, Inc.
1 Batterymarch Park
Quincy, MA 02169-7471
UNPACKING
1. Removelogsandappliancebase assem-
bly from carton(s).
COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS
These appliances are approved for installation in the US state of Massachusetts if the fol-
lowing additional requirements are met:
• Un-vented Room Heaters shall be installed in accordance with 527 CMR 30.
• Installation and repair must be done by a plumber or gas fitter licensed in the Common-
wealth of Massachusetts.
• Theflexiblegasline connector used shall not exceed36inches(92centimeters)in length.
• The individual manual shut-off must be a T-handle type valve.
• Unvented appliances may NOT be installed in bedrooms or bathrooms.
• A working smoke detector must be installed in the area where vent-free appliances are
installed.
Seller of unvented propane or natural gas-fired supplemental room heaters shall provide
to each purchaser a copy of 527 CMR 30 upon sale of the unit.
CAUTION: Do not remove
the data plates from the grate
assembly. The data plates
contain important warranty
and safety information.

126817-01D
6SuperiorFireplaces.us.com
OPERATION
This appliance is clean burning. It requires no
outsideventing.Thereisnoheatlossoutavent
or up a chimney. Heat is generated by both
realistic flames and glowing coals. This appli-
anceisdesignedforvent-freeoperationwithflue
damperclosed.Ithasbeentestedandapproved
totheANSIZ21.11.2standardforunventedap-
pliances. State and local codes in some areas
prohibit the use of vent-free appliances.
PRODUCT FEATURES
SAFETY DEVICE
This appliance has a pilot with an Oxygen
DepletionSensing(ODS)safetyshutoffsystem.
TheODS/pilotisarequiredfeatureforvent-free
room appliances. The ODS/pilot shuts off the
appliance if there is not enough fresh air.
ELECTRONIC IGNITION SYSTEM
Thisappliancehas anelectronicIgniter tolight
appliance fuel supply.
AIR FOR COMBUSTION AND VENTILATION
Today’s homes are built more energy efficient
thanever. Newmaterials,increased insulation
and new construction methods help reduce
heat loss in homes. Homeowners apply
weather strip and caulk around windows and
doors to keepthe cold air out andthe warm air
in. During heating months, homeowners want
their homes as airtight as possible.
While it is good to make your home energy
efficient, your home needs to breathe. Fresh
air must enter your home.All fuel-burning ap-
pliancesneedfreshair for proper combustion
and ventilation.
Exhaust fans, some fireplaces, clothes dryers
and some fuel-burning appliances draw air
from the house to operate. You must provide
adequate fresh air for these appliances. That
willensureproperventingofventedfuel-burning
appliances.
PROVIDING ADEQUATE
VENTILATION
Thefollowingareexcerpts from National Fuel
Gas Code, ANSI Z223.1/NFPA 54, Air for
Combustion and Ventilation.
All spaces in homes fall into one of the three
following ventilation classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on Pages6-8 will help you
classify your space and provide adequate
ventilation.
Unusually Tight Construction
The air that leaks around doors and windows
may provide enough fresh air for combustion
and ventilation. However, in buildings of un-
usually tight construction, you must provide
additional fresh air.
Unusually tight construction is defined as
construction where:
a. walls and ceilings exposed to the out-
side atmosphere have a continuous
water vapor retarder with a rating of
one perm (6 x 10-11 kg per pa-sec-m2) or
less with openings gasketed or sealed
and
b. weather stripping has been added on
openable windows and doors and
c. caulking or sealants are applied to
areas such as joints around window
and door frames, between sole plates
and floors, between wall-ceiling joints,
between wall panels, at penetrations
for plumbing, electrical and gas lines
and at other openings.
If your home meets all three criteria above,
you must provide additional fresh air. See
Ventilation Air From Outdoors, Page 8.
If your home does not meet all three criteria
above,proceedtoDeterminingFresh-AirFlow
For Heater Location, Page 7.
Confined and Unconfined Space
The National Fuel Gas Code, ANSI Z223.1/
NFPA54 allows two methods for determining
whetherthespace inwhichtheheater isbeing
installedisconfinedorunconfinedspace.The
WARNING: This heater shall not
be installed in a room or space un-
less the required volume of indoor
combustion air is provided by the
method described in the National
Fuel Gas Code, ANSI Z223.1/NFPA
54, the International Fuel Gas Code,
or applicable local codes. Read the
following instructions to ensure
properfresh air for this and other fuel-
burning appliances in your home.

SuperiorFireplaces.us.com
126817-01D 7
AIR FOR COMBUSTION AND VENTILATION
Continued
Vent-free fireplace __________Btu/Hr
Gas water heater* __________Btu/Hr
Gas furnace __________Btu/Hr
Vented gas heater __________Btu/Hr
Gas fireplace logs __________Btu/Hr
Other gas appliances* + _________ Btu/Hr
Total = _________Btu/Hr
* Do not include direct-vent gas appliances.
Direct-vent draws combustion air from the
outdoors and vents to the outdoors.
Example:
Gas water heater __________Btu/Hr
Vent-free fireplace + _________Btu/Hr
Total = _________Btu/Hr
4. Compare the maximum Btu/Hr the space
can support with the actual amount of Btu/
Hr used.
______Btu/Hr (maximum the space can
support)
______Btu/Hr (actual amount used)
Example: 51,200 Btu/Hr (maximum the
space can support)
73,000 Btu/Hr (actual amount of
Btu/Hr used)
The space in the above example is a confined
space because the actual Btu/Hr used is more
than the maximum Btu/Hr the space can sup-
port. You must provide additional fresh air. Your
options are as follows:
A. Rework worksheet, adding the space of an
adjoining room. If the extra space provides
anunconfined space,remove doortoadjoin-
ing room or add ventilation grills between
rooms. See Ventilation Air From Inside
Building, Page 8.
B. Vent room directly to the outdoors. See
Ventilation Air From Outdoors, Page 8.
C. Install a lower Btu/Hr heater, if lower Btu/Hr
size makes room unconfined.
If the actual Btu/Hr used is less than the maxi-
mum Btu/Hr the space can support, the space is
anunconfined space.Youwill neednoadditional
fresh air ventilation.
40,000
33,000
73,000
WARNING: If the area in which
the heater may be operated does not
meet the required volume for indoor
combustion air, combustion and
ventilation air shall be provided by
one of the methods described in the
National Fuel Gas Code, ANSI Z223.1/
NFPA 54, the International Fuel Gas
Code, or applicable local codes.
standardmethoddefinesa confined spaceas
a space whose volume is less than 50 cubic
feetper1,000 Btu/hr (4.8m3perkw)of the ag-
gregateinputratingofallappliancesinstalled
in that space and an unconfined space as
a space whose volume is not less than 50
cubic feet per 1,000 Btu/hr (4.8 m3per kw) of
the aggregate input rating of all appliances
installedinthat space.Roomscommunicating
directlywiththe spaceinwhichthe appliances
areinstalled*,throughopenings not furnished
with doors, are considered a part of the un-
confined space.
Where the air infiltration rate of a structure is
known,theKnownAir InfiltrationRateMethod
may be used. Follow The National Fuel Gas
Code, ANSI Z223.1/NFPA 54 to use this
method to determine if the space is confined
or unconfined.
* Adjoining rooms are communicating only if
therearedoorless passagewaysorventilation
grills between them.
DETERMINING FRESH-AIR FLOW
FOR HEATER LOCATION
Determining if You Have a Confined or
Unconfined Space Using the Standard
Method
Use this work sheet to determine if you have
a confined or unconfined space.
Space: Includesthe roomin whichyou willinstall
fireplace plus any adjoining rooms with door-
less passageways or ventilation grills between
the rooms.
1. Determine the volume of the space (length
x width x height).
LengthxWidth x Height=__________cu. ft.
(volume of space)
Example: Space size 20 ft. (length) x 16 ft.
(width) x 8 ft. (ceiling height) = 2560 cu. ft.
(volume of space)
If additional ventilation to adjoining room
is supplied with grills or openings, add the
volume of these rooms to the total volume
of the space.
2. Multiply the space volume by 20 to determine
the maximum Btu/Hr the space can support.
________ (volume of space) x 20 = (Maxi-
mum Btu/Hr the space can support)
Example: 2560 cu. ft. (volume of space) x 20
= 51,200 (maximum Btu/Hr the space can
support)
3. Addthe Btu/Hr ofall fuel-burningappliances
in the space

126817-01D
8SuperiorFireplaces.us.com
AIR FOR COMBUSTION AND VENTILATION
Continued
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation
grills or ducts. You must provide two perma-
nent openings: one within 12" of the ceiling
andonewithin12"ofthefloor. Connect these
items directly to the outdoors or spaces open
to the outdoors. These spaces include attics
and crawl spaces. Follow the National Fuel
Gas Code, ANSI Z223.1/NFPA 54, Air for
Combustion and Ventilation for required size
of ventilation grills or ducts.
IMPORTANT:Do not provide openings
for inlet or outlet air into attic if attic has a
thermostat-controlled power vent. Heated air
entering the attic will activate the power vent.
Figure 3 - Ventilation Air from Outdoors
Outlet
Air
Ventilated
Attic
Outlet
A
ir
Inlet
Air
Inlet Air Ventilated
Crawl Space
To
Crawl
Space
To Attic
Or
Remove
Door into
Adjoining
Room,
Option
3
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilation
Grills Into
Adjoining
Room,
Option 1
12"
12"
INSTALLATION
VENTILATION AIR
Ventilation Air From Inside Building
This fresh air would come from an adjoining
unconfined space. When ventilating to an
adjoiningunconfinedspace, youmustprovide
twopermanentopenings: onewithin12" ofthe
ceiling and one within 12" of the floor on the
wall connecting the two spaces (see options
1and2,Figure 2).You can alsoremovedoor
into adjoining room (see option 3, Figure 2).
Follow the National Fuel Gas Code, ANSI
Z223.1/NFPA 54, Air for Combustion and
Ventilation for required size of ventilation
grills or ducts.
Figure 2 - Ventilation Air from Inside Building
WARNING: A qualified service
person must install appliance. Fol-
low all local codes.
NOTICE:Stateorlocalcodesmayonlyallow
operation of this appliance in a vented con-
figuration. Check your state or local codes.
WARNING: Make sure the se-
lector switch is in the OFF position
before installing appliance.
WARNING:Anyoutsideairducts
and/or ash dumps in the fireplace
shallbepermanently closedattime
of appliance installation.
WARNING: Seal any fresh air
ventsorashclean-outdoorslocated
on floor or wall of fireplace. If not,
drafting may cause pilot outage
or sooting. Use a heat-resistant
sealant. Do not seal chimney flue
damper.
NOTICE: This appliance is intended
for supplemental heating. Use this
appliance along with your primary
heatingsystem.Donotinstallthisap-
pliance as your primary heat source.
If you have a central heating system,
you may run system’s circulating
blower while using appliance. This
willhelpcirculatetheheatthroughout
the house. In the event of a power
outage, you can use this appliance
as your primary heat source.

SuperiorFireplaces.us.com
126817-01D 9
WARNING: Never install the
appliance
• in a bedroom or bathroom
• in a recreational vehicle
•
where curtains, furniture, clothing
or other flammable objects are less
than 36" from front, 42" from top of
appliance; for side clearances see
Figure 4, Page 10
• in high traffic areas
• in windy or drafty areas
CAUTION:Thisappliancecreates
warmaircurrents.Thesecurrents
move heat to wall surfaces next
to appliance. Installing appli-
ance next to vinyl or cloth wall
coveringsoroperatingappliance
where impurities (such as, but
not limited to, tobacco smoke,
aromaticcandles,cleaningfluids,
oilorkerosenelamps, etc.)inthe
air exist, may discolor walls or
cause odors.
WARNING: This appliance is
equipped for either natural gas or
propane/LP gas but not both. Gas
typeisindicatedontheratingplate.
Field conversion is not permitted.
WARNING: Maintain the
minimumclearances. Ifyoucan,
provide greater clearances from
floor, ceiling and adjoining wall.
MINIMUM FIREPLACE CLEARANCE
TO COMBUSTIBLE MATERIALS
Side Wall 16", Ceiling 42"
Floor 5", Front: 36"
WARNING: Before installing in
a solid fuel-burning fireplace, the
chimney flue and firebox must be
cleanedofsoot,creosote,ashesand
loose paint by a qualified chimney
cleaner.Creosotewilligniteifhighly
heated. A dirty chimney flue may
createanddistributesootwithinthe
house.Inspectchimneyandfirebox
flue for damage. If damaged, repair
flue and firebox before operating
appliance.
INSTALLATION
Continued
IMPORTANT:Vent-free appliances add
moisture to the air.Although this is beneficial,
installing appliance in rooms without enough
ventilationairmaycausemildewtoformfrom
too much moisture. See Air for Combustion
and Ventilation, Page 6.
CHECK GAS TYPE
Usethecorrecttypeofgas(naturalorpropane/
LP). If your gas supply is not the correct gas
type, do not install appliance. Call dealer
whereyoupurchased theappliancefor proper
type appliance.
INSTALLATION AND CLEARANCES
FOR VENT-FREE OPERATION
LOG SIZING REQUIREMENTS
Log
Size
Minimum Firebox Size
Height Depth Front
Width Rear* Width
18" 20" 14" 28" 20"
24" 20" 14" 32" 22"
30" 20" 14" 40" 30"
Carefully follow the instructions below. This
will ensure safe installation into a masonry,
UL127-listedmanufacturedfireplaceorlisted
vent-free firebox.
Minimum Clearances For Side Combustible
Material, Side Wall and Ceiling
A. Clearances from the side of the fireplace
cabinet to any combustible material and
wall should follow diagram in Figure 4,
Page 10.
Example:Thefaceofa mantel,bookshelf,
etc. is made of combustible material
and protrudes 3-1/2" from the wall. This
combustible material must be 4" from the
side of the fireplace cabinet (see Figure
4, Page 10).

126817-01D
10 SuperiorFireplaces.us.com
INSTALLATION
Continued
Noncombustible
Material Distance
(A)
Requirements for
Safe Installation
1 2" or more Noncombustible mate-
rial OK.
Between 8" and 12" 24" or 30" Models:
Install fireplace hood ac-
cessory (GA6050 - see
Accessories,Page 36).
18" Model: Noncom-
bustible material OK.
Less than 8"
Noncombustible mate-
rial must be extended
to at least 8". See
Between 8" and 12",
above. If you cannot
extend material, you
must operate appliance
with flue damper open.
Figure 4 - Minimum Clearance for
Combustible to Wall
*Minimum 16" from Side Wall
*
Example
Minimum Noncombustible Material
Clearances
If Not Using Mantel
NOTE: If using a mantel proceed to If Using
Mantel. If not using a mantel, follow these
instructions.
You must have noncombustible material(s)
above the fireplace opening. Noncombustible
materials(such asslate, marble,tile,etc.)must
be at least 1/2" thick. With sheet metal, you
must have noncombustible material behind
it. Noncombustible material must extend at
least 8" up (for all models). If noncombustible
material is less than 12", you must install the
fireplacehood accessory (24"and30"Models
Only).SeeFigure 5 forminimumclearances.
Figure 5 - Heat Resistant Material (Slate,
Marble, Tile, etc.) Above Fireplace
If Using Mantel
You must have noncombustible material(s)
above the fireplace opening. Noncombus-
tible materials (such as slate, marble, tile,
etc.) must be at least 1/2" thick. With sheet
metal, you must have noncombustible ma-
terial behind it. Noncombustible material
must extend at least 8" up (for all models). If
noncombustiblematerialislessthan12",you
mustinstallthefireplacehoodaccessory (24"
and30"ModelsOnly).Evenif noncombustible
material is more than 12", you may need the
hood accessory to deflect heat away from
your mantel shelf. See Figure 5 and Figures
6 and 7, Page 11, for minimum clearances.
Heat Resistant
Material
(A)
NOTE: When installing your gas logs into
a manufactured firebox, follow firebox
manufacturer’s instructions for minimum
clearances to combustible materials.
B. Clearances from the top of the fireplace
opening to the ceiling should not be less
than 42".
Maintain adequate clearances for accessibility for purposes
of servicing and proper operation.

SuperiorFireplaces.us.com
126817-01D 11
INSTALLATION
Continued
MANTEL CLEARANCES
In addition to meeting noncombustible mate-
rial clearances, you must also meet required
clearances between fireplace opening and
mantelshelf.Ifyoudo notmeetthe clearances
listed below, you will need a hood.
Determining Minimum Mantel Clearance
If you meet minimum clearance between
mantel shelf and top of fireplace opening, a
hood is not required (see Figure 6).
Figure 6 - Minimum Mantel Clearances
Without Using Hood
Figure 7 - Minimum Mantel Clearances
When Using Hood
Minimum Non-
Combustible
Material
Minimum Non-
Combustible
Material Height
Distances to
Underside of
Mantel
Top of Fireplace
Opening
Underside of
Mantel Shelf
12"
8"
(A)
18"
14"
20"
17"
22"
19"
24"
20"
All minimum
distances are
in inches
Log Set
24"/30" Models
18" Model
2
1/2
"
6"
8"
10"
Mantel Shelf
Minimum
Noncombustible
Material 8"
Min.
12" 15" 18" 20"
2
1/2
"
6"
8"
10"
12"
Distances to
Underside of
Mantel
Hood (GA6050
or GA6053)
Top of
Fireplace
Opening
Underside
of Mantel
Shelf
Mantel Shelf
Figure 8 - Minimum Fireplace Clearances
If Installed at Floor Level
Figure 9 - Minimum Fireplace Clearances
Above Combustible Flooring
14"
Min.
Combustible
Material
Noncombustible Material
Hearth
5"
Min.
Combustible
Material
Determining Minimum Mantel Clearance
When Using a Hood
If minimum clearances in Figure 6 are not
met, you must have a hood. When using a
hood there are still certain minimum mantel
clearances required. Follow minimum clear-
ances shown in Figure 7, when using hood.
Minimum clearance requirements include any projections such
as shelves, window sills, mantels, etc. above the appliance.
NOTICE: Surface temperatures
ofadjacentwallsandmantelsbe-
comehotduringoperation.Walls
and mantels above the firebox
may become hot to the touch.
If installed properly, these tem-
peratures meet the requirement
ofthenationalproductstandard.
Follow all minimum clearances
shown in this manual.
NOTICE:Ifyourinstallationdoes
not meet the minimum clear-
ances shown, you must do one
of the following:
• operate the logs only with the
flue damper open
• raise the mantel to an accept-
able height
• remove the mantel
FLOOR CLEARANCES
A. If installing appliance on the floor level,
you must maintain the minimum distance
of 14" to combustibles (see Figure 8).
B. If combustible materials are less than
14" to the fireplace, you must install ap-
pliance at least 5" above the top surface
of combustible flooring including tile and
carpet (see Figure 9).

126817-01D
12 SuperiorFireplaces.us.com
INSTALLATION
Continued
WARNING: You must secure
thisappliancetofireplacefloor.If
not,appliancewillmovewhenyou
adjustcontrols.Movingappliance
may cause a gas leak.
WARNING: If installing in a
sunken fireplace, special care
is needed. You must raise the
fireplace floor to allow access to
appliance control panel. This will
ensureadequateairflowandguard
againstsootingandcontrolsbeing
damaged.Raisefireplacefloorwith
noncombustible material. Make
sure material is secure.
CAUTION: Do not pick up
appliance base assembly by
burners. This could damage the
appliance. Only handle base as-
sembly by grates.
INSTALLING APPLIANCE BASE
ASSEMBLY
IMPORTANT:Makesuretheapplianceburn-
ers are level. If appliance is not level, appli-
ance will not work properly.

SuperiorFireplaces.us.com
126817-01D 13
INSTALLATION
Continued
Figure 10 - Attaching Flexible Gas Hose
to Appliance Gas Regulator
Figure 11 - Attaching Base to Fireplace
Floor
Masonry Screw
Gas Control
Flexible Gas Hose
(Install if allowed
by local codes)
Elbow, 3/8 NPT x
3/8 Flare
Installation Items Needed
• hardware package (provided with appli-
ance)
• approved flexible gas hose and fittings
(provided) (if allowed by local codes)
• sealant (resistant to propane/LP gas, not
provided)
• electric drill with 3/16” masonry drill bit
1. Apply pipe joint sealant lightly to male
threads of the 1/2 NPT side of gas fitting
elbow (provided) and connect to inlet
side of gas control. Remove gas fitting
from flexible gas hose (provided) before
connecting to elbow (see Figure 10).
2. Position appliance base assembly in
fireplace.
3. Mark screw locations through holes in
front panel of base (see Figure 11). If
installinginabrick-bottomfireplace, mark
screw locations in mortar joint of bricks.
4. Remove appliance base from fireplace.
5. Drillholesatmarked locations using3/16"
drill bit.
6. Attachbase,throughholesinbacksidepan-
elsofbase,tofireplacefloorusingmasonry
screwsprovidedinhardwarepackage(see
Figure 11).
7. Connect to gas supply. See Connecting
To Gas Supply.
WARNING: This appliance
requiresa3/8"NPT(NationalPipe
Thread) inlet connection to the
pressure regulator.
WARNING:Aqualifiedservice
personmustconnectapplianceto
gassupply.Followalllocalcodes.
CAUTION: Never connect
propane/LP appliance directly
to the propane/LP supply. This
appliance requires an external
regulator (not supplied). Install
theexternalregulatorbetweenthe
applianceandpropane/LPsupply.
WARNING: Never connect
natural gas appliance to private
(non-utility) gas wells. This gas
iscommonlyknownaswellhead
gas.
CONNECTING TO GAS SUPPLY

126817-01D
14 SuperiorFireplaces.us.com
Installation Items Needed
Before installing appliance, make sure you
have the items listed below.
• external regulator (supplied by installer)
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• equipment shutoff valve *
• test gauge connection *
• sediment trap
• tee joint
• pipe wrench
• approvedflexiblegas line with gasconnec-
tor(ifallowed bylocalcodes)(not provided)
* An equipment shutoff valve with 1/8" NPT
tap is an acceptable alternative to test gauge
connection.
For propane/LP units, the installer must
supply an external regulator. The external
regulator will reduce incoming gas pressure.
You must reduce incoming gas pressure to
between 11" and 14" of water. If you do not
reduce incoming gas pressure, appliance
regulator damage could occur. Install exter-
nal regulator with the vent pointing down as
shown in Figure 12. Pointing the vent down
protects it from freezing rain or sleet.
INSTALLATION
Continued
Figure 12 - External Regulator With Vent
Pointing Down
Propane/LP
Supply Tank External
Regulator
with Vent
Pointing
Down
** Minimuminletpressurefor purposeofinput
adjustment.
Figure 13 - Gas Connection (Remote-
Ready Models Only)
Pipe Cap Tee
Nipple Joint
Gas
Control
3" Minimum
Sediment Trap
Approved Flexible
Gas Hose (if
allowed by local
codes)
PROPANE/LP
From External
Regulator
(11" W.C.**
to 14" W.C.
Pressure)
NATURAL
From Gas
Meter
(5" W.C.**
to 10.5"
W.C.
Pressure)
CAUTION: Use only new,
black iron or steel pipe. Inter-
nally-tinnedcoppertubingmay
beusedincertainareas.Check
your local codes. Use pipe of
1/2" diameter or greater to allow
propergasvolumetoappliance.
If pipe is too small, undue loss
of volume will occur.
WARNING: Use pipe joint
sealant that is resistant to liquid
petroleum (LP) gas.
Check your building codes for any special
requirements for locating equipment shutoff
valve to appliances.
Apply pipe joint sealant lightly to male NPT
threads.This will preventexcesssealantfrom
going into pipe. Excess sealant in pipe could
result in clogged appliance valves.
Installationmustinclude an equipmentshutoff
valve,unionandplugged1/8" NPTtap.Locate
NPT tap within reach for test gauge hook up.
NPT tap must be upstream from appliance
(see Figure 13).
IMPORTANT:Installequipmentshutoffvalve
in an accessible location. The equipment
shutoff valve is for turning on or shutting off
the gas to the appliance.

SuperiorFireplaces.us.com
126817-01D 15
CAUTION: Avoid damage to
gas control. Hold gas control
with wrench when connecting
it to gas piping and/or fittings.
WARNING:Testallgaspiping
and connections, internal and
external to unit, for leaks after
installing or servicing. Correct
all leaks at once.
WARNING:Neveruseanopen
flame to check for a leak. Apply
a noncorrosive leak detection
fluid to all joints. Bubbles form-
ingshowaleak.Correctallleaks
at once.
CAUTION: Make sure exter-
nal regulator has been installed
between propane/LP supply and
appliance. See guidelines under
ConnectingtoGasSupply,Page13.
INSTALLATION
Continued
We recommend that you install a sediment
trap in supply line as shown in Figure 13.
Locate sediment trap where it is within reach
for cleaning. Install in piping system between
fuel supply and appliance. Locate sediment
trap where trapped matter is not likely to
freeze. A sediment trap traps moisture and
contaminants. This keeps them from going
intoappliancecontrols.Ifsedimenttrapisnot
installed or is installed wrong, appliance may
not run properly.
3. Pressurizesupplypipingsystem by either
opening propane/LP supply tank valve
for propane/LP gas or opening main gas
valve located on or near gas meter for
natural gas or using compressed air.
4. Checkalljointsofgassupplypipingsystem.
Apply noncorrosive leak detection fluid to
all joints. Bubbles forming show a leak.
5. Correct all leaks at once.
6. Reconnect appliance and equipment
shutoff valve to gas supply. Check recon-
nected fittings for leaks.
Test Pressures Equal To or Less Than 1/2
PSIG (3.5 kPa)
1. Close equipment shutoff valve (see Fig-
ure 14).
2. Pressurizesupplypipingsystem by either
opening propane/LP supply tank valve
for propane/LP gas or opening main gas
valve located on or near gas meter for
natural gas or using compressed air.
3. Check all joints from gas meter to equip-
ment shutoff valve for natural gas or
propane/LP supply to equipment shutoff
valve for propane/LP (see Figure 15 or
Figure 16, Page 16).Apply noncorrosive
leak detection fluid to all joints. Bubbles
forming show a leak.
4. Correct all leaks at once.
Figure 14 - Equipment Shutoff Valve
Figure 15 - Checking Gas Joints
(Propane/LP Only)
Control Valve
Location
Propane/LP
Supply Tank Equipment
Shutoff Valve
Open
Closed
Equipment
Shutoff
Valve
CHECKING GAS CONNECTIONS
PRESSURE TESTING GAS SUPPLY
PIPING SYSTEM
Test Pressures In Excess Of 1/2 PSIG
(3.5 kPa)
1. Disconnect appliance with its appliance
main gas valve (control valve) and equip-
mentshutoffvalve from gassupplypiping
system. Pressures in excess of 1/2 psig
will damage appliance regulator.
2. Capoffopenendof gaspipewhere equip-
ment shutoff valve was connected.

126817-01D
16 SuperiorFireplaces.us.com
INSTALLATION
Continued
PRESSURE TESTING APPLIANCE GAS
CONNECTIONS
1.
Open equipment shutoff valve (see Figure
14, Page 15).
2. Open main gas valve located on or near
gas meter for natural gas or open pro-
pane/LP supply tank valve.
3. Make sure control knob of appliance is in
the OFF position.
4. Check all joints from gas meter to equip-
ment shutoff valve for natural gas or
propane/LP supply to equipment shutoff
valveforpropane/LP(seeFigure 14,Page
15 or Figure 16). Apply noncorrosive leak
detectionfluidtoall joints.Bubblesforming
show a leak.
5. Correct all leaks at once.
6. Light appliance (see Operation, Page 25).
Check all other internal joints for leaks.
7.
Turn off appliance (see To Turn Off Gas to
Appliance, Page 26).
Gas Meter
Figure 16 - Checking Gas Joints (Natural
Gas Only)
Control Valve
Location
Equipment Shutoff Valve
INSTALLING BATTERIES IN
REMOTE CONTROL AND RECEIVER
WARNING: Make sure your
selector switch is in OFF posi-
tion before installing or chang-
ing batteries in your hand-held
remote or receiver.
Hand-Held Remote Control
The hand-held remote control uses 3 AAA
batteries (not included).
To install batteries:
1. Removebatteryhousingcoverfromback
of hand-held remote (see Figure 17).
2. Install or replace batteries.
3. Replace battery housing cover.
Whenbatteriesareinstalled,the"little house"
icon with current room temperature will be
displayed (see Figure 18). This icon will
always show in the control window as long
as the batteries have power.
Figure 18 - Remote Display
Figure 17 - Battery Install Hand-Held Remote
Control
Figure 19 - Battery Install Remote
Control Receiver
Remote Receiver
The remote receiver uses 4AA batteries (not
included). To install or replace batteries:
1. Open lower louver to gain access to re-
ceiver.
2. Remove screws from cover place.
3. Remove battery housing cover.
4. Install or replace batteries.
5. Replace battery housing cover.
6. Replace cover plate.
Battery Housing
Cover
Cover Plate
Screws
Receiver
+
+
-
+
-
-
AAA
AAA
AAA
Battery Housing
Cover

SuperiorFireplaces.us.com
126817-01D 17
INSTALLATION
Continued
TF Series Burner System - Log
Compatibility Chart
Burner System
Models Fiber Log Models Concrete Log Models
TF18NV
TF18PV LTF18MM LTF18RS LTF18WT
TF2430NV
TF2430PV LTF24MM
LTF30MM
LTF24RS
LTF30RS
LTF24WT
LTF30WT
Figure 20 TF Series Burner System- Log
Compatibility Chart
LTF(18,24,30)-MM LOG PLACEMENT
It is very important to install the logs exactly
as instructed. Do not modify logs. Only use
logs supplied with appliance or as identified
forusewiththeapplianceas shown in Figure
20. Each log includes reference numbers
formed in the bottom or back of the log. The
circlednumberindicatestheorderitisplaced
ontheburnersystem.Theremainingnumbers
indicate the size burner system the logs are
designed to fit. For example, the first log for
a 24 inch burner system will include a circled
1 and also a 24.
1
Figure 21 - Installing Log # 1
''U'' -
Burner
Base
assembly
2. Place the middle log (#2) in front of the
U-burner and against the edges of the
plate as shown in Figure 22, Page 18.
3. Place the front left log (#3) onto the base
assembly between the middle log (#2)
and the grate fingers. The back of the
frontleftlog(#3)willrestagainstthefront
of the middle log (#2). The notch at the
end of the front left log (#3) will fit around
the grate bar. See Figure 23, Page 18.
4. Placethefrontright log(#4)ontothe base
assembly between the middle log (#2)
and the grate. The back of the front right
log (#4) will rest against the front of the
middle log (#2). The notch in the end of
the front right log (#4) will fit around the
grate bar. See Figure 24, Page 18.
Thecircled1indicatesthis is the firstlogtobe
installed. The 24 indicates this log belongs to
a24inch logset.SeePages39-41forreference
numbers detail.
1. Place the rear log (#1) on base assembly
as shown in Figure 21. Log will fit over
right end of burner and rest in middle of
U-burner.
WARNING: Failure to posi-
tionthepartsinaccordancewith
these diagrams or failure to use
only parts specifically approved
with this appliance may result
in property damage or personal
injury.
CAUTION: After installation
andperiodicallythereafter,check
to ensure that no flame comes
in contact with any log. With
heater set to Hi, check to see
if flames contact any log. If so,
reposition logs according to log
installation instructions in this
manual. Flames contacting logs
will create soot.
INSTALLING LOGS, EMBERS AND
VOLCANIC STONE

126817-01D
18 SuperiorFireplaces.us.com
INSTALLATION
Continued
Figure 26 - Installing Log # 6
Figure 25 - Installing Log # 5
Figure 24 - Installing Log # 4
Figure 23 - Installing Log # 3
Figure 22 - Installing Log # 2
2
3
6. Placethelefttop forkedlog(#6)on thetop
ofthemiddle log(#2).Match therectangu-
larprojectionontopofthemiddlelog(#2)
with the rectangular hole on the bottom
of the left top forked log (#6). Match the
metal pin on teh top of the middle log (#2)
with the round hold in the bottom of the
left top forked log (#6). See Figure 26.
4
6
5
Metal
Pin
Rectangular
Peg
Rectangular
Peg Metal
Pin
5. Place the left back top log (#5) on top of
the rear log (#1). Match the rectangular
peg on top of the left side of the rear log
(#1) with the rectangular hole on the bot-
tom of the left back top log (#5). Match
the metal pin on the top of the rear log
(#1) with the round hole in the bottom of
the left back top log (#5). See Figure 25.

SuperiorFireplaces.us.com
126817-01D 19
INSTALLATION
Continued
Figure 29 - Installing Log # 9
Figure 28 - Installing Log # 8
Figure 27 - Installing Log # 7
8. Placethefrontrightmidlog(#8)ontopof
thefrontrightlog(#4) as shown in Figure
28. Match the round metal pin on the top
of the front right log (#4) with the round
hole on the bottom of the front right mid
log (#8).
8
Metal
Pin
9
Round
Peg
Square
Peg
7
Round
Peg
Square Peg
10. Placetherightreartoplog(#10)ontopof
the right rear chunk log (#7) as shown in
Figure 30, Page 20. Match the rectangu-
lar peg on the top of the right rear chunk
log (#7) with the rectangular hole on the
bottom of the right rear top log (#10).
11. Place the left top log (#11) on top of the
left back top log (#5) and left top forked
log (#6) as shown in Figure 31, Page 20.
Match the round peg on the top of the left
top forked log (#6) with the round hole on
the bottom of the top left log (#11) and
rectangularpegonthetopoftheleftback
top log (#5) with the rectangular hole on
the bottom of the top left log (#11).
12. Final Assembly is shown in Figure 32,
Page 20.
9. Place the top right log (#9) on top of the
right rear chunk log (#7) and front right
mid log (#8) as shown in Figure 29.
Matchtheroundpegonthetopoftheright
rearchunklog(#7) with the roundholeon
the bottom of the top right log (#9) and
square peg on the top of the front right
mid log (#8) with the square hole on the
bottom of the top right log (#9).
7. Place the right rear chunk log (#7) on top
of the middle log (#2) and rear log (#1)
as shown in Figure 27. Match the round
peg on the top of the rear log (#1) with
the round hole on the bottom of the right
rearchunk (#7)logandsquare pegonthe
top of the middle log (#2) with the square
hole on the bottom of the right rear chunk
log (#7).

126817-01D
20 SuperiorFireplaces.us.com
Figure 30 - Installing Log # 10
Figure 31 - Installing Log # 11
INSTALLATION
Continued
10
11
Figure 32 - Final Assembly
Square
Peg
Round
Peg
Figure 33 - Installing Bottom Ember Log
Figure 34 - Installing Rear Log
LTF(18,24,30)-RS LOG PLACEMENT
It is very important to install the logs exactly
as instructed. Do not modify logs. Only use
logs supplied with appliance or as identified
for use with the appliance as shown.
1. Place bottom ember log on base as-
sembly as shown in Figure 33. The log
should fit over the left side of the burner
and rest in the middle of the U-burner.
2. Placetherearlog on the baseassembly
as shown in Figure 34. The rear log has
grooves in the bottom which will allow
the log to sit on the burner and behind
the bottom ember log
Rear Log
Base Assembly
Burner
Tube
Bottom Ember Log
Burner Tube
