1-1
Chapter 1: Introduction
Chapter 1
Introduction
1-1 Overview
Supermicro's SC836 storage chassis supports up to sixteen hot-swappable 3.5"
SAS/SATA hard drives, the industry's highest storage density for a 3U system. The
SC836 includes 100% cooling redundancy and high e󰀩ciency (1+1) redundant
power supplies with PM BUS functionality for enhanced power management. The
chassis is optimized for the next-generation dual-processor Intel Xeon (5500 series)
and AMD Opteron platforms. Direct attached HDD backplane (TQ version), multilane
backplane (A version) and expander backplane (E1, E2 versions) are available
for application-specic solution optimization. Heavy duty palletized packaging is
available to ensure secure system reliability during shipping. Tool-less, roller rail
designs for easy installation and maintenance are standard with each system.
SC836 Chassis Series
Model HDD PCI Slots Power Supply
SC836BE1C-R1K03B
SC836BE2C-R1K03B
16x 3.5" SAS
2x 2.5" SAS 7x FF 1000W (Redundant, Titanium)
SC836BHA-R1K28B
SC836BHE16-R1K28B
SC836BHE26-R1K28B
SC836BE16-R1K28B
SC836BE26-R1K28B
SC836BA-R1K28B
16x 3.5" SAS
(opt) 2x 2.5" SAS 7x FF 1280W (Redundant, Platinum)
SC836BE16-R920B
SC836BE26-R920B
SC836BA-R920B
16x 3.5" SAS
(opt) 2x 2.5" SAS 7x FF 920W (Redundant, Platinum)
SC836TQ-R500B
SC836E16-R500B
16x 3.5" SAS
2x 2.5" xed 7x FF 500W (Redundant, Platinum)
SC836E16-R1200B
SC836E26-R1200B
SC836A-R1200B
16x 3.5" SAS
3x 2.5" xed 7x FF 1200W (Redundant, Gold)
SC836TQ-R800V /
SC836TQ-R800B 16x 3.5" SAS 7x FF 800W (Redundant)
SC836TQ-R710B 16x 3.5" SAS 7x FF 710W DC (Redundant)
SC836BE1C-R1K23B 16x 3.5" SAS
(opt) 2x 2.5" SAS 7x FF 1200W (Redundant, Titanium)

SC836 Chassis Manual
1-2
1-2 Shipping List
Visit the Supermicro web site for the latest shipping lists and part numbers for
your particular chassis model at www.supermicro.com.
1-3 Chassis Features
The SC836 3U high-performance chassis includes the following features:
Processor Support
The chassis supports dual Dual-core Xeon processors and serverboards up to 13.7"
x 13", E-ATX and ATX. Refer to the motherboard specications pages on our web
site for updates on supported processors for this chassis.
Drives
The chassis supports up to sixteen 3.5" hot-swap SAS or SATA drives with SES2.
With RAID, these drives may be replaced without powering down the server. Some
models also support two hot-swap 2.5" drives in the rear, or two or three internal
xed 2.5" drives. Supporting backplanes are described in the the appendices.
The chassis supports one slim DVD drive (optional).
PCI Expansion Slots
Each version of the chassis includes seven full height, full width expansion slots.
Cooling
Three hot-plug 80mm fans plus two 80mm exhaust fans provide 100% cooling
redundancy, aided by an adjustable air shroud. The 4-pin fans are controlled
though IPMI.
Control Panel
The front control panel includes system status LED indicators and power switches.
