Supermicro Supero SC732 Series User manual

SC732 CHASSIS SERIES
USER’S MANUAL
1.0a
SC732D4F-500B SC732D4F-865B
SC732D4-500B SC732D4-865B
SC732D2-500B SC732D2-865B
SC732i-500B SC732i-865B
SUPER ®
SC732D SC732i

SC732 Chassis Manual
ii
Manual Revision 1.0a
Release Date: May 10, 2011
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and
documentation, is the property of Supermicro and/or its licensors, and is supplied only under a
license. Any use or reproduction of this product is not allowed, except as expressly permitted by
the terms of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2011 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SC732 chassis. Installation
and maintenance should be performed by experienced technicians only.
Supermicro’s SC732 chassis features a unique and highly optimized design, al-
lowing the user to install components with minimal or no use of screws or tools.
The chassis is equipped with a either a 500 Watt or 865 Watt whisper-quiet, high-
efciency power supply for superb power savings.
This manual lists compatible parts available when this document was published.
Always refer to the our Web site for updates on supported parts and congurations
at www.supermicro.com.

SC732 Chassis Manual
iv
Manual Organization
Chapter 1 Introduction
The rst chapter provides a description of the main components included with this
chassis and describes the main features of the SC732 chassis. This chapter also
includes contact information.
Chapter 2 System Safety
This section lists warnings, precautions, and system safety. It is recommended
that you thoroughly familiarize yourself with the chassis safety precautions before
installing and servicing this chassis.
Chapter 3 System Interface
Refer to this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
Chapter 4 Chassis Setup and Maintenance
Follow the procedures given in this chapter when installing, removing, or
reconguring your chassis.
Appendix A Chassis Cables, Screws and other Accessories
Appendix B Power Supply Specications

v
Preface
Table of Contents
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Where to get Replacement Components........................................................ 1-1
1-3 Shipping Lists.................................................................................................. 1-1
1-4 Contacting Supermicro.................................................................................... 1-3
1-5 Returning Merchandise for Service................................................................. 1-4
Chapter 2 System Safety
2-1 Overview ......................................................................................................... 2-1
2-2 Warnings and Precautions .............................................................................. 2-1
2-3 Preparing for Setup......................................................................................... 2-1
2-4 Electrical Safety Precautions .......................................................................... 2-1
2-5 General Safety Precautions ............................................................................ 2-2
2-6 System Safety ................................................................................................. 2-3
Chapter 3 System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Buttons ..................................................................................... 3-3
3-3 Communication Panel Components................................................................ 3-3
3-4 Control Panel LEDs ........................................................................................ 3-4
Chapter 4 Chassis Setup and Maintenance
4-1 Overview ......................................................................................................... 4-1
4-2 Removing the Chassis Side Covers ............................................................... 4-2
4-3 Rotating the Hard Drive Cage......................................................................... 4-3
4-4 Removing and Installing 3.5" Hard Drives...................................................... 4-4
4-5 Removing and Installing 2.5" Hard Drives (Optional)..................................... 4-7
4-6 Installing the I/O Shield and Motherboard ...................................................... 4-9
I/O Shield ........................................................................................................ 4-9
Motherboard Installation................................................................................ 4-10
4-7 Installing a 3.5" Device (Optional) .................................................................4-11
4-8 Installing Expansion Cards ........................................................................... 4-12
Expansion Card and PCI Slot Setup ............................................................ 4-12
Full-Height, Full-Length Expansion Card Setup ........................................... 4-13
4-9 Installing the System Fans............................................................................ 4-14
4-10 Installing the Front Bezel .............................................................................. 4-16
4-11 Power Supply ............................................................................................... 4-17
Appendix A Cables, Screws, and other Accessories
Appendix B SC732 Power Supply Specications

SC732 Chassis Manual
vi
Notes

Chapter 1
Introduction
1-1 Overview
Supermicro’s SC732 chassis features a unique and highly-optimized design, allow-
ing most conguration of the chassis to be accomplished without tools or screws.
The chassis is equipped with a high-efciency power supply and high-performance
fans provide ample optimized cooling for the FB-DIMM memory modules. Four
3.5" HDD drive bays and four optional 2.5" HDD drive bays offer maximum stor-
age capacity.
1-2 Where to get Replacement Components
Although not frequently, you may need replacement parts for your system. To
ensure the highest level of professional service and technical support, we strongly
recommend purchasing exclusively from our Supermicro Authorized Distributors/
System Integrators/Resellers. A list of Supermicro Authorized Distributors/System
Integrators/Reseller can be found at: http://www.supermicro.com. Click the Where
to Buy link.
1-3 Shipping Lists
Please visit the following link for the latest shipping lists and part numbers for
your particular chassis model http://www.supermicro.com/products/chassis/
tower/?chs=732
Chapter 1: Introduction
1-1

SC732 Chassis Manual
1-2
PWS-865-PQ
Model CPU HDD I/O Slots Power
Supply
SC732D4F-865B
SC732D4-865B
SC732D2-865B
SC732i-865B
DP/UP
4x 3.5"
2x 5.25"
(Optional)
7x FF
865W
high-
efciency
PWS-502-PQ
Model CPU HDD I/O Slots Power
Supply
SC732D4F-500B
SC732D4-500B
SC732D2-500B
SC732i-500B
DP/UP
4x 3.5"
2x 5.25"
(Optional)
7x FF
500W
high-
efciency

1-3
Chapter 1: Introduction
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacic
Address: Super Micro Computer, Inc.
4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei County
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone]

SC732 Chassis Manual
1-4
1-5 Returning Merchandise for Service
A receipt or copy of your invoice marked with the date of purchase is required be-
fore any warranty service will be rendered. You can obtain service by calling your
vendor for a Returned Merchandise Authorization (RMA) number. When returning
to the manufacturer, the RMA number should be prominently displayed on the
outside of the shipping carton, and mailed prepaid or hand-carried. Shipping and
handling charges will be applied for all orders that must be mailed when service
is complete.
For faster service, RMA authorizations may be requested online (http://www.super-
micro.com/support/rma/).
Whenever possible, repack the chassis in the original Supermicro carton, using the
original packaging material. If these are no longer available, be sure to pack the
chassis securely, using packaging material to surround the chassis so that it does
not shift within the carton and become damaged during shipping.
This warranty only covers normal consumer use and does not cover damages in-
curred in shipping or from failure due to the alteration, misuse, abuse or improper
maintenance of products.
During the warranty period, contact your distributor rst for any product problems.

2-1
Chapter 2: System Safety
Chapter 2
System Safety
2-1 Overview
This chapter provides a quick setup checklist to get your chassis up and running.
Following the steps in the order given should enable you to have your chassis set up
and operational within a minimal amount of time. This quick setup assumes that you
are an experienced technician, famailiar with common concepts and terminology.
2-2 Warnings and Precautions
You should inspect the box the chassis was shipped in and note if it was damaged
in any way. If the chassis itself shows damage, le a damage claim with carrier
who delivered your system.
Avoid areas where heat, electrical noise and electromagnetic elds are generated.
Position the chassis near at least one grounded power outlet.
2-3 Preparing for Setup
The SC732 chassis contains many features that are unique to the SC732 chassis
model. Read this manual in its entirety before beginning installation procedures.
2-4 Electrical Safety Precautions
Basic electrical safety precautions should be followed to protect yourself from harm
and the SC732 from damage:
Be aware of the locations of the power on/off switch on the chassis as well•
as the room’s emergency power-off switch, disconnection switch or electrical
outlet. If an electrical accident occurs, you can then quickly remove power from
the system.
Do not work alone when working with high-voltage components.•
Power should always be disconnected from the system when removing or in-•
stalling main system components, such as the serverboard, memory modules
and optical device drives. When disconnecting the power, you should rst power

SC732 Chassis Manual
2-2
down the server with the operating system and then unplug the power cords
from all the power supply modules in the system.
When working around exposed electrical circuits, another person who is fa-•
miliar with the power-off controls should be nearby to switch off the power, if
necessary.
Use only one hand when working with powered-on electrical equipment. This•
is to avoid making a complete circuit, which will cause electrical shock. Use
extreme caution when using metal tools, which can easily damage any electrical
components or circuit boards they come into contact with.
Do not use mats designed to decrease electrostatic discharge as protection from•
electrical shock. Instead, use rubber mats that have been specically designed
as electrical insulators.
The power supply power cord must include a grounding plug and must be•
plugged into a grounded electrical outlet.
Serverboard battery: CAUTION - There is a danger of explosion if the onboard•
battery is installed upside down, which will reverse its polarities. This battery
must be replaced only with the same or an equivalent type recommended by
the manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
Please handle used batteries carefully. Do not damage the battery in any way;•
a damaged battery may release hazardous materials into the environment. Do
not discard a used battery in the garbage or a public landll. Please comply
with the regulations set up by your local hazardous waste management agency
to dispose of your used battery properly.
DVD-ROM laser: CAUTION - This server may have come equipped with a•
DVD-ROM drive. To prevent direct exposure to the laser beam and hazardous
radiation exposure, do not open the enclosure or use the unit in any uncon-
ventional way.

2-3
Chapter 2: System Safety
2-5 General Safety Precautions
Keep the area around the chassis clean and free of clutter.•
Place the chassis top cover and any system components that have been re-•
moved away from the system or on a table so that they won’t accidentally be
stepped on.
While working on the system, do not wear loose clothing such as neckties and•
unbuttoned shirt sleeves, which can come into contact with electrical circuits or
be pulled into a cooling fan.
Remove any jewelry or metal objects from your body, which are excellent metal•
conductors that can create short circuits and harm you if they come into contact
with printed circuit boards or areas where power is present.
After accessing the inside of the system, close the chassis back up and secure•
it to the rack unit with the retention screws after ensuring that all connections
have been made.
2-6 System Safety
Electrostatic discharge (ESD) is generated by two objects with different electrical
charges coming into contact with each other. An electrical discharge is created to
neutralize this difference, which can damage electronic components and printed
circuit boards. The following measures are generally sufcient to neutralize this
difference before contact is made to protect your equipment from ESD:
Do not use mats designed to decrease electrostatic discharge as protection from•
electrical shock. Instead, use rubber mats that have been specically designed
as electrical insulators.
Use a grounded wrist strap designed to prevent static discharge.•
Keep all components and printed circuit boards (PCBs) in their antistatic bags•
until ready for use.
Touch a grounded metal object before removing any board from its antistatic•
bag.
Do not let components or PCBs come into contact with your clothing, which may•
retain a charge even if you are wearing a wrist strap.

SC732 Chassis Manual
2-4
Handle a board by its edges only; do not touch its components, peripheral chips,•
memory modules or contacts.
When handling chips or modules, avoid touching their pins.•
Put the serverboard and peripherals back into their antistatic bags when not•
in use.
For grounding purposes, make sure your computer chassis provides excellent•
conductivity between the power supply, the case, the mounting fasteners and
the serverboard.

3-1
Chapter 3 System Interface
Chapter 3
System Interface
3-1 Overview
There are several LEDs on the control panel as well as others on the drive carriers
to keep you constantly informed of the overall status of the system as well as the
activity and health of specic components. This chapter explains the meanings of
all LED indicators and the appropriate responses you may need to take. The fol-
lowing pages detail the features of the communication panel features of each of
the SC732 chassis models.

SC732 Chassis Manual
3-2
HDD LED
Figure 3-1: SC732 Communication Panels Listed by Chassis Model
SC732i
SC732D2
SC732D4
SC732D4F
Power
Button
Power
Button
Power
Button
Power
Button
Audio
Audio
Audio
2x IEEE 1394a 2x USB 2.0
2x USB2.0
2x USB2.0
2x USB2.0
2x USB 3.0
2x USB 3.0
Mic
Mic
Mic
NIC LED
HDD LED
OH LED
NIC LED
HDD LED
OH LED
NIC LED
HDD LED
OH LED
OH LED NIC LED

3-3
Chapter 3 System Interface
3-2 Control Panel Buttons
Power: The main power button is used to apply or remove power from the power
supply to the system. When the power is on, the power button will be lighted by a
blue LED. Turning off the system power with this button will cause the blue LED
to turn off and will remove the main power, but will keep standby power supplied
to the system. Therefore, you must unplug system before servicing the system.
3-3 Communication Panel Components
The SC732 features a front communication panel allowing easy access to the chas-
sis communication ports. The chassis models are equipped as follows:
SC732D4F model chassis:
Two IEEE 1394a ports•
Two USB 2.0 ports•
Two USB 3.0 ports•
One audio port•
One microphone port•
SC732D4 model chassis:
Two USB 2.0 ports•
Two USB 3.0 ports•
One audio port•
One microphone port•

SC732 Chassis Manual
3-4
SC732D2 model chassis:
Two USB 2.0 ports•
One audio port•
One microphone port•
SC732i model chassis:
Two USB 2.0 ports•

3-5
Chapter 3 System Interface
Overheat/Fan Fail
When Flashing: This LED indicates a fan failure.
When Continuously On (not ashing): This LED indicates an overheat condi-
tion caused by cables obstructing the airow in the system or the ambient room
temperature being too warm.
Correcting an Overheat/Fan Fail Condition
Check the routing of the cables and move any cables that restrict airow.1.
Conrm that all fans are operating normally.2.
Verify that the heatsinks are installed properly.3.
If the chassis cover is not aligned correctly, the airow may be disrupted. This 4.
leads to overheating. Conrm that the chassis cover is placed correctly.
This LED will remain active as long as the overheat condition exists.5.
HDD: Indicates IDE channel activity in the SAS/SATA drive, and/or DVD-ROM drive
activity when ashing.
NIC: Indicates network activity on GLAN when ashing.
3-4 Control Panel LEDs
The control panel located on the front of the SC732 chassis has three LEDs.
These LEDs provide you with critical information related to different parts of the
system. This section explains what each LED indicates when illuminated and any
corrective action you may need to take.

SC732 Chassis Manual
3-6
Notes
