User’s Manual
GPS-3505C
GPS + entertainment functions, to make your life and work easier and more enjoyable

Please read carefully the operations and instructions in the user’s manual
to avoid any damage to your Personal Navigation Assistant (PNA). If you
use it with incorrect procedures, or connect incompatible accessories, the
guarantee will be invalid.
It is possible that the electronic navigation data may not be consistent with
real traffic conditions because of road construction development taking
place in real life. Please comply with the real conditions. If you check or
use the PNA when you are driving you may cause an accident.
Updating and upgrading of information on firmware will be put on our
website. It’s dependant on you whether or not to update or upgrade.
The pictures in the manual are just for reference, subject to the real
device.

SECTION SUBJECT PAGE
1.1 PERSONAL NAVIGATION DEVICE and ACCESSORIES 1
1.2 ABOUT THE USER’S MANUAL 2
2.1 PRODUCT FEATURES 3
2.1.1 Product Description 3
2.1.2 Specifications 3, 4
2.1.3 Identifying Hardware Components 5
2.2 POWER SUPPLY and CHARGER 5
2.2.1 Power Supply 5
2.2.2 Charging the Battery by AC/DC Adaptor 6
2.2.3 Charging the Battery by Car Cigarette Lighter Adaptor 7
2.3 BASIC OPERATION PROCEDURES 7
2.3.1 Turn Battery on/off 7
2.3.2 Power on/off 7
2.3.3 Resetting the System 8
2.3.4 PNA Car Support Cradle 8
2.3.5 External Antenna 9
2.3.6 Pen for Touch Screen 9
2.3.7 Adjusting the Volume 10
2.3.8 SD Card 10
2.3.9 Hot Key 11
2.4 CONNECTION TO A COMPUTER 11

2.5 MAIN MENU and PRIMARY FUNCTIONS 12
2.6 PROTECT and CARE FOR YOUR PNA 13
3.1 NAVIGATION FUNCTIONS and FEATURES 14
3.2 ESSENTIAL KNOWLEDGE 14, 15
4.1 AUDIO PLAYER FUNCTIONS and FEATURES 16
4.2 AUDIO PLAYER INTERFACE and OPERATION 16, 17
5.1 PICTURE/PHOTO FUNCTION and FEATURES 18
5.2 PICTURE/PHOTO INTERFACE and OPERATION 18, 19
6.1 E-BOOK FUNCTIONS and FEATURES 20
6.2 E-BOOK INTERFACE and OPERATION 20-22
7.1 VIDEO FUNCTIONS and FEATURES 23
7.2 VIDEO INTERFACE and OPERATION 23, 24
8.1 SYSTEM FUNCTIONS ON MAIN MENU 25
8.2 VOLUME ADJUSTMENT 26
8.3 POWER SETTING and BATTERY STATUS 26, 27
8.4 BACKLIGHT SETTING 27, 28
8.5 TIME AND DATE SETTING 28, 29
8.6 LANGUAGE SELECTION 29
8.7 SYSTEM INFORMATION 30-32

Welcome as a user of GPS navigation. The navigator is used
mainly for navigation and also has functions for audio and Video
playing, (Multimedia MP3 and MP4), photo viewing and E-Book.
GPS + entertainment functions can make your life and work
easier and more enjoyable:
low-power consumption Atlas 376M CPU;
Simple user interface: simple, easy to operate the GPS and
MP3, MP4
Power management: Energy-saving mode allows you to
work longer and more steadily
Data transmission: communication with computer through
Microsoft ActiveSync by USB Cable.

Excellent on receiving Satellites signature: 20 channels /
accuracy positioning to provide a first class navigation
service;
Personal entertainment player: MP3 and MP4 functions
allow you to enjoy playing MP3 Songs and Video / Movie
downloaded to SD Card
1.1 Personal Navigation Device and Accessories
The product contains the following accessories:
GPS Device
USB cable
Car Adapter

1.2 About the User’s Manual
In order to get to know your device and enjoy all its functions and
features fully, please read the User’s Manual carefully first.
The information in this User’s Manual is only applicable to the
Personal Navigation Assistant (PNA).
Please refer to the SuperNav User’s Guide for detailed
information about the navigation software, including maps for
Egypt.
Support Bracket
User’s manual

In this Chapter we will introduce the PNA device and the basic
operations.
2.1 Product Features
2.1.1 Product description
- 3.5 inch TFT touch screen, Display resolution 320 x 240.
- Double-track headphone connector, 1W hi-fi speaker built in,
volume adjustor.
- Key-press and touch screen operate.
- SiRF STAR III GPS incept model built in.
- GPS antenna built in, can be connected with external antenna.
- Directly run SD navigation software, (support SD 4 mid-speed,
high-speed ）
- Supports MP3, MP4 and similar.
- Long-life, rechargeable 3.7V lithium battery built in, (DC12V
connection through cigarette lighter)
- Video player support: asf, avi, MP4, wmv
- Audio player support: MP3, wav, midi

- Picture browser support: BMP, JPG, PNG, GIF formats
- File browser support: TXT format
- Double indicators; blue light (glows blue to indicate working
and sleeping off) ； yellow/green light (glows yellow to indicate
battery charging in progress and green when the battery is
fully charged).
2.1.2 Specifications
Environmental Parameters
Size 90.5mm x 78mm x 22mm
Operation temperature -10
℃ ~ +70 ℃
Storage temperature -40
℃ ~ +80 ℃
Operation humidity 45% ~ 80%RH
Storage humidity 30% ~ 90%RH
Atmospheric pressure 860MBar ~ 1060Mbar

System Parameters
Operation frequency
400MHZ
MCU SAMSUNG S3C2440A-40
SDRAM 64MB
NAND FLASH 64MB
（ Up tp 4GB ）
Navigation software SD card or NAND FLASH built in
Operating system WINCE 4.2 NET
Compiler type ARMV4
General Parameters
TFT size 3.5 inch
Display
solution
320*240
Audio Stereo headphone/1w speaker bulit in
Sound power Double track earphone 0.25W/CHANEL, single
channel 8ou/1W
average 1.5W

power
Idle <20mW
DC voltage
input
9--30V
Battery According to customers
Battery time up to 3.5Hours ; 250 hours in sleeping
GPS Hardware Parameters
Chip Set SiRF Star III
Frequency L1/1.575GHZ
C/A CODE 1.023 MHZ chip rate
Channels 20 channels
Tracking sensitivity -159dBm
Precision 10m, 2D RMS
5m, 2D RMS, WAAS enable
rate 0.1m/s
Data update 1HZ
Requisition time Average 0.1s

Hot start time Average 1s(Open sky
Warm start time Average 38s(Open sky
Cold start time Average 42s(Open sky)
Altitude (max) 18,000m
Maximum Velocity 515m/s
Acceleration < 4g
internal Antenna Active antenna built in
internal Antenna gain
27dB
Internal Antenna
voltage
3.3V ± 5%
internal Antenna
current
15mA
External antenna type
MMCX
External antenna
voltage
3.3V ± 5%
External antenna gain
27dB
External antenna
current
15mA

2.1.3 Identifying hardware components
A ： SD card slot
B ： Stereo
headphone
interface
D ： USB
G
：
power
H ： GPS built-in antenna
J: Lock and
Unlock button
I ： Volume and
OK button
K ： DC5V in
E
： 3.5 inch TFT-LCD
F ： Menu
C ： Reset

Ref. Explanation Ref. Explanation
A SD card slot G Power on/off button
B
Stereo headphone
interface
H GPS built-in antenna
C reset I Volume and OK button
D USB J Lock and unlock button
E 3.5inch TFT-LCD K DC5Vin
F Menu
2.2 Power Supply and Charger
Please fully charge the battery by using AC/DC Adaptor before
you use this GPS navigator for first time.

2.2.1 Power supply
There are two methods of supplying power for the GPS built-in
battery; connection by the AC/DC connector or connection by the
USB connector.
The Symbol of [ ] at the top tight of the Display
indicates the PNA is using the build-in Li-battery to supply power
when it is not connecting with any adaptor. The symbol of
[ ] on the electrical setting interface indicates
the current battery capacity.
The PNA uses the external power supply from AC to DC when it
is connected with the adaptor.
Note: this PNA uses a built-in, factory installed Lithium battery.
In normal conditions (if the back light is not so bright), the fully

charged battery can be used for 10 hours, however the actual
supply hours can vary because of the different ways of using the
navigator. Some functions (audio playing, video playing, too
bright back light) will consume more electricity, which will reduce
the usage hours.
Important: this machine uses a built-in, factory installed Lithium
battery. In order to avoid the possibility of overheating or fire,
please do not poke, dent, take apart or throw the battery into fire
or water. The battery will crack and explode or release dangerous
chemical material.

2.2.2 Charging battery by AC/ DC Adaptor
Please fully charge the GPS by AC/DC adapter before use.
1. Connect the DC Jack of the Adaptor to the Power In port on
the right side of the machine.
2. The other end is connected to the electrical socket, to supply
AC power and charge the battery.
Note: the indication light is red when charging. Please do not pull out the
adaptor until the light turns green to show it is well charged. Please
charge your PNA in good time when it shows that battery power is low.

2.2.3 Charging by car cigarette lighter adaptor
1. Please connect one end of the car lighter adaptor to the
Power In port on the right side of the machine.
2. The other end is connected to the car light adaptor socket to
supply power and charge the battery.
Warning: Please connect the Car Kit adapter after starting the car's engine
to prevent the electrical surge from damaging the PNA.

2.3 Basic Operation Procedures
2.3.1 Turn battery on/off
The battery switch [ ] on the right side of the machine is
used to control the system power supply
Upward switch [ ] indicates power supply on, by battery
or adaptor.
Downward switch [ ] indicates power is off and the
system can not be started up.
Note: When the switch is off, it can still charge the machine as it
is just cut off the system power supply.
Extra Information: If the PNA has not been used for a long
time, you can save the power by using the downward switch.

2.3.2 Power on/off
The power key [ ] can control the power on/off. Power off
indicates the system is on Pause / Energy saving mode, the
system keeps the last operation status when you power on again.
1. Power on:
Please check: The battery is well charged, or the machine is
connected with adaptor and the switch is upward [ ].
Press the “power” key [ ] on the top of machine to power
on.
Important: When you carry the PNA from one place to another,
you need to wait until the machine has adapted to the local
environment to avoid the risk of short-circuit caused by changes
in humidity and temperature.
