Supertrax Rescue Response Kids Ride on Car User manual

Rescue Response
Kids Ride on Car
Installation and Operation Instructions
Please read this instruction manual carefully. It is important to
read and follow all of the steps during assembly to ensure proper
operation and safety of the child. Please keep this manual for
future reference.
Scan this QR Code
to view the
Assembly Video

SPECIFICATIONS:
Battery Type:
12V10AH
Avg. Speed:
2 –3 MPH
Age Range:
2 –5 Years
Charging time:
8-12 hrs –Minimum
1 Charge per month
Max. Weight:
70 lbs
Avg. Use Time:
48 - 90 Minutes
(depending on use)
Product Size:
49 x 27 x 25 inches
Remote Battery:
2 - AAA (not
included)
IMPORTANT!
•Assembly of car and charging of
battery is only to be done by an
adult.
•WARNING!! NOT TO BE USED
ON STREETS or IN TRAFFIC.
•Never modify the electric
circuit system or tamper with
electric system. This can cause
permanent damage.
•Please check the product
regularly for any loose parts or
wires to ensure proper
operation.
•Adult supervision is
recommended during
operation by child to avoid
injury. Safety equipment is
recommended.
•Please make sure that the child
uses caution to avoid falls and
collisions, which could cause
injury to the child or third
party.
•Do not pick up vehicle by
steering wheel.
•Do not pick up battery by wires
or charger.
•Keep all plastic bags out of the
reach of young children.
•Not recommended for children
under the age of 2 yrs. due to
small parts that could cause a
choking hazard.
•Battery must be charged for a
minimum of 8-12 hours prior to
first use of the car to avoid
damage to the battery. Power
switch must be in off position
when charging.
•Battery charger should be
examined for damage prior to
each use. It is important to
inspect the cord and both ends
for damage. If damage is
found, DO NOT USE THE
CHARGER! Contact us for
replacement charger.
•Please retain instruction
manual for future reference.
•Please retain packaging in the
event it is necessary to return.

If the charger is plugged into the charging port, the car
will not power up regardless if the charger is plugged into
the wall outlet or not.
PARTS LIST
No.
Name of
Part
Qty.
No.
Name of
Part
Qty.
1
Main Body
1
5
Rear
Wing
1
2
Seat
1
6
Driving
Wheel
4
3
Wind
Shield
1
7
Wheel
cover
4
4
Steering
Wheel
1
8

ADDITIONAL PARTS:
Gear Box
2
Parts Bag
1
Charger
1
Instruction
Manual
1
emote
Control
1
Steering
Shaft
1
All assembly videos can be found on
YouTube under SPORTrax
Assembly Instructions:
Front Tire Assembly:
Turn the car body upside down. Slide a washer onto each front axle.
Next, slide a tire onto each axle followed by a washer, and lock nut.
Tighten the lock nuts, with the wrench provided, until the end of axle
is even with the outside of the lock nut. (Do not over tighten) Snap
wheel cover into place by lining up the tabs on the wheel cover with
the corresponding slots in the wheels.

Back Tire Assembly:
Locate the 2 hub adaptors and screw the adaptors onto the back of
the 2 remaining tires with supplied screws. (you will need 4 screws
per tire) Once hub adaptors are installed onto the tires, slide tires
onto the rear axle and align the hub adaptor with the gear box. Next,
install a washer & lock nut and tighten down with wrench. Snap
wheel cover into place by lining up the tabs on the wheel cover with
the corresponding slots in the wheels.
Installation of Steering Shaft:
Locate the steering shaft and guide it up into the steering motor. The
hook at the end of the axis should hook into the eye hole on the front
axle assembly. Ensure the steering rod is properly seated into steering
motor on the bottom of the vehicle. Failure to do this step will result in
the inability to secure the steering wheel to the vehicle.

Steering Wheel Assembly:
Remove the nut and bolt from steering wheel. Connect the steering
wheel wires and slide the steering wheel onto the steering shaft. Place
bolt through the steering wheel column and replace nut to secure. The
steering wheel should never be used to pick-up the vehicle.
Seat Assembly:
Locate the seat of the vehicle. Make sure the seat belt is not covered
by the seat. Install seat by sliding hooks into the body of the vehicle,
and secure with 2 screws.

Power supply Connection:
Connect the power as shown in the diagram (most of the time this will
already been done for you). The red wire should be connected into the red
port, and the black wire going to the black port.
Charging:
The charging port is located under the seat of the vehicle. Plug the
charger into the charging port first, then plug the charger into a wall
outlet.
Please Note: As a safety precaution and to avoid damage to the
charger, the car will not power up while charger is plugged into the
charging port of the car.
BATTERY MUST BE CHARGED FOR A MINIMUM OF 8-12 HOURS
BEFORE INITIAL USE TO AVOID DAMAGE TO THE BATTERY. ONLY AN
ADULT SHOULD CHARGE AND RECHARGE THE BATTERY!
BATTERY REPLACEMENT AND DISPOSAL:
The battery will eventually lose the ability to hold a charge. Depending
on the amount of use, and varying conditions, the battery should
operate for one to three years. Follow these steps to replace and/or
dispose of the battery:
•Disconnect the battery connectors
•Remove the battery bracket
•Carefully lift the battery - you may want to wear protective
gloves before removal - Do Not lift the battery by its
connectors or cables
•Place the dead battery in a plastic bag
•Replace the battery and reconnect the connectors
Reinstall the battery bracket
Please give us a call for your battery replacement needs
or visit our website to place an order.

Fuse:
This vehicle comes with a self-setting fuse. If the vehicle stops
unexpectedly it will mainly be from a current that exceeded the fuse’s
specified allotment of current. When this happens wait 8 seconds and
then the fuse will automatically restart.
To avoid tripping the fuse:
Do not overload weight limit, stay within the weight recommendations.
Do not pull anything with the vehicle.
Do not let water or any other liquids touch circuits, battery, or other
parts.
Do not modify the structure or electric circuit system of this vehicle.
Remote Control Instructions:
Operating the remote control
1.Install batteries
2.Hold Mbutton for more than three seconds until light flashes
Then turn on the car, light should go solid and will be paired to the car.
1 Light=Slow Speed
2 Lights=Medium Speed
3 Lights=High Speed
P=Parking brake
S=Speed Control
M=Code Matching

Power Button Panel

WARNING:
- Use only the rechargeable battery and charger supplied with
your vehicle. NEVER substitute the battery or charger with
another brand. Using another battery or charger may cause
damage.
- NEVER modify the electric circuit system. Tampering with the
electric system may cause permanent damage to the system.
- Do not allow direct contact between battery terminals.
- Do not allow any type of liquid on the battery or its
components.
- Charge the battery in a well-ventilated area ONLY. Do not
charge near or around flammable materials.
- NEVER pick up the battery by the wires or charger. Damage can
occur to the battery and may cause a fire. Pick up the battery
by the case ONLY.
- Charge the battery in a dry area ONLY.
Wash hands after handling.
- Do not open the battery. Battery contains lead acid and other
materials that are toxic and corrosive.
- Do not open the charger. Exposed wiring and circuitry inside
case could cause electric shock. NEVER allow a child to handle
or charge the battery. Battery is heavy and contains lead acid
(electrolyte).
- Do not drop the battery. Permanent damage to the battery
could occur or cause serious injury.
- Before charging the battery, check for wear or damage to the
battery, charger, its supply cord and the connectors. DO NOT
charge the battery if any damage to parts has occurred.
- Do not allow the battery to drain completely. Recharge the
battery after each use or once per month if not used regularly.
- Do not charge the battery upside down.
- Always secure the battery with the bracket. Battery can fall out
and injure a child if vehicle tips over.
- The Power Switch must be turned in the OFF position when
charging.
- When the car begins to run slowly, recharge the battery.

GENERAL MAINTENANCE:
It is the parent’s responsibility to check main parts of the toy
before using. Regularly examine the car for potential hazard,
such as damage to the battery, charger, cable or cord, and plug.
Also, check that all screws are tightened throughout the car. In
the event of such damage, the toy must not be used until that
damage is repaired or replaced.
•Make sure the plastic parts of the vehicle are not cracked or
broken.
•Occasionally use a lightweight oil to lubricate moving parts
such as wheels.
•Park the vehicle indoors or cover it with a tarp to protect it
from wet weather.
•Keep the vehicle away from sources of heat, such as stoves
and heaters. Plastic parts may melt.
•Recharge the battery after each use. Only an adult should
handle the battery. Recharge the battery at least once a
month when not being used.
•Do not wash the vehicle with a hose. Do not wash the vehicle
with soap and water. Do not drive the vehicle in rainy or
snowy weather as water will damage the motor, electric
system and battery.
•Clean the vehicle with a soft, dry cloth. To restore shine to
plastic parts, use a non-wax furniture polish. Do not use car
wax. Do not use abrasive cleaners.
•Do not drive the vehicle in loose dirt, sand or fine gravel
which could damage moving parts, motors or the electric
system.
•For extended times when the car will not be used, the power
switch needs to be in the off position and the electrical
connections should be disconnected from the battery.

TROUBLE SHOOTING GUIDE:
Problem
Possible Cause
Possible Solutions
Car will not move
1. Battery voltage is low.
2. Battery connector or wires
are loose.
3. Battery is damaged or
dead.
4. Electrical box or motor is
damaged
Charge the battery
Re-connect the battery
connector to the car
Replace battery
Replace motor
The battery will not
charge.
1. Battery connector may
have come apart or have a
bad connection.
2. Battery charger plugged
into a bad wall outlet.
3. Battery charger is
damaged.
Re-connect the battery
connector to the car
electrical connector
Try another wall outlet
Replace battery charger
Shortened battery life
Battery was not charged fully
Battery is old
Charge battery fully
Change battery
Some Noise and heat
when charging battery
Chemical reaction
Normal
Low Speed
Battery is old
Battery is low on charge
Weight limit exceeded
Uneven or uphill path
Vehicle is being used in harsh
conditions
Change the battery
Charge the battery
Do not exceed max weight
limit
Use on flat surfaces
Avoid using car in harsh
conditions
Noise coming from
motor/gearbox
Gear in motor/gearbox broken
Call for replacement
motor
The car shakes when
moving
Bad Connection of the motor
wires
Possible motor failure
Reconnect wires
Call for replacement
motor
Car needs a push to go
forward
Poor contact of wires and/or
connectors
“Dead Spot” on motor
Check that the battery
connectors are firmly
plugged into each other. If
wires are loose around
the motor, contact the
distributor’s service
department
A dead spot means the
electric power is not being
delivered to the terminal
connection. Call our
service department
Self-Resetting Breaker –The vehicle is equipped with a self-resetting breaker. In
the event the power is tripped the breaker will reset itself in approximately one minute.
If you are unable to solve a problem, please feel free to contact us.
Phone: [phone] or Email: [e-mail]
