suprema XPass D2 User manual

XPass D2
INSTALLATION GUIDE
Version 1.07
English
EN 101.00.XPD2-MDB, XPD2-GDB, XPD2-GKDB V1.07A

CONTENTS
Safety instructions 2
Instructional icons 2
Introduction 4
Components 4
Name and function of each part 5
Installation 7
Fixing the bracket and the product 7
Power supply connection 9
RS-485 connection 9
Wiegand and other cable connections 10
Restoring the Factory Defaults  10
Resetting the baud rate of RS-485  10
Product specifications 11
Dimensions 12
XPD2-MDB 12
XPD2-GDB, XPD2-GKDB 12
FCC compliance information 13
EU Declaration of Conformity (CE)  13
Appendices 14
Disclaimers 14
Copyright notice 14
Open Source License 15

2
Safety instructions
Safety instructions
Please read this safety instructions before you use the product to prevent injury to yourself and others and to prevent
property damage. The term ‘product’ in this manual refers to the product and any items provided with the product.
Instructional icons
Warning: This symbol indicates situations that could result in death or severe injury.
Caution: This symbol indicates situations that may result in moderate injury or property damage.
Note: This symbol indicates notes or additional information.
Warning
Installation
Do not install or repair the product arbitrarily.
• This may result in electric shock, fire, or product damage.
• Damages caused by any modifications or failure to follow installation instructions can void your manufacturer’s
warranty.
Do not install the product in a place with direct sunlight, moisture, dust, soot, or a gas leak.
• This may result in electric shock or fire.
Install the product in a well-ventilated and cool place away from direct sunlight to prevent overheating when
installing it outside.
Do not place the product inside the sealed enclosure when installing it outside.
• It increases the internal temperature of the enclosure and this may result in electric shock, fire, or malfunction.
Do not install the product in a location with heat from an electric heater.
• This may result in fire due to overheating.
Install the product in a dry location.
• Humidity and liquids may result in electric shock or product damage.
Do not install the product in a location where it will be affected by radio frequencies.
• This may result in fire or product damage.
Operation
Keep the product dry.
• Humidity and liquids may result in electric shock, fire, or product damage.
Do not use damaged power supply adaptors, plugs, or loose electrical sockets.
• Unsecured connections may cause electric shock or fire.
Do not bend or damage the power cord.
• This may result in electric shock or fire.

3
Safety instructions
Caution
Installation
Do not install the product under direct sunlight or UV light.
• This may result in product damage, malfunction, discoloration, or deformation.
Do not install the power supply cable in a location where people pass by.
• This may result in injury or product damage.
Do not install the product near magnetic objects, such as a magnet, TV, monitor (especially CRT), or speaker.
• The product may malfunction.
Do not seal around the product with silicone, etc. when installing it on the wall.
• The product may malfunction.
Keep the minimum distance between products when installing multiple products.
• The product may be affected by radio frequencies emitted by other products and the product may malfunction.
Use the IEC/EN 62368-1 approved power adaptor that supports higher power consumption than the product. It
is highly recommended to use the power adaptor sold by Suprema.
• If the right power supply is not used, the product may malfunction.
It is recommended to use the enclosure if the product is installed outside.
• The product may malfunction if the water-resistant and dust-resistant features are damaged.
Operation
Do not drop the product or cause impacts to the product.
• The product may malfunction.
Do not disconnect the power supply while upgrading the firmware of the product.
• The product may malfunction.
Do not disclose the password to others and change it regularly.
• This may result in illegal intrusion.
Do not store your product in very hot or very cold places. It is recommended to use your product at
temperatures from -35 °C to 65 °C.
• The product may malfunction.
When cleaning the product, mind the following.
• Wipe the product with a clean and dry towel.
• If you need to sanitize the product, moisten the cloth or the wipe with a proper amount of rubbing alcohol and gently
clean all exposed surfaces including fingerprint sensor. Use rubbing alcohol (containing 70% Isopropyl alcohol) and a
clean, non-abrasive cloth like lens wipe.
• Do not apply liquid directly to the surface of the product.
Do not use the product for anything other than its intended use.
• The product may malfunction.
RTC battery
Discard the battery according to the appropriate regional or international waste regulations. Discard the battery according
to the appropriate regional or international waste regulations.

4
Introduction
Introduction
Components
Device and Wall Bracket
(XPD2-MDB)
Device and Wall Bracket
(XPD2-GDB)
Device and Wall Bracket
(XPD2-GKDB)
PVC Anchor x2 Fixing Screw x2 Bracket Fixing Screw
(Star Shaped)
132.2
83.5
39.8
XPD2-M
XP2-M
Drilling Template Shrink Tube 120 Ω resistor
XPass D2
XPass D2 MDB
201.00.XPD2 V1.06A
XPass D2
XPass D2 GDB
201.00.XP2 V1.03A
XPass D2
XPass D2 GKDB
201.00.XPD2 V1.03A
Open Source Software
Linux Kernel GPL
BoringSSL
Original SSLeay
AOSP Apache
306.00 V1.00A
G
Quick Guide
(XPD2-MDB)
Quick Guide
(XPD2-GDB)
Quick Guide
(XPD2-GKDB)
Open Source Software
Guide
• Components may vary according to the installation environment.
• When assembling the product with the bracket, you can use the included bracket fixing screw (Star Shaped)
instead of the product fixing screw for enhanced security.

5
Introduction
Name and function of each part
LED Indicator
RF card and
mobile access card
authentication unit
Reset Button
Cable
Name Description
LED Indicator
Indicates the operational status of the device with the color of the LED.
• Green solid: Authentication success
• Red solid: Authentication failure
• Blue/Sky blue blinking: Normal operation
• Blue/Green blinking: When initializing network settings
• Green blinking: Waiting for an input
• Green/White blinking: Connecting with the Airfob Pass (BLE) application of Suprema
• White blinking: Connecting with the Device Manager application of Suprema
RF card and mobile access card
authentication unit Reads RF cards for entering and exiting.
Reset button Initialize the device.
Cable
• Power cable
• RS-485 cable
• Wiegand output cable
• LED input cable
• Beep Input cable
• Tamper cable
Keypad

6
Introduction
Keypad
Used to authenticate by entering the card ID directly. If you want to enter the ID directly,
change the authentication method settings in BioStar 2.
• 0 ~ 9: Enters number.
• : Separates the FC code from the ID when entering the Wiegand card ID.
• : Used to finish entering.
Only the XPD2-GKDB model supports the keypad.
Cables
This document describes cable information based on the shape of the XPD2-MDB model. The same cable
configuration is also used for XPD2-GDB and XPD2-GKDB models.
12345678910
Pin Name Color
1PWR +VDC Red
2GND Black (White stripe)
3485 TRXN Yellow (Black stripe)
4485 TRXP Blue (White stripe)
5WG D0 Green
6WG D1 White
7LED RED Orange
8LED GRN Brown
9BEEP Purple
10 TMPR Gray

7
Installation
Installation
Fixing the bracket and the product
This document describes the installation method using XPD2-MDB model. Install XPD2-GDB and XPD2-GKDB
models in the same way.
1
Determine the correct position to install the bracket using the provided drilling template. Fix the bracket firmly using
fixing screws through the bracket to the position where XPass D2 will be installed.
• If installing XPass D2 on a concrete wall, drill holes, insert PVC anchors, and fix them with fixing screws.
• To avoid RF interference, a minimum separation distance must be maintained.
XPD2-MDB
Wall thickness
Distance
Wall
Wall thickness Distance
100 mm 360 mm
120 mm 360 mm
150 mm 300 mm
Wall
400 mm
XPD2-GDB, XPD2-GKDB
Wall thickness
Distance
Wall
Wall thickness Distance
100 mm 400 mm
120 mm 380 mm
150 mm 380 mm
Wall
430 mm
•
When using Suprema Mobile Access, install a minimum distance of 1 m between devices to avoid BLE interference.

8
Installation
2
Install XPass D2 onto the fixed bracket.
3
Assemble XPass D2 with the bracket by rotating the product fixing screw.
• When assembling the product with the bracket, you can use the included bracket fixing screw(Star Shaped)
instead of the product fixing screw for enhanced security.

9
Installation
Power supply connection
XPass D2 can be used as an RFID card reader by connecting to a master device or a CoreStation.
1
2
XPass D2
1 - PWR +VDC Red
2 - GND Black (White stripe)
DC power
• Use the IEC/EN 62368-1 approved power adaptor that supports higher power consumption than the product.
If you wish to connect and use another device to the power supply adaptor, you should use an adaptor with a
current capacity which is the same or larger than the total power consumption required for the terminal and
another device.
RS-485 connection
3
4
2
1
XPass D2
1 - PWR +VDC Red
2 - GND Black (White stripe)
3 - 485 TRXN Yellow (Black stripe)
4 - 485 TRXP Blue (White stripe)
DC power
• Use an AWG24 twisted pair with a maximum length of 1.2 km for the RS-485 cable.
• If connecting with a RS-485 daisy chain, connect the termination resistor (120 Ω) to both ends of the daisy
chain connection. If connected to the middle line, the signal level becomes smaller and the communication
performance will deteriorate. Make sure to connect it to both ends of the daisy chain connection.
Control device
