Surefire EDCL1-T User manual

18300 MT. BALDY CIRCLE
FOUNTAIN VALLEY, CA 92708-6122
WWW.SUREFIRE.COM
Patents: RE40125, 6547415, 6712485
Revision A 8-2021
71-01-1130
EDCL1-T
THE SUREFIRE NO-HASSLE GUARANTEE
We’ll do what it takes to keep your SureFire gear running smoothly. SureFire
warrants that if you — our customer — purchase one of our products, and we
determine that it is defective in material and/or workmanship during your lifetime,
we will repair or replace it — no hassle!
Our warranty does not cover consumables or normal wear-and-tear — things
like batteries draining, headbands and headpads wearing out, ink cartridges
running out, and switches wearing out — or damage resulting from abuse,
alterations, unauthorized repairs, or use contrary to SureFire’s user manuals.
Should you need a replacement product, SureFire reserves the right to replace an
obsolete product with a current production, like model. In the event that any issue
with a SureFire product is not covered under this warranty SureFire can arrange to
have the product repaired for a reasonable fee.
STANDARD DISCLAIMER
Except as specified above or prohibited by applicable law: all express or implied
conditions and warranties, including, without limitation, any implied warranty or
condition of merchantability or fitness for a particular purpose, or accuracy of
any informational content, are hereby excluded and disclaimed by SureFire; and
in no event will SureFire be liable for any special, direct, indirect, consequential,
incidental or punitive damages howsoever arising and regardless of the theory
of liability, even if advised of the possibility of such damages. Products, prices,
availability, specifications, and offers are subject to change or cancellation at any
time without notice.
WARRANTY CLAIMS
For claims, contact Customer Service at 714-545-9444 to obtain a Return
Merchandise Authorization number (RMA#). Then package the unit carefully
and send to (no CODs):
SureFire, LLC.
Repairs Department, RMA#____
17680 Newhope Street, Suite B
Fountain Valley, CA 92708
SureFire will pay any reasonable shipping costs to return the unit to you.
DUAL-OUTPUT EVERYDAY CARRY LIGHT
USER MANUAL
EDCL1-T
OUTPUT High: 500 Low: 5 lumens
RUNTIME High: 1.0 Low: 45 hours
PEAK BEAM INTENSITY 7,600 candela
DISTANCE 175 meters
CONSTRUCTION Aluminum
FINISH Hard Anodized (MIL-A-8625 Type III, Class 2)
WEIGHT (w/batteries) 3.3 oz (95 g)
LENGTH 4.5 in (11.3 cm)
BEZEL DIAMETER 1.125 in (2.85 cm)
BATTERIES One 123A lithium (incl.)
SWITCHING Dual stage tactical tailcap
All performance claims tested to ANSI/NEMA FL1-2019 Standard.
SPECIFICATIONS

LOCKOUT TAILCAP (US PAT. RE40125)
To enable, rotate tailcap clockwise until light activates when tailcap
pushbutton is pressed.
To lock out tailcap, rotate counterclockwise until light will not
activate when pushbutton is pressed.
LIGHT OPERATION
Press partially for the low output or press fully for the high-output. Twist
clockwise for constant on activation.
LANYARD INSTALLATION & REMOVAL
To install, pinch the middle section of the scissor snap like a set of
tweezers, hook it onto the tailcap’s lanyard ring and release.
To remove lanyard, pinch middle section of the scissor snap and unhook
it from lanyard ring.
BATTERY REPLACEMENT
1. Unscrew head counterclockwise and remove.
2. Remove old batteries and dispose of properly.
3. Insert two new 123A lithium batteries with their positive (+)
terminals oriented forward.
4. Replace head by screwing on clockwise. Press pushbutton
(with tailcap enabled) to test.
BATTERY INFORMATION & WARNINGS
For complete battery information and warnings, reference the enclosed
BATTERY INFORMATION / WARNING insert in your illumination tool’s
original packaging or visit www.surefire.com/batteries.
MAINTENANCE
Wipe with a clean, dry cloth. For tips on maintaining your SureFire illumina-
tion tool, visit www.surefire.com/faqs-maintenance.
ACCESSORIES
SureFire makes a full line of accessories for most of its illumination tools.
For a complete listing, visit www.surefire.com/parts-accessories.
ENABLE
DISABLE
PRESS FOR
MOMENTARY
OR TWIST FOR
CONSTANT ON.
