1
1. GENERAL INFORMATION
1.1 Packing List
The XenoWorks™ analog microinjector is shipped with the following components.
1. Analog Microinjector Drive
2. Micropipette holder
3. Pressure fittings
4. 1m tubing (2 pieces)
5. Ferrules (6 pieces)
6. Spare O-rings (6 pieces)
7. Instruction manual
Use the Figure 1-1 to identify the parts listed. If any items are missing or damaged, contact
Sutter Instrument immediately.
Figure 1-1. Components of the XenoWorks analog microinjector.
NOTE: To operate the Analog Microinjector, an appropriate syringe is also required. A 500-
microliter syringe has been supplied and has been shipped along with the Analog
Microinjector. Please contact Sutter Instrument immediately if this item cannot be located.
XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV. 4

.00 20100521( )
2
1.2 Controls and Features
The figure below illustrates the XenoWorks Analog Microinjector fully assembled, complete
with syringe.
Figure 1-2. Analog microinjector controls and features.
1.2.1 Syringe Clamp
This holds the glass body of the syringe barrel gently and firmly in place. See below for notes
on syringe attachment.
1.2.2 Plunger Clamp Screw
This grips the end of the syringe plunger, allowing it to be pushed in and out of the syringe
barrel by the movement of the black sliding block.
1.2.3 Sliding Block
The sliding block is moved along the body of the analog microinjector, moving the syringe
plunger that it grips, in and out of the syringe barrel. The sliding block is moved by rotation
of the micrometer screw (which can be seen running the length of the inside body of the
microinjector). The micrometer screw is turned by rotation of the coarse and fine controls.
1.2.4 Coarse and Fine Controls
Turning the coarse and fine controls rotates the micrometer screw that moves the sliding
block up and down the body of the microinjector and in turn moves the syringe plunger.
Turning either control clockwise moves the syringe plunger into the syringe barrel, pushing
out the hydraulic fluid and injecting the contents of any attached micropipette. Conversely,
rotation of the controls counter-clockwise pulls the plunger out of the syringe barrel and
XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV. 4

.00 20100521( )
3
creates suction in the attached micropipette. One rotation of the coarse control is equivalent
to ten turns of the fine control.
CAUTION: THE CONTROLS SHOULD BE OPERATED INDEPENDENTLY;
OPERATING BOTH CONTROLS SIMULTANEOUSLY MAY DAMAGE THE UNIT.
1.2.5 Angle Adjustment
This knob is used to fix the microinjector at an angle appropriate for comfortable use.
1.3 Micropipette Holder
The micropipette holder is attached, via a length of tubing, to the tip of the syringe. The
default holder will grip a 1mm diameter capillary micropipette. The figure below shows the
micropipette holder disassembled.
Figure 1-3. Micropipette holder components.
XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV. 4

XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV. 4.00 (20100521)
4
(This page intentionally left blank.)

.00 20100521( )
5
2. ASSEMBLY AND INSTALLATION
2.1 Installation and Assembly
The following steps describe the installation and assembly of the XenoWorks™ Analog
Microinjector.
NOTE: The XenoWorks™ Analog Microinjector is designed so that it can be assembled
without the need for tools. Do not use tools to tighten pressure fittings.
1. Unpack the XenoWorks Analog Microinjector drive and place it on a firm flat surface.
Ensure that the black sliding block is at approximately ¾ of its travel from the back of
the injector (the control end).
2. At one end of the tubing, attach the clear Luer connector and the black nut, capturing the
clear ferrule in between, as shown below. Take care to ensure that the angle of the ferrule
is pointing in the correct direction.
Figure 2-1. Attaching the tubing to the injector.
3. Unpack the syringe and ensure the plunger is pushed all the way in.
NOTE: If you have decided to use the system with air (instead of hydraulic fluid), skip to
Step 8.
4. Dip the tip of the syringe into a bottle or dish of the chosen hydraulic fluid, and gently
draw the plunger out so that the barrel fills completely with hydraulic fluid. Take care
not to draw the plunger up too fast since the fluid may cavitate and form air bubbles.
5. Turn the syringe upright, so that the tip is pointing upwards and allow any air bubbles to
float to the top. Gently tap the syringe to facilitate this.
6. Connect the tubing to the tip of the syringe as shown Figure 2-2 and gently and slowly
push the plunger so that hydraulic fluid moves to the tip of the tubing.
XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV. 4

6
NOTE: The tubing length supplied contains approximately 450 microliters of fluid. If a
syringe with less than 500 microliters volume is being used, a concomitantly shorter piece
of tubing must be attached, otherwise the fluid cannot be pushed to the tubing tip. A
guide to syringe volumes and appropriate tubing lengths is shown in the table in Figure
2-2, please refer to the Troubleshooting section for more information.
Syringe Volume Maximum Tubing
Length
1000 μl 1930 mm
500 μl 965 mm
100 μl 178 mm
Figure 2-2. Connecting the tubing to the tip of the syringe.
8. Once the hydraulic fluid has been pushed to the very tip of the tubing, dip the tip of the
tubing into the bottle or dish of hydraulic fluid and very slowly draw more hydraulic fluid
into the tubing until the syringe is approximately ¾ full. Again, take particular care not
to cavitate the hydraulic fluid or draw up any air bubbles. It may be necessary to repeat
Steps 3 - 7 until all bubbles are purged from the syringe and tubing.
XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV. 4.00 20100521( )

.00 20100521( )
7
Figure 2-3. Drawing hydraulic fluid into the syringe.
9. Place the syringe into the Analog Microinjector drive, placing the end of the syringe
plunger in the sliding block. It may be necessary to use the microinjector’s coarse control
to reposition the moving block before the plunger will drop into place.
10. With one hand, hold the syringe clamp down on the syringe barrel and tighten the clamp
screw until the syringe barrel is held securely. Next, tighten the plunger clamp screw.
Take care to tighten the black syringe barrel clamp first before tightening the silver
plunger screw.
CAUTION: To avoid breaking the syringe, clamp only the smooth glass
area, and do not over-tighten the clamp screws.
11. Remove the free end of the tubing from the bottle or dish of hydraulic fluid (if used), wipe
it with a clean cloth and thread the tip of the tubing through the rear of the micropipette
holder and assemble the micropipette holder as shown below.
XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV. 4

XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV.
8
Figure 2-4. Assembling the pipette holder.
12. Adjust the tilt of the microinjector using the angle adjustment knob to achieve a
comfortable angle for working and place the unit on the bench top by the
micromanipulator.
Your XenoWorks Analog Microinjector is now set up and ready for use.
4.00 (20100521)

.00 20100521( )
9
3. OPERATING INSTRUCTIONS
3.1 General
Typically, the XenoWorks™ Analog Microinjector is used to vary slightly the pressure in the
tip of a glass micropipette, thus depositing or aspirating cells or cellular components. The
XenoWorks analog microinjector has been designed to work with a number of different
syringe volumes, with different tubing lengths and with different hydraulic fluids or simply
with air. In this way, the performance of the device can be precisely tuned to the application
for which it is used.
The microinjector can employ air, mineral oils or water as the hydraulic fluid, and syringe
volumes from 100 to 1000 microliters can be used. A 500 microliter syringe is supplied
standard with the device, but 100 and 1000 microliter models are available from Sutter
Instrument.
100 microliter – part number V001183
500 microliter – part number V001185
1000 microliter – part number V001186
The XenoWorks Analog Microinjector has two controls: coarse and fine. The coarse control
provides ten times the fluid displacement of the fine control. Turn the controls clockwise to
inject and counter-clockwise to aspirate.
3.2 Fitting a Micropipette
NOTE: If using air instead of a fluid in the microinjector, skip Step 1.
1. First, remove the clear chuck from the front of the micropipette, and turn the injector’s
coarse control clockwise to advance the hydraulic fluid to the end of the black aluminum
pressure fitting.
2. Replace the clear chuck, but do not tighten it yet.
3. Gently ease a micropipette whose maximum outer diameter does not exceed 1mm into the
chuck. The three black O-rings inside the chuck will create a little resistance, which can
be overcome by gently turning the micropipette holder body while simultaneously
pushing the micropipette in. Do not use excessive force. If the micropipette will not fit
snugly in the holder, the O-rings are either damaged or are obstructing the holder and
should be replaced.
4. The micropipette should be pushed into the chuck until the hard backstop is felt. At this
point, stop pushing and withdraw the micropipette 1 to 2 mm.
5. Gently tighten the chuck so that the O-rings are compressed, and form a seal around the
outer diameter of the micropipette.
CAUTION: Do not over-tighten the chuck, or damage
may occur to the O-rings.
6. Turn the coarse control clockwise until the air-fluid meniscus is at the desired point in
the micropipette.
7. The newly fitted micropipette and holder can now be attached to the micromanipulator in
readiness for microinjection.
XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV. 4

XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV.
10
4.00 (20100521)
(This page intentionally left blank.)

.00 20100521( )
11
4. MAINTENANCE
4.1 Fitting New O-rings
Routine use will create wear on the three black O-rings located in the tip of the micropipette
holder chuck. Occasionally, the O-rings will need to be replaced. To do this, gently remove
the old O-rings with an appropriate tool (a bent paper clip, for example). Discard the old O-
rings and insert three new ones, taking care to ensure that they are flat against the back of
the chuck. The new O-rings can be pushed down inside the chuck by gently screwing the
chuck onto the knurled black aluminum pressure fitting. Take care not to damage the chuck
during this procedure.
4.2 Troubleshooting
Problem Cause Solution
1. The black O-rings in the
chuck are damaged.
Replace the O-rings.
2. There is an air bubble in the
hydraulic fluid.
Refill the system with
hydraulic fluid, taking care not
to introduce air bubbles.
There is poor control by the
injector of the material in the
micropipette.
3. The syringe plunger clamp
or barrel clamp is not tight.
Tighten the appropriate clamp
screws
When drawing hydraulic fluid
into the syringe (without
tubing attached), air bubbles
are forming inside the syringe
plunger.
When filling the syringe for the
first time, a little air is trapped
inside the tip of the syringe,
which is drawn into the barrel
when the plunger is pulled
back.
Slowly draw hydraulic fluid
into the barrel, then
immediately and rapidly expel
it back into the container.
Repeat this until a full barrel
of hydraulic fluid can be drawn
without drawing air bubbles.
XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV. 4

XENOWORKS ANALOG MICROINJECTOR OPERATION MANUAL – REV.
12
4.00 (20100521)
(This page intentionally left blank.)
