Suunto EON CORE 2.0 User manual

SUUNTO EON CORE 2.0
USER GUIDE
2020-04-14

1. Safety................................................................................................................................................................5
2. Getting started.............................................................................................................................................. 9
2.1. Set up................................................................................................................................................... 9
2.2. Display - modes, views, and states............................................................................................. 9
2.3. Icons...................................................................................................................................................10
2.4. Product compatibility...................................................................................................................... 11
3. Features.........................................................................................................................................................12
3.1. Alarms, warnings, and notifications............................................................................................ 12
3.2. Algorithm lock..................................................................................................................................14
3.3. Altitude diving..................................................................................................................................14
3.4. Ascent rate....................................................................................................................................... 15
3.5. Battery............................................................................................................................................... 15
3.6. Bookmark..........................................................................................................................................16
3.7. Clock...................................................................................................................................................16
3.8. Compass........................................................................................................................................... 16
3.8.1. Calibrating compass........................................................................................................... 16
3.8.2. Setting declination..............................................................................................................17
3.8.3. Locking the bearing........................................................................................................... 17
3.9. Customize dive modes with DM5...............................................................................................18
3.10. Decompression algorithm...........................................................................................................19
3.10.1. Diver safety.........................................................................................................................20
3.10.2. Oxygen exposure............................................................................................................ 20
3.11. Decompression dives.................................................................................................................. 20
3.11.1. Last stop depth................................................................................................................... 23
3.12. Deco profile................................................................................................................................... 23
3.13. Device info..................................................................................................................................... 25
3.14. Display.............................................................................................................................................25
3.15. Dive history.................................................................................................................................... 25
3.16. Dive modes....................................................................................................................................25
3.16.1. Air / nitrox mode................................................................................................................26
3.16.2. Gauge mode......................................................................................................................27
3.17. Dive planner................................................................................................................................... 28
3.18. Flip display..................................................................................................................................... 28
3.19. Gas consumption..........................................................................................................................28
3.20. Gas mixtures.................................................................................................................................29
3.21. Gas time..........................................................................................................................................30
3.22. Language and unit system....................................................................................................... 30
3.23. Logbook.........................................................................................................................................30
3.24. Multi-gas diving.............................................................................................................................31
3.24.1. Modifying gases during a dive.......................................................................................31
Suunto EON Core
2

3.24.2. Isobaric counterdiusion (ICD).................................................................................... 32
3.25. Oxygen calculations................................................................................................................... 33
3.26. Personal adjustments.................................................................................................................33
3.27. Rebreather diving.........................................................................................................................34
3.27.1. Closed-circuit gases.........................................................................................................35
3.27.2. Open-circuit gases.......................................................................................................... 35
3.27.3. Setpoints............................................................................................................................ 35
3.27.4. Bailouts...............................................................................................................................36
3.28. Safety stops and deepstops.....................................................................................................37
3.29. Sample rate...................................................................................................................................38
3.30. Standby and deep sleep........................................................................................................... 38
3.31. Surface and no-fly time...............................................................................................................38
3.32. Suunto app....................................................................................................................................39
3.33. Suunto DM5..................................................................................................................................40
3.33.1. Synchronizing logs and settings.................................................................................. 40
3.33.2. Updating firmware.......................................................................................................... 40
3.34. SuuntoLink.................................................................................................................................... 40
3.35. Tank pressure ...............................................................................................................................41
3.36. Timer................................................................................................................................................41
3.37. Water contacts............................................................................................................................... 41
4. Use.................................................................................................................................................................43
4.1. How to access device info........................................................................................................... 43
4.2. How to change display brightness............................................................................................43
4.3. How to set language and unit.................................................................................................... 43
4.4. How to set time and date.............................................................................................................44
4.5. How to install and pair a Suunto Tank POD............................................................................44
4.6. How to plan a dive using the Dive planner.............................................................................46
4.7. How to customize dive modes with DM5.................................................................................47
4.8. How to enable gas consumption metering............................................................................ 49
4.9. How to add bookmarks................................................................................................................49
5. Care and support.......................................................................................................................................50
5.1. Handling guidelines.......................................................................................................................50
5.2. Installing scratch guard................................................................................................................50
5.3. Changing strap to bungee........................................................................................................... 51
5.4. Charging battery............................................................................................................................. 51
5.5. Getting support.............................................................................................................................. 52
5.6. Disposal and recycling.................................................................................................................52
6. Reference.....................................................................................................................................................53
6.1. Technical specifications................................................................................................................ 53
6.2. Compliance..................................................................................................................................... 55
Suunto EON Core
3

6.3. Trademark........................................................................................................................................55
6.4. Patent notice...................................................................................................................................55
6.5. International Limited Warranty................................................................................................... 56
6.6. Copyright......................................................................................................................................... 57
6.7. Dive terms........................................................................................................................................ 57
Suunto EON Core
4

1. Safety
Types of safety precautions
WARNING: - is used in connection with a procedure or situation that may result in
serious injury or death.
CAUTION: - is used in connection with a procedure or situation that will result in
damage to the product.
NOTE: - is used to emphasize important information.
TIP: - is used for extra tips on how to utilize the features and functions of the device.
WARNING: all computers experience failures. It is possible that this device may suddenly
fail to provide accurate information during your dive. Always use a backup dive device and
only dive with a buddy. Only divers trained in proper use of diving equipment should use this
dive device! YOU MUST READ the leaflet and user guide for your dive computer before use.
Failure to do so may lead to improper use, serious injury or death.
NOTE: Make sure your Suunto dive computer always has the latest software with
updates and improvements. Check before every dive trip from www.suunto.com/support, if
Suunto has released a new software update to your device. When it is available, you must
install it before diving. Updates are made available to improve your user experience and are
part of Suunto´s philosophy of continuous product development and improvement.
Before you dive
Make sure that you fully understand the use, displays and limitations of your dive instruments.
If you have any questions about this manual or dive instrument, contact your Suunto dealer
before diving. Always remember that YOU ARE RESPONSIBLE FOR YOUR OWN SAFETY!
Before leaving on a dive trip, inspect your dive computer thoroughly to make sure everything
is functioning properly.
At the dive site, perform your manual pre-checks on each device before entering the water.
Dive Computer Pre-check
Ensure that:
1. Suunto EON Core is in the correct dive mode and the display is working as expected.
2. Altitude setting is correct.
3. Personal setting is correct.
4. Deep stops are set correctly.
5. Unit system is correct.
6. Compass is calibrated. Start the calibration manually in the menu under General »
Compass » Calibrate to also confirm that the dive computer audible sounds are working.
After successful calibration, you should hear a sound.
7. The battery is fully charged.
Suunto EON Core
5

8. All primary and backup gauges for time, pressure and depth, both digital and mechanical,
are showing correct, consistent readings.
9. If Suunto Tank PODs are in use, check that Suunto Tank POD is properly installed and the
tank valve is open. Please see the Suunto Tank POD User Guide for detailed information
and proper use.
10. If Suunto Tank PODs are in use, check that connections are working and gas selections
are correct.
NOTE: For Suunto Tank POD related information please see the instructions provided
with the product.
Safety precautions
WARNING: ONLY TRAINED DIVERS SHOULD USE A DIVE COMPUTER! Insucient
training for any kind of diving, including freediving, may cause a diver to commit errors, such
as incorrect use of gas mixtures or improper decompression, that may lead to serious injury
or death.
WARNING: You must read the printed quick guide and online user guide for your dive
computer. Failure to do so may lead to improper use, serious injury or death.
WARNING: THERE IS ALWAYS A RISK OF DECOMPRESSION SICKNESS (DCS) FOR ANY
DIVE PROFILE EVEN IF YOU FOLLOW THE DIVE PLAN PRESCRIBED BY DIVE TABLES OR A
DIVE COMPUTER. NO PROCEDURE, DIVE COMPUTER OR DIVE TABLE WILL PREVENT THE
POSSIBILITY OF DCS OR OXYGEN TOXICITY! An individual’s physiological makeup can vary
from day to day. The dive computer cannot account for these variations. You are strongly
advised to remain well within the exposure limits provided by the instrument to minimize the
risk of DCS. As an added measure of safety, you should consult a physician regarding your
fitness before diving.
WARNING: YOU ARE ADVISED TO AVOID FLYING ANY TIME THE COMPUTER COUNTS
DOWN THE NO-FLY TIME. ALWAYS ACTIVATE THE COMPUTER TO CHECK THE REMAINING
NO-FLY TIME PRIOR TO FLYING! Flying or traveling to a higher altitude within the no-fly time
can greatly increase the risk of DCS. Review the recommendations given by Divers Alert
Network (DAN). There can never be a flying-after-diving rule that is guaranteed to completely
prevent decompression sickness!
WARNING: If you have a pacemaker, we recommend you do not scuba dive. Scuba
diving creates physical stresses on the body which may not be suitable for pacemakers.
WARNING: If you have a pacemaker, consult a doctor before using this device. The
inductive frequency used by the device may interfere with pacemakers.
WARNING: Allergic reactions or skin irritations may occur when product is in contact with
skin, even though our products comply with industry standards. In such event, stop use
immediately and consult a doctor.
Suunto EON Core
6

WARNING: Not for professional use! Suunto dive computers are intended for recreational
use only. The demands of commercial or professional diving may expose the diver to depths
and conditions that tend to increase the risk of decompression sickness (DCS). Therefore,
Suunto strongly recommends that the device not be used for any commercial or professional
diving activities.
WARNING: USE BACKUP INSTRUMENTS! Ensure that you use backup instrumentation,
including a depth gauge, submersible pressure gauge, timer or watch, and have access to
decompression tables whenever diving with a dive computer.
WARNING: For safety reasons, you should never dive alone. Dive with a designated
buddy. You should also stay with others for an extended time after a dive as the onset of
possible DCS may be delayed or triggered by surface activities.
WARNING: PERFORM PRE-CHECKS! Always check that your dive computer is functioning
properly and has the correct settings before diving. Check that the display is working, the
battery level is OK, tank pressure is correct, and so forth.
WARNING: Check your dive computer regularly during a dive. If you believe or conclude
that there is any problem with any computer function, abort the dive immediately and safely
return to the surface. Call Suunto Customer Support and return your computer to an
authorized Suunto Service Center for inspection.
WARNING: THE DIVE COMPUTER SHOULD NEVER BE TRADED OR SHARED BETWEEN
USERS WHILE IT IS IN OPERATION! Its information will not apply to someone who has not
been wearing it throughout a dive, or sequence of repetitive dives. Its dive profiles must
match that of the user. If it is left on the surface during any dive, the dive computer will give
inaccurate information for subsequent dives. No dive computer can take into account dives
made without the computer. Thus, any diving activity up to four days prior to initial use of the
computer may cause misleading information and must be avoided.
WARNING: DO NOT EXPOSE ANY PART OF YOUR DIVE COMPUTER TO ANY GAS MIX
CONTAINING MORE THAN 40% OXYGEN! Enriched air with greater oxygen content presents
a risk of fire or explosion and serious injury or death.
WARNING: DO NOT DIVE WITH A GAS IF YOU HAVE NOT PERSONALLY VERIFIED ITS
CONTENTS AND ENTERED THE ANALYZED VALUE INTO YOUR DIVE COMPUTER! Failure to
verify tank contents and enter the appropriate gas values where applicable into your dive
computer will result in incorrect dive planning information.
WARNING: Using a dive planner software such as in Suunto DM5 is not a substitute for
proper dive training. Diving with mixed gases has dangers that are not familiar to divers
diving with air. To dive with Triox, Heliox and Nitrox or all of them, divers must have
specialized training for the type of diving they are doing.
WARNING: Do not use Suunto USB Cable in areas where flammable gases are present.
Doing so may cause an explosion.
Suunto EON Core
7

WARNING: Do not disassemble or remodel Suunto USB Cable in any way. Doing so may
cause an electric shock or fire.
WARNING: Do not use Suunto USB cable if cable or parts are damaged.
WARNING: You must only charge your device using USB adapters that comply with the
IEC 60950-1 standard for limited power supply. Non-compliant adapters are a fire hazard and
a risk to personal injury and might damage your Suunto device.
CAUTION: DO NOT allow the connector pins of the USB cable to touch any conductive
surface. This may short circuit the cable, making it unusable.
Emergency ascents
In the unlikely event that the dive computer malfunctions during a dive, follow the emergency
procedures provided by your certified dive training agency to immediately and safely ascend.
Suunto EON Core
8

2. Getting started
2.1. Set up
To get the most out of your Suunto EON Core, use some time to customize features and
displays. Make absolutely sure that you know your computer and have it set up as you want
before getting into the water.
To get started:
1. Wake up the device by connecting the USB cable to PC/Mac.
2. Follow the startup wizard to set up the device. When ready, the device goes to surface
state.
3. Fully charge before first dive.
The startup wizard guides you through:
•Language
•Units
•Time format (12h/24h)
•Date format (dd.mm / mm.dd)
•Connecting with Suunto app (optional)
2.2. Display - modes, views, and states
Your Suunto EON Core has three buttons that have dierent functions in dierent views. Short
pressing or long pressing them gets you to dierent functionalities.
Suunto EON Core
9

By default Suunto EON Core has two main dive modes: Air / Nitrox and Gauge.
Press and hold the middle button to enter Main menu and select the appropriate mode for
your dive under Dive settings » Mode.
Suunto EON Core automatically restarts to change mode.
Suunto EON Core has two main views: time/no deco and compass. Change the main view by
pressing the middle button.
More views are available through customization in DM5. See 4.7. How to customize dive
modes with DM5.
For more detailed information on the views availabe in the dierent modes, see 3.16. Dive
modes.
Suunto EON Core automatically switches between surface and dive state. If you are more
than 1.2 m (4 ft) below the water level and the water contact is on, the dive state is activated.
When tank pressure screen is in use, you see the following information:
•Present depth is 19.0 m
•Dive time is 22 minutes
•Tank pressure left is 125 bar
•No decompression time is 50 minutes
•Safety stop is ahead at 3.0 meters
•16 hours of diving time left before need to recharge
•Temperature is 21°C
The switch window in the bottom right corner has diferrent information that can be changed
by short pressing the lower button.
2.3. Icons
Suunto EON Core uses the following icons:
No-fly time
Surface (interval) time
Suunto EON Core
10
