SVBONY SV605MC User manual

SV605MC
User Manual
EN
DE
FR
IT
ES
JP
RU

To Customers
Hello, friends! You can download SV605MC User Manual pdf file or print
this file. SVBONY has the rights to modify this document without prior
notice. Please download the latest version User Manual, Driver and
Software from our official website www.svbony.com.
Thanks for purchasing your new SVBONY astronomy camera! This manual
will give you a brief introduction of the SV605MC camera. Please read this
manual completely before using it. If you have any questions, please feel
free to contact us:
Facebook: www.facebook.com/svbony
Email Address: [e-mail]

Contents
---------------------------------------------------------------------------01
----------------------------------------------------------------01
------------------------------------------------------------02
---------------------------------------------------------------------------06
------------------------------------------------------------------07
-------------------------------------------------------------------------------09
-----------------------------------------------------------09
-------------------------------------------------------------------10
-----------------------------------------------------------------------------11
---------------------------------------------------------------------------79
Package List
Camera Appearance
How to Use the Camera
Specification
Performance Chart
Structure
Store and General Clean
Quality Assurance
WARNINGS
GUARANTEE
DE(12-23)
FR(24-34)
IT(35-45)
ES(46-56)
JP(57-67)
RU(68-78)

1. Package List
2. Camera Appearance
Supply Unit×1 Camera Bag×1 SV605MC Camera×1 User Manual×1
2 inch Cover×1 T2 Adapter×1 M42-M48 Ring×1 T2-1.25 inch Adapter×1
M42M-M42F-21L×1 M42M-M48F-16.5L×1 1.25-inch T-Adapter×1 USB3.0 Data Cable×1
USB3.0 Data Interface
Cooling
Fan
Refrigeration
power
Interface
Drying
Chamber
Radiator
01

3. How to Use the Camera
3.1 Driver Installation
For Windows system users
3.1.1 Download the latest SVBONY Driver from official website www.svbony.com
SUPPORT-- Software & Driver--Windows--Svbony cameras
3.1.2 Unzip the file, and install the Svbony Driver to the computer.
3.1.3 Check the Driver installed successfully
02

3.2 Image Software Installation
For Sharpcap Users
3.2.1, Download the Sharpcap software from official website: www.sharpcap.co.uk.
Remember if your computer run 64 bit system, then download the 64 bit Sharpcap.
Or the 32 bit sharpcap is ok.
3.2.2, Install Sharpcap sofftware to your computer.
3.3 Equipment
The SV605MC camera works with filters, telescopes and camera lens via adapters.
Most adapters are already included. Other adapters you can purchase directly from
svbony website.
3.3.1 Connecting 1.25 inch telescope
3.3.2 Connecting 2 inch telescope
3.3.3 Connecting the filter wheel and telescope
03

3.4 Connect with software
Using Sharpcap，Login Sharpcap software, Click the CAMERAS button, and choose
the SV605MC camera, If the Native Driver installed without any problems, you will
see the image on the screen, and the frame rates. Like showing in the following
image：The camera works
Note:
• If the sharpcap can't recognize the camera, please check if the camera recognized
by the computer in the device manager.
• The introductory operation guide of sharpcap can be viewed in the "Help" option of
the software. At the same time, there is a PDF file download under "Documents" on
the homepage of sharpcap's official website, which can be downloaded and studied.
04

For N.I.N.A. Users
Log in N.I.N.A. —Nighttime Imaging ‘N’ Astronomy software. Connect via svbony
native driver.
Turn on the refrigerator to set the temperature.
Set the exposure time to capture the image.
05

4. Specification
Model Number
Sensor Size
Diagonal
Image Size
Resolution
Total Pixels
Maximum Frame Rate
Pixel Size
Shutter Type
Exposure
Readout Noise
QE
Full Well
ADC
Digital Noise Reduction
Temperature Display
Cooling System
Format
ROI
Pixel Binning
Protective Window Optical
Glass
Back Intercept
Support Operating System
Working Temperature
Storage Temperature
Working Humidity
Storage Humidity
Working Current
Stand-by Current
SV605MC DSO Mono Camera
1 inch CMOS
15.968mm
15.469mm(H) x16.375mm(V)
3003*3003
9MP
20FPS
3.76μm(H) x 3.76μm(V)
Rolling Shutter
32ms-2000S
1.0-3.3e-
91%
50Ke-
14bit
Support
Display on software
TEC Semiconductor 2-Stage Refrigeration
Mono8/Mono16
Support
BIN1,BIN2,BIN3,BIN4
AR Coating
6.5/17.5mm
Windows，Linux，Mac OS，Chrome OS，
Raspberry Pi OS
-10°---+50°
-20°---+60°
20% RH-80% RH
20% RH-95% RH
＜300MA
＜30MA
06

5. Performance Chart
5.1 QE & Readout Noise
QE curve and readout noise are the most important parameters to measure camera
performance. Higher QE and lower readout noise are necessary conditions to
improve the image signal-to-noise ratio.
Readout noise includes pixel noise, circuit noise, and ADC quantization noise. The
lower readout noise, the better. As shown in the figure, the readout noise of the
SV605MC is very low compared with conventional CCD cameras. Built-in HCG
mode, which can effectively reduce readout noise at high gain, so that the camera
maintains the same wide dynamic range as at low gain. When the gain is 100, the
HCG mode is automatically turned on, the readout noise is as low as 1.2e, and the
dynamic range can still reach a level close to 14bit. The parameter settings are also
different depending on your shooting target. Turn down the gain, the dynamic range
will become larger, suitable for long exposures. Increase the gain, the readout noise
will be further reduced, which is suitable for short exposure or lucky imaging.
5.2 Power Consumption
The SV605MC camera is a low-power camera. When the camera is powered by a
USB cable, the maximum power consumption is 1.85W. But for cooling function, you
need to use a 12V@5A power adapter (D5.5*2. lmm, center positive), or you can use
a lithium battery (supports a wide range of 11V to 15V). The picture below is the
cooling efficiency diagram of our freezer camera. A cooling temperature difference of
30 degrees only requires a current of 0.5A.
07

5.3 TEC Cooling System
The TEC cooling system of the SV605MC camera can precisely control the
temperature of the sensor. Different from the traditional CCD, the SV605MC camera
has ultra-low readout noise, efficient cooling and adjustable gain. It is no longer
necessary to use ultra-long exposures to capture targets, which greatly reduces the
requirements for the camera system and guide star system. However, if short
exposures are used (e.g. less than 100ms), cooling has little effect on the image. The
cooling system can be set to a minimum of 35~40°C below the ambient temperature
(Tested based on ambient temperature of 30°C). Please note that the maximum
temperature difference may fluctuate after pro-longed use. Meanwhile, when the
ambient temperature decreases, the cooling temperature difference will also
decrease accordingly. The figure below is the dark current curve of the SV605MC
sensor between -20°C and 35°C.
5.4 AR Coating Filter
The SV605MC camera sensor is equipped with a protective window and uses an AR
coated filter.
08

6. Structure
7. Store and General Clean
Protect the Refrigerator
Thermal shock should be avoided when using the camera. The so-called thermal
shock refers to the internal strong stress that the refrigerator has to bear due to the
principle of thermal expansion and contraction when the temperature of the
refrigerator suddenly rises or falls. Severe thermal shock can shorten the life of the
cooler or even damage it completely. Therefore, when you start using the cooler to
adjust the temperature of the CMOS, you should avoid turning on the cooler to
maximum power at once. Instead, the power of the cooler should be gradually
increased. Before disconnecting the power supply, if the power of the cooler is
relatively high, the power of the cooler should be gradually reduced, and then
disconnect the power supply.
Cleaning of CMOS Sensors and Optical Window
If you find dust on the CMOS sensor, you can remove the front half of the camera.
Then use the cleaning kit for DSLR camera sensors to clean the CMOS sensor. You
must be careful when cleaning it. You can also use a DSLR cleaning tool or lens
tissue to clean it. Be careful not to use too much force, because the coating of the
CMOS sensor is very fragile and can be scratched
easily. The general identification of whether the dust is on the sensor or on the
window glass is as follows.
09

Dry Camera CMOS Chamber
The CMOS sensor is located in the CMOS chamber. There is a hole on the side of
the front of the camera. If moisture in the CMOS chamber fogs the sensor glass, you
can dry it by connecting a silicone tube through this hole. Please put an effective
silica gel desiccant in the silica gel stick and make sure that there is cotton inside to
prevent silica gel from entering the CMOS chamber.
8. Quality Assurance
The SV605MC camera warranty time is one year. Within warranty period, if the
camera fails to function, we will provide free after-sales maintenance service.
Besides the warranty days, we provide life-long maintenance services and charge
only the parts that need repair or replacement. The buyer will pay for the postage of
returning camera to factory to be repaired. Within the warranty period, if the following
condition occurs, certain maintenance costs will be charged.
• The malfunction and damaged caused by incorrect use, the unauthorized repairs
and alteration.
• The damage caused by fire, flood, earthquake, other natural disasters and
secondary product damage.
• The product malfunction caused by the fall and transportation failures after
purchase.
• The malfunction and damaged caused by the other barriers (man-made factors or
external device).
• Purchase without the warranty card and purchase invoices.
10

Before using this device, read this guide which
contains important operating instructions for safe
usage and control for compliance with applicable
standards and regulations.
FCC Requirements:
• Products authorized under Part 15 using SDoC or Certification require a
label containing one of the following compliance statements
• This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
CE Requirements:
• Disposal
The crossed-out wheeled-bin symbol on your product, literature, or packaging
reminds you that in the European Union, all electrical and electronic products,
batteries, and accumulators (rechargeable batteries) must be taken to
designated collection locations at the end of their working life. Do not dispose
of these products as unsorted municipal waste. Dispose of them according to
the laws in your area.
IC Requirements:
CAN ICES-3(B)/NMB-3(B)
Avoid Choking Hazard
Approved Accessories
(1)Receivers associated with licensed device service operaions:
This device complies with part 15 of the FCC Rules. Operation is
subject to the condition that this device does not cause harmful
interference.
(2)Stand-alone cable input selector switch:
This device complies with part 15 of the FCC Rules for use with
cable television service.
(3)All other devices:
• (Simple EU declaration of conformity) Hong Kong Svbony
Technology Co.,Ltd declares that the equipment type is in
compliance with the essential requirements and other relevant
provisions of RED Directive 2014/30/EU and the ROHS Directive
2011/65/EU and the WEEE Directive 2012/19/EU; the full text of
the EU declaration of conformity is available at the following
internet address: www.svbony.com.
Small Parts. Not for children under 3 years.
• This device meets the regulatory standards when used with the
Svbony accessories supplied or designated for the product.
• For a list of Svbony-approved accessories for your item, visit
the following website: http://www.Svbony.com.
WARNING
11

1. Liste der Pakete
2. Kamera-Erscheinungsbild
Supply Unit×1 Camera Bag×1 SV605MC Camera×1 User Manual×1
2 inch Cover×1 T2 Adapter×1 M42-M48 Ring×1 T2-1.25 inch Adapter×1
M42M-M42F-21L×1 M42M-M48F-16.5L×1 1.25-inch T-Adapter×1 USB3.0 Data Cable×1
USB3.0 Data Interface
Cooling
Fan
Refrigeration
power
Interface
Drying
Chamber
Radiator
12

3. Wie man die Kamera benutzt
3.1 Treiberinstallation
Für Windows-Systembenutzer
3.1.1 Laden Sie die neuesten SVBONY Treiber von der offiziellen Website
www.svbony.com
SUPPORT-- Software & Driver--Windows--Svbony cameras
3.1.2 Entpacken Sie die Datei und installieren Sie den Svbony-Treiber auf Ihrem
Computer.
3.1.3 Prüfen Sie, ob die Treiberinstallation erfolgreich war
13

3.2 Installation der Image-Software
Für Sharpcap Benutzer
3.2.1 Download der Sharpcap-Software von der offiziellen Website www.Sharpcap.-
co.uk Denken Sie daran, 64-Bit-Sharpcap herunterzuladen, wenn auf Ihrem
Computer ein 64-Bit-System ausgeführt wird Oder 32-Bit-sharpcap kann auch
3.2.2 Installieren Sie die Sharpcap Software auf Ihrem Computer
3.3 Ausrüstungen
SV 605 MC Kamera über Adapter in Verbindung mit Filterteleskop und Kameraobjek-
tiv Die meisten Adapter sind bereits im Lieferumfang enthalten Andere Adapter
können direkt von der svbony Website gekauft werden
3.3.1 Anschluss an ein 1,25 Zoll Teleskop
3.3.2 Anschluss eines 2-Zoll-Teleskops
3.3.3 Verbinden Sie das Filterrad mit dem Teleskop
14

3.4 Verbindung mit der Software
Melden Sie sich mit Sharpcap in der Sharpcap Software an Klicken Sie auf den
Kamera-Button und wählen Sie die SV 605 MC-Kamera aus. Wenn der native
Treiber ohne Probleme installiert ist, sehen Sie das Bild auf dem Bildschirm sowie die
Bildrate. Die Kamera funktioniert einwandfrei, wie im folgenden Bild zu sehen ist
Hinweis:
• Wenn sharpcap die Kamera nicht erkennt, überprüfen Sie im Geräte-Manager, ob
der Computer die Kamera erkennt
• Eine einführende Bedienungsanleitung für sharpcap finden Sie in den
Hilfeoptionen der Software Zur gleichen Zeit gibt es eine PDF-Datei zum
Herunterladen auf der Startseite der offiziellen sharpcap-Website, die zum Lernen
heruntergeladen werden kann
15

Für N.I.N.A. Benutzer
Anmelden N.I.N.A. —Nighttime Imaging 'N' Astronomy-Software. Verbinden Sie sich
über den nativen svbony-Treiber.
Schalten Sie den Kühlschrank ein, um die Temperatur einzustellen.
Stellen Sie die Belichtungszeit ein, um das Bild aufzunehmen
16

4. Spezifikation
Modell
Größe des Sensors
Diagonale
Größe des Bildes
Die Lösung
Gesamtzahl der Pixel
Maximale Bildrate
Größe der Pixel
Shutter
Belichtung
Auslesen von Rauschen
Quantitative Lockerung
The Full Well
ADC
Digitale Rauschunterdrückung
Anzeige der Temperatur
Kühlsystem
Das Format
Return on Investment
Pixel Bining
Schutzfenster optisches Glas
Umgekehrter Schnittpunkt
Unterstützte Betriebssys-
teme
Betriebstemperatur
Lagertemperatur
Luftfeuchtigkeit bei der Arbeit
Luftfeuchtigkeit der Lagerung
Betriebsstrom
Backup-Strom
SV 605 MC DSO Monokamera
1 Zoll CMOS
15.968mm
15.469mm(H) x16.375mm(V)
3003*3003
9MP
20FPS
3.76μm(H) x 3.76μm(V)
Die Rolltore
32ms-2000S
1.0-3.3e-
91%
50Ke-
14bit
unterstützt
Anzeige auf der Software
TEC Semiconductor Level 2 Kühlung
Mono8/Mono16
unterstützt
BIN1,BIN2,BIN3,BIN4
AR-Beschichtung
6.5/17.5mm
Windows，Linux，Mac OS，
Chrome OS，Raspberry Pi OS
-10°---+50°
-20°---+60°
20% RH-80% RH
20% RH-95% RH
＜300MA
＜30MA
17
