SWAGTRON EB7 Elite Plus User manual

USER MANUAL
In order to continue serving our customers and providing the best products, our product information including our user manuals
may receive updates from time to time. Please check our website for the latest user manuals and product materials.
Ver. 1.0 7/24/19
Scan here to
download the
user manual

1ENGLISHSWAGTRON EB7 Elite Plus
PRODUCT SAFETY NOTICE
The SWAGTRON EB7 Elite Plus eBike has been designed with plenty of safeguards in place for its riders. Extra precautions have
been taken to protect the user from hardware malfunctions through our meticulous design and engineering.
Like any mode of transportation, however, the SWAGTRON EB7 Elite Plus has inherent hazards associated with its use (e.g., losing
control, falling off, or riding into hazardous situations). Be sure to read and follow all instructions and safety recommendations in
this user manual prior to and when riding your eBike.
Before each ride, especially before and after traveling long distances, inspect your bike. Check the tires for proper ination and
cracks on the tire walls. Keeping the tires properly inated and maintained will help prevent ats and maximize performance.
Second, check all cables and cable housings for fraying, breaks, rust, or corrosion and replace if necessary. Lastly, inspect the
brakes to make sure they are working properly. Additionally, check the brake pads for any damage as they will wear over time and
eventually need replacement.
If a replacement of the brake pads or any other part is needed, please contact customer support for replacement service. In
general, it is recommended to make sure all nuts and bolts are taut and properly fastened to prevent injury and unnecessary wear
and tear on your eBike.
Max. Rider Capacity 264 lb. / 120 kg
Max. Speed (Throttle-Only) 18.6 mph / 29.9 km/h
Range per Charge (throttle-only) Up to 19 mi / 30.6 km (mode 1)
Max. Incline (Throttle-Only) 25° (throttle only)
This device requires coordination, agility and balance. Use your best judgment to determine if an individual can use the
SWAGTRON EB7 Elite Plus eBike safely.

2
ENGLISH SWAGTRON EB7 Elite Plus
SAFETY GEAR, CLOTHING, AND FOOTWEAR Please wear appropriate clothing and safety gear including
shoes, kneepads, elbow pads and an ASTM F1492 approved
helmet.
Avoid wearing anything that can drape over or get caught
into/under the wheels. Wear closed-toe, at shoes to maintain
exibility and stability.
MODIFICATIONS AND REPAIRS The SWAGTRON EB7 Elite Plus is a highly sophisticated
electronics product that includes complex, technical circuitry.
Attempting to repair or modify your can void all warranties. Only
authorized repair centers may service the EB7 Elite Plus.
OBEY LOCAL LAWS AND REGULATIONS Always check and adhere to local laws regarding personal
transportation devices, including pedestrian laws.
The eBike is considered a motor vehicle and should not be
ridden after consuming alcohol or drugs.
By riding the SWAGTRON EB7 Elite Plus eBike, the user acknowledges and accepts personal responsibility of all risks
associated with the use of the SWAGTRON EB7 Elite Plus eBike, which may include, but are not limited to, muscle injuries,
broken bones, lacerations, or serious injury that may be sustained while using the SWAGTRON EB7 Elite Plus eBike.

3ENGLISHSWAGTRON EB7 Elite Plus
Section 1. General Information
Before operating your eBike, please read all instructions. This manual will guide you through the functions, usage, and proper care
of your EB7 Elite Plus. If you have any questions or cannot nd the information you need in the manual, please contact your place
of purchase or our customer service at 1-844-299-0625. Before contacting customer service, please have your purchase information
ready as this may be needed during the call.
When reading this manual, note these icons:
Notes with this icon MUST be read, understood, and obeyed to prevent injury or damage.
Notes with this icon include relevant information.
1.1 About the SWAGTRON EB7 Elite Plus
The EB7 Elite Plus is a compact, zero-emissions, personal
transportation device that feels like a bike but rides like a
moped! It's environmentally-friendly and built with premium-
grade components using industry-leading manufacturing
processes.
• Eco-friendly with zero emissions
• Folds at the frame, stem and pedals
• Offers powered speeds up to 18.6 mph
• Rechargeable, portable and durable

4
ENGLISH SWAGTRON EB7 Elite Plus
1.2 What’s In the Box?
• 1 x SWAGTRON EB7 Elite Plus eBike
• 1 x Charging Cable & Adapter
• 2 x Keys
• 1 x User Manual
User Manual x 1Keys x 2
Charging Cable & Adapter x 1SWAGTRON EB7 Elite Plus Electric Bike
x 1
USER MANUAL
In order to continue serving our customers and providing the best products, our product information including our user manuals
may receive updates from time to time. Please check our website for the latest user manuals and product materials.
Ver.1.0 7/24/19
Scan her e to
downloa d the
user manual

5ENGLISHSWAGTRON EB7 Elite Plus
1.3 Product Overview
FRONT WHEEL
KICKSTAND
PEDAL
CHARGING PORT
MOTORIZED HUB
REAR WHEEL
SEAT CLAMP
STAND
SUSPENSION
SEAT
FRONT BRAKE
GEAR SWITCH
GEAR BUTTON
HANDLE CLAMP
STEM
THROTTLE
HORN
DISPLAY
REAR BRAKE
HEADLIGHT
LATCH BOLT
LATCH

6
ENGLISH SWAGTRON EB7 Elite Plus
Section 2. Assembling the Handlebar
Step 1. Pull the stem upright ( 1).
Step 2. Fold the latch up to close it. It will snap into place.
Step 3. Unmount the clamp on top of the stem ( 2), and put the handlebar onto the top of stem, then re-install the
clamp to x the handlebar onto the stem ( 3).
123

7ENGLISHSWAGTRON EB7 Elite Plus
Section 3. Handling Your eBike
3.1 Folding & Unfolding the Head
Be careful not to position your ngers between the latch and the stem. Doing so may result in injury.
To Unfold ( 4& 5):
Step 4. Pull the handlebar stem upright.
Step 5. Fold the latch up to close it. It will snap into place.
To Fold ( 6& 7):
Step 1. Locate the silver bolt in the side of the latch and pull
it up.
Step 2. While holding the bolt up, use your other hand to
unfold the latch by pulling it down away from the
stem. There is a notch on the other side of the latch
to make this easier.
Step 3. With the latch undone, fold the stem down.
45
Silver bolt
67

8
ENGLISH SWAGTRON EB7 Elite Plus
3.2 Folding & Unfolding the Frame
To Unfold the Frame
Unfold the rear wheel / section and keep your eBike upright with the kickstand. While holding
the latch lock up, push the latch closed. Make sure the hook end of the latch is secure and let
the latch lock turn down into the latch to lock everything in place. ( 8).
To Fold the Frame
While holding the latch lock up, use your other hand to open the latch by pulling it away from
the frame ( 8). Fold the rear wheel / section towards the other wheel and use the stand under
the frame as needed.
3.3 Adjusting the Handlebars
Unfold the clamp, then rotate and adjust the direction of the handlebars to a comfortable position ( 9). Secure the handlebars by
ipping the clamp closed (10).
8
Latch Latch Lock
10
9
Clamp

9ENGLISHSWAGTRON EB7 Elite Plus
3.4 Adjusting the Seat Height
Positioning the seat at the right height is key for better pedaling, safety and overall comfort. The rider’s leg length is used
to determine the seat’s position. When pedaling, your hips should remain level and your legs shouldn't over-extend. To
determine the right seat height, sit on the eBike with one pedal at its lowest point and place the ball of your foot on the
pedal. If your knee bends slightly at this position, the seat is at the right height. Additionally, when placing your heel on the
pedal, your leg should be nearly straight.
Open the clamp under the seat post. Pull the seat up or push it down to adjust height. Check
to make sure the seat post is fully inserted into the frame and the head of the seat is parallel
with the frame. Lastly, close the clamp to secure the seat in place (11).
3.5 Unfolding & Folding the Pedals
Holding the crank arm vertical, fold or unfold the pedal. Repeat with the other pedal as
needed (12).
Clamp
11
12

10
ENGLISH SWAGTRON EB7 Elite Plus
Section 4. Charging the Battery
4.1 Charging Instructions
Charge the eBike before using it.
Step 1. Make sure the bike is turned off and connect the charger’s cables and adapter if needed.
Step 2. Plug the charger into a wall outlet (100V-240V) then plug the other end into the charging port. Remove the cap as needed.
Step 3. Allow ~5 hours’ time for charging. The charging adapter’s light will turn red during charging and then turn green once
charging is complete. Disconnect all cables once charging is nished.
For your convenience, the battery can also be charged while detached from the EB7 Elite Plus. (See 4.2 for detaching
instructions.)
Charging Port
Charging Cable

11 ENGLISHSWAGTRON EB7 Elite Plus
• Fully charge the battery before your rst use, this may take up to 5 hours.
• Perform periodic visual inspection of the battery ports and charging cables.
• Keep your charging environment clean and dry at all times.
• If the charging port is damp or has any liquid on it, do not charge your eBike.
• In order for the battery to operate at maximum efciency, avoid charging your eBike in extremely hot or extremely cold
environments.
• DO NOT, under any circumstances, use the bike while it is charging or connected to the charger.
• The charging time is ~5 hours. Charging longer than that may affect battery life and/or performance. If the charging adapter's
light doesn’t turn on, it may not be fully connected. Check that it is securely connected to the wall and to the bike.
• Use only the charger provided with your EB7 Plus. If you have lost or misplaced your charger, contact customer support to
obtain a replacement.

12
ENGLISH SWAGTRON EB7 Elite Plus
4.2 Battery Lock/Removal
For your convenience, the EB7 Elite Plus's battery can be removed and locked as needed. Fold the bike rst before unlocking and/
or removing the battery.
Step 1. Use the included keys to unlock the battery via the keyhole inside the folded frame ( 8). To unlock the battery, insert the
key, and turn it to the unlock position.
Step 2. With the key inserted into the keyhole, lift the handle and use it to pull the battery out ( 9).
Step 3. To reinstall the battery, reinsert it into the frame. Turn the key to the locked position.
Remember to lock the battery and remove the key before unfolding and/or riding the bike.
89

13 ENGLISHSWAGTRON EB7 Elite Plus
Section 5. Riding Your eBike
5.1 How to Ride
FRONT BRAKE REAR BRAKE
HORN
GEAR BUTTON
GEAR SWITCH
THROTTLE
POWER BUTTON
+/- BUTTONS
DISPLAY
• Start your eBike by pressing and holding the power button ~2s, or ride it with your feet directly. Power-assisted mode will be on
whenever power is on.
• Move forward by twisting the throttle.
• Switch between 7 gears by pressing the gear button or pushing the gear.
Gear Button only shifts up in gear.
• To stop, release the throttle, then squeeze the front and rear brakes to slow the front and rear wheels down.
• Use the horn and headlight to alert pedestrians and other riders of your presence.
5.2 Buttons Information
The EB7 Elite Plus eBike’s display features several different elements.
: Press and hold for ~2 seconds to turn the eBike on/off. Quick-press to cycle between TRIP, VOL, TI, and ODO on display.
: Quick-press to switch between speed modes (1-3). Press and hold for ~2 seconds to turn the headlight on/off.
: Quick-press to switch modes 1, 2, and 3.

14
ENGLISH SWAGTRON EB7 Elite Plus
5.3 Display Information
: This icon indicates cruise control’s status (on/off). Maintain speed for ~7 seconds to
use this feature. Brake to turn it off.
: This icon indicates the headlight’s status (on/off).
: Current speed, as measured in mph or km/h.
TRIP: These numbers show distance data for a single trip. Data is automatically cleared
when the bike is powered off.
ODO: These numbers show odometer data, i.e., cumulative distance from 0 to 6213 mi. Data accumulates in increments of 0.63
mi. If a single trip is less than 0.63 mi, it is not included in the total mileage. When data exceeds the maximum (6213 mi), the
odometer will automatically reset to zero.
TI: These numbers show time data for a single trip.
VOL: These numbers show current voltage information.
Battery Level: This icon indicates how much battery life you have left.
MODE: Displays the current speed mode (1, 2 or 3). Each mode has a different maximum
speed (throttle-only):
Mode 1 max. speed is 11.3 mph.
Mode 2 max. speed is 13.7 mph.
Mode 3 max. speed is 18.6 mph
5.4 Display Settings
Press and hold and buttons for ~2s to enter the display setting screen.
Adjust display brightness: Press the button to enter P01screen, then use and
buttons to adjust the brightness of the display's backlight.
Switch measurement system: Press the button to enter P02screen, then use and
buttons to set the display to the desired measurement type between imperial (miles, mph) and metric (km, km/h).

15 ENGLISHSWAGTRON EB7 Elite Plus
Section 6. Safe Riding Techniques & Tips
Consider the following techniques and info to help ensure you have a safe, fun riding experience. Before riding, always check to
make sure your brakes are working properly.
•Makesureyourfeetarealwaysonthepedals.Takingyourfeetoffthepedalswhileridingisdangerous.
•RemembertoremainseatedwhenusingtheeBike'scruisecontrolfunction.
•Makesurethebatteryisfullycharged,especiallyifyouplantotravellongdistances.
•Foryourownsafetyandthesafetyofothers,rideonlyatspeedsyouarecomfortablewithandbereadytostopatanytime.
•Keepasafedistancefromfellowriderstoavoidcollisions.
•Payattentiontoyoursurroundings.Youreyesareyourbesttoolsforsafelyavoidingobstaclesandunsafesurfaces.
•Rideinopenspacesandatareas.Avoidslopesorhightrafcareasuntilyou’refamiliarwithriding.
•Donotrideathighspeeds,onuneventerrain,ininclementweather,orotherwiseunsafeconditions.
•NeverusetheeBiketodoanythingthatmaycausepersonalinjuryorpropertydamage.
•Donotattempttocarrypassengersorheavyitems.Thebikecanonlysupporttheweightofonepersonatatime.Donot
exceed the weight limit.
•OnlyridetheeBikewherepermitted.YouMUSTcomplywithlocallawsandgivewaytopedestrians.
DO NOT USE THE EBIKE TO PERFORM DANGEROUS MANEUVERS. FAILURE TO EXERCISE GOOD JUDGMENT AND HEED THE
ABOVE WARNINGS INCREASES THE RISK OF SERIOUS INJURY OR, IN VERY RARE CASES, DEATH. USE WITH APPROPRIATE
CAUTION AND SERIOUS ATTENTION TO SAFE OPERATION.
6.1 Before Your First Ride
Inspect gears, examine brakes and check tire pressure. Proper tire ination can reduce ats and improve performance, including
travel distance per charge. See Section 7.1 for more.

16
ENGLISH SWAGTRON EB7 Elite Plus
6.2 Daily Bike Inspections
Routine inspections before and after every ride will help you maintain optimal bike performance and catch potential problems
before they turn into safety concerns. Regularly check brakes, lights, seat and tire pressure.
6.3 Semi-Annual Bike Mechanic Inspections
Bikes require regular maintenance. Take your bike in to your local bike shop for a tune-up twice yearly. Complex components
should always be inspected, serviced and adjusted by experienced mechanics.
Section 7. Maintenance
• Do not perform any kind of maintenance while the eBike is powered on or charging.
• Attempting to repair or modify your eBike can void all warranties. Only authorized repair centers may service the eBike.
If you need assistance, please contact customer service.
7.1 Tire Ination
You will need a pressure gauge, a standard bicycle pump to inate the EB7 Elite Plus eBike’s tires.
Step 1. Ensure the eBike is powered off and stable.
Step 2. Visually inspect the tires for damage, or puncture marks. If the tire is damaged, DO NOT INFLATE IT. Contact customer
service immediately.
Step 3. Find the valve located on the inside of the wheel and remove the cap.
Step 4. Use a standard bicycle pump to pump air to the tires slowly.
Step 5. Use the pressure gauge periodically to check PSI.

17 ENGLISHSWAGTRON EB7 Elite Plus
Step 6. When the tire reaches 40-65 PSI/2.8-4.5BAR, stop inating and replace the valve cap.
Step 7. Repeat with other tire.
• AnyPSImarkingsonthetiresindicatesamaximum.DONOTinatethefronttiretothisvalue.Onlyinatetoamaximum
of 65 PSI as directed above.
• Underinationisstronglyrecommendedifyouintendtorideoutdoorsintemperaturesabove90°Fdegrees.Bringthe
EB7 Elite Plus eBike indoors and deate the tires to 58.5 PSI. If the PSI is too high and the tire are exposed to excessively
high temperatures, riding outdoors may cause serious damage to the tire including but not limited to stretching and/or
rupturing.
7.2 Cleaning
Proper cleaning of your eBike can guarantee a longer lifespan and a smooth riding experience.
• Wipe the outer body of your eBike with a soft, dry microber cloth.
• Check around the wheels and ensure there is no blockage. The eBike’s design allows for easy wheel maintenance.
• The eBike meets IPX4 water-resistance, meaning it can withstand splashes; however, do not submerge the eBike in water.
• Do not let water and liquids get into the eBike’s electric parts or battery.
7.3 Storage
Below are some tips to consider when storing your EB7 Elite Plus eBike.
• Before storing, fully charge the eBike to prevent battery over-discharge due to non-use.
• If storing the eBike for more than one month, discharge and recharge the battery at least once a month.
• Cover the eBike to keep dust out. Do not store in a dusty environment as this may cause damage over time.

18
ENGLISH SWAGTRON EB7 Elite Plus
7.4 Transportation
Before moving, lifting, or otherwise transporting the eBike, turn it off. The eBike weighs approximately 42.3 lb. If you are unsure of
your ability to lift this much weight, ask someone for help.
Lithium-ion batteries are considered hazardous materials; therefore, transportation is governed by federal, state and local laws.
International law prohibits the shipping of bare lithium-ion batteries. If you are shipping your EB7 Elite Plus eBike, you must ship it
with the battery installed.
7.5 Disposal at End-of-Life
This product must not be disposed of by incineration, landlling, or mixing with household trash. Improper disposal of the
battery contained within this product may result in the battery heating up, rupturing, or igniting which may cause serious injury.
The substances contained inside the battery present chemical risks to the environment. The recommended disposal for any
SWAGTRON product at its end-of-life is to dispose of the entire unit at or through an e-waste recycling center, program, or facility.
Local regulations and laws pertaining to the recycling and disposal of lithium-ion batteries and/or products containing them will
vary according to country, state, and local governments. You must check laws and regulations corresponding to where you live in
order to properly dispose of the battery and/or unit. It is the user’s responsibility to dispose of their waste equipment properly with
accordance with local regulations and laws.
For additional information about where you should drop off your batteries and electrical or electronic waste, please contact your
local or regional waste-management ofce, your household waste disposal service, or your point-of-sale.

19 ENGLISHSWAGTRON EB7 Elite Plus
Section 8. Specications
Item Parameters
Model Name EB7 Elite Plus
Net Weight 42.3 lb. / 19.2 kg
Unfolded Dimensions 52.8 x 22 x 42.1 in. / 1340 x 560 x 1070 mm
Folded Dimensions 29.5 x 16.5 x 26 in. / 750 x 420 x 660 mm
Max. Incline (Throttle-Only) 25˚
Max. Capacity 264.5 lb. / 120 kg
Max. Speed (Throttle-Only) 18.6 mph / 30 km/h
Range Per Charge (Throttle-Only) Up to 18.6 miles (mode 1); 16.2 miles (mode 2); 14.3 miles (mode 3)
Battery Voltage 36V 6.4 Ah
Charging Voltage 100V - 240V / 50 - 60Hz /42V 1.5A
Voltage 36V 0.5W
Wheel Size 16" Front / Rear
Wheel Ination 40-65 PSI / 2.8-4.5 BAR
Charging Time 5 Hours
Water Resistance IPX4
Warranty 1 Year Limited
