SWAGTRON SWAGDRONE 210-UP User manual

QUICK START GUIDE
SAVE THIS GUIDE FOR FUTURE USE
www.SWAGTRON.com
210-UP

Thank you for your purchase of the SwagDrone™ 210-UP by SWAGTRON®!
If you want real swag, you’re in the right place. The SwagDrone 210-UP boasts plenty of
features and all new ways to take your swag to new heights.
To ensure your safety and the safety of others, please read and be sure to follow all
instructions and safety recommendations in this User Manual prior to and when flying your
SwagDrone.
If you have any questions regarding the SwagDrone™, contact us at 1-844-299-0625 for
further assistance.
Happy Flying!
-The SWAGTRON™ Team

Table of Contents
1.0 SwagDrone Parts 4
2.0 Remote Control 5
3.0 Specifications 6
4.0 Pre-Flight Check 7
5.0 Battery Charging 7
6.0 Preparing the SwagDrone 210-UP 7
•Mushroom Antenna Installation 7
•Propeller Installation 8
•Battery installation 8
7.0 Pre-Flight Setup 8
7.1 Binding Your SwagDrone 9
7.2 Locking & Unlocking the Motor 10
•Motor Unlock 10
•Motor Lock 11
8.0 Flight Control 11
•Racing Flight 12
9.0 Landing 13
10.0 Additional Instructions 13
10.1 Remote Control Settings 13
•Main Interface 13
•Wing Type (WING) 14
•Device Output (OUTPU) 14
•Reverse Settings (REVSW) 15
10.3 OSD Overview 15
10.4 Video Transmitter Channel 15
Selection
10.5 Power Board Overview 16
10.6 OSD Information 16
•Upgrade 16
10.7 Receiver Introduction 17
•Fixed ID Code Removal 17
10.8 Introduction for Main Flight
Controller 17
10.9 Connection Diagram of 18
Brushless ESC & Brushless
Motor
11.0 GA009 Balance Charger 18
•Parameters 18
•Features 18
•Instructions 19
12.0 Warnings & Information 19
12.1 Safety Warnings 19
12.2 Disposal at End-of-Life 20
•12.3 FCC Information 20
13.0 Warranty Information 21
•1 Year Limited Warranty 21

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide
4
1.0 SwagDrone Parts
+The SwagDrone 210-UP body is created using CFP for outstanding crash survivability.
+Modern industrial and modular design helps improve product performance.
+Advanced 5.8ghz live video and OSD for an unforgettable, first-person visual (FPV)
experience.
+Modern flight control system for acrobatic flight routines such as rolls, flips, and race course
moves.
1. Camera
2. Headlight
3. Propeller (CW)
4. Propeller (CCW)
5. Clockwise Motor
(Levogyrate thread is counterclockwise)
6. Counterclockwise Motor
(Dextrogyrate thread is clockwise)
7. Li-Po Battery
8. Brushless ESC (CW)
9. Brushless ESC (CCW)
10. Power Port (XT60)
11. Mushroom Antenna
12. Main Flight Controller
13. Left Red LED Light
14. Right Red LED Light
15. LEFT Turn Indicator Light
16. RIGHT Turn Indicator Light
17. Receiver Antennas

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide 5
2.0 Remote Control
The included SwagDrone Remote Controller works with the SwagDrone 210-UP and can be
used to switch modes so that the drone is easier to operate according to the user. Select the
flight mode that corresponds to your skill level.
For your first flight, start with the first mode listed below.
+Primary Flight: The flight control system uses automatic stabilization to achieve stability
without rolling over. This mode is suitable for beginners.
+Mid-level Flight: The flight control system uses a partial stabilization to achieve a relatively
flexible operation and allows rollover. This mode is for advanced users.
+High-Level Flight: The flight control system uses flexible stabilization for advanced operation
and rollover. This mode is for advanced users.
The images and examples below show MODE 2 (Left-hand throttle). The controller is
set to MODE 2 by default.
Throttle Up
Throttle Down
Pitch Down
Pitch Up
Yaw
Left
Yaw
Right
Roll
Right
Roll
Left
Left Stick Right Stick
Toggle the MIX Switch to 0 Toggle the MIX Switch to 1 Toggle the MIX Switch to 2
Primary Flight
Mode
Mid-level Flight
Mode
High-level Flight
Mode
11. MIX Switch
12. ELE/ROLL/YAW D/R Switch
13. Right Stick
14. Right Trim
15. Power Switch
16. ROLL Trim
17. R+ Key
18. L- Key
19. ENT Key
20. Display
1. HOLD TRN Switch
2. GEAR Switch
3. AUX2 Knob
4. Left Stick
5. Left Trim
6. YAW Trim
7. UP+ Key
8. DN- Key
9. EXT Key
10. FMOD Key
20

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide
6
3.0 Specifications
• Read this guide in its entirety before attempting to use the SwagDrone 210-UP
SwagDrone 210-UP
Main Rotor Diameter:
Dimensions:
Weight:
Battery:
Flight Time:
Working Temperature:
128mm
182 (L) x 182 (W) x 103 (H) mm
370g (Battery excluded)
14.8V 1300mAh 40C 4S LiPo
8~9mins
14°F ~ 104°F
TX5825 (FCC) / TX5824 (CE) Transmitter
Camera (700TVL)
5.8G Wireless Image Transmission
TX5825(FCC) Bind B Section: 4 Channels
TX5824(CE) B Section: 8 Channels
TX5825(FCC) Output Power ≤200mW
TX5824(CE) Output Power ≤25mW
Horizontal Resolution:
System Committee:
Video Out:
Power Input:
700TVL
PAL/NTSC
1.0Vp-p/75Ω
DC 12V
182mm
182mm
128mm
103mm

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide 7
4.0 Pre-Flight Check
1. The SwagDrone 210-UP is recommended for pilots 14 and up who have piloted drones
before.
2. Only fly the SwagDrone 210-UP in dry weather with low wind conditions. Please do not
fly in rain, snow, or heavy fog.
3. Always choose large open fields for flying. Check local laws and ordinances for legal
flying areas.
4. To avoid injury from high-speed propellers, always keep a distance of 15 feet from the
drone when the motor is unlocked. Always lock the motor before handling the drone.
5. Do not fly close to high-voltage power lines, cell, or radio towers as these may disrupt
your control signal.
6. Always check local laws before flying. Never fly over crowds, near animals or children,
or within sports stadiums.
5.0 Battery Charging
STEP1. Connect the power-cable to the
wall-outlet. The GA009 charger
accepts voltage from 100V to 240V.
The LED will turn green.
STEP2. Insert the LiPo battery plug into the
GA009 charger. During the charging
process, the LED will turn solid red.
STEP3. When the battery is almost done
charging, the LED will flash red and
green. When charging is done, the
LED will turn solid green.
• If the yellow light flashes, there may be
a problem with the charger or battery. If
you see a yellow light, immediately stop
charging and call customer service.
• Refer to Section 11 for details for the
GA009 Balance Charger.
6.0 Preparing the SwagDrone 210-UP
Mushroom Antenna Installation
Install the mushroom onto the mounting brackets as shown. Next,
lock in the video transmitter, and tighten in the rotating collar with
the included wrench.
GA009 Balance Charger
14.8V LiPo
Battery
Wrench

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide
8
Propeller Installation
Fix the CW Propellers onto the clockwise
motor according to the direction of blue
arrow, and fix the CCW Propellers onto
the counterclockwise motor according to
the direction of orange arrow. Tighten the
propellers manually and make sure that all
propellers have been properly fastened.
• Install the propellers by hand and tighten the motor with the included wrench.
• You can use the wrench to help remove broken props in the event of a crash.
Battery installation
• DO NOT connect the battery at this stage.
STEP1. Place the anti-slip mat into the battery
compartment. Place the battery on
top and position it so that it is evenly
balanced.
STEP2. Grab the drone by the COG (center
of gravity) line and move the battery
forwards and backwards until the
drone balances.
STEP3. Once the battery is balanced inside its
compartment, use the velcro strap to
secure it in place.
7.0 Pre-Flight Setup
• Place the drone in a wide openspace with the rear facing you. This position is known as "Tail
In".
• Put the function switches to the 0 position, and place the trims and dials to the middle position.
Move the throttle to the lowest position.
• Video receiving equipment is needed to display image and OSD information. Refer to Sections
10.3 to 10.7.
• The OSD provides a visual reference for the remaining battery power.
• When the voltage reaches below 14 volts, the right LED will flash quickly and the beeper alarm
will sound. Land the drone as soon as possible if you hear the alarm or the OSD shows 7 volts.
• The 210-UP is designed for FPV racing, as there is no automatic landing mode.
Wrench
Front
CW propeller
CW propeller
CCW propeller
CCW propeller
COG Line
Front
Anti-Slip Mat
Battery

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide 9
7.1 Binding Your SwagDrone
• PROCEED WITH CAUTION. The drone will immediately receive power to all parts including the
propellers once the battery is connected. Do not allow loose clothing, hair, fingers or any other
part of your body to come in contact with or near the propellers during battery installation.
STEP1. Set the drone on a flat, level surface
and check that the battery is secured
in its compartment and that the
Mushroom Antenna is securely
attached.
For your safety, it is recommended to
extend both the Receiver Antennas
before the next step.
STEP2. Connect the battery to the drone using the matching connectors. Make sure that the
red and black cables match the cables underneath the battery compartment. Once
the battery is connected, the drone will make noise, the left red LED light should
turn on, and the propellers may move slightly. Move at least 15 feet away for safe
clearance.
STEP3. Put the function switches to the 0 position and place the trims and dials to the
middle positions. Doing this puts everything in neutral. Use the image on the next
page to check that everything is in the correct position then turn on the remote
control. The controller will automatically start to bind to the drone once it is on.
With everything in the correct positions (neutral), turn on the remote. The controller
will automatically start to bind to the drone once it is on.
Left LED light
Right LED light
Back View
90°

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide
10
• Do not move the SwagDrone 210-Up during binding.
If the error reading THST K or any other combination appears on the remote’s
screen, at least one of the trims, dials, or sticks is not in the correct position. Turn
the controller off, check the above
image, make any needed adjustments,
and turn it on again.
STEP4. Once the drone successfully binds
to the controller, the red LED will
blink slowly and the drone should
stop making noise.
In the event that everything has been done correctly but the buzzer keeps making
noise, please try binding the drone again. For any further troubleshooting, contact
customer service.
7.2 Locking & Unlocking the Motor
After successfully binding, the motor is locked by default.
Motor Unlock
Check that everything is in neutral (see Section 7.1, STEP 3),
then turn the remote on. Gently push the left stick down-left
and hold it in this position for at least 2 seconds. When the
motor unlocks, the right red LED light will turn on and the
drone will beep. Be very careful at this point, as pushing the
throttle up will start the motors.
You can test this by pushing the left stick up a little; the motors should start.
0
1
0
2
Left LED light Right LED light
Back View
ELEV/RUDD THRO/AILE
MODE 1 (Throttle stick on the right)
MODE 2 (Throttle stick on the left)

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide 11
Motor Lock
Check that everything is in neutral (see Section 7.1, STEP 3),
then gently push the left stick down-right and hold it in this
position for at least 2 seconds. When the motor locks, the
right red LED light will turn off, and the drone will beep.
8.0 Flight Control
• Unlock the motor before take off, then manually take
off by slowly pushing the left stick upward.
• Tricks such as flips and rolls etc. should not be
attempted unless you are able to pilot the drone in mid
or high-level flight mode.
Ensure that the MIX switch is in position 1 or 2 for Mid-
level or High-level Flight modes. Postilion 0 is for Primary
level or beginner flight mode. Tricks are not possible for in
Primary mode.
• Always select large open spaces with soft ground for flying.
• Rolls and flips are best suited for experienced pilots.
• In the event that you do wish to perform rolls and flips, it is highly recommended that you
gain an appropriate amount of altitude first.
ELEV/RUDD THRO/AILE
MODE 1 (Throttle stick on the right)
MODE 2 (Throttle stick on the left)
Loop
(Forward/Downward Rollover)
Loop
(Backward/Upward Rollover)
Backward/Upward
Rollover
Forward/Downward
Rollover
Toggle the MIX Switch to 1
Mid-Level Flight Mode
Toggle the MIX Switch to 2
High-Level Flight Mode
Loop
(Forward/Downward Rollover)
Loop
(Backward/Upward Rollover) Backward/Upward
Rollover
Forward/Downward
Rollover
Toggle the MIX Switch to 1
Mid-Level Flight Mode
Toggle the MIX Switch to 2
High-Level Flight Mode
Loop
(Forward/Downward Rollover)
Loop
(Backward/Upward Rollover)
Backward/Upward
Rollover
Forward/Downward
Rollover
Toggle the MIX Switch to 1
Mid-Level Flight Mode
Toggle the MIX Switch to 2
High-Level Flight Mode

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide
12
Ensure that the MIX switch is in position 1 or 2 for Mid-
level or High-level Flight modes.
Aileron rolls may be more difficult to attempt while
using Mid-level Flight Mode.
• Always select large open spaces with soft ground for
flying.
• Rolls and flips are best suited for experienced pilots.
• In the event that you do wish to perform rolls and flips,
it is highly recommended that you gain an appropriate
amount of altitude first.
Racing Flight
• Racing is suitable only for experienced pilots as obstacle avoidance requires advanced flight
skills.
• During racing, flight must be controlled within 984 feet (300 meters) of signal receiving range
(actual range depends on flying environment and weather conditions.)
• When racing, be sure to keep away from crowds, animals, and power lines. Be aware of your
surroundings at all times.
Toggle the MIX Switch to 1
Mid-Level Flight Mode
Toggle the MIX Switch to 2
High-Level Flight Mode
Aileron
(Left side rollover)
Aileron
(Right side rollover)
Toggle the MIX Switch to 1
Mid-Level Flight Mode
Toggle the MIX Switch to 2
High-Level Flight Mode
Aileron
(Left side rollover)
Aileron
(Right side rollover)

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide 13
9.0 Landing
STEP1. For the SwagDrone, manual landing is required. Slowly pull down on the left stick
until the drone lands and then lock the motor.
STEP2. Power off the drone by unplugging the battery and turning off the remote.
STEP3. Remove the battery from the drone.
10.0 Additional Instructions
10.1 Remote Control Settings
Main Interface
Model Select (SELEC)
This controller option can be used to save certain configurations if you decide to use
it for different flying styles etc.
Right Trim
Battery Level
YAW Trim
Timer
Left Trim
Roll Trim
Throttle/Model
00 00
TH 0%
Press UP or DN to select the desired number then press ENT to confirm.
Press the EXT Key to return to the previous menu.
Main Interface ENT ENTENT
UP/DN UP/DN
MODEL SELEC
MODEL
MOD 1
MOD 2

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide
14
Wing Type (WING)
Device Output (OUTPU)
UP/DN
MODEL WING ENT
MODEL
WING
NORM
Press the L or R keys to select "NORM" and press the ENT key to confirm.
Press the EXT Key to return to the previous menu.
MODEL
GEAR
MIX
MODEL
GEAR
ACT
MODEL
FLAP
ACT
MODEL
FLAP
FMOD
MODEL
AUX2
GEAR
MODEL
AUX2
ACT
ENT
R/L
DN
R/L
DN
R/L
DN
R/L
DN
R/L
MODEL OUTPU
DN R/L
After setting, press the ENT Key to confirm then press the EXT Key to return to the Main Interface.
Model Name (NAME)
UP/DN
MODEL NAME ENT
MODEL
0 1
F210
Model Type (TYPE)
UP/DN
MODEL TYPE ENT
MODEL
HELI
AERO
Press R or L button to change the character and
figure, named model as F210. Press ENT to
confirm. Press the EXT Key to return to the previous
menu.
Press UP or DN to select AERO, Press ENT to
confirm. Press the EXT Key to return to the previous
menu.

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide 15
Reverse Settings (REVSW)
10.3 OSD Overview
+The OSD information is visible on your video receiver.
The video switch and OSD module code switch can be found on page 17 and 18.
10.4 Video Transmitter Channel Selection
There are 8 channels available. Choose the best channel based on image quality for your
screen. Select the channel by adjusting the dip-switches on your video transmitter according
to the diagram.
• Only 2, 4, 6, 8 channels are available for the TX5825(FCC) transmitter.
• Video transmitter channel must match the receiver channel.
Battery volume
Timer
ROLL PITCH
Interior voltage
10:00
16.8V R 15° P 15° 5V
E NG
AV
Main Interface
After setting, press the ENT
Key to confirm then press the
EXT Key to return to the Main
Interface.
Press ENT to enter
the REVSW interface.
Press R or L to
select “NORM”.
ENT
UP/DN
UP/DN
FUNCTION REVSW
FUNCTION
ELEV
NORM
NORM NORM
THRO
NORM
RUDD GEAR
NORM
FLAP
NORM
AUX2
NORMNORM
ELEV
(PITCH)
AILE
(ROLL)
1
5866MHz 5847MHz 5828MHz 5809MHz 5790MHz 5771MHz 5752MHz 5733MHz
2 3 4 5 6 7 8
Channel
Frequency
Code
Position
(on/off)
O N
321
O N
321
O N
321
O N
321
O N
321
O N
321
O N
321
O N
321

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide
16
10.5 Power Board Overview
10.6 OSD Information
Upgrade
For upgrades, please go to swagtron.com for details. Use the UP02 cable and connector to
connect.
1. 5V power output
2. Brushless ECS connectiont position(CCW)
3. Brushless ECS connectiont position(CW)
4. Lighting Lamp Connection port
5. Camera Connection Port: (3 pins/11.1V)
6. Main controller Flexible flat cable Connection port
7. Buzzer:
(An alarm which sounds automatically when the signal
between the drone and remote controllers are suddenly
lost or the battery voltage dips below 14.0V)
8. Rear LED light connection port
9. Connection port for receiver or
external receiver converter
10. OSD connection port
11. Transmitter connection port
12. Video switch:
Without OSD, Please turn the switch from
“1” to "ON" position to start the video.
With OSD, Please turn the switch to "1"
position to shut off the video.
Front
Back
HeadHead
O N
2
1
O N
2
1
1. 5V power output
2. Brushless ECS connectiont position(CCW)
3. Brushless ECS connectiont position(CW)
4. Lighting Lamp Connection port
5. Camera Connection Port: (3 pins/11.1V)
6. Main controller Flexible flat cable Connection port
7. Buzzer:
(An alarm which sounds automatically when the signal
between the drone and remote controllers are suddenly
lost or the battery voltage dips below 14.0V)
8. Rear LED light connection port
9. Connection port for receiver or
external receiver converter
10. OSD connection port
11. Transmitter connection port
12. Video switch:
Without OSD, Please turn the switch from
“1” to "ON" position to start the video.
With OSD, Please turn the switch to "1"
position to shut off the video.
Front
Back
HeadHead
O N
2
1
O N
2
1

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide 17
10.7 Receiver Introduction
Fixed ID Code Removal
In the event that you want to clear the fixed ID from
the remote controller, follow these steps.
STEP1. Press the Clearing Key button, and power
on the 210-UP.
STEP2. The Receiver's RED LED will slowly blink to
indicate that the fixed ID has been cleaned.
STEP3. Set the Remote Control's Fixed ID setting to
OFF.
10.8 Introduction for Main Flight Controller
Port Introduction
1. Upgrade port: used for program upgrading
2. Code switch: slide the code switch from“1” to "ON" to start the OSD
Please use UP02 and the UP02 adapter to upgrade.
O N
21
UP02 Adapter
UP02
Port Introduction
Data port
3. USB Port (Used for upgrading)
4. Connection Port
(Used for connection to the flexible flat cable)
Flexible Flat Cable Connection
USB Cable
The metal surface of the flat
flexible cable plug should be
inserted downward to power
the board port properly.
The metal surface of a flexible
flat cable should be inserted
upward to the main controller
port properly.
1. 4-Pin Port (Not used)
2. 6-Pin Port (Not used)
Upgrading
Please upgrade online via the SWAGTRON official site.
UP02 components not included.
Clearing Key

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide
18
10.9 Connection Diagram of Brushless ESC & Brushless Motor
11.0 GA009 Balance Charger
Parameters
Features
+The GA009 utilizes microcomputer chips to monitor and control the charging process. LED
indicator lights that help display the charging status in real time.
+GA009 can be used to charge 3S & 4S (11.1V &14.8V) Li-ion and Li-Polymer battery packs.
Port Introduction
Data port
3. USB Port (Used for upgrading)
4. Connection Port
(Used for connection to the flexible flat cable)
Flexible Flat Cable Connection
USB Cable
The metal surface of the flat
flexible cable plug should be
inserted downward to power
the board port properly.
The metal surface of a flexible
flat cable should be inserted
upward to the main controller
port properly.
1. 4-Pin Port (Not used)
2. 6-Pin Port (Not used)
Upgrading
Please upgrade online via the SWAGTRON official site.
Front
Brushless
ESC(CCW)
Brushless
ESC (CW)
Brushless
ESC(CW)
Brushless
ESC(CCW) Brushless Motor (CCW)
Brushless
Motor (CCW)
Brushless
Motor (CW)
Brushless
Motor (CCW)
Head
C
W
Black
Blue
Red
C
W
Black
Blue
Red
C
C
W
Blue
Black
Red
C
C
W
Blue
Black
Red
Input Voltage Output Current Output Power Dimensions
3.3A100-240V 50/60HZ 60W 137 x 57 x 32mm

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide 19
Instructions
• The GA009 can only be used to charge a 3S or 4S Li-On or LI-Polymer battery. It is forbidden
for you to simultaneously charge two or more sets of batteries. Either the charger or battery
may be damaged.
• While charging, the GA009 should be placed in a dry and well ventilated place and be placed
far away from heat sources and flammable and explosive substances.
• The battery should be removed from the helicopter when charging. In order to avoid the risk
of accidents, never leave the charger unsupervised during the charging process.
• DO NOT CHARGE YOUR BATTERY IMMEDIATELY AFTER ITS FLIGHT IS FINISHED, OR THE
TEMPERATURE HAS NOT FINISHED FULLY COOLING. OTHERWISE THE BATTERY WILL RISK
COMBUSTING.
• ENSURE THAT THE BATTERIES ARE AT THE CORRECT POLARITY BEFORE CHARGING.
• Avoid dropping or roughly handling the battery during the process of charging. Dropping and
roughly handling the battery will result in short circuiting.
• Please use only the original charging equipment (wall adapter and GA009 Balance charger)
and battery. Please change the batteries one at a time
• If the battery is kept in the charger for a long time after being fully charged, it will
automatically begin to discharge. When the charger detects that the voltage of individual
cells is lower than the rate voltage, it will recharge until it is full charged again. Frequently
charging and discharging will shorten the lifetime of your battery.
12.0 Warnings & Information
It is important that you follow all instructions and regard all notes that appear throughout this
manual.
12.1 Safety Warnings
+Always remove the battery to turn the product off before transporting or storing.
+Store the product indoors at a dry and stable temperature. Do not store in an unheated
garage, shed, or other location with extreme temperature fluctuations.
+Before using the product, remove all objects which may easily sustain or cause damage if
bumped during flight.
GA009 Balance Charger
3S Adapter Cable 3S (11.1V)
LiPo battery

SWAGTRON®SWAGDRONETM 210-UP Racing Quadcopter Quick Start Guide
20
+Clean the outside with a dry, non-abrasive cloth only. Do not spray water or liquids onto the
product.
+Do not leave children or animals unsupervised around the product.
+Do not place the product near any source of significant heat or combustible materials.
+This product is for outdoor use only.
+Properly dispose of all packaging material. Some items may be packed in plastic bags or
material and may cause suffocation or injury to pets or children.
+Do not place heavy weight on the product or any of its accessories.
+Do not place anything inside the product other than battery as described in this manual.
+Do not use the product for any purpose other than described in this user manual.
12.2 Disposal at End-of-Life
This product must not be disposed of by incineration, landfilling, or mixing with household
trash. Improper disposal of the battery contained within this product may result in the battery
heating up, rupturing, or igniting which may cause serious injury. The substances contained
inside the battery present chemical risks to the environment. The recommended disposal
for any SWAGTRON™ product at its end-of-life is to dispose of the entire unit at or through
an e-waste recycling center, program, or facility. Local regulations and laws pertaining to
the recycling and disposal of lithium ion batteries and/or products containing them will vary
according to country, state, and local governments. You must check laws and regulations
corresponding to where you live in order to properly dispose of the battery and/or unit. It is
the user’s responsibility to dispose of their waste equipment properly with accordance with
local regulations and laws.
For additional information about where you should drop off your batteries and electrical
or electronic waste, please contact your local or regional waste-management office, your
household waste disposal service, or your point-of-sale.
12.3 FCC Information
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
CAUTION: Modification or changes to this equipment not expressly approved by Radio
Systems Corporation may void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
