Swagway X1 User manual
EN
User's Manual
Thank you for your purchase of the Swagway X1! To ensure your safety and the safety of
others, please read and follow these instructions. Happy riding!
EN
EN
It is important that you follow all safety warnings that appear throughout your Swagway
Hands-Free smart board manuals and that you use good judgment when you ride your
Swagway. If you have questions, or do not have the Swagway Manual or Safety Video, contact
Swagway before you attempt to use your Swagway board.
The Swagway is a self-balancing, personal transporter that uses balancing technology.
Note: Balancing technology cannot prevent injury if you do not ride the Swagway safely. Please review the below safety warnings.
• Always wear shoes, a helmet, and appropriate safety gear such as knee and elbow pads when riding. Use an approved bicycle or
skateboard helmet that fits properly with the chin strap in place, and provides protection for the Front, back and sides of your head.
• Do not ride without proper training, please review manual and how to videos before use.
• Avoid obstacles and slippery surfaces that could result in a loss of balance or traction and cause a fall.
• Do not ride at high speeds, on uneven terrain, or on slopes. Do not perform stunts or turn abruptly.
• Never place anything on the rider detection pads except your feet. Doing so could interfere with the Rider Detection system and
may allow the Swagway to travel on its own, risking running into a person or property and causing injury or damage.
• Never step off of the Swagway when it is in motion. If you step off of the Swagway while in motion, you risk injury to yourself,
others, and damage to the Swagway.
• Although the Swagway is designed to be as stable as possible for a design that utilizes two self-balancing wheels, it is possible
to “override” the Swagway and tip over when riding too fast for the conditions. Always be aware of the riding surface and environ-
mental conditions while riding. Be alert. Scan both far ahead and in front of the Wheels—your eyes are your best tool for safely
avoiding obstacles and slippery surfaces.
• Do not carry one or more passengers.
• Do not ride your Swagway after consumption of alcohol, drugs, or while intoxicated. You must comply with local laws and give
way to pedestrians.
• All riders must be over 4’ tall and must weigh more than 44 lbs. The maximum weights limit 220 lbs.
RISK OF DEATH OR SERIOUS INJURY
Assumption of Risk: By riding our Swagway the user acknowledges and accept responsibility of all risks associated with the use
of the Swagway Hands-Free Smart Board, which may include, but are not limited to, muscle injuries, broken bones, lacerations,
serious injury, and possibly death, which may be sustained while using the Swagway.
To ride safely, you must read and follow all instructions and warnings in the User Manual.
EN
EN
EN
Chapter II Product introduction
1.1 About the manual
Before operating this vehicle, read all the instructions for safe assembly and operation.
This User's Manual will guide you through the functions and usage of your Swagway electric skateboard.
If you have any questions or you cannot find the information you need in the manual, please contact your place of
purchase or our company immediately.
1. 2 The risk of driving
The Swagway is a self-balancing smart transportation and recreational device. It has gone through rigorous testing to
ensure its safety. However, if you don't follow the instructions in the manual, you may be injured.
No matter when and where, there is a possibility you may crash, fall off, lose control, etc., causing injury and even death.
In order to avoid being injured, please read this manual carefully.
1. 3 Before you begin
Before using, check that the battery is fully charged. Please find more details in Chapter VII. The likelihood of injury or
death will increase if you don't follow the proper operating instructions in this manual.
1. 4 Important information
When reading this manual, please pay attention to 'WARNING' and 'NOTE' in all capital letters.
Caution: read and understand the following or you may be injured.
The following explanation requires your attention.
EN
Chapter II Product introduction
2.1 Description of the Swagway
The Swagway is a self-balancing electric skateboard which can go forwards and backwards. It’s steering
and stopping are controlled by Dynamic Equilibrium. It is simple to operate, easy to control, environmen-
tally friendly, and looks incredibly cool!
04
EN
2.2 Swagway Diagram
05
EN
EN
Do not step on the center pivot point of
the Swagway. This is dangerous, and
may break your Swagway.
EN
EN
Chapter IV Safe Use
4.1 Weight limitation
We sincerely hope every operator can ride the Swagway safely and enjoy it. Think back to when you
learned to ride a bike, drive a car, go skiing or skateboarding, etc. Remembering those experiences will
help you learn how to master your Swagway faster.
• Follow this User's Manual to learn to ride the Swagway safely. We highly advise you read the manual
carefully the first time. Before riding, make sure the tires are undamaged and mechanical parts
are not loose. If there is anything abnormal, please contact us for repair immediately.
• Please read the manual carefully. It covers lots of important information, including speed
limitations, indicator warnings, how to turn off safely, etc.
• Please never use the Swagway to do anything that may cause personal injury and property damage.
• Please don't modify the mechanical parts of the Swagway. This is a high tech, precision device. Any
modifications can cause unexpected results, breaking the Swagway or causing injury.
• The reason for the weight limitation: 1. To guarantee the safety of the operator; 2. To ensure the
Swagway operates properly.
• Maximum load: 220 LBS (100 KG)
• Minimum load: 44 LBS (20KG)
If the Swagway is overloaded, you may fall off and be injured.
09
EN
4.2 Range per charge
The range per charge is related to many factors.for example:
• Topography: On smooth even road, the range per charge will increase. If you are on rough
terrain or on a slope, it will decrease.
• Weight: The weight of the operator will influence the driving distance.
• Temperature: If the Swagway gets too hot or too cold, it will decrease the driving distance.
• Maintenance: If the Swagway is charged properly and the battery is kept in good condition, the
driving distance will increase. Improper charging and maintenance will decrease the driving distance.
• Speed and driving style: keep a moderate, consistent speed to increase the driving distance.
Frequently starts, stops, acceleration, and deceleration will reduce the driving distance.
4.3 Max. Speed
• The maximum speed of the Swagway is 10 mph (16 km/h).
• When the operator exceeds the maximum speed, the Swagway will sound an alarm.
• At recommended speeds, the electric Swagway will balance itself well. When the speed is faster
than the recommended speed, you will lose balance and fall off.
4.4 Max. Incline
• Do not operate on hills or slopes of more than 30° incline.
• At recommended inclines, the electric Swagway will balance itself well. When the incline is steeper than
recommended, you will lose control or fall off.
10
EN
This User's Manual includes instructions and notes; the operator must read it carefully and follow these
instructions. It is very important for you to know all these rules.
5.1 Operating Steps
Step 4: Shift your weight to turn. Putting more weight on your right foot turns left. Putting more weight on your
left foot turns right.
Step 5: Get off. Before you get off, make sure that the Swagway is stopped, then step off one foot at a time.
Please be careful.
If the Swagway doesn't self-balance when you trigger the foot-switch, the warning LED will light. Do
not operate the Swagway. Wait a few minutes and try again. If you are on a slope, move the Swagway
to flat ground. If this continues, please contact technical support. DO NOT OPERATE!
Be sure your Swagway is fully charged before riding.
First plug the charger into the charge port, then into the
wall. Charge fully before first use.
Step 1: Press the power switch to turn on the Swagway.
Step 2: Get ready to drive. First, step on one pedal to
trigger the foot-switch. The system will enter
self-balancing mode. T hen step on with your
other foot.
Step 3: Stand upright but relaxed. Do not make any
sudden or jerky movements. Shift your weight
forward or back to control the Swagway.
Chapter V Learning to use it
Charging Port
POWER Button
EN
EN
EN
EN
EN
