Gyroor K1 User manual

USER MANUAL

1
Contents
LIMITS……………………………………………………………………………………………………………… 02
COMPONENTS LIST…………………………………………………………………………………………… 02
ASSEMBLY STEPS……………………………………………………………………………………………… 03-04
SAFE USING……………………………………………………………………………………………………… 05
MAINTENANCE AND CLEANING…………………………………………………………………………… 06
TERMS AND CONDITIONS OF WARRANTY AND CLAIMS………………………………………………06
EXPLANATION OF SYMBOLS………………………………………………………………………………… 07
SAFETY INSTRUCTIONS…………………………………………………………………………………………08
CONTACT………………………………………………………………………………………………………… 09

LIMITS
Respect these limits to use this product safely:
Max. speed limit: 12 km/h
Max. weight limit: 100 kg
COMPONENTS LIST
Allen key x 1
Allen wrench x 1
Allen screw M8*50 mm x 4
Knob x 1
Allen Screw M8*20 mm x 4
Anti-slip nut M8 x 4
ASSEMBLY STEPS
Follow these steps to assemble it correctly:
Open the box and check if there is no missing parts.Step 1:
Front tube: put the tube into it and adjust the suitable hole. Use the Knob Step 2:
(COMPONENTS 4) to fit in suitable length.
Step 3: (COMPONENTS 2)Handles: Use Allen wrench and Allen key (1) to assemble handles
with four Allen screws M8*50MM and four Anti-slip nuts M8 (COMPONENTS 3)
(COMPONENTS 6). Make sure that you have attached the handles correctly before
next step.
Step 4: (COMPONENTS 1)Seat: Use Allen key to fasten the seat to the transverse support with
3 four Allen screws M8*20MM .(COMPONENTS 5)
3
2
1 2
3 4 5 6
1
2
3
4
5
5

Step 5: Attach the complete assembly to a board and adjust the nut on the end of the
transverse support, so that it fit the board size. Fasten this assembly to the board with
the belts. Check if the belts are firmly tighted before each using.
WARNING:
• Don’t let this device work without any
person sitting on. It could be dangerous.
• If you want to detach this device from the
board, loose the belts.
SAFE USING
Before each riding:
1.Sit on the seat.
2.Keep handles horizontally.
3.Turn on the power switch.
Horizontal stop
Keep both handles horizontal.
Backwards
Lift up both handles.
Forward
Push both handles down.
Turn left
Put down the right handle.
Do not move your left handle.
Turn right
Put down the left handle.
Do not move your right handle.
5
4

MAINTENANCE AND CLEANING
Regular maintenance and cleaning can increase the product life.
•Check all parts, wheels and bearings for wear.
•Replace damaged or worn parts immediately.
•Don’t use a lot of water to wash it. Metal parts could go rusty.
•Use only little soapy water (cold or lukewarm).
•Use a duster cloth to clean it.
•Don’t use any chemical cleaners.
TERMS AND CONDITIONS OF WARRANTY AND CLAIMS
1.The K1 brand device is free from design and material defects that could affect its functionality,
provided that the instruction manual provided at the conclusion of the contract was followed.
2.The warranty covers only the territory of United States, and the warranty period for K1 devices
is12 months, counting from the date of sale of the equipment, however, not longer than 15
months from the date of production placed on the product. Product warranty is 12 months from
the date of sale of the equipment.
3.Defects revealed during the guarantee period will be removed free of charge within the
shortest possible time, not exceeding 21 business days from the device being physically accepted
to the site. If it is necessary to bring spare parts from abroad, the deadline may be extended by
another 30 days.
4.This warranty does not cover damage resulting from the fault of the customer, in addition, the
guarantor is not liable for damages and losses resulting from the use of the device being
repaired
5.By the provisions of this warranty, further-reaching claims for damages are excluded, unless
they result from the mandatory provisions of law. This text is only a brief description of the terms
of the warranty. Full warranty terms and information can be found at gyroorboard.com
EXPLANATION OF SYMBOLS
This symbol means that the product must not be disposed of the
combination of waste electrical and electronic equipment together
with other waste. You can prevent potential negative effects on the
environment and human health that could arise from inappropriate
handling of waste from used electronic equipment if the product is
disposed of properly.
The symbol means that the packaging contains an instruction manual
that must be read before use.
7
6

SAFETY INSTRUCTIONS
Read this manual carefully before use and keep it for future reference.
Checking if all components, like screws and nuts fit well. Check wheels and bearings before use.
Pay attention to speed limits.
Don’t expose yourself or others to danger while riding. Don’t ride on steep slopes or on uneven surface.
Use it only according to attached manual. Don’t do any improper adjustment or maintenance. This could
decrease safety of this equipment.
Incorrect using can cause serious injuries.
Check this equipment regularly and be aware that worn or used parts must be replaced immediately.
Do not use if you notice any damage at the product.
Do not use it if you find any sharp edges at the product.
Train and gain experience before first riding. Try to learn how to use it properly before first ride. If you are
not sure, ask someone for help or advice.
Pay attention using this equipment on public roads or sidewalks if it is allowed to use. Make sure that you
don’t violate local laws or prescriptions. If you are not sure, ask local authorities.
Don’t use it at public roads (including motorways).
Only one person can use it at the same time. Don’t use it for transportation of other people.
Don’t carry items while riding.
Never use it in darkness or at night time. Don’t use it in worsened visibility conditions.
Wear protectors (elbow, knee, wrist etc.) and helmet before each riding.
This equipment is only for personal using. Don’t use it for commercial purposes.
Don’t let children under 7 use it otherwise you do it at your own and your child risk.
This is not suitable for elderly people and pregnant women.
Don’t ride after drinking or using drugs.
Be familiar with local traffic regulations and comply with local laws. Have respect to pedestrians.
Control you speed and pay attention to your all facts, which would influence your riding. Good visibility is
very important.Don’t exceed the speed limit and observe the weight limit to avoid an accident.
In case of any accident, stay in place and wait for help.
When you ride along with other users, keep safe distance between each other to avoid a collision.
Other activities (such as: phone using, listening the music etc.) can distract your attention from riding. This
is not recommended.
Don’t ride at slippery or wet roads and don’t use it during the rain. Don’t ride on uneven surface. Don’t use
it in snow or frozen area. Avoid dirt and small stones. Use it only on flat and clean surface.
CONTACT
89
