Razor Siege User manual

Owner’s Manual
Version: 2_01_10
NOTE: Manual illustrations are for demonstration purposes only. Illustrations
may not reflect exact appearance of actual product. Specifications subject to
change without notice.
Read and understand this entire manual before
allowing child to use this product!
For assistance contact Razor. DO NOT RETURN TO STORE.
Item Number:
13055899
Siege Caster Scooter
™
For warranty assistance, please contact
Razor at 866-467-2967

AN IMPORTANT MESSAGE TO PARENTS: This manual contains
important information. For your child’s safety, it is your responsibility to
review this information with your child and make sure that your child
understands all warnings, cautions, instructions and safety topics. Razor
USA recommends that you periodically review and reinforce the information
in this manual with younger riders and that you are required to inspect and
maintain your child’s caster scooter to insure their safety.
GENERAL WARNING: Caster scooter riding can be a hazardous
activity. Caster scooters can and are intended to move and it is therefore
possible to get into dangerous situations and/or lose control and/or fall.
If such things occur you can be seriously injured or die. LIKE ANY OTHER
MOVING PRODUCT, USING A CASTER SCOOTER CAN BE A DANGEROUS
ACTIVITY AND MAY RESULT IN INJURY OR DEATH EVEN WHEN USED
WITH PROPER SAFETY PRECAUTIONS. USE AT YOUR OWN RISK AND USE
COMMON SENSE.
•Alwayswearsafetyequipmentsuchasahelmet,kneepadsandelbow
pads. Always wear a helmet when riding your caster scooter and keep the
chinstrap securely buckled.
•Alwayswearshoes.
•Rideonsmooth,pavedsurfacesawayfrommotorvehicles.
•Avoidsharpbumps,drainagegratesandsuddensurfacechanges.Caster
scooter may suddenly stop.
•Avoidstreetsandsurfaceswithwater,sand,gravel,dirt,leavesandother
debris. Wet weather impairs traction, braking and visibility.
•Donotrideatnight.
•Avoidexcessivespeedassociatedwithdownhillrides.
•Adultsmustassistchildrenintheinitialadjustmentprocedurestounfold
scooter, adjust handlebar and steering height and finally to fold scooter.
•Obeyalllocaltrafcandscooteringlawsandregulations.
•Watchoutforpedestrians.
•Donotexceed143lbs(65kgs)totalweightonthecasterscooter.
•Donotallowchildrenunderageeight(8)tousethecasterscooter.All
children and preteens should ride with adult supervision at all times.
•Riderweightdoesnotnecessarilymeanachild’ssizeisappropriatetot
or maintain control of the caster scooter.
•Theskillrequiredtoridethisproductmaybegreaterthanthatrequiredto
ride a traditional kick scooter.
•Aparent’sdecisiontoallowhisorherchildtoridethisproductshouldbe
based on the child’s maturity, skill and ability.
•Refertothesectiononsafetyforadditionalwarnings.
ACCEPTABLE RIDING PRACTICES AND CONDITIONS
Direct parental supervision is required. Caster scooters are meant to be
used only in controlled environments free of potential traffic hazards and
not on public streets. Do not allow your child to ride a caster scooter in any
areas where vehicle traffic is present. The child must maintain a hold on the
handlebars at all times. Never allow more than one child at a time to ride
a caster scooter. Never use near steps, sloped driveways, hills, roadways,
alleys or swimming pool areas. Keep fingers and other body parts away from
the product when folding or unfolding. Adults must not allow children to
assist in folding or unfolding the caster scooter.
Do not ride a caster scooter in wet weather. Caster scooters are intended for
use on solid, flat, clean and dry surfaces such as pavement or level ground
without loose debris such as rocks or gravel. Wet, slick or uneven and rough
surfaces may impair traction and contribute to possible accidents. Do not ride
acasterscooterinmud,ice,puddlesorwater.Avoidexcessivespeedsthat
can be associated with downhill rides. Never risk damaging surfaces such as
carpet or flooring by use of a caster scooter indoors. Do not ride at night or
when visibility is impaired.
PROPER RIDING ATTIRE
Always ensure child is wearing proper protective equipment such as an
approved safety helmet. A helmet may be legally required by local law
or regulation in your area. A child should always wear shoes, never ride
barefooted or in sandals and should keep shoelaces tied and out of the way
of the wheels.
FAILURE TO USE COMMON SENSE AND HEED THE ABOVE WARNINGS
FURTHER INCREASES RISK OF SERIOUS INJURY. USE AT YOUR OWN RISK
AND WITH APPROPRIATE AND SERIOUS ATTENTION TO SAFE OPERATION.
USE CAUTION.
WARNING: ALWAYS INSPECT THE CASTER SCOOTER PRIOR TO
RIDING. Properly inspecting and maintaining your caster scooter can reduce
the risk of injury. Always inspect your caster scooter before riding and
regularly maintain it.
WARNING: CHECK LOCAL LAWS REGARDING CASTER SCOOTER
USE. Check local laws and regulations to see where and how you may use
your Razor caster scooter legally. In many states and local areas caster
scooter riders are required BY LAW to wear a helmet. Check local laws
and regulations regarding laws governing helmet use and caster scooter
operation in your area.
SAFETY WARNINGS
Safety Warnings ............................................................ 1
Before You Begin........................................................... 2
Set Up and Usage Instructions...................................... 3
Check Before Riding...................................................... 4
Caster Scooter Parts List .............................................. 5
Safety Tips ..................................................................... 6
Warranty ........................................................................ 6
CONTENTS
1

Removecontentsfrombox.Removethefoamseparatorsthatprotectthecomponentsfromdamageduringshipping.
Inspectthecontentsoftheboxforscratchesinthepaintanddentsthatmayhaveoccurredduringshipping.Because
yourcasterscooterwasassembledandpackedatthefactory,thereshouldnotbeanyproblems,eveniftheboxhasa
few scars or dents.
BEFORE YOU BEGIN
2
WARNING: DO
NOT USE NON-RAZOR
PRODUCTS WITH YOUR
CASTER SCOOTER.
Razor scooters have been built to
certain Razor design specifications.
The original equipment supplied at
the time of sale was selected on
the basis of its compatibility with
the frame, fork and all other parts.
Certain aftermarket products may
or may not be compatible. Use of
any non-Razor parts will void your
warranty.
q Required Tools
Need Help? Visit our web site for updates and a list of authorized service centers at www.razor.com
or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM Pacific Time.
3mm&5mm
allen wrench
Handlebars
Quick-release lever
Extension/steeringtube
Joint lever/pivoting mechanism
T-bar
Collar clamp
Front fork
Deck
Caster

WARNING: Failure to
properly engage the spring-loaded
buttons may cause the handlebars
to dislodge while riding and may
cause you to lose control and
fall. When correctly engaged the
handlebars will not rotate nor will
they move sideways. Note that
when properly engaged, the spring-
loaded buttons are clearly visible in
the holes on the T-bar.
2Make certain the spring-loaded
button engages the hole in the
T-bar for each handlebar.
1Insert and secure the left and
right handlebars by pressing the
spring-loaded buttons and
inserting them into the T-bar.
SET UP AND USAGE INSTRUCTIONS
1To release the folding mecha-
nism, hold the T-bar with one hand
between the collar clamp and the
quick-release lever and place one
footonthedeckplate.Pulllever(A)
on folding mechanism outward. Then
pullupontheredreleaselever(B)
and pull handlebars upward until
steering tube is locked into place.
Move folding mechanism lever
inward to lock in place.
2The Joint lever is spring-loaded
and will automatically lock in the
upright position when fully upright.
Note: If tension on folding
mechanismlever(A)istootight/too
loose, carefully twist the black knob
located on the opposite side of the
lever(A)totighten/loosentheten-
sion so you can secure the steering
tube in place.
WARNING: Keep
your fingers clear of the pivoting
mechanism when folding or
unfolding the scooter. Make sure
others are standing clear.
1To adjust the height of the
handlebars,unlocktheextension
tube by pulling outward on the
quick-release lever and pushing the
buttonlocatedontheextension
tube. Slide the T-bar to the desired
height and secure by pushing
inward on the quick release lever.
2The tension of the quick-release
lever can be adjusted by tightening
or loosening the allen bolt. Be care-
ful not to over-tighten. You should
be able to open and close the quick-
release lever by hand.
WARNING: Failure to
properly secure the quick-release
lever may cause the T-bar to slide
up or down while riding which
may cause you to lose control
and fall. With the quick-release
properly adjusted and secured,
the handlebars will not move up or
down.
Installing the Handlebars
3
Folding/Unfolding the Scooter
Adjusting the Handlebar Height
BA

Usingthe5mmAllenwrench,checkthatthecollarclampboltistightenedsecurely.
Note: If the handlebars are not properly aligned with the front wheel, loosen the bolt on the collar clamp and position
the front wheel until it is perpendicular with the steering tube; re-tighten bolt on colllar clamp to lock in place.
q Collar Clamp
q Wheels and Bearings
Under normal circumstances and conditions, Razor wheels and wheel bearings are maintenance free. Nonetheless, it
istheresponsibilityoftheownerorguardiantoperiodicallyinspectthewheelsforwearandtear,theaxleforproper
tightness, and bearings for side-to-side play and loose parts. When a wheel or wheel bearing develops play, this is an
indicationofexcesswearandreplacementisnecessary.ReplaceimmediatelywithonlygenuineRazorwheels.Worn
wheels and bearings are considered normal wear-and-tear and are not covered by the Razor Warranty. Wheels other
than genuine Razor wheels may not be compatible with your Razor caster scooter. The use of anything other than
genuine Razor replacement parts may affect your safety and will void your warranty.
q Cleaning Your Caster Scooter
Wipe with a damp cloth to remove dirt and dust. Do not use industrial cleaners or solvents as they may damage the
surfaces. Do not use alcohol, alcohol-based or ammonia-based cleaners as they may damage or dissolve the plastic
components or soften the decals or decal adhesive.
q How to Ride
With your hands on the grips and holding the scooter upright, place one foot on the scooter deck, leaving your other
foot on the ground for stability. Roll the scooter back and forth a bit to make sure you are comfortable and secure on
it before taking off. When you are ready to go, simply use your ground foot to push off and begin rolling. Once rolling,
the Siege™ Caster Scooter’s unique design will allow you to gain speed without having to step down and drift around
corners as though on ice! To gain speed without stepping down, simply sway the back end of the scooter back and
forth. This fishtail motion will begin to propel the scooter forward, eliminating the need to step down and pedal. In or-
der to drift around corners, all you have to do is lean the rear deck plate into the turn. The degree of drift is completely
up to you and is controlled by a combination of how fast you’re going and how hard you lean into the drift.
WARNING: Wheelies
and other stunt-type riding reduces
your ability to maneuver and
control your caster scooter. Take
the necessary precautions, such as
wearing appropriate protective gear
and practice in a area free from
obstructions.
4
CHECK BEFORE RIDING

Keep your caster scooter running for years with genuine Razor parts. Visit our web site or e-mail us for more information on spare part availability.
(Specicationssubjecttochangewithoutnotice.)
CASTER SCOOTER PARTS LIST
1
2
3
4
5
6
7
9
10
11
8
12
13
15 14
9
9
1. Grips
2. Handlebars
3. T-Bar
4. QuickReleaseLever
5. Extension/SteeringTube
6. CollarClamp
7. HeadsetBearings(upper/lower)
8. FrontFork
9. AxleBolts
10. 125mmFrontWheel
11. Supporting Tube
12. 64mmRearWheel
13. Caster
14. Deck
15. FoldingMechanism
5

Be Careful!
You will see people on TV and maybe even people you know doing
tricks and stunts. These are people who have been practicing on
scooters for a very long time. Don’t try something until you are
ready. Avoid steep inclines and don’t ride too fast — you can lose
control and fall. Skateboard parks are not designed for scooters.
Never ride in traffic or on the street and watch your surroundings
for pedestrians, bikers, boarders, scooter riders and skaters.
Maintain a hold on the handlebars at all times.
Razor Limited Warranty
The manufacturer warranties this product to be free of manufacturing defects
foraperiodof6monthsfromdateofpurchase.ThisLimitedWarrantydoes
not cover normal wear and tear of wheels and bearings or any damage,
failure or loss caused by improper maintenance or storage.
This Limited Warranty will be void if the product is ever
•usedinamannerotherthanforrecreation
•modiedinanyway
•rented
The manufacturer is not liable for incidental or consequential loss or damage
due directly or indirectly to the use of this product.
Razordoesnotofferanextendedwarranty.Ifyouhavepurchasedan
extendedwarranty,itmustbehonoredbythestoreatwhichitwas
purchased.
WARRANTY
Need Help? Visit our web site for updates and a list of authorized service centers at www.razor.com
or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM Pacific Time.
Printed in China for:
Razor USA LLC
P.O. Box 3610
Cerritos, CA 90703
Copyright © 2003-2010 Razor USA, LLC. All rights reserved. RAZOR and the Razor Logo De-
sign are among the registered trademarks of Razor USA LLC in the United States and/or select
foreign countries. Siege™ is a trademark of Razor USA.
For your records, save your original sales receipt with this manual and write
the serial number below.
__________________________________________
Loose Parts
Check and secure all fasteners before every ride. Make sure the
steeringtubeclamps,steeringtubeextensionquickrelease,
and handlebars spring buttons are locked properly in place
before riding.
Replacement Parts
For a complete selection of parts, visit our website at
www.razor.com.
Safety Gear
Always wear proper protective equipment such as an approved
safety helmet. Elbow pads and kneepads are recommended.
Alwayswearshoes(lace-upshoeswithrubbersoles),neverride
barefooted or in sandals, and keep shoelaces tied and out of the
way of the wheels.
SAFETY REMINDERS
q
q
q
PRE-RIDE CHECKLIST
6
01/2010
DO NOT RETURN TO STORE
Failure to follow these instructions may damage
your caster scooter and void your warranty.
q
Item Number:
13055899
