Swan Analytical Instruments AMI Turbiwell User manual

Operator’s Manual
Firmware V6.23 and higher
AMI Turbiwell
A-96.250.511 / 091120

© 2020, Swan Analytische Instrumente AG, Switzerland, all rights reserved.
The information contained in this document is subject to change without notice.
Customer Support
Swan and its representatives maintain a fully trained staff of technical specialists around
the world. For any technical question, contact your nearest Swan representative, or the
manufacturer:
Swan Analytische Instrumente AG
Studbachstrasse 13
8340 Hinwil
Switzerland
Internet: www.swan.ch
E-mail: [email protected]
Document Status
Title: AMI Turbiwell Operator’s Manual
ID: A-96.250.511
Revision Issue
02 July 2009 including auto-drain
03 Jan 2010 incl. W/LED, initial demonstration of performance
04 Jan. 2012 Flow measurement with deltaT flow sensor
Calibration functionality implemented
05 Feb. 2013 Update to FW release 5.30
Initial demonstration of performance removed.
06 Aug. 2013 Matching function added, mainboard v 2.4
07 Jan. 2014 Wet Verification added.
08 March 2016 Mainboard V2.5, firmware 6.00
09 July 2020 Mainboard V2.6

A-96.250.511 / 091120
AMI Turbiwell
3
Table of Contents
1. Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1. Warning Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2. General Safety Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3. Restrictions for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2. Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1. Instrument Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.2. Instrument Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.1. Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.2. Mounting of Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.3. Installation of Sample Degasser Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.4. Installation of deltaT Option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.5. Installation of Flowcontroller Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.6. Connect Sample and Waste . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.7. Electrical Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.7.1 Connection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.7.2 Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3.8. Relay Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
3.8.1 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
3.8.2 Alarm Relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
3.8.3 Relay 1 and 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3.9. Signal Outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3.9.1 Signal Output 1 and 2 (current outputs). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3.10. Interface Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3.10.1 Signal Output 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3.10.2 Profibus, Modbus Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3.10.3 HART Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
3.10.4 USB Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4. Instrument Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.1. Adjusting the deltaT Flow Sensor (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.2. Calibration, Matching and Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.3. ppm Calculation, e.g. “Oil in water” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5.1. Function of the Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5.2. Measured Values and Symbols on the Display. . . . . . . . . . . . . . . . . . . . . . . . . 52
5.3. Software Structure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
5.4. Changing Parameters and Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

A-96.250.511 / 091120
AMI Turbiwell
4
6. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.1. Maintenance Schedule. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.2. Cleaning the Measuring Chamber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6.3. Cleaning the Degasser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
6.4. Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
6.5. Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
6.5.1 Swan Verification Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
6.5.2 Wet Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
6.6. Longer Stop of Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
7. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
7.1. Calibration Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
7.2. Matching Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
7.3. Verification Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
7.4. Error List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
7.5. Replacing Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
8. Program Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
8.1. Messages (Main Menu 1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
8.2. Diagnostics (Main Menu 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8.3. Maintenance (Main Menu 3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
8.4. Operation (Main Menu 4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
8.5. Installation (Main Menu 5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
9. Program List and Explanations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
1 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
2 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
3 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
5 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
10. Default Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
11. Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
12. Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

A-96.250.511 / 091120
AMI Turbiwell
Safety Instructions
5
AMI Turbiwell–Operator’s Manual
This document describes the main steps for instrument setup, opera-
tion and maintenance.
1. Safety Instructions
General The instructions included in this section explain the potential risks
associated with instrument operation and provide important safety
practices designed to minimize these risks.
If you carefully follow the information contained in this section, you
can protect yourself from hazards and create a safer work environ-
ment.
More safety instructions are given throughout this manual, at the re-
spective locations where observation is most important. Strictly fol-
low all safety instructions in this publication.
Target
audience
Operator: Qualified person who uses the equipment for its intended
purpose.
Instrument operation requires thorough knowledge of applications,
instrument functions and software program as well as all applicable
safety rules and regulations.
OM Location Keep the AMI Operator’s Manual in proximity of the instrument.
Qualification,
Training
To be qualified for instrument installation and operation, you must:
read and understand the instructions in this manual as well as
the Material Safety Data Sheets.
know the relevant safety rules and regulations.

A-96.250.511 / 091120
AMI Turbiwell
Safety Instructions
6
1.1. Warning Notices
The symbols used for safety-related notices have the following
meaning:
DANGER
Your life or physical wellbeing are in serious danger if such warn-
ings are ignored.
Follow the prevention instructions carefully.
WARNING
Severe injuries or damage to the equipment can occur if such
warnings are ignored.
Follow the prevention instructions carefully.
CAUTION
Damage to the equipment, minor injury, malfunctions or incorrect
process values can be the consequence if such warnings are ig-
nored.
Follow the prevention instructions carefully.
Mandatory
Signs
The mandatory signs in this manual have the following meaning:
Safety goggles
Safety gloves

A-96.250.511 / 091120
AMI Turbiwell
Safety Instructions
7
Warning Signs The warning signs in this manual have the following meaning:
Electrical shock hazard
Corrosive
Harmful to health
Flammable
Warning general
Attention general

A-96.250.511 / 091120
AMI Turbiwell
Safety Instructions
8
1.2. General Safety Regulations
Legal
Requirements
The user is responsible for proper system operation. All precautions
must be followed to ensure safe operation of the instrument.
Spare Parts
and
Disposables
Use only official SWAN spare parts and disposables. If other parts
are used during the normal warranty period, the manufacturer’s war-
ranty is voided.
Modifications Modifications and instrument upgrades shall only be carried out by
an authorized Service Technician. SWAN will not accept responsibili-
ty for any claim resulting from unauthorized modification or alter-
ation.
WARNING
Electrical Shock Hazard
If proper operation is no longer possible, the instrument must be
disconnected from all power lines, and measures must be taken
to prevent inadvertent operation.
To prevent from electrical shock, always make sure that the
ground wire is connected.
Service shall be performed by authorized personnel only.
Whenever electronic service is required, disconnect instrument
power and power of devices connected to.
– relay 1,
– relay 2,
– alarm relay
WARNING
For safe instrument installation and operation you must read and
understand the instructions in this manual.
WARNING
Only SWAN trained and authorized personnel shall perform the
tasks described in this document.

A-96.250.511 / 091120
AMI Turbiwell
Safety Instructions
9
1.3. Restrictions for use
Sample Re-
quirements
Flow rate: 20–60 l/h
Temperature: 1–45 °C.
Swan recommends that the sample temperature is no
more than 20 °C above the ambient temperature.
The outlet has to be pressure-free against atmosphere.
Sample degasser: Only to be used for turbidity below 1 FNU/
NTU.
Flow rate of sample inlet at degasser: 10–12 l/h.
Maximum turbidity of the sample:
– Turbiwell 7027 and Power: 200 FNU
– Turbiwell W/LED: 100 NTU
CAUTION
Wrong measured values due to dirty optical components.
Touching the optical components in the cover of the measuring
cell may result in wrong measured values.
Cleaning and re-calibration at SWAN is necessary.
Never touch the optical components.

A-96.250.511 / 091120
AMI Turbiwell
Product Description
10
2. Product Description
Application The AMI Turbiwell is used to measure turbidity in potable water, sur-
face water, effluents and water steam cycles.
The turbidimeter is also suitable for the measurement of other liquids
of which the turbidity correlates with the concentration of a suspend-
ed solid or an emulsified liquid, e.g. oil in water. See chapter ppm
Calculation, e.g. “Oil in water”, p. 48 for details.
Available
Models
The instrument is available in three different models:
AMI Turbiwell 7027: with an IR LED according to ISO 7027
AMI Turbiwell W/LED: with white light LED (approved, alterna-
tive method to US EPA 180.1)
AMI Turbiwell Power: variant on steel panel with IR LED
according to ISO 7027
Configurations
and Options
The AMI Turbiwell 7027 and the AMI Turbiwell W/LED are available
in the following configurations:
Automatic or manual drain valve
Sample degasser (option)
deltaT flow sensor (option)
Flowcontroller (option)
On small panel with remote transmitter
The AMI Turbiwell Power is equipped with a flow meter as standard
and available in the following configurations:
Automatic or manual drain valve
Signal
Outputs
Two signal outputs programmable for measured values (freely
scalable, linear or bilinear) or as continuous control output (control
parameters programmable).
Current loop: 0/4–20 mA
Maximal burden: 510 Ω
Third signal output available as an option. The third signal output can
be operated as a current source or as a current sink (selectable via
switch).
Relay Two potential-free contacts programmable as limit switches for mea-
sured values, controllers or timer for system cleaning with automatic
hold function. Both contacts can be used as normally open or nor-
mally closed.
Maximum load: 1 A / 250 VAC

A-96.250.511 / 091120
AMI Turbiwell
Product Description
11
Alarm Relay Two potential free contacts.
Alternatively:
Open during normal operation, closed on error and loss of
power.
Closed during normal operation, open on error and loss of
power.
Summary alarm indication for programmable alarm values and in-
strument faults.
Input For potential-free contact to freeze the measured value or to interrupt
control in automated installations (hold function or remote-off).

A-96.250.511 / 091120
AMI Turbiwell
Product Description
12
Measuring
Principle
Nephelometric system: A water sample colored by dissolved sub-
stances is a homogeneous system that only attenuates radiation
passing through the sample. A water sample containing undissolved
substances attenuates radiation and, additionally, the insoluble parti-
cles scatter the radiation unequally in all directions.
To obtain the turbidity value of the sample, the diffuse radiation is de-
termined at an angle of 90°.
The AMI Turbiwell uses a non-contact turbidimeter to avoid fouling of
optical surfaces.
The light beam of the LED (light emitting diode) impinges the water
surface and is refracted. At an angle of 90°, the detector measures
the incoming, scattered light.
The barrier avoids measurement errors due to light reflections.
Depending on the model, the LED emits light with a wavelength of
860 nm (near infrared LED) according to ISO 7027 or in the range
from 400 to 600 nm (white LED) as an approved alternative method
to US EPA 180.1.
On-line
Operation
The sample enters at the sample inlet [G]. The constant head [H]
guarantees a constant sample flow into the measuring chamber [J],
and air bubbles are removed. Excess sample overflows directly into
waste 1 [I]. The sample flows into the measuring chamber, fills it, and
then flows via overflow [F] into waste 1. The LED beam impinges con-
tinuously on the calm surface.
A
B
C
LED
Sample
Light beam
D
E
F
Barrier
Detector
Drain
CDAB EF

A-96.250.511 / 091120
AMI Turbiwell
Product Description
13
If the optional sample degasser is used, the sample first flows
through this device before entering the measuring chamber.
The drain valve [K] is used to empty the measuring chamber for
maintenance work like cleaning the measuring chamber or perform-
ing a verification.
Verification For the verification, three different verification kits (low turbidity, high
turbidity, liquid) can be used. The kits are available as an option.
Calibration The AMI Turbiwell is factory-calibrated, therefore it is not necessary
to perform a calibration in the field. The emission intensity of the LED
is monitored by an external photodiode. A loss of intensity due to ag-
ing will be automatically compensated.
To meet the requirements of some public authorities it is possible to
calibrate the instrument with a formazine standard.
A
E
G
H
LED
Detector
Sample inlet
Constant head
I
J
K
Waste 1
Measuring chamber
Manual drain valve waste 2
G
H
II
J
KK
J
E
F
A

A-96.250.511 / 091120
AMI Turbiwell
Product Description
14
2.1. Instrument Specification
Note:
• If the maximum sample temperature of 45 °C is exceeded for a
short time, the instrument will not be damaged.
• Swan recommends that the sample temperature is no more
than 20 °C above ambient temperature. With increasing
temperature difference condensation will form to a higher
extent, but the measurement will not be affected. However, it is
possible that a temperature difference significantly higher than
20 °C will cause condensation directly on the optics, which can
lead to incorrect measurements.
Power Supply AC variant:
DC variant:
Power consumption:
100–240 VAC (±10%)
50/60 Hz (±5%)
10–36 VDC
max. 35 VA
Transmitter
Specifications
Housing:
Range of operation:
Storage and transport:
Humidity:
Display:
aluminum housing with a protection
degree of IP 66 / NEMA 4X
-10 to +50 °C
-30 to +85 °C
10–90% rel., non condensing
backlit LCD, 75 x 45 mm
Sample
Requirements
Flow rate:
Sample temperature:
Inlet pressure:
Outlet pressure:
approx. 20–60 l/h (flow rate through mea-
suring chamber: approx. 10–15 l/h)
1–45 °C (sample temperature max. 20 °C
over ambient temperature)
1–10 bar with flow controller option
pressure free
On-site The analyzer site must permit connections to:
Requirements Sample inlet:
Sample outlet:
Nozzle diam. 10 mm
2 drains diam. 16 mm, tubing 15 x 20 mm,
which must end in a pressure free waste of
sufficient capacity.

A-96.250.511 / 091120
AMI Turbiwell
Product Description
15
Turbidimeter
Specifications
Measuring range: 0.000–200.0 FNU, Turbiwell 7027
0.000–200.0 FNU, Turbiwell Power
0.000–100.0 NTU, Turbiwell W/LED
Precision: ±(0.003 FNU +1% of reading)
Accuracy (based
on formazine):
Range 0–40 FNU:
±(0.01 FNU +2% of reading)
Range >40 FNU:
±5% of reading
Response time:
Chamber volume:
Calibration:
Light emitting diode:
t90 typically 3 min
0.75 l
Factory-calibrated with formazine
- IR LED (860 nm) or
- white light LED (400–600 nm)

A-96.250.511 / 091120
AMI Turbiwell
Product Description
16
Dimensions
Turbiwell 7027
and Turbiwell
W/LED
Panel:
Dimensions:
Screws:
Weight:
PVC
400x850x200 mm
6 pieces, 5 or 6 mm diameter
11.0 kg
Exit Enter
AMI Turbiwell
30 mm / 1.18"
13 mm / 0.51"
6 x dia. 6.5 mm / 0.26"
412 mm / 16.22" 850 mm / 33.46" 824 mm / 32.44"
374 mm / 14.72"
400 mm / 15.75"

A-96.250.511 / 091120
AMI Turbiwell
Product Description
17
Dimensions
Swansensor
Turbiwell
Turbidity meter mounted on small PVC plate for use with separate
transmitter.
Dimensions:
Screws:
Weight:
400x420 mm
4 pieces, 5 or 6 mm diameter
3.5 kg
13 mm / 0.51"
4 x dia. 6.5 mm / 0.26"
420 mm / 16.54" 394 mm / 15.51"
374 mm / 14.72"
400 mm / 15.75"
30 mm / 1.18"

A-96.250.511 / 091120
AMI Turbiwell
Product Description
18
Dimensions
Turbiwell
Power
Panel:
Dimensions:
Screws:
Weight:
stainless steel
400x850x150 mm
4 pieces, 8 mm diameter
14.0 kg
13 mm / 0.51"4 x dia. 10 mm / 0.39"
850 mm / 33.46" 824 mm / 32.44"
374 mm / 14.72"
400 mm / 15.75"
Exit Enter
AMI Turbiwell

A-96.250.511 / 091120
AMI Turbiwell
Product Description
19
2.2. Instrument Overview
A
B
C
D
Panel
Transmitter
Cover with optical
measurement system
Measuring chamber
E
F
G
H
Quick fastener screw
Waste 1
Drain valve
deltaT flow sensor (option)
A
B
C
D
E
F
G
H

A-96.250.511 / 091120
AMI Turbiwell
Installation
20
3. Installation
3.1. Installation Checklist
On-site
requirements
AC variant: 100–240 VAC (10%), 50/60 Hz (5%)
DC variant: 10–36 VDC
Power consumption: 35 VA maximum.
Protective earth connection required.
Sample line with sufficient sample flow and pressure (see Instrument
Specification, p. 14).
Installation Mount the instrument in vertical position.
Display should be at eye level.
Connect the sample inlet and waste lines.
Adjust the measuring chamber to horizontal position with the adjust-
ing screw. Check with spirit level.
Electrical Wiring Do not switch on the Instrument until all electrical connections have
been made.
Connect all external devices like limit switches, current loops and
pumps, see Connection Diagram, p. 38.
Connect power cord.
Power-up Turn on the sample flow and wait until the measuring chamber is
completely filled.
Switch on power.
Instrument
Setup
Program all parameters for external devices (interface, etc.).
Program all parameters for instrument operation (limits, alarms).
Run-in time Let the instrument operate for 24 h without interruption at normal
sample conditions to rinse out any pollution from manufacturing and
transport.
Matching Each verikit has to be matched with the current calibration values
before it can be used for a verification.
Verification Never perform before the run-in time is over and before the mea-
sured value is stable.
Can be performed to verify the device functions.
