Swann activair SH16810N User manual

20L Dehumidifier
Model: SH16810N
Help line
0333 220 6050
SH16810N_IM.indd 1 06/05/2020 09:23

2
• When using the unit, please observe the following safety
precautions:
• Unplug the power supply cord before cleaning or storage.
• The appliance can be used indoors but not in laundry rooms.
• Do not set the unit close to heat-generating devices or near
flammable and dangerous materials.
• Never put your fingers or objects into the intake or discharge
ducts.
• Do not sit or stand on the unit.
• Discard water that has collected in the tank as required
• Do not operate the dehumidifier in a closed area such as
inside a closet, as it may cause a fire
• Do not sue the unit near edible items, objects of art, or
scientific materials
• Install drain piping at a downhill grade to make sure that
condensed water can be drained continuously.
• If the power supply cord is damaged it must be replaced by
the manufacture or a similarly qualified person in order to
avoid a hazard.
• The appliance must be positioned so that the plug is
accessible.
• Please keep a distance 20 cm around unit and the wall or
other objects to ensure air circulation.
• The appliance shall be installed in accordance with local
national wire regulations.
• The appliance cannot be used in public transportation.
• This appliance can be used by children aged from 8 years
and above if they have been given supervision or instruction
concerning use of the appliance in a safe way and if they
understand the hazards involved. Cleaning and user
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
SH16810N_IM.indd 2 06/05/2020 09:23

3
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
maintenance shall not be made by children unless they are
older than 8 and supervised. Keep the appliance and its
cord out of reach of children aged less than 8 years.
• Appliances that are obviously damaged must not be
operated.
• WARNING: Do not use means to accelerate the defrosting
process or to clean, other than those recommended by the
manufacturer.
• The appliance shall be stored in a room without continuously
operating ignition sources (for example: open flames, an
operating gas appliance or an operating electric heater).
• Do not pierce or burn.
• Be aware that refrigerants may not contain an odour.
• Appliance shall be installed, operated and stored in a room
with a floor area larger than 4 square metres.
• Servicing shall be performed only as recommended by the
manufacturer.
• The appliance shall be stored so as to prevent mechanical
damage from occurring.
• Any person who is involved with working on or breaking into
a refrigerant circuit should hold a current valid certificate
from an industry-accredited assessment authority, which
authorizes their competence to handle refrigerants safely
in accordance with an industry recognized assessment
specification.
• Servicing shall only be performed as recommended by the
equipment manufacturer. Maintenance and repair requiring
the assistance of other skilled personnel shall be carried
out under the supervision of the person competent in the
use of flammable refrigerants.
SH16810N_IM.indd 3 06/05/2020 09:23

4
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
• Appliance is filled with flammable gas R290.
• Any repairs you need, contact the nearest authorised
Service Centre.
The refrigerant gas
contained in the circuit of
this device is isopropane
(R290), low pollutant but
flammable gas.
When transporting and
installing the unit, take care
not to damage any part of
the refrigerant circuit.
Read the instructions for
use:
Read and observe the
safety instructions before
using the device. Keep this
leaflet and inform potential
users as it contains impor-
tant information.
User Manual. Identify the
location where the user
manual is stored or iden-
tify information about the
instructions for use. Indicate
that the operating instruc-
tions must be taken into ac-
count when using the device
or control near the location
of the symbol
Service manual; Read the
technical manual: To indicate
that a machine or equipment
requires service. To indicate
that the service manual
should be consulted. To iden-
tify the location where the
service manual is stored.
Caution: Risk of fire
Caution: Risk
of fire
SH16810N_IM.indd 4 06/05/2020 09:23

5
Description: 20L Dehumidifier
Model: SH16810N
Input Voltage: 220-240V ~ 50Hz
Power: 310 Watts
Water tank capacity: 4 Litres
Refrigerant/charge: R290 / 80g
The dehumidification capacity is rated at a room temperature of 30C with a relative humidity of 80%.
The operational temperature is in the range of 5 - 35C and max relative humidity of 80%. If the room
temperature is outside of this range, the unit will not operate normally.
Low Temperature Operation with Automatic Defrost
When the unit is running in a room temp. between 5 - 12C, it will be stop to defrost for every 30 minutes
When the unit is running in a room temp between 12 - 20C, it will be stop to defrost for every 45 min-
utes
TECHNICAL DATA
CLEARANCE
Maintain the minimum clearance around
the dehumidifier when the unit is operating
as shown in the drawing.
SH16810N_IM.indd 5 06/05/2020 09:23

6
GET TO KNOW YOUR PRODUCT
1. Control panel
2. Handle
3. Wind deflector
4. Castor
5. Filter compartment
6. Water tank
7. Power cord
CONTROL PANEL
SH16810N_IM.indd 6 06/05/2020 09:23

7
OPERATION
The Digital display has numerous functions:
1. When the unit is plugged in, it will indicate the room humidity level.
2. When you set the humidity, it will indicate the humidity that you have
selected
3. When you program the time for the unit to turn on and off, it will
show the hours.
4. When the room humidity is lower than 35%, it will show “35”
5. When the room humidity is higher than 95%, it will show “95”
OPERATING INSTRUCTIONS
The buzzer will sound several times when the unit is powered on. The LED will show
the room humidity for 3 seconds, then it will automatically turn off.
1. Turn on/off, press:
2. Humidity setting, press: Then press: or to select humidity level.
40% to 80%, in 5%, increments. The LED display will flash when adjusting. Stop
pressing for 5 seconds, it will return to normal display. The default value of humidity
is 55%.
3. Fan speed setting, press: Press repeatedly to cycle through the fan speeds.
The corresponding LED light will illuminate.
4. Swing setting, press: After the machine has started the louvres will swing
back and forth. Press again to stop.
5. Timer setting, press: when the unit is stopped, then press or to set
start time. Start time range is between 1 - 24 hours.
To set run time: With machine running press then press or to set how
long the unit will run for before it switches itself off. Run time range is 1 - 24 hours.
Please note: if the tank gets full during the selected run time, the unit will stop, a
buzzer will sound and the tank full indicator will illuminate.
SH16810N_IM.indd 7 06/05/2020 09:23

8
OPERATION
Emptying the Drainage Tank
1. Lightly press on the sides of the tank with both hands
and pull the tank out gently.
2. Discard the collected water.
3. If the drainage tank is dirty, wash it with cold or lukewarm water. Do not use
detergent, scouring pads, chemically treated dust cloths, gasoline, benzene, thinner,
or other solvents, as these can scratch and damage the tank and cause water leak-
age
4. When replacing the drainage tank, press the tank firmly into place with both
hands. If the tank is not positioned properly, the “TANK FULL” sensor will be acti-
vated, and the dehumidifier will not operate.
SH16810N_IM.indd 8 06/05/2020 09:23

9
OPERATION
Continuous Water Drainage
The unit features a continuous drainage port. Using a plastic pipe not included (in-
ner diameter of 10mm) inserts into the drain hole (on intermediate plate), site the
other end of the pipe to a permanent drain.
CLEANING & MAINTENANCE
Always unplug the appliance and keep it away from any socket before cleaning.
• To clean the outer surface of the appliance, use a lightly damp cloth. Then, dry it thor-
oughly with a soft, dry cloth before using again.
• Do not use any cleaning or chemical products of any kind. Do not let water enter the
openings on the dehumidifier.
• When the appliance is not being used for prolonged periods, ensure that the filter and
water tank is cleaned well. Don’t allow water to sit in the appliance for long periods!
• Unplug from the socket and store in its packaging.
To clean the air filter:
• Open the inlet grille first and
remove the air filter.
• Run a vacuum cleaner lightly
over the surface of the air filter
to remove dirt. If the air filter is
exceptionally dirty, wash it with
warm water and a mild cleanser
and dry thoroughly.
To re-fit, offer the filter up to the front of the humidifier and fit the grille over it. Then
snap into place.
SH16810N_IM.indd 9 06/05/2020 09:23

10
TROUBLE SHOOTING
Problem Possible cause Solution
The unit doesn’t operate Check power cord Connect power cord
Is the tank full indicator
blinking? Is tank properly
fitted?
Empty tank. Refit tank
correctly.
Is temperature of the
room above 35C or
below 5C?
Unit cannot run in these
temperatures
Dehumidifying function
doesn’t work.
Is the air filter clogged? Clean the air filter
Is the intake duct or dis-
charge duct obstructed?
Remove the obstruction
No air is discharged Is the air filter clogged? Clean the air filter
Operation is noisy Is the unit tilted or un-
steady?
Move unit to a more suit-
able location
Is the air filter clogged Clean the air filter.
SPARES
The following spares are available via our web site:
SH16810N01 - air filter
www.swan-brand.co.uk
SH16810N_IM.indd 10 06/05/2020 09:23

11
WARRANTY
This product is guaranteed for 2 years from the date of original purchase. If any defect arises due to faulty
materials of workmanship the faulty products must be returned to the place of purchase. Refunds or
replacement is at the discretion of the store.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• Swan Products Ltd has limited liability for incidental or consequential loss or damage.
• This guarantee is valid in the UK and Eire Only.
BS PLUG
The wires in the mains lead are coloured in accordance with the following code:
BLUE NEUTRAL
BROWN LIVE
As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings
identifying the terminals on your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or
coloured black. The wire which is coloured BROWN must be connected to the terminal which is marked
with the letter L or coloured red.
WARNING: THIS APPLIANCE IS DOUBLE INSULATED. DO NOT CONNECT ANY WIRE TO THE EARTH PIN
DISPOSAL OF UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You
are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items. Please visit www.weeeireland.ie for access to information
about the recycling of electrical items purchased in Ireland. The WEEE directive, introduced in
August 2006, states that all electrical items must be recycled, rather than taken to landfill. Please arrange
to take this appliance to your local Civic Amenity site for recycling, once it has reached the end of its life.
SH16810N_IM.indd 11 06/05/2020 09:23

www.swan-brand.co.uk
Copyright © Swan Products Ltd.
PO Box 3117, Stoke-on-Trent ST4 9GD
Est.1931
We love
what we do
s
2year
GUARANTEE
we’re proud
of our quality
Scan this QR code
to hear about
our story
Find us on Facebook
*
* on selected products
SH16810N_IM.indd 12 06/05/2020 09:23
