Swann SD6080N Series User manual

2.5L Fryer
Model: SD6080N
Help line
0333 220 6050 v1.3
SD6080N_IM.indd 1 17/01/2018 09:56

2
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
When using any electrical appliance, basic safety
precautions should always be followed including the
following:
1. Always ensure that the voltage on the rating label
corresponds to the mains voltage in your home
2. Incorrect operation and improper use can damage the
appliance and cause injury to the user.
3. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards
involved. children shall not play with the appliance.
4. Check the power cord and plug regularly for any damage.
If the cord or the plug is damaged, it must be replaced by
the manufacturer or qualified person in order to avoid an
electrical hazard.
5. Do not use the appliance if it has been dropped or damaged
in any way. In case of damage, take the unit in for examination
and/or repair by an authorised service agent.
6. Never immerse the unit in water or any other liquid for
cleaning purposes.
7. Remove the plug from the socket by gripping the plug. Do
not pull on the cord to disconnect the appliance from the
mains. Unplug the unit when not in use or before cleaning
8. The use of accessory attachments that are not
recommended or supplied by the manufacturer may result
in injuries, fire or electric shock.
SD6080N_IM.indd 2 17/01/2018 09:56

3
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
1. Do not let the cord hang over the edge of a table or
counter. Ensure that the cord is not in a position where it
can be pulled on inadvertently.
2. Do not allow the cord to touch hot surfaces and do not
place on or near a hot gas or electric burner or in a heated
oven.
3. Do not use the appliance on a gas or electric cooking top
or over or near an open flame.
4. Use of an extension cord with this appliance is not
recommended. However, if it is necessary to use an extension
lead, ensure that the lead is suited to the power consumption
of the appliance to avoid overheating of extension cord,
appliance or plug point. Do not place the extension cord
in a position where it can be pulled on by children or animals
or tripped over.
5. This appliance is not suitable for outdoor use. Do not use
the appliance for anything other than its intended use.
6. Do not carry the appliance by the power cord.
7. Do not leave the appliance unattended during use.
8. Always operate the appliance on a smooth, even, stable
surface. Do not place the unit on a hot surface.
9. The manufacture does not accept responsibility for any
damage or injury caused by improper or incorrect use, or for
repairs carried out by unauthorised personnel.
10. In case of technical problems, switch off the product
and do not attempt to repair it yourself. Return the appliance
to an authorised service facility for examination, adjustment
or repair.
SD6080N_IM.indd 3 17/01/2018 09:56

4
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
Always insist on the use of original spare parts.
Failure to comply with the above mentioned precautions and
instructions, could affect the safe operation of this product
Your appliance must never be switched on through an
external timer or any kind of separate remote control system
DO NOT USE SOLID FAT OR LARD IN THIS PRODUCT
This appliance is intended to be used in household and similar
applications such as: staff kitchen areas, in shops, offices
and other working environments; farm houses; by clients in
hotels, motels and other residential type environments; bed
and breakfast type environments.
SD6080N_IM.indd 4 17/01/2018 09:56

5
PARTS
Specification
Model No. SD6080N
230V~50/60Hz
1800W
1. VIEWING WINDOW 8. THERMOSTAT KNOB
2. LID 9. POWER LIGHT
3. INNER COVER 10. BASKET HANDLE
4. FILTER SYSTEM 11. HANDLE BUTTON
5. HOUSING 12. OPEN BUTTON
1
2
3
4
5
6
13
12
11
10
9 8 7
14
6. POWER CORD 13. OIL POT
7. WORKING LIGHT 14. FRY BASKET
KEEP AWAY FROM CHILDREN!
DO NOT DRAPE CORD!
CAUTION: SURFACES BECOME HOT DURING USE
SD6080N_IM.indd 5 17/01/2018 09:56

6
HOW TO USE
Before first use please ensure all packaging is removed. Wash the basket in warm
soapy water. Rinse and dry thoroughly
Press the lid open button and the lid will pop up. To remove the basket, pull the han-
dle button toward you and lift the handle. The basket will lift. Pull straight upward to
remove the basket completely. It is best to become familiar with this mechanism
before using the product
TO REMOVE THE LID
To remove the lid, lift the lid to a vertical position and pull it upwards.
Note: It is useful to be able to remove the lid, as it can be put in the dishwasher to
clean the metal mesh filter. We recommend doing this every 30 fries or so. Please
ensure the lids is WELL drained of water and dried thoroughly before refitting to the
fryer.
SD6080N_IM.indd 6 17/01/2018 09:56

7
HOW TO USE
1. Pour between 2-2.5 litres of oil into the fryer. The level of oil must be between
the MAX and MIN level marked on the surface of the pot.
2. Use only good quality vegetable oil or sunflower oil for deep frying. Olive oil or
solid fat is not to be used
3. Smear the viewing window with a little oil
4. Plug in the mains and set thermostat to the required temperature (see the
reference menu on product) The temperature light will go out when the set
temperature is reached
5. Add food (as dry as possible) into the basket first. Do not overload basket. Place
food of uniform size into the basket so that it cooks evenly. Be sure to dry all
food before frying
6. Place the basket back into the fryer and close the lid. Turn the BASKET knob
down to have basket and food immersed in the oil. Do not add water or wet
items to the cooking oil, even small amounts of water will cause oil to spatter.
After cooking, lift the basket out of the oil to drain. Push the LID-RELEASE BUT-
TON to open the lid.
HINTS
Use only metal kitchen utensils with insulated handles in hot oil.
Care should be taken when frying, especially when children are nearby.
Take into account the food type and select the temperature for frying. As a general
guide, food that has been pre-cooked in some way needs a higher temperature and
less cooking time than raw food.
CLEANING
• Disconnect from power supply before cleaning.
• Allow the oil to cool completely. Oil or fat retains its temperature for a long time after
use
• Do not attempt to move or carry the fryer while it is still hot.
• Oil can be reused several times. However, sunflower oil will need to be changed more
frequently than vegetable oil.
• Oil should be filtered after use each use for maximum oil life.
• After draining the oil, the fryer should be wiped out with absorbent paper then with damp
cloth and a little detergent and finally cleaned with a dry cloth. The interior of the fryer
has a non-stick surface. To avoid damage, no abrasives or sharp instruments should be
used.
• The exterior can be cleaned with damp cloth, don’t use abrasives or scouring pads.
• The basket can be washed in warm soapy water.
• The whole lid can be removed and put in the dishwasher to clean the metal mesh filter.
Ensure it is well drained and dry before refitting to fryer
SD6080N_IM.indd 7 17/01/2018 09:56

8
The wires in the mains lead are coloured in accordance with the following code:
BLUE NEUTRAL
BROWN LIVE
GREEN/YELLOW EARTH
As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings
identifying the terminals on your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or
coloured black. The wire which is coloured BROWN must be connected to the terminal which is marked
with the letter L or coloured red. The wire which is coloured GREEN/YELLOW must be connected to the
terminal which is marked with the letter E or (earth symbol) and is coloured GREEN or GREEN/YELLOW.
WARNING: THIS APPLIANCE MUST BE EARTHED
BS PLUG
WARRANTY
This product is guaranteed for 2 years from the date of original purchase. If any defect arises due to faulty
materials of workmanship the faulty products must be returned to the place of purchase. Refunds or
replacement is at the discretion of the store.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• Swan Products Ltd has limited liability for incidental or consequential loss or damage.
• This guarantee is valid in the UK and Eire Only.
SD6080N_IM.indd 8 17/01/2018 09:56

9
DISPOSAL OF UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You
are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items. Please visit www.weeeireland.ie for access to information
about the recycling of electrical items purchased in Ireland. The WEEE directive, introduced in
August 2006, states that all electrical items must be recycled, rather than taken to landfill. Please arrange
to take this appliance to your local Civic Amenity site for recycling, once it has reached the end of its life.
