Swann A851 User manual

A851 Vari-Focal HD
Dome Security Camera
EN
For use with Swann 4400 Series HD DVRs
INSTRUCTION MANUAL

1
Congratulations on your purchase of this A851
Vari-Focal HD Dome Security Camera. A highly
versatile surveillance camera with manually ad-
justable zoom and focus to suit any environment.
It has a variable focal length of 2.8 – 12mm and
offers up to 4x optical zoom on your target area.
This lets you adjust the field of view from 27° -
65° for the perfect frame. The 720p (1 Megapixel)
resolution is perfect for close up detail such as
license plates, facial detail, clothing and more.
With the latest infrared cut filter, it has amazing
night vision to 65ft/20m and excellent clarity in
low light.
Important note - All jurisdictions have specific
laws and regulations relating to the use of cam-
eras. Before using any camera for any purpose,
it is the buyer’s responsibility to be aware of all
applicable laws and regulations that prohibit or
limit the use of cameras and to comply with the
applicable laws and regulations.
Important safety instructions
1) Make sure product is fixed correctly and sta-
ble if fastened in place.
2) Do not operate if wires and terminals are ex-
posed.
3) This camera can only be used in combination
with Swann’s DVR4-4400, DVR8-4400 or DVR16-
4400 digital video recorders.
4) Use a small flat-head screwdriver to adjust the
zoom and focus settings. Do not overexert when
adjusting both settings.
Warning - Modifications not approved by the
party responsible for compliance could void us-
er’s authority to operate the equipment.
Important safety instructions.s
Introduction

2
Choosing a location for your Camera
With a vari-focal camera, you have some flexibility on
where the camera can be mounted. Some things to
consider when choosing a location -
1) What you want to monitor and where you’ll get the
best view of it.
2) How you’re going to connect the camera to your
DVR; remember that cables and connections should
be kept out of the weather.
3) It’s recommended to mount your cameras at an
elevated position to keep out of harm’s way.
4) Make sure your camera has minimal sky in it as
the light in daylight can make the foreground of the
image darker.
5) Think about the most likely way a potential offender
may approach your home.
6) The camera’s casing is resistant to water and
tampering. However, the cable and connector are
vulnerable and require protection.
7) Even though the camera is weather and water-
resistant, prolonged exposure to adverse weather
conditions such as sunlight or excessive moisture,
may eventually damage the internal components of
the camera and adversely affect its performance.
8) When running your cable, try to avoid bending it at
sharp angles.
9) Don’t put your cable near live electrical wiring. AC
electricity generates radio “noise” which can interfere
with the signal from your camera.
10) A vari-focal camera allows you to adjust between
its top and bottom limits on its view angle. This means
that you have the ability to manually set both the view
angle and level of zoom. Have a scenario where you
need to zoom in on a gate or other access point?
Use the 12mm setting (27° and about 4x zoom).
Need a wide angle view? Go with 2.8mm (65°). Need
something in between? Try 6mm (43°) or 9mm (30°).

3
Connecting your Camera
1. Connect the video output and power
input connection on the camera to the
corresponding connections on the video
& power cable.
2. Connect the video connection
on the other end of the video &
power cable to one of the video
inputs on the DVR.
3. Connect the power adapter
to the power input on the video
& power cable then connect
the power connection to a
spare wall socket.
4. Use the zoom
function to adjust the
viewing angle and
the focus function to
sharpen the image.
PTZ
75 3 1
86 4 2
eSATA
HDMI LAN & USB B A DC 12V
IN
VGAVIDEO IN AUDIO OUT
AUDIO IN
Video & Power Cable
Power Input
Video Output
ZOOM
FOCUS
Zoom
Focus
Power Adapter
1
1 2
3

4
Mounting your Camera
The camera can be mounted onto a flat, vertical
or horizontal surface using the supplied mounting
screws. The surface must have sufficient strength
to hold the camera. Hardwood, brick or masonry
surfaces are recommended.
• Remove the three screws located at the base
of the camera. Position the base in the location
you want to mount it, and mark the screw holes
on the surface to position the screws. Secure
the base using the appropriate screws for the
surface you are mounting to.
• If you’re mounting to a wooden surface, screw
the base directly to the surface.
• When mounting to a masonry surface, you’ll
need to use the included wall plugs.
• Screw the camera module to the base but don’t
overly tighten each screw.
Aiming the camera:
• The dome cover can be rotated left or right.
• The camera module can be aimed in almost any
direction from wherever you choose to mount it.
• Use the zoom function to adjust the viewing
angle and the focus function to sharpen the
image.
• After you’ve finished adjusting the viewing angle,
tighten each screw to lock the camera module’s
position in place.
Positioning the cables:
• Avoid bending the cable at sharp angles.
• Avoid positioning the cable near live electrical
wiring. AC electricity generates radio noise
which can interfere with the signal from the
camera.

5
Limited Warranty - Terms & Conditions
Swann Communications warrants this product
against defects in workmanship and material for
a period of one (1) year from its original purchase
date. You must present your receipt as proof of
purchase for warranty validation. Any unit which
proves defective during the stated period will be
repaired without charge for parts or labour or re-
placed at the sole discretion of Swann. The end
user is responsible for all freight charges incurred
to send the product to Swann’s repair centres. The
end user is responsible for all shipping costs in-
curred when shipping from and to any country
other than the country of origin.
The warranty does not cover any incidental, acci-
dental or consequential damages arising from the
use of or the inability to use this product. Any costs
associated with the fitting or removal of this prod-
uct by a tradesman or other person or any other
costs associated with its use are the responsibility
of the end user. This warranty applies to the origi-
nal purchaser of the product only and is not trans-
ferable to any third party. Unauthorized end user
or third party modifications to any component will
render all warranties void. By law some countries
do not allow limitations on certain exclusions in
this warranty. Where applicable by local laws,
regulations and legal rights will take precedence.
For Australia: Our goods come with guarantees
which cannot be excluded under Australian Con-
sumer Law. You are entitled to a replacement
or refund for a major failure and for compensa-
tion for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of ac-
ceptable quality.

6
FCC Verification
This equipment has been tested and found to comply with the limits for Class B digital device, pursu-
ant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected
• Consult the dealer or an experienced radio/TV technician for help
These devices comply with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) These devices may not cause harmful interference.
(2) These devices must accept any interference received, including interference that may cause unde-
sired operation.
