Swann SW331-PR6 User manual

1
SW331-PR6
www.swannsecurity.com SR331-PR6-60010-040909
Operating Instructions
PRO-650™
™
™
Advanced security made easy
Operating Instructions
PRO-650™
™
™
Advanced security made easy
Pan Tilt Zoom
Dome Camera

222
FCC Verification:
NOTE: This equipment has been tested and found to comply with the limits for
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are de-
signed to provide reasonable protection against harmful interference in a residen-
tial installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encouraged to try to cor-
rect the interference by one or more of the following measures:
· Reorient or relocate the receiving antenna
· Increase the separation between the equipment and the receiver
· Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected
· Consult the dealer or an experienced radio/TV technician for help
IMPORTANT NOTE: Prohibition against eavesdropping
Except for the operations of law enforcement officers conducted under lawful
authority, no person shall use, either directly or indirectly, a device operated pursu-
ant to the provisions of this Part for the purpose of overhearing or recording the
private conversations of others unless such use is authorized by all of the parties
engaging in the conversation.
WARNING: Modifications not approved by the party responsible for compliance
could void user’s authority to operate the equipment.
IMPORTANT SAFETY INSTRUCTIONS:
· Make sure product is fixed correctly and stable if fastened in place
· Do not operate if wires and terminals are exposed
2
Before You Begin
FOR BEST RESULTS:
This is a semi-professional 360º PTZ dome camera, conforming to PELCO P/D stand-
ards. To obtain the best image quality, please use a high quality cable, particularly if
the cables required length exceeds 100ft/35m. For the highest video quality, use a
cable with a solid copper inner conductor and shielded with copper braid.

3
Contents
Before You Begin
Before you Begin 2
Table of Contents 3
Quick Reference 3
Overview 4
Package Contents 4
Layout of the Camera and PTZ Controller 5
Layout of Remote Control 6
Connecting the Camera 8
Mounting the Camera 10
Setting the Command Address 12
Configuring the PTZ Controller 12
Connecting Multiple PTZ Systems 13
Operating the Camera 14
Advanced Operation 16
Additional Functions 17
Troubleshooting Guide 18
Technical Specifications 19
Warranty / Technical Support Rear Cover
Quick Reference
PRO-650 4” Pan, Tilt, Zoom Dome
Default PTZ Configuration
Default Command Address: 1
Protocol: Pelco-D
Baud Rate: 2400bps
RS485 Polarity:
+A Purple Wire
- B White Wire

444
Overview
Congratulations on your purchase of this 360º PTZ Camera Dome! This system
is an ideal solution for monitoring a large area – a combination of a quality Sony
CCD image sensor mounted in a contained dome with the option to pan fully
360º. Nothing will be out of sight for long!
Whether you wish to do this using the full complement of manual controls, or
program a detailed surveillance program for the camera to run, the PRO-650 gives
you all the options you need to simply and effectively monitor a large range of
locations without the hassle of multiple cameras.
The PRO-650 features an included fully functional PTZ controller, great low-light
performance and a 3x optical zoom – great for getting up close to what you want
to see. All this comes mounted in a simple but elegant 4” dome.
PRO-650 PTZ 4” Dome Camera
Roof Mounting Arm/Bracket
Wall Mount Arm
PTZ Controller/Receiver
Remote Control
Mounting Screws
Operating Instructions
2 x Power Adaptors (DC 12V)
50ft (15m) RS485 Command Cable
Spare Camera Cable & Plug Board
Package Contents
If any of these components are missing, contact Swann Technical Support.
Contact details are on the back cover of this booklet.

55
Layout of the Camera and PTZ Controller
1. Wall-Mount Arm
For mounting the PRO-650 Dome to a wall, post or similar vertical surface.
2. Ceiling-mount Bracket
For mounting the PRO-650 Dome to the underside of a ceiling or overhang.
3. Camera Housing
Contains the camera, PTZ unit and associated circuitry and electronic components.
4. Dome Cover
Protects the camera.
4
1. Wall-Mount Arm
1
3
2
5. LED Display
Displays the current status of the PTZ controller.
6. DC 12V
Connect the supplied power adaptor to this socket.
7. RS485 Port
Insert the RS485 plug into this socket.
8. RS485 Plug
Connect the end of the purple and white control wires into this plug, using the attached screws
to secure wires in position. The PURPLE wire is “+”, the WHITE wire is “-”.
8
6
7
Rear View
Front View
5

666
Layout of Remote Control
DISP (Display)
Toggles the display on the front of the PTZ Controller,
showing the Command Address, Protocol and Baud
Rate.
PRESET (HOLD to define)
Changes or accesses preset points.
PATTERN (press and HOLD)
Allows for the programming of lists of preset points for
the camera to view in sequence.
DELETE (press and HOLD)
Will remove a Preset Point or Pattern.
RUN
Commands the system to begin executing the
programmed pattern.
HOME
Master Preset Point. Whilst not in Cruise Mode
(see page 15) the camera will automatically
return to this position whilst idle.
A & B
Master Preset Points. They are defined in the same way
as other Preset Points (see page 14). They operate as
shortcut buttons thereafter.
0 – 9
The number buttons. Used to enter a numerical value
into the PTZ controller.
C
Clear. Removes the last digit entered into the controller,
somewhat like the ‘backspace’ key on your computer.
-/--
Allows for the entry of more than one digit at a time. “-”
represents a single digit, whilst “--” indicates space to
enter two digits.
S1 ~ S4
Shortcut to the SPEED setting for the
camera. 1 is the slowest shortcut speed,
4 is the highest.
P1 ~ P8
Shortcuts to PRESET POSITIONS. Pressing
the button will send the camera directly to
the corresponding PRESET POSITION.
5

7
ZOOM + / -: Increases and decreases the level of magnification, respectively.
The PRO-650 features a 3x optical zoom.
FOCUS + / - and
IRIS OPEN / CLOSE
The PRO-650 PTZ Dome features automatic focus and exposure adjustment.
As a result, you will not need to use these buttons whilst operating the PRO-
650. They’ve been included on the remote so that the controller can be used
for multiple PTZ systems (including ones without automatic focus and exposure
adjustment) if you choose.
ARROWS
Used to move the camera.
SHOT
Readies the controller to accept a numerical
value for a Preset Position, noted on the display
by the letter “P”.
CAM
Readies the controller to accept a new
Command Address (use numerical buttons to
enter a new value).
ENTER
Confirms a selection. Whilst the camera is
moving, ENTER will hold it still.
SPEED
Adjusts the speed at which the camera moves.
Higher numbers represent faster speeds.
AUTO
Toggles Auto-scan Mode on and off. Whilst in
Auto-scan Mode, the camera will continually
move as it attempts to sweep the entire field
of view as efficiently as it can.
FORMOREdetailedinformationaboutoperating
the PTZ features of the PRO-650 Dome, see
Operating the Camera on page 14.
ESC (Escape)
Stops the current action and returns to the
default interface. Aborts half completed
sequences, such as programming a cruise
pattern.
SETUP
Readies the PTZ Controller to accept new
values for Baud Rate and Protocol. The “p”
and “d” are protocols (Pelco-P and Pelco-D
respectively) and the numerical value is the
abbreviated Baud Rate.
S1 ~ S4
Shortcut to the SPEED setting for the
camera. 1 is the slowest shortcut speed,
4 is the highest.
P1 ~ P8
Shortcuts to PRESET POSITIONS. Pressing
the button will send the camera directly to
the corresponding PRESET POSITION.

888
Connecting the Camera
12
5
7
4
3
After running the camera cable through the mounting arm/bracket,1.
attach to the main plug on the camera circuit board (see opposite).
Connect the BNC connector and power connectors to an extension2.
cable.
Connect the purple and white wires to the RS485 plug, and insert3.
the RS485 plug into the RS485 port on the rear of the controller (see
opposite).
Attach the BNC plug on the end of the extension cable to a BNC input4.
on your TV, VCR or DVR (as applicable). If your monitor/recorder does
not have a BNC connection, then use a BNC to RCA adaptor.
Connect the power connector on the end of the extension cable to5.
the DC plug of a power adaptor (DC 12V).
Attach the power connector on the rear of the PTZ controller to a6.
power supply (DC 12V).
Plug the DC 12V power adaptors into mains power.7.
6

9
1. Connecting the Camera Cable
Before mounting the camera, it is
important to connect it correctly.
Run the cable through the mounting1.
arm or bracket you would like to
use.
Make sure you run the cable2.
through starting with the camera
end (not the end with the BNC
connectors - they’re too big to fit).
Once the cable has been pulled3.
through, plug it into the top of the
camera.
If you’re planning to mount the4.
dome outside, cover the screw
threads with a silicon sealant before
screwing the unit together. Failing
to do so will compromise the
waterproofing of the dome.
Then, screw the mounting arm/5.
bracket onto the dome.
Be careful not to damage the connectors
on the end of the cable or to the camera,
particularly when unplugging the
camera, as the connectors are fragile!
3. Connecting the RS485 Cables
Remove the RS485 plug from the back of1.
the PTZ controller.
Insert the WHITE wire into the -B side of2.
the RS485 plug, and screw into place.
Insert the PURPLE wire into the +A side of3.
the RS485 plug, and screw into place.
Plug the RS485 plug into the RS485 port4.
on the back of the PTZ controller.
Note: If you need a longer cable to reach
the location you’d like to put the PTZ
controller, the RS485 cable can be extended.
If you are unfamiliar with cable construction
and maintenance, we suggest getting a
professional to do this.

101010
NOTE: Before you begin, be sure that there are no live electrical cables in the area
you wish to mount the camera.
To mount the camera:
After connecting the camera as described on page 8 and installing the cables as
shown on page 9, place it in the desired location. Then, using an appropriate screw
for the surface you’re fixing the dome to, screw the arm/bracket into place.
Ensure you have enough cable coming through the mounting arm/bracket to
connect it to your system. If you want to run the cables through a wall/ceiling, be
sure to drill a hole for the cable as well.
Placement Tips
For best results, carefully consider where you want to mount the dome. Whilst the
optimal placement solution will vary form application to application depending
on intent of installation, the environment of use and the lighting conditions
encountered there, there are a few points which are almost universal.
What you want to monitor:
The most obvious factor to consider when planning where to install your camera is
the question of what you wish to monitor, and how a movable PTZ system can be
incorporated into your specific environment.
Ensure that the camera is located close enough to what you want to monitor•
to capture the required details. For example, if you wish to capture the details
of a face, the camera should be located within a dozen feet (about 4m) of
the subject. This is also true if trying to read printed information - such as a
vehicle’s registration plate.
Try to place the camera in an position that a potential security threat will find•
it difficult to avoid.
A strategy which is often effective is to monitor entrances and exits - after all,•
a security threat has to get in somewhere.
Mounting the Camera
