Swema SwemaFlow 126 User manual

Operating instructions
vers 1.02 CW20160621
SWEMA AB
Pepparv. 27
123 56 FARSTA, SWEDEN
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Web site: www.swema.com
Contents:
1. Introduction........................ 1
2. Technical data...................... 1
3. Function............................. 2
4. Charging............................. 7
5. Driver Installation................ 7
6. SwemaTerminal 3................ 8
7. PC-menu in instrument....... 9
v
er
s
Direct line [phone] | [email protected]

1.
1. Introduction
Thank you for choosing a quality instrument from Swema.
SwemaFlow 125D measures air flow directly in l/s, m3/h or cfm
(when set to US units).
SwemaFlow 126 includes:
• Flow capture instrument
•
Flow hood 300x300mm for exhaust flow (Some valves also supply)
• Carrying case, USB-cable, charger, Operating instructions
• Calibration certificate
Accessories:
Supply / Exhaust Flow hood 650 x 650 mm, h = 800 mm, Part.no: 769640
Cross for Swirl diffusers, Part no. 769650
Supply / Exhaust Flow hood 250 x 650 mm, h = 800 mm, Part.no: 760740
Exhaust Flow hood 300 x 300 mm, h = 130 mm, Part.no: 761550
2. Technical data
Measuring range:
Air Flow: 1,5... 125 l/s, 5,4... 450 m3/h, 3.2... 260 cfm
Temperature: 0...+50°C, 32...122°F
Barometer: 600... 1200 hPa, 18...35 inHg
Measurement uncertainty:
Air Flow: ±3% read value, min 0,5 l/s
Temperature: ±0,5°C
Barometer: ±3,5 hPa
Back-pressure method uncertainty: ±10% min 1 l/s
At 95% coverage probability in non condensing, non moist air, <80
% RH, non aggressive gases
Measuring method:
Mass flow, net of hot wires
Weight:
1,82 kg (including capture hood 300x300mm and throttle ring)
Direct line [phone] | [email protected]

3. Function
The current flow is presented on the display two times seconds.
Swema Flow 126 can display real or standard flow by measuring air
temperature and barometric pressure.
On/Off (RED button)
Turn on and off the instrument by pressing the RED button. When
turning on the instrument, the display will first show firmware ver-
sion and then battery voltage. ”It will after that go into BP (Back
Pressure) mode. When ”Real” is displayed SwemaFlow 126 the flow
at actual temperature och barometric pressure. To change to stan-
dard flow ”std” (The flow is recalculated to a density at 20°C and
1013hPa) the PC-program SwemaTerminal 3 is used. The program
can be downloaded at www.arwmisure.it
Toggle the display light by pressing the RED button while the BLUE
button is held down. The istrument is shot off automatically after
ten minutes if no button is pressed.
Unit (BLUE button)
By pressing the BLUE button the display toggles between l/s, m3/h,
air temperature (°C) and barometric pressure (hPa). When set to US
units it toggles between cfm, air temperature (°F) and barometric
pressure (inHg).
Mode (GREY button)
Toggle between Back Pressure mode, Flow Factor mode and stored
values (notE).
2.
Direct line [phone] | [email protected]

Flow hood selection
For exhaust flow any hood size can be selected. For supply flow, use
a longer hood (650x650 or 250x650mm) to stabilize the flow.
The included 300x300 hood can be used for supply if it gives the
same result on the valve type as one of the longer hoods.
All hoods to SwemaFlow 126 can be used for exhaust flow measure-
ments.
BP Mode (Back Pressure)
When measuring with any Flow capture the flow may be influenced
by the Flow capture itself. The flow may be throttled. This can be
corrected by using Back Pressure mode. By measuring two times,
with and without an extra throttle ring, SwemaFlow 126 calculates
the flow that reflects the true flow with no capture interference.
It doesn’t matter if you start to measure with or without the throttle
ring the important thing is that one measurement is with the throttle
ring and the other one without. It’s important where the throttle ring
is placed, when measuring with the throttle ring it should always be
placed after the hot wires in the sense of flow direction.
3.
Direct line [phone] | [email protected]

BP Measurement (BLACK button)
Place the hood with the sealing list making a proper seal around the valve.
Start with or without the throttle ring and press the BLACK button
(button on the side).
SwemaFlow 126 will wait 2 seconds to let the
flow stabalize in the flow capture, the display will show ”P1” (Point 1)
and start to count up from 0 to 2 (the stabilization time). It will af-
ter that make a measurement for 5 second during wich the display
will show the measured value. When finished ”P2” (Point 2) will be
shown in the display. Within 1 minute Point 2 need to be measured
otherwise SwemaFlow 126 will return to Point 1. Remove or put on
the throttle ring and press the BLACK button again, SwemaFlow 126
will repeat the same procedure as for P1. When finished the display
will show the True value without any influence by the flow capture.
If the value is flashing it means that something is wrong and the va-
lue might not be correct, if so, make a new measurement. By pres-
sing the GREY button the lowest measurement (with throttle ring) of
the two points are displayed for 2sec before it return to the true va-
lue again. By pressing the BLUE button the higher of the two points
will be displayed for 2sec.
Save measurement (BLACK button held down)
When P1 and P2 is measured the measurement can be saved by
holding down the BLACK button for 2 sec. The display will show
which note number the measurment is saved as and then return to
measuring mode.
If you don’t want to save the measurement just press the BLACK
button and you will return to measurement mode without saving.
4.
Direct line [phone] | [email protected]

Take a measurement with a Flow Factor
To measure with the flow factor displayed next to F press BLACK
BUTTON for less than 2 seconds. To change the flow factor instead
hold down the BLACK button for minimum 2 seconds when F1.00
is shown. The first digit will start flashing. Change value by pres-
sing GREY or BLUE button. When correct value is choosen confirm
by press shortly the BLACK button and the second digit will start
flashing. Reapet the same procedure with the second and third digit.
After the third digit is confirmed the instrument will start measuring
in F-mode. Measuring can be stored in the same way as in BP-mode.
To return to BP Mode press GREY button 3 times (First press will
show FX.XX, second will show notE and the third will take you to BP
mode).
HOLD function (BLACK button)
If the BLACK button is pressed down shortly the display will freeze
the measured value. ”Hold” is shown in the upper left corner of the
display. Press the BLUE button to toggle between the freezed values
(freezed air flow, temperature and barometric pressure).
Realese frozen values by pressing down the BLACK button for less
than 2 seconds.
Save measurement (BLACK button held down)
If a measurement is freezed it can be saved by holding down the
BLACK button for 2 sec. The display will show which note number
the measurment is saved as in the note book and then return to
measuring mode.
Flow Factor Measurement (F-mode)
In Flow Factor mode the flow is multiplied with a flow factor (flow
factor 1.00 will not alter the flow). A flow factor can be used to com-
pensate for example a leakage. Warning: Changing to anything else
than 1.00 will alter the reading from calibration certificate. The dis-
paly will show the text ”Factor” when the instrument is in F-mode.
While in BP Mode change to F-mode by pressing the GREY button.
(Bp-mode does not use a Flow factor) The instrument will change to
F-mode and display F1.00 or the value of flow factor that the instru-
ment used last time in F-mode after being turned on. For example
F1.10 will multiply measured flow with 1.10 and display the result.
5.
Direct line [phone] | [email protected]

Note book (notE)
If GREY button is pressed two times when in BP Mode notE will be
displayed. To enter the note book press the BLACK button. ”Note”
and the number of the last saved note will be shown on the display.
With GREY and BLUE button it’s possible to scroll through the saved
notes. To return to notE press RED button.
To see saved measurement in a note press BLACK button. With
GREY and BLUE button it’s possible to scroll through the saved mea-
surements in the note (air flow, temperature and barometric pres-
sure). To return to notes press the RED button. To erase the note
memory hold down the BLACK button for 2sec, ”E ALL” (Erase All?)
will be shown in the display. To erase the note memory hold down
the BLACK button for 2sec, ”E ALL” (Erase All?) will be shown in
the display. After all notes are erased ”notE” will be shown in the
display, press GREY button to go to BP Mode. Use the PC-program
SwemaTerminal 3 to transfer saved data to PC.
6.
Direct line [phone] | [email protected]

4. Charging
SwemaFlow 125D has built-in rechargeable Li-ion-batteries. Battery
charge time is approxematley 4h. The charger can be connected to
the instrument longer without damaging the battery. The battery
can also be charged with a USB cable connected to a computer. The
green led will have a fixed light during charging, when fully charged
the green led will be turned off. It is recommended not to use the
instrument while charging. Therefor the display is blinking as a war-
ning during charging. Caution! Use only the original charger other
charger can damage the batteries.
Batterinivå
När du slår på instrumentet kommer displayen att visa spänningsni-
vån på batteriet. Ett fulladdat batteri visar ungefär 4,1 V (den kom-
mer att sjunka till 3,8-3.9V ganska snabbt). När spänningen är lägre
än 3,1 V kommer en batteri symbol att börja visas på displayen. När
spänningen är lägre än 2,8 V kommer instrumentet att automatiskt
5. Driver installation
To use SwemaFlow 126 with a Windows 10 PC, just connect the USB
cable and wait for the driver installation to complete. To use Swema-
Flow 125D with an earlier OS driver matching .inf-files must be used
by the OS. The necessary files and drivers are automatically installed
with the free software ”SwemaTerminal 3”.
1. Download ”SwemaTerminal 3”
2. Unzip the file and run the setup file. When the setup is done con-
nect the USB cable to the PC and turn the instrument on. The PC will
now install the necessary drivers automatically.
In case the driver installation dosen`t succeed you can also do it ma-
nually. Open the device manager, right click on ”unknown device” and
then ”update driver”. The drivers can be found at ”C:/Program Files/
Swema” (make sure that the box ”include sub folders” is checked).
7.
Direct line [phone] | [email protected]

8.
6. SwemaTerminal 3
With SwemaTerminal 3 it’s possible change settings, print stored
measurements, update firmware, print calibration protocol. Informa-
tion of what kind of instrument and at which COM-port it’s connec-
ted can be found on the top left side. For SwemaFlow 126 it is only
possible to change settings in ”Terminal Window”.
Firmware update
On www.swema.com the newest firmware version will be possible to
download. To update the firmware first download the new firmware
to your PC. Start SwemaTerminal 3 with the SwemaFlow 125D con-
nected to a USB port with the USB cable.In SwemaTerminal 3 click
on ”File” and then ”Update firmware”. A new window is opened, fol-
low the instructions in that window.
Terminal Window
Under the ”File” dropdown menu it’s possible to open a Terminal
window through SwemaTerminal 3 to access the instrument PC
menu. There is access to for example Averaging time, automatic
shut off time and the possibility to erase saved data (Erase Note-
book).
Direct line [phone] | [email protected]

”Averaging time”:
A higher ”Averaging time” will use more internal samples for the
averaging and give a more stable value.
”Real” or ”Standard flow”:
If set to ”Real” the flow shows as it is at present temperature and
barometric pressure. Standard air flow is used to present the air
flow at standard condition of 1013 hPa (29,9 inHg) and 20 °C (68 °F).
”Auto Shutoff”:
Set in minutes after how long time the instrument will be turned off
if not used. If set to 0 min the auto shutoff is disabled.
”Print calibration certificate” och ”Print Notebook”:
Show SwemaFlow 125D:s calibration certificate and print the stored
measurements to the PC.
9.
7. PC-menu in instrument
After ”Terminal Window” is clicked a new window is opened. Press
”Enter” on the keyboard and the main terminal menu for Swema-
Flow 126 will be opened. To change a setting use the PC keyboard
and press on the corresponding letter.
SwemaFlow 126 Firmware: 1.02 Hardware: 0.9
[T] Averaging Time: 0.2 seconds responsive
[D] Density compensation: Real Flow
[S] Auto Shutoff: 10 minutes
[P] Print Calibration Certificate
[N] Print Notebook
[E] Erase Notebook
[O] Delimiter: Comma
[U] Unit System: US
[H] Charging: On
[ ] Space - Print Measurement Values
Direct line [phone] | [email protected]

”Point” or ”Comma”:
Set point or comma as decimal separator for the the prinout of sto-
red values and for logged measurement to PC.
”US” or ”EU/ASIA”:
Set unit system to US (ft3/min, °F, inHg) or EU/ASIA (l/s, °C, hPa).
Charging On /Off
OBS: When transfering measurements values (with space), charging
should be set to Off because the measurement values can be influ-
enced by the charging.
Space
Sends measurement values to PC.
10.
Direct line [phone] | [email protected]

SWEMA AB
ARROWELD ITALIA Spa
Via Monte Pasubio, 137
36010 Zanè (VI)
Tel: [phone]
Fax: [phone]
[email protected]
www.arwmisure.it
Direct line [phone] | [email protected]
