Swift S30 Series User manual

User Guide: The New S30 Stereo Microscope Series
Version 2.1

1
Welcome to your Swift new S30 Series stereo microscope! Whether you are a seasoned
professional or a beginner hobbyist, Swift has the perfect microscope for you.
This guide will introduce you to the components of your new microscope and help you
begin using it. For more information about our microscopes, software downloads, product
manuals, or customer service requests, please visit www.swiftoptical.com.
Table of Contents
I. Specifications 2
II. Parts of the microscope 3
III. Assembling the microscope 5
IV. Using the microscope 5
V. Maintenance and repair 6
VI. Troubleshooting 7
VII. Warranty information and customer support 8

2
I. Specifications
Model S304 S306 S306S
Observation tube Forward-facing
Binocular 360° Rotatable head
Inclination 45° inclined
Interpapillary distance 55-75 mm
Eyepieces WF10X/20mm, standard
20X/10mm as optional add-ons
Diopter adjustment On left tube, +/-5
Objectives 2X, 4X
Working distance 57mm 63mm 63mm
Focusing travel range 41mm
Max. specimen thickness 68mm 62mm 62mm
Stand
Pillar plain stand Pillar plain stand Slim pillar stand
with transmitted
light, dimmable
Pillar stand with
transmitted light
Pillar stand with
transmitted light
Illumination
Upper incident LED
light
Upper incident LED
light Upper incident &
bottom transmitted
LED lights
Upper incident &
bottom transmitted
LED lights
Upper incident &
bottom transmitted
LED lights
Power supply 110-240V

3
II. Parts of the microscope
S304 with Pillar Transmitted Light Stand
S304 with Pillar Plain Stand
(1) Eyepiece
(2) Diopter adjustment
(3) Forward-facing Binocular head
(4) 2X/4X objectives turret
(5) Fastening knob
(6) Focusing knob
(7) Incident light
(8) Power switch
(9) Stage clips
(10) Stage plate
(11) Pillar transmitted light stand
1
2
3
4
1
0
1
1
9
5
7
6
8
(1) Eyepiece
(2) Diopter adjustment
(3) Forward-facing Binocular head
(4) 2X/4X objectives turret
(5) Focusing knob
(6) Incident light
(7) Power switch
(8) Stage clips
(9) Stage plate
(10) Pillar plain stand
1
2
3
4
5
6
7
8
9
10

4
S306 with Pillar Transmitted Light Stand
S306S with Slim Pillar Transmitted Light Stand
(1) Eyepiece
(2) Diopter adjustment
(3) 360° Rotatable Binocular head
(4) 2X/4X objectives turret
(5) Fastening knob
(6) Focusing knob
(7) Incident light
(8) Power switch
(9) Stage clips
(10) Stage plate
(11) Pillar transmitted light stand
1
2
3
6
4
10
9
11
8
7
5
(1) Eyepiece
(2) Diopter adjustment
(3) 360° Rotatable Binocular head
(4) 2X/4X objectives turret
(5) Focusing knob
(6) Incident light
(7) Power switch
(8) Stage clips
(9) Stage plate
(10) Dimming handwheel
(11) Slim pillar transmitted light
stand
1
2
3
5
4
8
9
6
7
10
11

5
S306 with Pillar Plain Stand
III. Assembling the microscope
The components for the microscope are shipped detached for protection. Open the
Styrofoam packing with care and do not leave any components attached to the packing
being removed. Do not discard any of the packing materials until all of the components
have been identified. Remove the plastic covers from the microscope.
Locate the power cord and plug it in. Locate the power switch on the top of the stand and,
if applicable, select the incident or transmitted illumination as needed.
IV. Using the microscope
Interpapillary adjustment
Adjust the two eyepiece tubes until only one circular field can be seen through the two
eyepieces. If two separate circles appear, the interpapillary distance is too large; if two
overlapping circles appear, the interpapillary distance is too small. The eyepiece tube
allows a flexible adjustment of the interpapillary distance between 54 and 76mm.
(1) Eyepiece
(2) Diopter adjustment
(3) 360° Rotatable Binocular head
(4) 2X/4X objectives turret
(5) Focusing knob
(6) Incident light
(7) Power switch
(8) Stage clips
(9) Stage plate
(10) Pillar plain stand
1
2
3
4
9
10
1
5
6
7
1
8

6
Focusing the microscope
To focus the sample, use the focusing knobs located on both sides of the head holder.
By turning these knobs, the microscope can be moved up or down a certain distance.
This movement is enabled by a “rack and pinion” mechanism.
Using the focusing knob, focus the sample until the image is clear. If the sample cannot
be brought into focus within the travel range of the S303/S304 pole arm and stand, adjust
the microscope head height along the vertical pillar to a working distance of 57mm from
the sample. Remember to tighten the locking screw and support collar after adjusting the
height of the microscope.
Magnification and working distance
Select the desired magnification strength by adjusting the objective turret. Change the
optional eyepieces to increase magnification range.
Total magnification used can be calculated by multiplying the eyepiece magnification by
the objective lens magnification.
V. Maintenance and repair
Cleaning
Keep all lenses clean. Fine dust on the surface of the lens should be gently blown off with
an air canister or wiped off with a soft lens cloth or lens tissue. Stubborn fingerprint
smudges or oil marks can be wiped off with lens tissue moistened with a small amount of
xylene or a 3:7 mixture of alcohol and ether. Never use organic solutions to clean any
other surface (especially the plastic surfaces). If necessary, please choose a mild
detergent.
Storage
After use, cover the microscope with the dust cover provided and store it in a dry and
clean place free from moisture to prevent rust. Remove the eyepieces when not in use,
and place covers on the eyepiece holders.

7
Repair
Do not attempt repairs on your own, particularly on the optical parts. Contact a Swift
Optical representative through our customer service email or phone line with any issues.
VI. Troubleshooting
If you have a problem, you may be able to correct it yourself. Here are some common
issues and easy solutions you can try before calling customer support for service.
*Caution: Never disassemble the electrical, mechanical, or optical components. This
servicing should only be done by a Swift technician.
Issue Possible cause Solution
Double images Interpapillary distance is
not correct
Readjust the eyepieces
Diopter adjustment is not
correct
Readjust the diopter rings
Magnification of each
eyepiece is not the same
Mount eyepieces of the
same magnification
Dirt appears in the field
of view
Dirt on the specimen Clean the specimen
Dirt on the surfaces of
eyepiece
Clean the surfaces
Image is blurry Objective surfaces are
dirty
Clean the objective
Diopter adjustment is not
correct
Readjust the diopter
Focus is incorrect Readjust the focus

8
The focusing knob is not
smooth
The focusing knob is too
tight
Loosen it to a suitable
position
Head keeps slipping
down
The focusing knob is too
loose
Tighten it to a suitable
position
Eyes fatigue easily Diopter adjustment is not
correct
Adjust the diopter rings
Light is too bright Dim the brightness
Illumination does not
work when the switch is
on
No power supply Check the connection
with the power supply
VII. Warranty information and customer support
Our microscopes are manufactured to meet ISO 9001 standards. Swift warranties are as
follows:
● Five (5) Year Warranty for Microscopes: Microscopes come with a five (5) year
warranty against manufacturing defects. Does not cover normal wear, routine
maintenance, add-on accessories, damage resulting from repair by unauthorized
parties, accident, alteration, shipping, misuse or abuse is not covered.
● One (1) Year Warranty for Electrical and Video components. Does not cover light
bulbs, batteries, fuses, or electrical cords.
All warranties start from the original date of purchase. Swift provides the repair or
replacement of warrantied parts for free, including labor, during the warranty period. Proof
of original purchase is required. Buyers are responsible for shipping to and from our
warehouse for warranty services. The warranty does not cover damages resulting from
normal wear and tear, abuse, or unauthorized repairs.

9
*For customers living outside the United States, Swift Optical Instruments, Inc. will
provide standard warranty service. Both inbound and outbound shipping costs
(including duties and taxes) is the responsibility of the consumer.
For more information or to submit a repair request, please contact our Customer
Support department:
North America
Tel: [phone], option 1 (USA)
Email: [email protected]
Europe
Tel: [phone] (UK)
Email: [email protected]
*In order to serve Europe customers efficiently, we recommend to call the hotline during
working hours 8 AM – 4 PM (London Time).
Disclaimer: We are constantly working to improve our instruments and to adapt them in
response to customer feedback. These improvements occasionally involve small
modifications to the mechanical structure and optical design of our microscopes.
Therefore, some descriptions, illustrations, and specifications in this instruction manual
may vary slightly from the microscope you receive.
Swift Optical Instruments, Inc.
[phone]
www.swiftoptical.com
