SwiftSensors SG3-1010 User manual

Quick
Start Guide
Gateway and Sensor
Setup

02 | Swift Sensors Quick Start Guide
Contents
What’s in the Box 03
Coonect Your Gateway with WiFi 04
Connect Your Gateway with Cellular 09
Connect Your Gateway with Ethernet 10
Connect Your Gateway with Power over Ethernet 10
Register Your Gateway 11
Turn On and Add Your Sensors 14
Congure Your Console 16
Add the Swift Console Web App to Your Mobile Phone 18
Troubleshooting 22
Help/Support Resources 24

Swift Sensors Quick Start Guide | 03
Gateway
What’s
in the Box?
Power Supply
Quick Start Guide
Antenna
(SG2-1012 Only)

Connect Your Gateway
Using WiFi
Connect the antenna to gateway.
Plug in gateway.
Wait about 2 minutes until the light turns RED.
PRESS AND HOLD the button in the center of
the gateway label for 1 SECOND to start WiFi
Hotspot setup.
Wait about 20 SECCONDS until the LED light is
SOLID BLUE.
1
2
3
5
4
04 | Swift Sensors Quick Start Guide
*If connecting with Cellular, go to Page 9
*If connecting with Ethernet, go to Page 10

1
After 2 minutes
Press for 1 Second
After 20 seconds, the
light will turn solid blue
2
3
Swift Sensors Quick Start Guide | 05
4
5

Connect to Gateway
WiFi Hotspot
• From your phone, go to Settings > WiFi. Select Swift
Sensors (last four digits of your gateway ID). (It may
take a few minutes before the network appears).
• Scan the QR code on your gateway or below with your
phone, or open your phone’s web browser and enter
192.168.42.1 to access your gateway’s WiFi Setup.
• Tap the Set Up WiFi button. Select your WiFi Network
and tap the blue checkmark.
• Enter your WiFi network password and tap the blue
checkmark.
1
2
3
4
06 | Swift Sensors Quick Start Guide
Gateway Status Lights
• The gateway is booting up. This light is briey visible right
after powering up the gateway.
• The gateway is online and communicating with the Swift
Sensors Cloud.
• Blinking: the gateway is attempting to connect.
Solid: there is no internet at your facility.
• The gateway is oine. If using WiFi, it could not connect
to your WiFi router. Try again with a dierent password.
• Blinking: the gateway is activating Set Up WiFi mode.
Solid: the gateway is in Set Up WiFi mode.
Gateway WiFI Setup
QR Code

1
Swift Sensors Quick Start Guide | 07
2
34

After 20 seconds, your gateway light will turn green indicating
successful connection to the network.
After 20 seconds, the
light will turn green.
08 | Swift Sensors Quick Start Guide

Connect Your Gateway
with Cellular
1. Plug the provided power cable into the gateway.
2. Plug the cellular modem into the gateway’s USB port. If
the Internet light is green after 5 minutes, your gateway
is online. If not, see Troubleshooting.
USB
Cellular
Modem
1
2
After 2 minutes, the
light will turn green.
Swift Sensors Quick Start Guide | 09
2

1. Plug the provided power cable into the gateway.
2. Plug the Ethernet cable into the gateway. If the
Internet light is green after 2 minutes, your gateway is
online. If not, see Troubleshooting.
Connect Your Gateway
using Ethernet
Ethernet
Router
1
1
After 2 minutes, the
light will turn green
Connect Your Gateway
using Power over Ethernet (PoE)
1. Plug the Ethernet cable into the gateway. If the
Internet light is green after 2 minutes, your gateway is
online. If not, see Troubleshooting.
Router
Ethernet
10 | Swift Sensors Quick Start Guide
2

Register Your Gateway to
a New Account*
*If you already have a Swift Sensors account, go to Page 12
1. Go to my.swiftsensors.net
2. Click Create Account.
3. Fill out the form and click Create Account. If you see
an error message, make sure you have connected your
gateway.
4. Click Verify Email in the email you receive from
[e-mail].
5. Enter the password you created in step 2. and click
Verify Email, then click Console. Your new gateway will
appear in your Hardware list.
Swift Sensors Quick Start Guide | 11
2

Register Your Gateway to
an Existing Account
1. Sign in to my.swiftsensors.net
2. Select List in the navigation bar.
3. Select Add Gateway from the Gear menu.
4. Enter the last four digits of your gateway ID and click the
check button to save. Your new gateway will appear in
your Hardware list. If you see an error message, complete
make sure you have connected your gateway.
12 | Swift Sensors Quick Start Guide

Click on the
Gear menu
and select Add
Gateway
Enter the last 4 digits
of your Gateway ID
Swift Sensors Quick Start Guide | 13
2
3
4

Turn On and Add Your
Sensors to Your Account
Your sensor was shipped to you in the “O” state. By simply
turning on the sensor, your gateway will be able to detect it.
14 | Swift Sensors Quick Start Guide
1. To turn your sensor on, CLICK the center button on the
sensor. The green light will blink for 6 times to indicate
that the sensor is on. (Do not press and hold the button
as this will turn the sensor o).
2. Select Add Sensors from the Gear menu. This will
display all available sensors detected by your gateway.
3. Select the sensors that you would like to add to your
account and click the Add button (+). Your Sensor will
now appear in the List view.
1

Swift Sensors Quick Start Guide | 15
Gear Menu
2
3
To Turn O Sensors
HOLD the center button of the sensor until the green light
stops blinking and glows solid for a few seconds to indicate
the sensor is o.

Congure Your Swift Sensors
Console
Please sign in to my.swiftsensors.net and follow the Installation
and Setup Guide on our Online Help page to congure your
console.
1. Setup your gateways and sensors according to location
and function.
2. Create notications and assign them to your measure-
ments and users.
3. Add a cell phone number to your user prole so you can
receive SMS or voice notications.
16 | Swift Sensors Quick Start Guide

Scan the following QR code to access additional
tutorial information within the Console.
Swift Sensors Quick Start Guide | 17

Add the Swift Sensors
Web - App to Your Phone
Apple iOS*
*If using Android, go to Page 20
1. Using mobile Safari, sign into swiftsensors.net with your
user credentials.
2. In the Safari footer, tap the Export button at the bottom
center.
3. In the actions row at the bottom, swipe left and tap Add
to Home Screen.
4. At the top, enter a custom name such as Swift
Sensors and tap Add.
1
2
18 | Swift Sensors Quick Start Guide

3
Add the Swift Sensors
Web - App to Your Phone
Google Android*
1. Using mobile Chrome, sign into swiftsensors.net with your
user credentials.
2. In the Chrome header, tap the icon with three vertical
dots in the upper right corner.
3. Select Add to Home screen from the popup menu.
4. Click Add automatically on the the rst Add to Home
screen page.
5. Click Add on the second Add to Home screen page.
6. Enter a custom name such as Swift Sensors on the third
Add to Home screen page and click Add.
4
Swift Sensors Quick Start Guide | 19

1
2
20 | Swift Sensors Quick Start Guide
3
4
