Swisher L116-336001 User manual

COMMERCIAL PRO
60” FAST FINISH
TRAIL MOWER
OWNER’S
MANUAL
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE., WARRENSBURG MO 640 3
PHONE [phone] FAX [phone] EMAIL [e-mail]
MODEL NO.
FC14560CPKA
FC14560CPKA-CA
Assembly
Operation
Service and Adjustment
Repair Parts
www.swisherinc.com
20 27 REV 16-336
STARTING SERIAL #:
L116-336001
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
IMPORTANT
ade I The
USA
of US and Global Parts

ꁆ ﵇﵇
ˆ 
LIMITED WARRANTY
The manufacturer’s warranty to the original consumer purchaser is: This product is free from
defects in materials and workmanship for the period's shown below beginning from the date
of purchase by the original consumer purchaser. We will repair or replace, at our discretion,
parts found to be defecti e due to materials or workmanship. This warranty is subject to the
following limitations and exclusions:
As required y CFR § 1060.120, the fuel system related components, which have een
certified to this equipment y SAI are to e free of defects in material and workmanship for a
period of two (2) years from the date of purchase y the original consumer purchaser.
1) Engine Warranty All engines utilized on our products ha e a separate warranty
extended to them by the indi idual engine manufacturer. Any
engine ser ice warranty is the responsibility of the engine
manufacturer and in no way is Swisher or its agents responsible
for the engine warranty. The Kawasaki Engine Ser ice Hotline is
1-877-364-6404 or email [e-mail]
2) Commercial Use This product has a 1yr Limited Commercial - 2 Year
Limited Consumer on All Non-Engine Parts from the date
of purchase.
3) Limitations This warranty applies only to products, which have een
properly assem led, adjusted, and operated in accordance with
the instructions contained within this manual. This warranty
does not apply to any product of Swisher that has een su ject
to alteration, misuse, a use, improper assem ly or installation,
shipping damage, or to normal wear of the product.
4) Exclusions Excluded from this warranty are normal wear, normal
adjustments, and normal maintenance.
In the event you have a claim under this warranty, you must return the product to an
authorized service dealer. All transportation charges, damage, or loss incurred during
transportation of parts su mitted for replacement or repair under this warranty shall e orne
y the purchaser. Should you have any questions concerning this warranty, please contact us
toll-free at 1-800-222-8183. The model num er, serial num er, date of purchase, and the
name of the authorized Swisher dealer from whom you purchased the mower will e needed
efore any warranty claim can e processed.
THIS WARRANTY DOES NOT APPLY TO ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES AND ANY IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME
PERIODS STATED HEREIN FOR ALL EXPRESSED WARRANTIES. Some states do not
allow the limitation of consequential damages or limitations on how long an implied warranty
may last, so the a ove limitations or exclusions may not apply to you. This warranty gives
you specific legal rights and you may have other rights, which vary from state-to-state. This is
a limited warranty as defined y the Magnuson-Moss Act of 1975.
2

˨
SAFETY PRECAUTIONS
• Read the manual. Learn to operate this machine safely.
• Always disconnect the spark plug wire and place the wire where it cannot contact the spark plug, to prevent
accidental starting the engine when setting up, transporting, adjusting or making repairs.
• Keep all shields and guards in place.
• Understand the speed, steering and sta ility of this machine. Know the positions and operations of all
controls efore you operate this machine. Check all of the controls in a safe ar
ea efore starting to work with
this machine.
• Allow only responsi le adults who are familiar with these instructions to operate this machine. Never allow
children to operate this machine.
• Clear the area of o jects such as rocks, toys, wire, etc. that can e picked up and thrown y the lade.
• Be sure the area is clear of other people efore mowing. Be aware of the mower discharge direction and do
not point at anyone. Stop the machine if anyone enters the mowing area. Children are often attracted to the
machine and the mowing activity. Never assume that children will remain where you last saw them.
Keep
children under the watchful care of another responsi le adult.
• No riders!
• Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening at all times.
• Do not mow in reverse. Always look down and ehind efore and while acking.
• Turn off the lades when not mowing. Before leaving the machine, turn off the lades and stop the engine.
• Watch for traffic when operating near or crossing roadways.
• Do not operate the mower if it has een dropped or damaged in any manner or if the mower vi rates
excessively. Excessive vi ration is an indication of damage. Repair mower as necessary.
• Dress properly. Do not operate the mower when arefoot or wearing open sandals. Wear only solid shoes
with good traction when mowing.
• Do not operate the machine while under the influence of alcohol or drugs.
• Do not operate on slopes greater than 15 degrees.
• Never tamper with safety devices. Check their proper operation regularly.
• Stop and inspect the equipment if you strike an o ject. Repair, if necessary, efore restarting.
• Never make adjustments or repairs with the engine running.
This Safety Alert Symbol indicates important messages in this
manual. When you see this symbol, carefully read the message that
follows and be alert to the possibility of personal injury.
Read this manual completely. This machine can amputate hands, feet, and throw
objects. Failure to observe the following safety instructions could result in serious
injury or death.
3

矐ڱ
4
SAFETY DECALS
Replace decals immediately if damaged. Order y part num er from Swisher.
OD45- Warning Decal
OD11- No step Decal
OD55- Triangle Danger Decal
OD33- Speed Decal
OD29- Danger Decal
OD43- Flying De ris Decal

5
*Battery cover not shown
Battery Mounting Detail
A U1 battery is required
(not included). Position
battery hold down
bracket as shown.
Tighten nuts so battery
will not shift position.
REQUIRED ASSEMBLY
FRONT WHEEL CASTER ASSEMBLY
1. Remove single nut and washers from caster shaft.
2. Place one washer (NB195) on the shaft of the caster/wheel su assem ly.
3. Slide same shaft through the earing/frame with wheel towards the ground.
4. Place the other washer (NB195) on the shaft; it should e resting on the top earing.
5. Add thin washer (17x195).
6. Thread nyloc jam nut onto shaft.
7. Tighten nut snuggly, making sure shaft threads enter the nyloc of the nut. Over-
tightening
of this nut will bind caster.
8. Repeat process for other front side.
9. Push on plastic dust covers over nut and thin washer until it snaps into place.
REAR WHEEL ASSEMBLY
1. Remove cotter pin from axle and remove thin washer (NB149) from axle. Leave two
NB178 washers on axle.
2. If necessary (to take up space) slide extra washer (NB178) over axle, then wheel (with
valve stem out).
3. Slide on washer (NB149) and replace cotter pin in end of axle.
4. Bend cotter pin so it will not fall out.
5. Repeat process for other wheel.
OFFSET & CENTER TOW HITCH BAR ASSEMBLY
1. Lay out parts according to the diagram.
2. Insert part 661A into part 662 and pin with the hitch pin (H11).
3.
Insert part 661 into part 661A. Choose from the 3 holes to set the desired hitch length. Pin
with a hitch pin (H11).
4. Part 662 slides into the front tu e of the frame. Again, choose from the 3 holes to arrange
desired offset. Pin with a hitch pin (H11).
5. Eliminate step 2 for hitching from the center racket. Only one method can e used at a
time.

끆 ﵇﵇
ˆ 
OPERATING YOUR TRAIL MOWER
INTENDED USE
This Trail Mower is designed to produce a quality finish cut on lawns, golf courses, etc. It is
not designed to clear rush or cut saplings. Your Trail Mower should e towed ehind an
ATV, a golf cart, lawn tractor, or similar approved vehicle. It is not meant for speeds
exceeding 5 mph.
ATTACHING TRAIL MOWER TO TOW VEHICLE
• Place mower ehind vehicle and ack vehicle up to desired attaching position.
• When offsetting Trail Mower do so to side opposite the discharge of the tow vehicle.
• Attach tow hitch (661) to the swivel hitch with hitch pin (H11). Make certain hitch
pin goes completely through each piece and is clipped to prevent accidental
separation.
• Attach red safety tether (H9C) to oth the towing vehicle and to the Trail Mower
toggle switch (685SP), located on the left attery side cover (17614). Its purpose is to
manually stop mower engine or to stop mower engine in case the two machines
ecome separated. (See Motor Base Detail page 14).
• It is extremely important the safety tether is secured properly to both the toggle
switch and the towing vehicle.
STARTING THE ENGINE
See engine manufacturer’s instructions for the type and amount of oil and fuel used. Trail
Mowers with electric start engines will need a attery (sold separately). Swisher
recommends using a standard “U 1 R” lawn & garden attery.
The operation of any mower can produce foreign o jects to e thrown into the
eyes, resulting in severe eye damage. Always wear certified safety glasses or
wide-vision safety goggles over spectacles efore starting any cutting machine and
while operating such a machine.
The operation of any cutter produces sound waves that are damaging to the
human ear. Ear protection is recommended.
CAUTION!
Tragic accidents can occur if the operator is not alert to the presence of
children. Children are often attracted to the machine and the mowing
activity. Never assume that children will remain where you last saw them.
6
IMPORTANT: This engine is not equipped with a spark arrester muffler. It is a iolation of
California Public Resource Code Section 4442 to use or operate the engine on any forest-co ered,
brush-co ered, or grass-co ered land. Other states or federal areas may ha e similar laws.

ڷ
•
Engine must e level to accurately check and fill oil. Do not overfill.
• Make sure the tow vehicle parking rake is set, mower is level, and lades are disengaged.
• Check spark plug wire, oil, and fuel.
• Check all electrical connections (See Schematics).
• Make sure toggle switch is turned “ON” and the red tether is properly attached.
• Set engine idle to “CHOKE” position.
• With feet clear of mower deck, turn key switch to the “START” position and release when
engine egins to run.
• Set engine idle at desired RPM.
BREAKING IN YOUR MOWER
• Set vehicle parking rake or chock wheels to prevent accidental rolling.
• Start engine properly.
• Slowly, engage lade control.
• In a safe environment, i.e. no children, allow lades to rotate and engine to idle for 5
minutes. This reaks in the elts and the engine.
• Stop mower properly.
MOWER HEIGHT ADJUSTMENT
• Adjust while mower is not running.
• The cutting range is approximately 1” to 5.5”. The height should e measured from the
ground to the lade tip without the engine running.
• Rotate height adjust crank handles (H7N) in a clockwise direction to lift the mower deck. A
counter-clockwise direction is used to lower the mower deck.
• Make sure the height adjustment is the same at side crank handles. For est results, see
“SUGGESTED PRACTICE” section. Graduated scales are for reference only, not the
actual cutter height.
• Place crank handle in a retracted position to maintain height adjustment.
STARTING TO MOW
• Adjust the cutting height.
• Dou le check vehicle to mower attachment.
• Start mower engine properly.
• Slowly, activate the lade engage lever (18976
) y rotating it forward and left until the lever
locks into place.
• Carefully mount tow vehicle and start mowing slowly.
STOPPING THE MOWING SESSION
• Pull safety tether to shut toggle switch “OFF”. If the engine fails to stop or if the safety
tether has ecome inopera le, then use Alternative Stopping Method.
CAUTION!
SHUT OFF MOWER ENGINE AND REMOVE SPARK PLUG WIRE FROM
SPARK PLUG BEFORE MAKING ANY ADJUSTMENTS TO THE MOWER.
7

ڷ
ALTERNATIVE STOPPING METHOD
• Bring vehicle to complete stop, shut off engine, and set parking rake.
• Disengage lade engage lever (18976).
• Manually shut toggle and key switches to their “OFF” positions.
• Always remem er to remove keys to avoid irresponsi le usage.
TRANSPORTING MOWER
• Stop mower properly.
• Place mower deck in its highest position.
• If transporting without the use of a tow vehicle, then remove spark plug wire and
place where it cannot contact the spark plug.
SUGGESTED MOWING PRACTICES
• Operate mower engine at full throttle to assure the est cutting performance and
maximum material discharge.
• Allow wet grass to dry. Clumps of wet grass will collect under the mowing deck.
• Mowing should e started with tow vehicle in low gear and increased only as safe
mowing conditions permit. This speed should not exceed 5 mph.
•
The average lawn should e cut to approximately 2.5” during the cool season and to
over 3” during the hot months.
• For a healthier lawn and etter aesthetics, your lawn should e mowed often and
after moderate growth.
• When cutting high or dense grass areas go slowly. Some areas may need to e
mowed twice. The second cut should e at 90 degrees to the first, if possi le.
• Mowing thick or high grass. Raise rear height crank handles to .5”-
.75” a ove the
other two handles.
• Creating a manicured lawn. Lower rear height crank handle to .25”-.5” elow
front of deck. This allows grass lades to e cut twice. It also continually cuts
clippings to produce a mulching effect.
GENERAL TROUBLE SHOOTING
• The mower is not cutting level.
o Level deck, making sure the side crank-handles are equal.
o Check air pressure of all tires; make sure they are equal, and to
manufactures specifications.
o Examine lades for damage, while mower engine is not running.
• The engine will not start.
o
Disengage lades, turn toggle switch to “ON” position, check attery and all
other electrical connections, and inspect spark plug and wire.
o Check for fuel in the engine.
• Engine runs poorly.
o See engine manual.
o Check throttle adjuster.
o Replace fuel, clean fuel filter and fuel line.
IF PROBLEMS PERSIST HAVE A QUALIFIED MECHANIC SERVICE THE
MOWER. NEVER ATTEMPT TO MAKE AN ADJUSTMENT THAT YOU ARE
NOT SURE IS CORRECT. DOING SO CAN CAUSE OTHER PROBLEMS.
8

˨
MOWER MAINTENANCE
GENERAL RECOMMENDATIONS
The warranty on this Trail Mower does not cover items that have een su jected to operator a use or negligence.
To receive full value from the warranty, operator must maintain unit as instructed in this manual.
Some adjustments will need to e made periodically to maintain your unit properly.
All adjustments in this manual should e checked at least once each season.
Periodically inspect and clean excessive de ris inside the attery cover (17340) and elt covers (18391
). Disconnect
spark plug wire efore cleaning.
BEFORE EACH USE
• Check engine oil level on a level surface. Check twice to insure an accurate reading.
• Check condition of air filter; clean and replace as necessary.
• Check lade operation; keep lades in good condition.
• Check for loose fasteners and tighten them as needed.
AFTER EACH USE
• Keep lades sharp.
• Remove fresh grass clippings with garden hose.
• Grass clippings hardened to the underside should e scraped out with a putty knife.
• Keep fluids at proper levels.
• Cover unit to prevent rain or other de ris uildup. Definitely cover the engine.
BEFORE AND/OR AFTER EACH SEASON
• Replace the spark plug.
• Clean or replace the air filter.
• A new spark plug and clean air filter assure proper air-fuel mixture and help your engine run etter and last
longer.
• Check lades and elts for wear. Replace as necessary.
STORAGE RECOMMENDATIONS
CAUTION!
Do not store engine indoors or other poorly ventilated area. Keep engine away from gas appliances
where fumes could contact open flame, pilot lights, or sparks.
If engine is to be stored for 30 or more days, prepare unit as follows:
• Drain fuel outside into an approved container.
• Start engine properly and run until unit is out of fuel.
• Let engine cool.
• Remove remaining gasoline from car uretor and fuel tank to prevent gum deposits from forming within
the engine. Gum deposits can cause malfunction in the engine.
• Store mower with lades disengaged to prevent elts from eing permanently stretched.
BLADE CARE AND SERVICE
For est results cutter lades must e kept sharp. The lades can e sharpened with a few strokes of a file or
grinding wheel. Do not attempt to sharpen lades while they are on the mower. Disconnect spark plug wire before
servicing unit.
Important: Replace blades that have been damaged or deeply nicked.
Important: Check blade and spindle hardware on a regular basis to make sure nuts are tight.
Only a qualified mechanic should e used for any
adjustments, disassem ly or other kind of repairs.

˨
10
FRAME ASSEMBLY
ITEM # QTY .
PART NO.
DESCRIPTION
1 1 3664 Bar - Right Sway
1 3665 Bar - Left Sway
3 1 17600* Weldment - T60 Frame
4 F4157WK Wheel/Tire 5/8" Bearing 13/5/6 NHS; Blk
5 1 66 * Weldment - Tongue Offset Ext ension
6 1 661A* Weldment - Solid Stock Hitch
7 1 661* Weldment - Tongue Hitch Ext ension
8 -- See Caster/Wheel Assembly Detail
ITEM # QTY. PART NO. DESCRIPTION
9 6 NB1 6 Pin - 1/8" X 1" Cott er
10 4 T PB Bushing - Plastic
11 4 NB178 Washer - 5/8 ID X 1 OD 10 GA
1 NB149 Washer - 5/8 ID X 1 OD 14 GA
13 4 H11 Pin - Safety Hitch
14 3 10579 Bushing -Stepped Height Adjust
15 3 H7N Assembly - Height Adjustment
16 3 10038 Bolt - Eye
ONLY INCLUDED ON “CA MODELS
(FOR CALIFORNIA ONLY)
Item # Qty Description Part #
1 1 Carbon Canister - 2.50 Gallon, 3/16 Line 18224
2 2 Cable Tie - Carbon Canister 18219
3 4 Nut - 10-24 Nylon Lock 024900
4 2 Bracket - Carbon Canister, ZT 17127
5 4 Screw - 10-24 X 3/4 Phil Truss Head ZP 024203
Item # Qty Description Part #
1 2 Ubolt - SQ , 3/8-16X2.437 X 3 Lg GR 5 ZY 12447
2 2 Nut - Nylock 1/4-20 NB180
3 4 Nut - Nyloc 3/8-16 ZY NB182
4 1 Mount - For EPA/CARB Gas Tank 18331*
5 1 Fuel Tank - 2.5 Gallon, Carb 18214
6 1 Cap, Fuel - 2.50 Gallon, Carb Sealed 18221
7 1 Bracket - Fuel Tank 18225
8 2 Bolt - Serr Flange 1/4-20 X 1 3/4 GR5 ZY 18236
GAS TANK
ASSEMBLY DETAIL
4
5
Part # Description
11782 Line - Fuel, Bulk, 1/4" Low Perm
18232 Line - Fuel, Bulk, 3/16" Low Perm
18223 Clamp - Fuel Line 13/32 OD, 3/16 ID Tube
AS021 Tie, Black 5 1/2"
Parts Not Shown
When ordering replacement parts
*USE PAINT CODE: GT=GRAY TK=BLACK
SEE HEIGHT ADJUST
HANDLE DETAIL
SEE CASTER/WHEEL
ASSEMBLY DETAIL

蕆 ﵇﵇
ɚ 
11
OUTER BLADE DRIVER DETAIL
Part No. Torque (ft-lbs)
NB175 90
NB238N 35
NB524 20
NB216 35
Recommended Torque Specifications
CENTER BLADE DRIVER DETAIL
When ordering replacement parts
*USE PAINT CODE: GT=GRAY TK=BLACK

칆 ﵇﵇
ˆ 
12
GRASS CHUTE &
SPRING DETAIL
ITEM # QTY. PART NO. DESCRIPTION
1 1 166X34 Spring - Torsion
1 NB18 Nut - Nyloc 3/8-16 zy
3 1 NB784 Bolt - HCC 3/8-16 x 7
4 1 09 100 Chut e - Discharge
ITEM # QTY PART NO DESCRIPTION
1 1 -- See Motor Base Detail
1 -- See Safety Switch Bracket Detail
3 -- See Out er Blade Driver Det ail
4 1 -- See Center Blade Driver Detail
5 1 -- See Grass Chut e & Spring Detail
6 1 -- See Engage Lever Detail
7 1 0946 See Idler Det ail
8 T PB Bushing - Plastic
9 AS001 Roller - Anti-Scalp 3/8 ID
10 1 NB707 Bolt - Carriage 3/8-16X4
11 1 NB 07 Nut - Nyloc 3/8-16
1 11 NB596 Bolt - Serr Flange 5/16-18 X 3/4
13 13 NB170 Nut - Serr Flange 5/16-18 Z
14 4 6X 49 Screw - .31 -18X.75
15 1 NB13 Bolt -1/ -13 X 4 HCC
16 3 NB688 Nut - Nyloc Jam, 1/ -13 ZY
17 1 NB 81 Nut - Nyloc 1/ -13 ZY
18 NB1 1 Nut - Jam Lock 1/ -13 -Way
19 3511 Wheel - Gauge
0 1 18383* Bracket - Middle Roller
1 1 18384* Bracket - Deck Hanger
18391 Cover - Belt, Black Composite
3 NB577 Bolt -1/ -13 X 3 1/
4 1 09 104* Bracket - Deflect or
5 1 15780* Bracket - Wheel Right
6 1 15779* Bracket - Left Wheel
7 1 1838 *
Deck - Weldment T60 Roundback
8 1 NB509 Bolt - 1/ -13 X HCC
9 NB106 Bolt - 5/16-18 X 3/4 HCC
30 NB181 Nut - Nyloc 5/16-18
31 8 18531 Washer - Bent . 5" ID X 18GA
3 8 NB703 Screw - MSC, 10- 4 X 1 1/4
33 8 1853 Nut - Clip, 10- 4
CASTER / WHEEL
ASSEMBLY DETAIL
ITEM # QTY. PART NO. DESCRIPTION
1 B98 Bearing
1 17X195 Washer - Flat
3 1 094618 Cap
4 NB195 Washer - 13/16 ID X 1 1/4 OD X 1/8
5 1 663L Spacer
6 1 NB595 Nut - Locking Jam, Way 5/8-11
7 NB178 Washer - 5/8 ID X 1 OD 10 GA
8 1 665* Weldment - Caster
9 1 F4157WK
Tire/Wheel - 5/8 Bearing 13x5x6 NHS, Blk
10 1 NB1 Nut - Nyloc Jam 3/4-16
11
1
NB6 4
Bolt - 5/8"-16 X 7" HCC ZY Grade 5
MOWER DECK DETAIL
When ordering replacement parts
*USE PAINT CODE: GT=GRAY TK=BLACK

酆 ﵇﵇
ɚ 
13
Slide plastic tube snug
Against toggle switch.
18057 Harness - Wiring, Briggs (13- 0 hp)
BCSR Cable - Battery (10" Red)
BCLB Cable - Battery (19 1/ "or 0" Black)
KSK Keys - For Key Switch (set of two)
BCBT Boot - Rubber, Small, Battery Cable
PARTS NOT SHOWN
ITEM # QTY. PART NO. DESCRIPTION
1 1 NB 0 Bolt - Shlder, 1/ X 1-9/16 W3/4 Gr ZY
1 18387* Motor Base - Weldment
3 17760 Bolt-L
4 1 17794* Bracket - Battery Hold Down
5 8 6x 9 Screw - Hex Tek 1/4 X 1/
6 10 0 4 06 Screw - 1 X 1/ Hex Self Tap
7 1 N/A Engine (Reference Model Shown)
8 1 17840* Cover - Battery Top
9 1 0935 Guide - Belt, FC
10 1 14869 Guide - Belt; T60
11 NB 50 Bolt - 1/4- 0 X 3/4 GR5
1 NB5 4 Nut - Serr Flange, 1/4- 0 Grade 5
13 1 NB596 Bolt - Serr Flange, 5/16-18 X 3/4 Gr 5
14 1 4 6K Knob - T, For Thrott le Cable
15 1 NB170 Nut - Serr Flange 5/16-18 Case Hrd
16 4 NB 75 Washer - SAE Flat 5/16
17 1 689L Spacer - Long, Engine Pulley, 1.5"
18 1 688 Pulley - Engine, 5.5"
19 1 9031 Key Stock - 1/4 X 1 Undr Size
0 1 689S Spacer - Short , Engine Pulley, .687
1 1 TR150W Washer - .531IDX1 1/ ODX.06 (Ht Trtd)
699 Washer - Belleville 7/16 X 1 1/4
3 1 NB45 N Bolt - 7/16- 0 X 1 HCF GR5 Nylock
4 1 685SP Switch - Toggle, Single Pole
ITEM # QTY. PART NO. DESCRIPTION
5 1 36 3 Switch - Key
6 1 H9C Tether - Safety, Coiled
7 1 17898 Cable - Throttle; T60
8 1 T SM Spring
9 1 100 004 Solenoid - 3 Pole
30 4 NB711 Washer - Split Lock, 3/8 ZY, Medium
31 4 NB618 Bolt - 3/8-16 X 1 1/4 GR5 ZY
3 NB180 Nut - Nylock 1/4- 0
33 3 NB181 Nut - Nyloc 5/16-18
34 1 44 Spring - Idler Tension, Bent Leg
35 1 10636YZ Bolt - Spade, 5/16-18 X1
36 1 NB 80 Nut - Way Lock 3/8-16 Wax Gr A
37 1 NB107 Bolt - 3/8-16 X 1 1/ HCC GR5
38 1 NB501 Bolt - 5/16-18 X 1 HCC GR5
39 1 B5 7 Pulley - Idler, OD3. 5" ID3/8"
40 1 6009* Idler - Engage Weldment
41 1 17614* Cover - Bat tery Top Front
4 1 17615* Cover - Battery Left
43 1 17616* Cover - Batt ery Right
44 1 9087 Nut - Key Swit ch
45 1 9088 Washer - Lock, Key Switch
46 1 NB 10Z Nut - 5/16-18 HNC
47 1 -- See Saftey Switch Detail
48 1 NB18 Nut - Nyloc 3/8-16
Item # 26
Item # 24
MOTOR BASE DETAIL
U1 Battery
(Not Included)
When ordering replacement parts
*USE PAINT CODE: GT=GRAY TK=BLACK

﵇﵇
ˆ
14
Engage Lever Detail Height Adjust Handle Detail Safety Switch & Bracket Detail
Belt Configuration
20946 Idler Detail
ITEM # QTY. PART # DESCRIPTION
1 1 NB155 Bolt - 1/ -13 X 5 HCC GR5 ZP
NB1 1 Nut - Way Lock 1/ -13 ZY
3 1 18976* Engage - Weldment
4 1 NB170 Nut - Serr Flng 5/16-18
5 1 NB 53 Bolt - Serr Flng,5/16-18 X1 1/4
6 1 NB181 Nut - Nyloc 5/16-18
7 1 4578* Pivot - Engage
8 NB555 Washer - 1/
9 1 11158 Nut - Jam, -Wy Lck, 5/16-18
ITEM # QTY. PART # DESCRIPTION
1 1 H7N1TK** Tube - Height Adjust
1 ES 14** Rod - Crank, For H7N
3 1 H7K** Knob - Height Adjustment
4 NB117** Nut - Push, 5/16
5 1 OD41** Decal - Ruler
**Parts Included in Service Part # H7N
ITEM # QTY. PART # DESCRIPTION
1 1 18390* Mount - Switch Safety
1 3695 Switch - Normally Closed
3 NB197 Screw - Phillips Truss 8-3 X 1/
4 NB 01 Nut - Kep 8-3
ITEM # QTY. PART # DESCRIPTION
1 1 6054* Idler - Bott om
1 0183 Pulley - Idler, 1" X 4" X 3/8" ID
3 1 NB107 Bolt - 3/8-16 X 1 1/ GR5
4 NB181 Nut - Nyloc 5/16-18
5 1 NB18 Nut - Nyloc 3/8-16 ZY
6 1 NB 7 Washer - SAE Flat 3/8
7 1 NB 80 Nut - Way Lock 3/8-16 Gr A
8 1 NB501 Bolt - 5/16-18 X 1 GR5
9 1 6037 Bushing - Idler
10 1 NB18 Nut - Nyloc 3/8-16
11 1 6040Z Washer - Idler
1 1 NB618 Bolt - 3/8-16 X 1 1/4 GR5
13 1 TZ S Spring
14 1 10546 Eyebolt - Turned 3/8-16 X 5 ZY STD
15 1 NB173 Nut - Jam 5/16-18
When ordering replacement parts
*USE PAINT CODE: GT=GRAY TK=BLACK
5058 Long Belt 6046HP Short Belt

鵆 ﵇﵇
ɚ 
NOTES:
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
15

诰ۀ
OWNER’S
MANUAL
HOW TO ORDER
REPAIR PARTS:
60” FAST FINISH
TRAIL MOWER
COMMERCIAL PRO
Each mower has its own model num er. Each engine has its
own model num er. The model num er for the mower will e
found at the left rear of the unit on the elt cover skirt.
The model num er for the engine will e found on the top of
the lower fan housing.
All mower parts listed herein may e ordered directly from
Swisher or your nearest Swisher dealer.
All engine parts may e ordered from the nearest dealer of the
engine supplied with your mower.
Color cannot e guaranteed on service parts.
WHEN ORDERING PARTS, PLEASE HAVE THE
FOLLOWING INFORMATION AVAILABLE:
* PRODUCT – FC60 FAST FINISH TRAIL MOWER
* SERIAL NUMBER - _______________
* MODEL NUMBER - _______________
* ENGINE MODEL NUMBER - _______________
TYPE - _______________
* PART NUMBER
* PART DESCRIPTION
TELEPHONE - 1-800-222-8183
FAX - 1-660-747-8650
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE
WARRENSBURG, MO 64093
www.swisherinc.com
MODEL NO.
FC14560CPKA
FC14560CPKA-CA
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment .
IMPORTANT
CHANGING YOUR LANDSCAPE SINCE 1 45
