Swisher COMMERCIAL PRO PREDATOR TALON User manual

8/23/2019
OWNER’S
MANUAL
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093
PHONE [phone] FAX [phone]
MODEL NO.
Operation
Service and Adjustment
Repair Parts
WHERC10224C
WHERC10224
swisherinc.com
21024 REV 17-335
STARTING SERIAL #:
L117-335001
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
IMPORTANT
COMMERCIAL PRO
24” WALK BEHIND
12V ROUGH CUT
ade I The
USA
of US and Global Parts
PREDATOR TALON
WHERC10224C
PREDATOR
WHERC10224

2
In the event you have a claim under this warranty, you must return the product to an authorized
service dealer. All transportation charges, damage, or loss incurred during transportation of parts
submitted for replacement or repair under this warranty shall be borne by the purchaser. Should you
have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The
model number, serial number, date of purchase, and the name of the authorized Swisher dealer from
whom you purchased the mower will be needed before any warranty claim can be processed.
THIS WARRANTY DOES NOT APPLY TO ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES AND ANY IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME
PERIODS STATED HEREIN FOR ALL EXPRESSED WARRANTIES. Some states do not
allow the limitation of consequential damages or limitations on how long an implied warranty may
last, so the above limitations or exclusions may not apply to you. This warranty gives you specific
legal rights and you may have other rights, which vary from state-to-state. This is a limited warranty
as defined by the Magnuson-Moss Act of 1975.
LIMITED WARRANTY
The manufacturer’s warranty to the original consumer purchaser is: This product is free from defects
in materials and workmanship for a period of (1) year from the date of purchase by the original
consumer purchaser. We will repair or replace, at our discretion, parts found to be defective due to
materials or workmanship. This warranty is subject to the following limitations and exclusions:
TABLE OF CONTENTS
WARRANTY………………....….2
INTRODUCTION………………..3
SAFETY..……………………….3-4
PRE-OPERATING..….……..……4
OPERATION.……………………….5-7
DECALS…..………….……………….8
PARTS BREAKDOWN…………….9-14
ELECTRICAL & BELT ROUTING...15
1) Engine Warranty All engines utilized on our products have a separate warranty extended
to them by the individual engine manufacturer. Any engine service
difficulty is the responsibility of the engine manufacturer and in no
way is Swisher or its agents responsible for the engine warranty. Please
visit engines.honda.com and click on find a dealer or find a distributor.
2) Limitation This warranty applies only to products which have been properly
assembled, adjusted, and operated in accordance with the instructions
contained within this manual. This warranty does not apply to any
product of Swisher that has been subject to alteration, misuse, abuse,
improper assembly or installation, shipping damage, or to normal wear
of product.
3) Exclusions Excluded from this warranty are normal wear, normal adjustments, and
normal maintenance.

SAFETY PRECAUTIONS
This Safety Alert Symbol indicates important messages in this
manual. When you see this symbol, carefully read the message that
follows and be alert to the possibility of personal injury.
Read this manual completely. This machine can amputate hands and feet, and
throw objects. Failure to observe the following safety instructions could result in
serious injury or death.
Thank you for choosing Swisher’s 24” Walk Behind Rough Cut. Before
operating your Walk Behind, please read, understand and follow all of the safety
precautions and other instructions explained in this manual. As with all power
equipment, lawn mowers can be potentially dangerous if not properly used.
3
• Read the manual. Learn to operate this machine safely.
• Always disconnect the spark plug wire and place the wire where it cannot contact the
spark plug, to prevent accidental starting the engine when setting up, transporting,
adjusting or making repairs.
• Keep all shields and guards in place.
• Understand the speed, steering and stability of this machine. Know the positions and
operations of all controls before you operate this machine. Check all of the controls in
a safe area before starting to work with this machine.
• Allow only responsible adults who are familiar with these instructions to operate this
machine. Never allow children to operate this machine.
• Clear the area of objects such as rocks, toys, wire, etc. that can be picked up and
thrown by the blade.
• Be sure the area is clear of other people before mowing. Be aware of the mower
discharge direction and do not point at anyone. Stop the machine if anyone enters the
mowing area. Children are often attracted to the machine and the mowing activity.
Never assume that children will remain where you last saw them. Keep children
under the watchful care of another responsible adult.
•No riders!
• Do not put hands or feet near or under rotating parts.
• Do not mow in reverse. Always look down and behind before and during backing.

• Turn off the blade when not mowing. Before leaving the machine, turn off the blade
and stop the engine.
• Watch for traffic when operating near or crossing roadways.
• Do not operate the mower if it has been dropped or damaged in any manner or if the
mower vibrates excessively. Excessive vibration is an indication of damage. Repair mower
as necessary.
• Dress properly. Do not operate the mower when barefoot or wearing open sandals. Wear
only solid shoes with good traction when mowing.
• Never allow operation by untrained persons.
• Do not operate the machine while under the influence of alcohol or drugs.
• Do not operate on slopes greater than 15 degrees.
• Never tamper with safety devices. Check their proper operation regularly.
• Stop and inspect the equipment if you strike an object. Repair, if necessary, before
restarting. Never make adjustments or repairs with the engine running.
• Mower blades are sharp and can cut. Wrap the blades or wear gloves, and use extra
caution when servicing them.
• Do not operate at too fast a rate.
• Disengage spark plug wire and place where it cannot make a connection.
• Check engine oil. All engines are filled with oil at the factory. Verify oil level and
add if necessary before starting engine (See Engine Owner’s Manual).
• Verify fuel level and add if necessary before starting engine.
• Reconnect spark plug wire.
• Refer to pages 5-7 in this manual for proper operating procedures.
PRE-OPERATING INSTRUCTIONS
4

The operation of any mower can produce foreign objects to be thrown into the
eyes, resulting in severe eye damage. Always wear certified safety glasses or
wide-vision safety goggles over spectacles before starting any cutting machine and
while operating such a machine.
The operation of any mower produces sound waves that are damaging to the
human ear. Ear protection is recommended.
CAUTION!
Tragic accidents can occur if the operator is not alert to the presence of
children. Children are often attracted to the machine and the mowing
activity. Never assume that children will remain where you last saw them.
OPERATING YOUR NEW WALK BEHIND
INTENDED USE
This is not a lawn mower. The Predator and Predator Talon is designed for cutting
overgrown brush, weeds, and other types of organic growth. This unit is capable of
clearing small saplings of 1.5” in diameter or less to a height of approximately 4”.
TRAVEL SPEED
Speed can be varied by choosing a higher or lower gear using the gearshift lever at the
rear of the machine or by changing the engine speed with the engine throttle. Do not
adjust speed with the blade engaged. To shift the cutter into reverse, release the
“GROUND CONTROL” lever, disengage the blade, and rotate the shift lever to the left.
When the lever stops, lift up the reverse lockout latch and continue to move the shift
lever to the left until it stops again.
PROPULSION
The Predator and Predator Talon is self-propelled and is controlled by a “GROUND
CONTROL” lever. To engage the drive, shift the transaxle to a gear and activate the left
lever by squeezing it against the handle. Releasing the lever will disengage the self-
propel.
Under most conditions cutting should be done in a low gear (1st or 2nd). Upper gears
should be used for conditions where weeds and brush are thinned out or not as tall. In
confined areas the machine can be pushed forwards or backwards by releasing the
“GROUND CONTROL” lever, shifting the transaxle to neutral, and pushing the
machine.
ENGAGING THE BLADE
An “OPERATOR PRESENCE” lever and a “BLADE ENGAGE DRIVE” control work
together to engage the blade. Both devices must be activated before the blade will work.
Releasing the “OPERATOR PRESENCE” lever will disengage both the blade and the
“BLADE ENGAGE DRIVE” control. 5

STARTING THE ENGINE
See engine manufacturer’s recommendations for the type and amount of oil and fuel used.
Engine must be level to accurately check and fill oil. Do not overfill.
• Make sure unit is level, blade is disengaged, and transaxle in “NEUTRAL”
• Check spark plug wire, oil level, and fuel level.
• Check all electrical connections for build-up of debris.
• Move throttle control to “FAST”, or “CHOKE” if choke is needed.
• For recoil starting, turn ignition key to the “ON”
position and pull rope with a
single fluid motion. For electric starting, turn the key to the “START” position.
• Set engine throttle control to “FAST”. The throttle must be set in the fast position for
maximum performance.
STOPPING
• Bring the Walk Behind to a complete stop by releasing the “GROUND CONTROL”
lever (left).
• Disengage mower blade by releasing the “BLADE ENGEGE DRIVE” control (right).
• Reduce engine idle speed, and allow engine to run momentarily for cooling.
• Place transaxle in the “NEUTRAL” position.
• Turn the ignition key to “OFF” position.
BREAKING IN YOUR WALK BEHIND
• Start engine properly.
• Slowly engage blade control.
• Under supervision, allow blade to rotate and engine to idle for 5 minutes.
• Disengage blade.
• Shift through each gear. While in each gear engage the “GROUND CONTROL” lever
and travel 20 yards to ensure transaxle works properly.
BEGIN CUTTING
• Make sure area is clear of all bystanders.
• Make sure that all guards, belt guides, and the spark plug wire are properly attached.
• Start engine, set engine throttle control at maximum engine idle speed for best results.
• Allow engine to run a few moments and slowly engage blade.
• Move transaxle into low gear and activate “GROUND CONTROL” lever.
• Turning is done by rotating the handles left or right. This machine has significant
weight and may take more effort to turn than one may expect. Turning could take
practice.
BACKING UP
• Disengage blade.
• Check behind you for safety.
• Move transaxle into “REVERSE” position.
• Activate “GROUND CONTROL” lever.
6
IMPORTANT: This engine may not be equipped with a spark arrester muffler. It is a violation of
California Public Resource Code Section 4442 to use or operate the engine on any forest-covered,
brush-covered, or grass-covered land. Other states or federal areas may have similar laws.

TRANSPORTING
• Remove the key from ignition switch.
• Shut off fuel at the engine.
• Secure in place while unit is being transported.
• Unit should be left in low gear to avoid any slight rolling.
SUGGESTED PRACTICES
• Always operate engine at full throttle when cutting to assure the best cutting
performance and proper discharge of material.
• If grass is wet, allow it to dry. Wet grass clumps will collect on the bottom of the
deck.
• Go slow when cutting dense areas. Some dense areas may need to be gone over
twice. Better results occur if the second cut is 90 degrees to the first cut.
BEFORE EACH SEASON
A new spark plug and clean air filter assure proper air-fuel mixture and help your engine run
better and last longer.
• Replace the spark plug.
• Clean or replace the air filter.
• Check blades and belts for wear.
BEFORE EACH USE
• Check engine oil level. Do this twice to ensure an accurate reading.
• Check condition of air filter and clean or replace if necessary.
• Check blade operation.
• Check for loose fasteners.
• Check tires for proper inflation. See tires for maximum inflation.
- Rear tire valve stems are located on the inside of the wheel rim.
- Front tire valve stems should be turned to avoid contact with caster yoke.
DAILY MAINTENANCE
Make sure all nuts and bolts are tight and cotter pins and retainer springs are secure.
Keep blades sharp. Observe all safety precautions.
BLADE CARE AND SERVICE
For best results blades must be kept sharp. The blades can be sharpened with a few strokes of a
file or grinding wheel. Do Not attempt to sharpen blades while they are on the machine.
Important: Replace blades that have been damaged or deeply nicked.
Important: Check blade and spindle hardware on a regular basis to make sure nuts are
tight.
7

SAFETY AND OPERATIONAL DECALS
Replace decal immediately if damaged. Order by part number from Swisher.
20076--SWISHER FLAG DECAL
OD55--DANGER DECAL OD45--WARNING DECAL
OD83--RN1234 SHIFT DECAL 10749--REVERSE LOCK DECAL
8
OD99112--LARGE LOGO WHITE DECAL
OD99156--SMALL LOGO WHITE DECAL
19722-- Predator Talon LH Decal
19732-- Predator Talon RH Decal
OD85--Predator LH Decal
OD86--Predator RH Decal
20000--Commercial Pro Decal
DECALS NOT SHOWN

Item # Description Part # Item # Description Part #
1 Guard - Engine, Cover 19888* 10 Pad - Battery BATPAD
2 Guard - Engine, Right 20595* 11 Bolt - Serr Flange, 5/16-18 X1 10548
3 Bolt - Serr Flange 5/16-18 X3/4 NB596 12 Cover - Belt 19889*
4 Clip - Tinnerman 5/16-18 3706 13 Nut - Serr Flange 5/16-18 NB170
5 Guard - Engine, Left 19885* 14 Channel - Side, Right 19211*
6 Guard - Engine, Front 19884* 15 Channel - Side, Left 19212*
7 Strap - Tarp, 9" AS013 16 Clip - Nylon 1/2" NB683
8 Hook - Tarp Strap AS049 17 Bolt - Serr Flange, 5/16-18 X2 1/4 NB622
9 Battery (Not Included) N/A 18 Mount - Handle Height Adjust 19214*
ASSEMBLY DETAIL
WHERC10224C MODEL SHOWN WITH CASTERS
9
When ordering replacement parts
*USE PAINT CODE: TK=BLACK
Tip: Valve stems should be turned
to avoid contact with caster yoke.
BATTERY NOT INCLUDED:
REQUIRES A 12V LAWN AND GARDEN
BATTERY WITH A 235 MIN CCA. U1 GROUP
FOR CORRECT FIT.

ENGINE & PULLEY ASSEMBLY
10
Important: Spring
must be hooked in
Idler Arm as shown.
Install Transmission Cable
(Not Shown) in Idler Arm
before installing Idler Arm
to Motor Plate.
When ordering replacement parts
*USE PAINT CODE: TK=BLACK
Item # Description Part # Item # Description Part #
1 Nut - Nyloc 5/16-18 NB181 17 Bolt - 3/8-16 X 1 1/2 NB107
2 Bolt - Serr Flange, 5/16-18 X 1 10548 18 Washer - SAE Flat 3/8 NB272
3 Nut - Serr Flange 5/16-18 NB170 19 Pulley- Idler, OD-2.16", ID-3/8" B27
4 Bolt- 5/16-24 X 1 HCF GR5 ZY NB451 20 Bolt - 3/8-16 X 1 NB604
5 Bolt - Serr Flange, 5/16-18 X 1 1/2 NB254 21 Bushing - Idler 6037
6 Spacer - Engine Pulley BB105S 22 TransmissionIdler Arm 20594*
7 Weldment - Belt Retention 10767 23 Bolt - 1/4-20 X 3/4 NB250
8 Belt - Transmission, 35" 690 24 Spring T2SM
9 Washer - 1 X 1 1/2 NB614HT 25 Nut - Serr Flange,1/4-20 NB524
10 KeyStock - 1/4 X 1 9031 26 Nut - 2 WayLock 3/8-16 NB280
11 Engine Pulley- 4.25"OD,1 1/4 ID BB105 27 Plate - Motor Base 19213*
12 Washer - .531IDX1 1/2OD TR150W 28 Bolt - Serr Flange, 5/16-18 X 3/4 NB596
13 Bolt- HCF, 7/16-20 X 1 1/2 NB637 29 Valve - Oil Drain 16000
14 Washer - Belleville 7/16 X 1 1/4 699 30 Oil DrainAdaptor 20881
15 Pulley- Engine,2.5" 2411 31 Engine, Honda 389cc 20694
16 KeyStock - 1/4 X 1/2 4258 N/A Harness -Wiring (NOTSHOWN) 20988

11
Item # Description Part #
1 Nut - Serr Flange 5/16-18 NB170
2 Plate - Cover, Back 10679*
3 Arm - Anti Reverse 10680*
4 Spacer B99S
5 Bolt - Serr Flange, 5/16-18 X 3/4 NB596
REAR COVER ASSEMBLY
HANDLE BAR & LEVER ASSEMBLY
When ordering replacement parts
*USE PAINT CODE: TK=BLACK
Item # Description Part #
1 Knob - T 4226K
2 Bolt - TCS 1/4-20 X 1/2 NB114
3 Cable - Throttle 4226
4 Weldment - Handle 21077*
5 Nut - Key Switch 9087
6 Washer - Lock, Key Switch 9088
7 Switch - Key 3623
8 Nut - Nyloc 1/4-20 NB180
9 Grip - Handle 7826
10 Lever - Blade Engagement Weldment 19444*
11 Control - Latching Drive 19208
12 Nut - Nyloc 5/16-18 NB181
13 Washer - SAE Flat 1/4 NB274
14 Bolt - 1/4-20 X 1 3/4 NB278
15 Cable - Transmission 20597
16 Bolt - MSC 1/4-20 X 1/2 NB113
17 Lever - Engagement 10685*
18 Plate - Blade Lever Cable 10713*
19 Bolt - Serr Flange 5/16-18 X 3/4 NB596
20 Bolt - 1/4-20 X 2 3/4 19455
Description Part #
Keys - KeySwitch, Set of Two KSK
Harness - Wiring, 20988
NOT SHOWN

Item # Description Part #
1 Nut - Jam 3/4-16 NB175
2 Washer - Belleville .760 X 1.5 X .098 AS155
3 Pulley- Blade, 5.5" 20651
4 Spacer - 3/4 ID X 1 12823
5 Washer - 3/4 ID X 1 1/4 OD NB179
6 Bearing - Blade B98
7 Shaft - Blade 6", Long Shoulder 9078
8 Nut - Serr Flange 5/16-18 NB170
9 Housing - Blade Bearing 9091*
10 Bolt - Serr Flange, 5/16-18 X 3/4 NB596
11 Washer -Flat3/4 ID X 1 3/4 OD B98W
12 Nut - Lock, Two Way3/8-24 NB216
13 Plate - Blade Mount 9008
14 Blade - G6 Gator 24" 20114
15 Bolt - 3/8-24 X 1 1/4 HCC GR5 ZY NB166
16 Washer - SP Bellville .413 X.945 X.118 NB607
17 Bolt - HHC 3/8-24 X 1 NB238N
18 Blade Driver - Assembly 10712
Item # Description Part #
1 Nut - Jam, Nyloc 3/8-16 NB207
2 Washer - SAE Flat 3/8 NB272
3 Finger for Belt Release T30F
4 Nut - Jam 3/8-16 NB174
5 Pulley - Idler Clutch, 2 3/4 OD T30V
6 Nut - 2 Way Lock 3/8-16 NB280
7 Idler - Blade Weldment 10668*
8 Bolt - HTC, 3/8-16 X 2 NB231
9 Pulley - Idler, OD3.25 X ID3/8 B527
10 Bolt - 1/2-13 X 3 HCC NB131
11 Nut - Jam Lock, 1/2-13 2-Way NB121
12 Bolt - 3/8-16 X 2 1/2 HTC NB619
13 Washer - Hardened 3/8 NB196
14 Spacer - .625 OD X 1.25 8072*
15 Spring - Torsion Brake BT297
16 Pad - Brake, Cylindrical 9114
17 Spring - Brake Pad Retainer BP370S
18 Chain - Sgl Jk Chn, Zps, Sz12, 16# AS080
19 Bolt - 3/8-16 X 1 1/2 HCC NB107
12
BLADE DRIVER ASSEMBLY
BRAKE ASSEMBLY
When ordering replacement parts
*USE PAINT CODE: TK=BLACK

PAGE 12
Item # Description Part #
1 Deck - Weldment 10695*
2 Bolt - 1/4-20 X 3/4 NB250
3 Clip - Blade EngagementCable 10673*
4 Nut - Nyloc 1/4-20 NB180
5 Nut- Serr Flange 5/16-18 NB170
6 Weldment - WB Skid 18512*
7 Bolt - Serr Flange, 5/16-18 X 3/4 NB596
8 Washer - 5/8 ID X 1 OD NB149
9 Tire/Wheel - 8 X 3 19641
10 Nut - Lock Jam, 5/8-11 2 Way NB595
11 Bolt - 5/8-11 X 5 19642
12 Weldment - Caster, Txt Blk 19638*
13 Washer- 13/16 X 1 1/4 X 1/8 NB195
14 Bearing B98
15 Weldment - Brush Guard Housing 19631*
16 Washer - Flat 17X195
17 Nut - Jam, Nyloc 3/4-16 NB122
18 Cap 094618
13
DECK & CASTER
ASSEMBLY
FOR MODEL WHERC10224C
When ordering replacement parts
*USE PAINT CODE: TK=BLACK
DECK & FRONT GUARD
ASSEMBLY
FOR MODEL WHERC10224
Item # Description Part #
1 Deck - Weldment 10695*
2 Bolt - 1/4-20 X 3/4 NB250
3 Clip - Blade Engagement Cable 10673*
4 Nut - Nyloc 1/4-20 NB180
5 Nut - Serr Flange 5/16-18 NB170
6 Weldment - WB Skid 18512*
7 Bolt - Serr Flange, 5/16-18 X 3/4 NB596
8 Guard - Predator Brush 10681*

TRANSAXLE ASSEMBLY
Item # Description Part # Item # Description Part #
1 Wheel- AsyRight;WB24 4.8x8 2401RK 9 Grip - Transmission Lever 2427
2 Screw - Set 5/16-18 X 1/2 NB312 10 Lever - Transmission 20652*
3 Pulley- Transmission, 8" 2410 11 Nut - Serr Flange 5/16-18 NB170
4 Washer - SAE Flat 1/4 NB274 12 Transaxle - 4 Speed 19563
5 Washer - 1/4 Split Lock NB135 13 Washer - 3/4ID X 1 1/4OD NB184
6 Bolt - Hex1/4-28 X 3/4 06X105 14 KeyStock - 3/16 X 1 1/2 2434
7 Bolt - Serr Flange, 5/16-18 X 3/4 NB596 15 Wheel - AsyLeft; WB24 4.8x8 2401LK
8 Weldment - Shift Handle 13897* 16 Ring - E-Style Retaining 3/4 NB621
When ordering replacement parts
*USE PAINT CODE: TK=BLACK 14

15
WIRING CONFIGURATION
BELT CONFIGURATION
20651 – BLADE PULLEY
2410
TRANSAXLE PULLEY
690 – TRANSAXLE BELT
TOP ENGINE PULLEY
CONFIGURATION
B27 – TRANSAXLE IDLER PULLEY 2411 – TOP ENGINE PULLEY
BB105 – LOWER ENGINE PULLEY
T30V – V-BELT PULLEY
B527 – BLADE IDLER PULLEY
20655 – BLADE ENGAGEMENT BELT
BOTTOM ENGINE PULLEY CONFIGURATION
Wiring Harness PN 20988

OWNER’S
MANUAL
MODEL NO.
Each cutter has its own model number. Each engine has its
own model number. The model number for the cutter will be
found on the right hand side of the drive belt housing. The
model number for the engine will be found on the engine block.
All cutter parts listed herein may be ordered directly from
Swisher or your nearest Swisher dealer.
All engine parts may be ordered from the nearest dealer of the
engine supplied with your cutter.
WHEN ORDERING PARTS, PLEASE HAVE THE
FOLLOWING INFORMATION AVAILABLE:
* PRODUCT – WALK BEHIND ROUGH CUT
* SERIAL NUMBER - _______________
* MODEL NUMBER - _______________
* ENGINE MODEL NUMBER - _______________
TYPE - _______________
* PART NUMBER
* PART DESCRIPTION
TELEPHONE - 1-800-222-8183
FAX - 1-660-747-8650
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE
WARRENSBURG, MO 64093
swisherinc.com
CHANGING YOUR LANDSCAPE SINCE 1945
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
IMPORTANT
WHERC10224C
WHERC10224
COMMERCIAL PRO
24” WALK BEHIND
12V ROUGH CUT
