Swisher L117-235001 User manual

COMMERCIAL PRO
60” FAST FINISH
TRAIL MOWER
OWNER’S
MANUAL
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE., WARRENSBURG MO 640 3
PHONE [phone] FAX [phone] EMAIL [e-mail]
MODEL NO.
FC14560CPKA
FC14560CPKA-CA
Assembly
Operation
Service and Adjustment
Repair Parts
www.swisherinc.com
20 27 REV 17-235
STARTING SERIAL #:
L117-235001
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
IMPORTANT
ade I The
USA
of US and Global Parts

穆
˸
LIMITED WARRANTY
The manufacturer’s warranty to the original consumer purchaser is: This product is free from
defects in materials and workmanship for the period's shown below beginning from the date
of purchase by the original consumer purchaser. We will repair or replace, at our discretion,
parts found to be defective due to materials or workmanship. This warranty is sub ect to the
following limitations and exclusions:
As req ired by CFR § 1060.120, the f el system related components, which have been
certified to this eq ipment by SAI are to be free of defects in material and workmanship for a
period of two (2) years from the date of p rchase by the original cons mer p rchaser.
1) Engine Warranty All engines utilized on our products have a separate warranty
extended to them by the individual engine manufacturer. Any
engine service warranty is the responsibility of the engine
manufacturer and in no way is Swisher or its agents responsible
for the engine warranty. The Kawasaki Engine Service Hotline is
1-877-364-6404 or email kawpow[email protected]
2) Commercial Use This prod ct has a 1yr Limited Commercial - 2 Year
Limited Consumer on All Non-Engine Parts from the date
of purchase.
3) Limitations This warranty applies only to prod cts, which have been
properly assembled, adj sted, and operated in accordance with
the instr ctions contained within this man al. This warranty
does not apply to any prod ct of Swisher that has been s bject
to alteration, mis se, ab se, improper assembly or installation,
shipping damage, or to normal wear of the prod ct.
4) Excl sions Excl ded from this warranty are normal wear, normal
adj stments, and normal maintenance.
In the event yo have a claim nder this warranty, yo m st ret rn the prod ct to an
a thorized service dealer. All transportation charges, damage, or loss inc rred d ring
transportation of parts s bmitted for replacement or repair nder this warranty shall be borne
by the p rchaser. Sho ld yo have any q estions concerning this warranty, please contact s
toll-free at 1-800-222-8183. The model n mber, serial n mber, date of p rchase, and the
name of the a thorized Swisher dealer from whom yo p rchased the mower will be needed
before any warranty claim can be processed.
THIS WARRANTY DOES NOT APPLY TO ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES AND ANY IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME
PERIODS STATED HEREIN FOR ALL EXPRESSED WARRANTIES. Some states do not
allow the limitation of conseq ential damages or limitations on how long an implied warranty
may last, so the above limitations or excl sions may not apply to yo . This warranty gives
yo specific legal rights and yo may have other rights, which vary from state-to-state. This is
a limited warranty as defined by the Magn son-Moss Act of 1975.
2

顆 掐
ɋҎ
SAFETY PRECAUTIONS
• Read the man al. Learn to operate this machine safely.
• Always disconnect the spark pl g wire and place the wire where it cannot contact the spark pl g, to prevent
accidental starting the engine when setting p, transporting, adj sting or making repairs.
• Keep all shields and g ards in place.
• Understand the speed, steering and stability of this machine. Know the positions and operations of all
controls before yo operate this machine. Check all of the controls in a safe ar
ea before starting to work with
this machine.
• Allow only responsible ad lts who are familiar with these instr ctions to operate this machine. Never allow
children to operate this machine.
• Clear the area of objects s ch as rocks, toys, wire, etc. that can be picked p and thrown by the blade.
• Be s re the area is clear of other people before mowing. Be aware of the mower discharge direction and do
not point at anyone. Stop the machine if anyone enters the mowing area. Children are often attracted to the
machine and the mowing activity. Never assume that children will remain where you last saw them.
Keep
children nder the watchf l care of another responsible ad lt.
• No riders!
• Do not p t hands or feet near or nder rotating parts. Keep clear of the discharge opening at all times.
• Do not mow in reverse. Always look down and behind before and while backing.
• T rn off the blades when not mowing. Before leaving the machine, t rn off the blades and stop the engine.
• Watch for traffic when operating near or crossing roadways.
• Do not operate the mower if it has been dropped or damaged in any manner or if the mower vibrates
excessively. Excessive vibration is an indication of damage. Repair mower as necessary.
• Dress properly. Do not operate the mower when barefoot or wearing open sandals. Wear only solid shoes
with good traction when mowing.
• Do not operate the machine while nder the infl ence of alcohol or dr gs.
• Do not operate on slopes greater than 15 degrees.
• Never tamper with safety devices. Check their proper operation reg larly.
• Stop and inspect the eq ipment if yo strike an object. Repair, if necessary, before restarting.
• Never make adj stments or repairs with the engine r nning.
This Safety Alert Symbol indicates important messages in this
manual. When you see this symbol, carefully read the message that
follows and be alert to the possibility of personal injury.
Read this manual completely. This machine can amputate hands, feet, and throw
objects. Failure to observe the following safety instructions could result in serious
injury or death.
3

虆 ཰
˸҇
4
SAFETY DECALS
Replace decals immediately if damaged. Order by part n mber from Swisher.
OD45- Warning Decal
OD11- No step Decal
OD55- Triangle Danger Decal
OD33- Speed Decal
OD29- Danger Decal
OD43- Flying Debris Decal

5
*Battery cover not shown
Battery Mounting Detail
A U1 battery is required
(not included). Position
battery hold down
bracket as shown.
Tighten nuts so battery
will not shift position.
REQUIRED ASSEMBLY
FRONT WHEEL CASTER ASSEMBLY
1. Remove single n t and washers from caster shaft.
2. Place one washer (NB195) on the shaft of the caster/wheel s bassembly.
3. Slide same shaft thro gh the bearing/frame with wheel towards the gro nd.
4. Place the other washer (NB195) on the shaft; it sho ld be resting on the top bearing.
5. Add thin washer (17x195).
6. Thread nyloc jam n t onto shaft.
7. Tighten n t sn ggly, making s re shaft threads enter the nyloc of the n t. Over-
tightening
of this nut will bind caster.
8. Repeat process for other front side.
9. P sh on plastic d st covers over n t and thin washer ntil it snaps into place.
REAR WHEEL ASSEMBLY
1. Remove cotter pin from axle and remove thin washer (NB149) from axle. Leave two
NB178 washers on axle.
2. If necessary (to take p space) slide extra washer (NB178) over axle, then wheel (with
valve stem o t).
3. Slide on washer (NB149) and replace cotter pin in end of axle.
4. Bend cotter pin so it will not fall o t.
5. Repeat process for other wheel.
OFFSET & CENTER TOW HITCH BAR ASSEMBLY
1. Lay o t parts according to the diagram.
2. Insert part 661A into part 662 and pin with the hitch pin (H11).
3. Insert part 20954 into part 661A. Choose from the 3 holes to set the desired hitch length.
Pin with a hitch pin (H11).
4. Part 662 slides into the front t be of the frame. Again, choose from the 3 holes to arrange
desired offset. Pin with a hitch pin (H11).
5. Eliminate step 2 for hitching from the center bracket. Only one method can be sed at a
time.

OPERATING YOUR TRAIL MOWER
INTENDED USE
This Trail Mower is designed to prod ce a q ality finish c t on lawns, golf co rses, etc. It is
not designed to clear br sh or c t saplings. Yo r Trail Mower sho ld be towed behind an
ATV, a golf cart, lawn tractor, or similar approved vehicle. It is not meant for speeds
exceeding 5 mph.
ATTACHING TRAIL MOWER TO TOW VEHICLE
• Place mower behind vehicle and back vehicle p to desired attaching position.
• When offsetting Trail Mower do so to side opposite the discharge of the tow vehicle.
• Attach tow hitch (661) to the swivel hitch with hitch pin (H11). Make certain hitch
pin goes completely thro gh each piece and is clipped to prevent accidental
separation.
• Attach red safety tether (6736) to both the towing vehicle and to the Trail Mower
toggle switch (685SP), located on the left battery side cover (17614). Its p rpose is to
man ally stop mower engine or to stop mower engine in case the two machines
become separated. (See Motor Base Detail page 14).
• It is extremely important the safety tether is secured properly to both the toggle
switch and the towing vehicle.
STARTING THE ENGINE
See engine man fact rer’s instr ctions for the type and amo nt of oil and f el sed. Trail
Mowers with electric start engines will need a battery (sold separately). Swisher recommends
sing a standard “U 1 R” lawn & garden battery.
The operation of any mower can prod ce foreign objects to be thrown into the
eyes, res lting in severe eye damage. Always wear certified safety glasses or
wide-vision safety goggles over spectacles before starting any c tting machine and
while operating s ch a machine.
The operation of any c tter prod ces so nd waves that are damaging to the
h man ear. Ear protection is recommended.
CAUTION!
Tragic accidents can occ r if the operator is not alert to the presence of
children. Children are often attracted to the machine and the mowing
activity. Never assume that children will remain where you last saw them.
6
IMPORTANT: This engine is not equipped with a spark arrester muffler. It is a violation of
California Public Resource Code Section 4442 to use or operate the engine on any forest-covered,
brush-covered, or grass-covered land. Other states or federal areas may have similar laws.

ꡆ
掐
ɋ Ҏ
•
Engine m st be level to acc rately check and fill oil. Do not overfill.
• Make s re the tow vehicle parking brake is set, mower is level, and blades are disengaged.
• Check spark pl g wire, oil, and f el.
• Check all electrical connections (See Schematics).
• Make s re toggle switch is t rned “ON” and the red tether is properly attached.
• Set engine idle to “CHOKE” position.
• With feet clear of mower deck, t rn key switch to the “START” position and release when
engine begins to r n.
• Set engine idle at desired RPM.
BREAKING IN YOUR MOWER
• Set vehicle parking brake or chock wheels to prevent accidental rolling.
• Start engine properly.
• Slowly, engage blade control.
• In a safe environment, i.e. no children, allow blades to rotate and engine to idle for 5
min tes. This breaks in the belts and the engine.
• Stop mower properly.
MOWER HEIGHT ADJUSTMENT
• Adj st while mower is not r nning.
• The c tting range is approximately 1” to 5.5”. The height sho ld be meas red from the
gro nd to the blade tip witho t the engine r nning.
• Rotate height adj st crank handles (H7N) in a clockwise direction to lift the mower deck. A
co nter-clockwise direction is sed to lower the mower deck.
• Make s re the height adj stment is the same at side crank handles. For best res lts, see
“SUGGESTED PRACTICE” section. Grad ated scales are for reference only, not the
act al c tter height.
• Place crank handle in a retracted position to maintain height adj stment.
STARTING TO MOW
• Adj st the c tting height.
• Do ble check vehicle to mower attachment.
• Start mower engine properly.
• Slowly, activate the blade engage lever (18976
) by rotating it forward and left ntil the lever
locks into place.
• Caref lly mo nt tow vehicle and start mowing slowly.
STOPPING THE MOWING SESSION
• P ll safety tether to sh t toggle switch “OFF”. If the engine fails to stop or if the safety
tether has become inoperable, then se Alternative Stopping Method.
CAUTION!
SHUT OFF MOWER ENGINE AND REMOVE SPARK PLUG WIRE FROM
SPARK PLUG BEFORE MAKING ANY ADJUSTMENTS TO THE MOWER.
7

鑆 ㊠
˸҂
ALTERNATIVE STOPPING METHOD
• Bring vehicle to complete stop, sh t off engine, and set parking brake.
• Disengage blade engage lever (18976).
• Man ally sh t toggle and key switches to their “OFF” positions.
• Always remember to remove keys to avoid irresponsible sage.
TRANSPORTING MOWER
• Stop mower properly.
• Place mower deck in its highest position.
• If transporting witho t the se of a tow vehicle, then remove spark pl g wire and
place where it cannot contact the spark pl g.
SUGGESTED MOWING PRACTICES
• Operate mower engine at f ll throttle to ass re the best c tting performance and
maxim m material discharge.
• Allow wet grass to dry. Cl mps of wet grass will collect nder the mowing deck.
• Mowing sho ld be started with tow vehicle in low gear and increased only as safe
mowing conditions permit. This speed sho ld not exceed 5 mph.
•
The average lawn sho ld be c t to approximately 2.5” d ring the cool season and to
over 3” d ring the hot months.
• For a healthier lawn and better aesthetics, yo r lawn sho ld be mowed often and
after moderate growth.
• When c tting high or dense grass areas go slowly. Some areas may need to be
mowed twice. The second c t sho ld be at 90 degrees to the first, if possible.
• Mowing thick or high grass. Raise rear height crank handles to .5”-
.75” above the
other two handles.
• Creating a manicured lawn. Lower rear height crank handle to .25”-.5” below
front of deck. This allows grass blades to be c t twice. It also contin ally c ts
clippings to prod ce a m lching effect.
GENERAL TROUBLE SHOOTING
• The mower is not c tting level.
o Level deck, making s re the side crank-handles are eq al.
o Check air press re of all tires; make s re they are eq al, and to
man fact res specifications.
o Examine blades for damage, while mower engine is not r nning.
• The engine will not start.
o
Disengage blades, t rn toggle switch to “ON” position, check battery and all
other electrical connections, and inspect spark pl g and wire.
o Check for f el in the engine.
• Engine r ns poorly.
o See engine man al.
o Check throttle adj ster.
o Replace f el, clean f el filter and f el line.
IF PROBLEMS PERSIST HAVE A QUALIFIED MECHANIC SERVICE THE
MOWER. NEVER ATTEMPT TO MAKE AN ADJUSTMENT THAT YOU ARE
NOT SURE IS CORRECT. DOING SO CAN CAUSE OTHER PROBLEMS.
8

둆 ㊠
ɋ҂
MOWER MAINTENANCE
GENERAL RECOMMENDATIONS
The warranty on this Trail Mower does not cover items that have been s bjected to operator ab se or negligence.
To receive f ll val e from the warranty, operator m st maintain nit as instr cted in this man al.
Some adj stments will need to be made periodically to maintain yo r nit properly.
All adj stments in this man al sho ld be checked at least once each season.
Periodically inspect and clean excessive debris inside the battery cover (17340) and belt covers (18391
). Disconnect
spark pl g wire before cleaning.
BEFORE EACH USE
• Check engine oil level on a level s rface. Check twice to ins re an acc rate reading.
• Check condition of air filter; clean and replace as necessary.
• Check blade operation; keep blades in good condition.
• Check for loose fasteners and tighten them as needed.
AFTER EACH USE
• Keep blades sharp.
• Remove fresh grass clippings with garden hose.
• Grass clippings hardened to the nderside sho ld be scraped o t with a p tty knife.
• Keep fl ids at proper levels.
• Cover nit to prevent rain or other debris b ild p. Definitely cover the engine.
BEFORE AND/OR AFTER EACH SEASON
• Replace the spark pl g.
• Clean or replace the air filter.
• A new spark pl g and clean air filter ass re proper air-f el mixt re and help yo r engine r n better and last
longer.
• Check blades and belts for wear. Replace as necessary.
STORAGE RECOMMENDATIONS
CAUTION!
Do not store engine indoors or other poorly ventilated area. Keep engine away from gas appliances
where f mes co ld contact open flame, pilot lights, or sparks.
If engine is to be stored for 30 or more days, prepare unit as follows:
• Drain f el o tside into an approved container.
• Start engine properly and r n ntil nit is o t of f el.
• Let engine cool.
• Remove remaining gasoline from carb retor and f el tank to prevent g m deposits from forming within
the engine. G m deposits can ca se malf nction in the engine.
• Store mower with blades disengaged to prevent belts from being permanently stretched.
BLADE CARE AND SERVICE
For best res lts c tter blades m st be kept sharp. The blades can be sharpened with a few strokes of a file or
grinding wheel. Do not attempt to sharpen blades while they are on the mower. Disconnect spark plug wire before
servicing unit.
Important: Replace blades that have been damaged or deeply nicked.
Important: Check blade and spindle hardware on a regular basis to make sure nuts are tight.
Only a q alified mechanic sho ld be sed for any
adj stments, disassembly or other kind of repairs.

ꁆւ
˸ p
10
FRAME ASSEMBLY
GAS TANK
ASSEMBLY DETAIL
4
5
When ordering replacement parts
*USE PAINT CODE: GT=GRAY TK=BLACK
Item Qty Description Part
1 4 Nut - Nyloc 3/8-16 ZY NB182
2 1 Mount - For EPA/CARB Gas Tank 18331*
3 2 Ubolt - SQ , 3/8-16X2.437 X 3 Lg GR 5 ZY 12447
4 1 Cap, Fuel - 2.50 Gallon, Carb Sealed 18221
5 1 Bracket - Fuel Tank 18225
6 2 Bolt - Serr Flange 1/4-20 X 1 3/4 GR5 ZY 18236
7 1 Fuel Tank - 2.5 Gallon, Carb 18214
8 2 Washer - SAE Flat 1/4 ZY NB274
9 2 Nut - Nylock 1/4-20 NB180
Part Description
11782 Line - Fuel, Bulk, 1/4" Low Perm
18232 Line - Fuel, Bulk, 3/16" Low Perm
18223 Clamp - Fuel
AS021 Tie, Black 5 1/2"
Parts Not Shown
ONLY INCLUDED ON “CA” MODELS
(CALIFORNIA COMPLIANT)
Item Qty Description Part
1 4 Screw - 10-24 X 3/4 Phil Truss Head ZP 024203
2 2 Bracket - Carbon Canister, ZT 17127
3 4 Nut - 10-24 Nylon Lock 024900
4 1 Carbon Canister - 2.50 Gallon, 3/16 Line 18224
5 2 Cable Tie - Carbon Canister 18219
ITEMS 4-8 ARE PART OF
ASSEMBLY 20954
ITEM # QTY.
PART NO.
DESCRIPTION
1 1 662* Weldment - Tong e Offset Extension
2 1 661A* Weldment - Solid Stock Hitch
3 4 H11 Pin - Safety Hitch
4 2 NB622 Bolt - Serr Flange, 5/16-18X2 1/4
5 1 21152* Plate - Clevis, Top
6 1 20953* T be - Tow Hitch
7 1 21153* Plate - Clevis, Bottom
8 2 NB170 N t - Serr Flange 5/16-18
9 1 3664 Bar - Right Sway
ITEM # QTY. PART NO. DESCRIPTION
10 3 10579 B shing -Stepped Height Adj st
11 6 NB126 Pin - 1/8" X 1" Cotter
12 4 T2PB B shing - Plastic
13 3 10038 Bolt - Eye
14 1 3665 Bar - Left Sway
15 1 17600* Weldment - T60 Frame
16 4 NB178 Washer - 5/8 ID X 1 OD 10 GA
17 2 F4157WK Wheel/Tire
18 2 NB149 Washer - 5/8 ID X 1 OD 14 GA

11
OUTER BLADE DRIVER DETAIL
Part No. Torque (ft-lbs)
NB175 90
NB238N 35
NB524 20
NB216 35
Recommended Torque Specifications
CENTER BLADE DRIVER DETAIL
When ordering replacement parts
*USE PAINT CODE: GT=GRAY TK=BLACK

ւ཰
˸ p
12
GRASS CHUTE &
SPRING DETAIL
ITEM # QTY. PART NO. DESCRIPTION
1 1 166X34 Spring - Torsion
2 1 NB182 N t - Nyloc 3/8-16 zy
3 1 NB784 Bolt - HCC 3/8-16 x 7
4 1 092100 Ch t e - Discharge
CASTER / WHEEL
ASSEMBLY DETAIL
ITEM # QTY. PART NO. DESCRIPTION
1 2 B98 Bearing
2 1 17X195 Washer - Flat
3 1 094618 Cap
4 2 NB195 Washer - 13/16 ID X 1 1/4 OD X 1/8
5 1 663L Spacer
6 1 NB595 N t - Locking Jam, 2 Way 5/8-11
7 2 NB178 Washer - 5/8 ID X 1 OD 10 GA
8 1 665* Weldment - Caster
9 1 F4157WK Tire/Wheel - 5/8 Bearing 13x5x6 NHS, Blk
10 1 NB122 N t - Nyloc Jam 3/4-16
11
1
NB624
Bolt - 5/8"-16 X 7" HCC ZY Grade 5
MOWER DECK DETAIL
When ordering replacement parts
*USE PAINT CODE: GT=GRAY TK=BLACK
ITEM # QTY PART NO DESCRIPTION
1 2 18391 Cover - Belt, Black Composite
2 8 18531 Washer - Bent .25" ID X 18GA
3 8 NB703 Screw - MSC, 10-24 X 1 1/4
4 8 18532 N t - Clip, 10-24
5 1 -- See Grass Ch te & Spring Det ail
6 11 NB596 Bolt - Serr Flange 5/16-18 X 3/4
7 1 092104* Bracket - Deflector
8 2 NB577 Bolt -1/2-13 X 3 1/2
9 3 3511 Wheel - Ga ge
10 4 NB121 N t - Jam Lock 1/2-13 2-Way
11 1 15780* Bracket - Wheel Right
12 13 NB170 N t - Serr Flange 5/16-18 Z
13 1 18383* Bracket - Middle Roller
14 1 NB688 N t - Nyloc Jam, 1/2-13 ZY
15 1 NB132 Bolt -1/2-13 X 4 HCC
16 1 NB281 N t - Nyloc 1/2-13 ZY
17 1 -- See Engage Lever Detail
18 2 T2PB B shing - Plastic
19 1 18384* Bracket - Deck Hanger
20 1 NB509 Bolt - 1/2-13 X 2 HCC
21 1 15779* Bracket - Left Wheel
22 1 NB707 Bolt - Carriage 3/8-16X4
23 2 AS001 Roller - Anti-Scalp 3/8 ID
24 1 NB207 N t - Nyloc 3/8-16
25 1 18382*
Deck - Weldment T60 Ro ndback
26 2 NB106 Bolt - 5/16-18 X 2 3/4 HCC
27 4 26X249 Screw - .312-18X.75
28 2 NB181 N t - Nyloc 5/16-18
29 1 -- See Center Blade Driver Detail
30 1 -- See Motor Base Detail
31 1 20946 See Safety Switch Bracket Detail
32 1 -- See Idler Detail
33 2 -- See O ter Blade Driver Detail

ւ챆
ɋ p
13
Slide plastic tube snug
against toggle switch.
20899 Harness - Wiring
BCSR Cable - Battery (10" Red)
BCLB Cable - Batt ery (19 1/2"or 20" Black)
KSK Keys - For Key Switch (set of two)
BCBT Boot - R bber, Small, Battery Cable
PARTS NOT SHOWN
Item # 52
Item # 10
MOTOR BASE DETAIL
U1 Battery
(Not Included)
When ordering replacement parts
*USE PAINT CODE: GT=GRAY TK=BLACK
ITEM # QTY. PART NO. DESCRIPTION
1 10 024206 Screw - 12 X 1/2 Hex Self Tap
2 1 17840* Cover - Battery Top
3 1 17616* Cover - Bat tery Right
4 2 26X263 Screw – TCS 1/4-20 X 5/8
5 1 4226K Knob - T, For Throttle Cable
6 1 20916 Cable - Thrott le
7 1 17614* Cover - Battery Top Front
8 1 9087 N t - Key Switch
9 1 9088 Washer - Lock, Key Switch
10 1 685SP Switch - Toggle, Single Pole
11 6 NB161 Screw - HX Tek 1/4 X 3/4 ZP
12 1 3623 Swit ch - Key
13 2 NB180 N t - Nylock 1/4-20
14 1 17794* Bracket - Batt ery Hold Down
15 1 17615* Cover - Battery Left
16 2 17760 Bolt-L
17 3 NB524 N t - Serr Flange, 1/4-20 Grade 5
18 1 14869 G ide - Belt; T60
19 3 NB275 Washer - SAE Flat 5/16
20 3 NB250 Bolt - 1/4-20 X 3/4 GR5
21 1 N/A Engine (Reference Model Shown)
22 1 1002004 Solenoid - 3 Pole
23 1 20935 G ide - Belt , FC
24 4 NB711 Washer - Split Lock, 3/8 ZY, Medi m
25 4 NB618 Bolt - 3/8-16 X 1 1/4 GR5 ZY
ITEM # QTY. PART NO. DESCRIPTION
26 1 NB210Z N t - 5/16-18 HNC
27 2 NB181 N t - Nyloc 5/16-18
28 1 NB280 N t - 2 Way Lock 3/8-16 Wax Gr A
29 1 6009* Idler - Engage Weldment
30 1 B527 P lley - Idler, OD3.25" ID3/8"
31 1 NB272 Washer - SAE Flat 3/8
32 1 NB107 Bolt - 3/8-16 X 1 1/2 HCC GR5
33 1 10636YZ Bolt - Spade, 5/16-18 X12
34 1 20919 M ffler - Kawasaki
35 1 689L Spacer - Long, Engine P lley, 1.5"
36 1 9031 Key Stock - 1/4 X 1 Undr Size
37 1 688 P lley - Engine, 5.5"
38 1 689S Spacer - Short, Engine P lley, .687
39 1 TR150W Washer - .531IDX1 1/2ODX.062(Ht Trtd)
40 2 699 Washer - Belleville 7/16 X 1 1/4
41 1 NB452N Bolt - 7/16-20 X 1 HCF GR5 Nylock
42 1 NB182 N t - Nyloc 3/8-16
43 1 20904* Motor Base - Weldment
44 1 -- See Saftey Switch Detail
45 1 BRS6 Spring
46 1 NB596 Bolt - Serr Flange, 5/16-18 X 3/4
47 1 4422 Spring - Idler Tension, Bent Leg
48 1 NB220 Bolt - Sho lder 3/8-16X3/4 1/2X1-9/16
49 1 16000 Valve - Oil Drain
50 1 18810 Adapter - Oil Drain, Kawasaki
51 2 NB114 Bolt - TCS 1/4-20 X 1/2
52
1
6736
Tether - Safety, Coiled

ւ덆
˸ p
14
Engage Lever Detail Height Adjust Handle Detail Safety Switch & Bracket Detail
Belt Configuration
20946 Idler Detail
ITEM # QTY. PART # DESCRIPTION
1 1 NB155 Bolt - 1/2-13 X 5 HCC GR5 ZP
2 2 NB121 N t - 2 Way Lock 1/2-13 ZY
3 1 18976* Engage - Weldment
4 1 NB170 N t - Serr Flng 5/16-18
5 1 NB253 Bolt - Serr Flng,5/16-18 X1 1/4
6 1 NB181 N t - Nyloc 5/16-18
7 1 4578* Pivot - Engage
8 2 NB555 Washer - 1/2
9 1 11158 N t - Jam, 2-Wy Lck, 5/16-18
ITEM # QTY. PART # DESCRIPTION
1 1 H7N1TK** T be - Height Adj st
2 1 ES214** Rod - Crank, For H7N
3 1 H7K** Knob - Height Adj stment
4 2 NB117** N t - P sh, 5/16
5 1 OD41** Decal - R ler
**Parts Included in Service Part H7N
ITEM # QTY. PART # DESCRIPTION
1 1 18390* Mo nt - Switch Safety
2 1 3695 Switch - Normally Closed
3 2 NB197 Screw - Phillips Tr ss 8-32 X 1/2
4 2 NB201 N t - Kep 8-32
When ordering replacement parts
*USE PAINT CODE: GT=GRAY TK=BLACK
5058 Long Belt 6046HP Short Belt
ITEM # QTY. PART # DESCRIPTION
1 1 NB618 Bolt - 3/8-16 X 1 1/4 GR5
2 1 6040Z Washer - Idler
3 1 6054* Idler - Bottom
4 1 6037 B shing - Idler
5 2 NB182 N t - Nyloc 3/8-16
6 1 NB280 N t - 2 Way Lock 3/8-16 Gr A
7 1 NB272 Washer - SAE Flat 3/8
8 1 20183 P lley - Idler, 1" X 4" X 3/8" ID
9 1 11223 Eyebolt - T rned 3/8-16 X 5 ZY STD
10 1 NB181 N t - Nyloc 5/16-18
11 1 TZ2S Spring
12 1 NB170 N t - Serr Flange 5/16-18
13 1 NB501 Bolt - 5/16-18 X 1 GR5
14 1 NB107 Bolt - 3/8-16 X 1 1/2 GR5

ｿ཰
ɋOO
NOTES:
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
15

뽆 瞠
˸Ґ
OWNER’S
MANUAL
HOW TO ORDER
REPAIR PARTS:
60” FAST FINISH
TRAIL MOWER
COMMERCIAL PRO
Each mower has its own model n mber. Each engine has its
own model n mber. The model n mber for the mower will be
fo nd at the left rear of the nit on the belt cover skirt.
The model n mber for the engine will be fo nd on the top of
the blower fan ho sing.
All mower parts listed herein may be ordered directly from
Swisher or yo r nearest Swisher dealer.
All engine parts may be ordered from the nearest dealer of the
engine s pplied with yo r mower .
Color cannot be g aranteed on service parts.
WHEN ORDERING PARTS, PLEASE HAVE THE
FOLLOWING INFORMATION AVAILABLE:
* PRODUCT – FC60 FAST FINISH TRAIL MOWER
* SERIAL NUMBER - _______________
* MODEL NUMBER - _______________
* ENGINE MODEL NUMBER - _______________
TYPE - _______________
* PART NUMBER
* PART DESCRIPTION
TELEPHONE - 1-800-222-8183
FAX - 1-660-747-8650
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE
WARRENSBURG, MO 64093
www.swisherinc.com
MODEL NO.
FC14560CPKA
FC14560CPKA-CA
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
IMPORTANT
CHANGING YOUR LANDSCAPE SINCE 1 45
