HOT & COLD WATER PURIFIER
CLIMA PISO
User Manual
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
CONTENTS:
Instructions related with ower ------------------------------------------------------- 2
Installation Instruction ------------------------------------------------------------------- 3
How to use ---------------------------------------------------------------------------------- 4
Life s an of the filters -------------------------------------------------------------------- 8
Basic Troubleshooting--------------------------------------------------------------------- 9
S ecification -------------------------------------------------------------------------------- 11
Filter Elements ------------------------------------------------------------------------------ 13
PISO
MESA
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
Instructions related with Power
Please read the instruction contained in this manual carefully to
avoid
misuses and injury.
!
Use only AC 240V and do not
modify the ower cord without
ermission.
Do not touch or ull the cord with
wet hands.
Do not connect the ower cord
with several electrical a liances
together.
If ower cord is damaged, lease
contact the authorized service
center and re lace it.
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
Installation Instructions
!
Kee the roduct away from fire
and direct sunlight
Kee the roduct away from water
or moist area.
Do not use thinner, benzene or wax
for cleaning, and kee the roduct
away from the volatile chemical
agent.
Install the roduct on the flat and
firm surface.
Do not im act or a ly force to the
roduct
Do not tilt the roduct over 45
degree while moving, and do not
o erate while the roduct is tilted
over 15 degree.
DO
Install the roduct at least 10 mm
distance away from the wall
DON’T
Do not disassemble and re air
without ermissions.
Su ly the ower after 30 minutes
in case of moving the roduct
Do not twist or sna the inlet hose
Do not lace roduct where the
tem erature is below O
o
C
Clean the ower cord if dusts or
foreign object substances are on
the in of the ower lug
Do not lay heavy material on
roduct
Connect to the cold water feeding
i e that is below 35
o
C.
If leakage occurs, close the valve
connected with ta and un lug
ower lug. Contact authorized
service center for assistance.
Do not reach for hot water using
your hand.
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
Other Instructions
How to use
•
O en the valve that is connected to the ta
•Connect the ower lug
•Turn on the Hot Water switch after checking the hot water
su ly. Time to ready for hot water su ly is a roximately 30
minutes.
•Turn off Hot Water switch to save electrical bills if using cold
water only.
!
Let the urified water to flow out over 20L at the first time use after
installation or if the roduct is not been used for a long time.
Use only genuine arts and filters by us for installation and
re lacement.
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
How to use the hot water child safet lock
Removing Filters Set (MESA)
*We strongly advise to engage service center for experienced personnel for filter replacement
Push to release the child safety lock
Release to activate child safety lock
(1) Disconnect the ower lug and
close the valve connected with
dis enser.
(2) Unscrew the to cover at the
back of the system.
(3) O en the to cover and close
the valve inside.
(4) Disconnect the blue & white
hoses from the valves and ull out
the whole filter set to bring to
nearest sink for filter re lacement.
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
Removing Filters Set (PISO)
*We strongly advise to engage service center for experienced personnel for filter replacement
(1) Turn off & disconnect the
ower lug. Close the water valve
connected to the dis enser.
(2) Push down the bottom cover to
o en and access the filter set.
(3) Disconnect the blue & white hoses from the valves and ull out the
whole filter set to bring to nearest sink for filter re lacement.
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
Removing Filters Set – cont.
(4)(a) To disconnect the hoses from
the valves, firstly to take out the
locking cli s at the valve.
(4)(b) Then a ly ressure to the
valve to loosen the hose.
(4)(c) And at the same time ull
the hose out.
(5) Once at the sink, o en the filter
housing(s) by twisting the body
anti-clockwise.
(6) After re lacing or cleaning the filter(s), ut back the filter set and connect
all the hoses back accordingly. Do make sure that all the connections are
tightened.
Please monitor and check for an leakages at all the connection points at
least 10 – 15 minutes before turning on the power.
If in doubts, lease call the service center for assistance.
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
Filter S stem
Life span of Filters
•
The life s an might be varies de ending on water quality and usage.
Filter Prefilter Carbon Filter Ceramic Filter
Lifespan 9 – 12 months 9 – 12 months 2 – 3 years
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
Basic Troubleshooting
Please check below for troubleshooting. If the roblem ersists, lease contact and
inquire to the authorized service center.
S mptom
Cause
Measure
Tem erature of
hot water is low
Su lied ower
is low.
Check su lied ower is 240V, and if not,
adjust ower to 240V.
Heater switch
not on
Check hot water LED is on, and if not,
turn on the heater switch located at the
back of the system.
No cold water
su ly
Su lied ower
is low.
Check su lied ower is 240V, and if not,
adjust ower to 240V.
Cooler s oiled Check cold water LED is on, and if not,
lease contact the service center.
No cold and hot
water su ly
Filters are
blocked.
Disconnect the ower, turn off water
su ly and remove the filter set from the
system. Clean/Re lace filters if necessary.
No water
su ly
Check the main water su ly and make
sure all the valves are on.
Sna ed Hose Find the location of the sna ed hose
and re lace if necessary.
Inconsistent hot
and cold water
su ly
Amount of
water intake is
large
Wait for 5 – 6 minutes.
Water tank is filled
u too slowly
Filters are
blocked
Disconnect the ower, turn off water
su ly and remove the filter set from the
system. Clean/Re lace filters if necessary.
Water ressure
too low
Make sure at least 2 water bar ressure is
available.
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
S mptom
Cause
Measure
Water Leakage Joints are
defective
Close the main valve connected to the
ta and turn off ower. Contact service
center.
Bad taste or odor
is resent
Carbon filter is
reaching its
lifes an
Re lace Carbon filter and drain at least
10 L of water before use.
Contaminated
water tank
Clean water tank.
Stagnant water Drain the water in the tank 2 ~ 3 times
before use.
White bubbles in
urified water
Air bubbles
formed due to
microfiltration.
If they do not disa ear after a while,
contact service center.
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
Specifications
Country of Origin South Korea
Dimension 340 (W) x 375 (D) x 1100 (H) – PISO
340 (W) x 375 (D) x 530 (H) – MESA
Heating & Cooling Storage Ca acity 10 L / hr (Hot)
22 L / hr (Cold)
Cold Water Tem erature 4
o
C ~ 12
o
C
Hot Water Tem erature 70
o
C ~ 90
o
C
Safety Device THERMOSTAT
(For Cold Water Tem . Control)
THERMISTOR
(For Hot Water Tem . Control)
Rated Voltage 220 - 240V / 50Hz
Heater Power Consum tion 450W
Motor Power Consum tion 100W
Com ressor Gas R-134a
PISO
MESA
15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357
Filter Elements
3 Ste s Swiss ro Filter Process
Step 1: Prefilter
It works effectively against sus ended solids
that are more than 5 micron, such as rust
and/or sand articles, without any use of
chemicals.
Step 2: Carbon Filter
Is a high erformance activated carbon filter
that removes other organic contaminants &
heavy metals such as Lead.
Step 3: Micro Ceramic Filter
A 0.2 micron ceramic microfilter that tra s all bacteria and other microorganisms that is
harmful for the health. It also has ermanently incor orated Katadyn silver that is working
against bacteria recontamination from the outlet ta .
Uniquely cleanable ceramic surface which can be reuse again and again till the end of the
lifes an (est. up to 50’000L)
