SWITCH MADE LS1911K User manual

USER
MANUAL
LINE S1911K(B)
LINE S1911C(B)
LINE S1911P(B)
w w w . s w i t c h - m a d e . c o mw w w . s w i t c h - m a d e . c o m
Please read the manual carefully before installation and application, and use the product in the correct way.
Instructions on accessories are included in the manual.
Please properly maintain the manual after reading and understanding it for convenient reference by all users
of the product in the future.
SWITCH MADE

CONTENTS
Installation
Cutting
Surface mounted
02
Components
01
04
Wall mounted
03
Applications
05
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Essential Lighting Source and Power Supply *
* Optional parts
1
2
5
6
3
Flexible strip
Power supply
Prole x1
“K” diuser×1
-1
3
“C” diuser×1
-2
3
“P” diuser×1
-3
End cap×4
Clip ×8
Installation accessories *
7
Pendant accessories
8
180°extender
Others *
9
4
End cap with opening
1
9
2
6
7
4
8
5
3
3-2
3-3
-1
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Surface mounted
Installation
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Wiring at the installation location (mains supply)1
Fixe the clips on the rubber plug or plate
7Connect the strip wire in the prole with the output line of the power supply8
Install the power supply at a proper location
2
Do not touch with wet hand or there is risk of electric shock
Place insulation on both ends of the strip and place the strip on the prole3 Mount the diuser on the prole (K, C or P diuser to be selected depending
on the application demand)
4
Mount the end caps (with and without hole)5 Make an hole of φ5mm at the mounting position and seal it with a rubber
plug
6
Do not place the power supply in water or remove it without permission
Strips with exposed copper foil on the back shall be insulated
End cap
End cap with hole
LED-
LED+
DIM-
DIM+
Driver GND
AC-N
AC-L
Connect to DIM
LED-
LED+
DIM-
DIM+
Driver GND
AC-N
AC-L
Connect to DIM
-
+
LED
If assembling is required, please read the detailed prole assembling steps on P08
and do it in the correct way If the product is mounted on a plate, skip the step
The number of clips to be used depends on the prole length (L):
·When L ≤1.2m, 2pcs of clips are recommended
·When 1.2m ＜L ≤2.5m, 4pcs of clips are recommended
For an end cap without hole, wire goes out from the prole bottom, while it goes out
from an end cap with an hole of φ6mm
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Fix the prole on the clips8 Completed8
When smoke or the smell of burning is found from the xture, please immediately turn it o
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Suspended
Installation
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Wiring at the installation location (mains supply)1
Slip the other end of the pendant cable into the prole and x the wire with
the pendant cable by a cable clip
Fasten the pendant cable on the prole and x the pendant rope with the strip
wire by the protective sleeve
78
Install the power supply at a proper location
2
Do not touch with wet hand or there is risk of electric shock
4 Fix one end of the pendant cable on the rubber plug or plate4
Make an opening of φ5mm at the mounting position and seal it with a rubber
plug
3
Do not place the power supply in water or remove it without permission
The number of pendant cables to be used depends on the prole length (L):
If the product is mounted on a plate, skip the step
Place insulation on both ends of the strip and place the strip on the prole5 Mount the diuser on the prole (K, C or P diuser to be selected depending
on the application demand)
6
Strips with exposed copper foil on the back shall be insulated
LED-
LED+
DIM-
DIM+
Driver
GND
AC-N
AC-L
Connect to DIM
·When L ≤1.2m, 2pcs of pendant cables are recommended
·When 1.2m ＜L ≤2.5m, 4pcs of pendant cables are recommended
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

9Fix the pendant cable at the mounting position
10
Connect the strip wire in the prole with the output line of the power supply
11 Adjust height of the xture
12
Completed
Fix the end caps (with and without hole) on the prole with screws
13
Please make sure the pendant cable is rmly xed
LED-
LED+
DIM-
DIM+
Driver
GND
AC-N
AC-L
Connect to DIM
-
+
LED
When smoke or the smell of burning is found from the xture, please immediately turn
it o
If assembling is required, please read the detailed prole assembling steps on P08
and do it in the correct way
For an end cap without hole, wire goes out from the prole bottom, while it goes out
from an end cap with an hole of φ6mm
End cap
End cap with hole
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Prole assembling
Fix one end of the 180° extender in the slot on the prole back
1Slip the other end of the 180° extender into the prole to be assembled and x it
2
Please read carefully the detailed installation steps before installing the assembling strips. The installation
steps are as follows:
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Cutting
1Mount the diuser on the prole 2
Prole cutting by a cutting machine
It is recommended to set the speed at 1,000 – 1,200rpm. Too high a speed may cause
damage to the diuser
A light source is not slowed to be placed on the prole during cutting
Please make sure the product is rmly xed during cutting. The break shall be ground
smooth to remove burr after cutting, and metal chips shall be completely removed from inside the track
34 Cut the strip to match the prole and weld the red and black wire on one
end of the strip
4
5
24V+ 24V+
24V- 24V-
24V+ 24V+
24V- 24V -
24V+ 24V+
24V- 24V-
24V+ 24V+
24V- 24V -
24V+ 24V+
24V- 24V-
24V+ 24V+
24V- 24V-
24V+ 24V+
24V- 24V -
24V+
24V-
24V+
24V-
φ8mm
When the wire goes out from the end cap, it is unnecessary to make an hole
in the prole. When it goes out from the prole bottom, an hole is to be made,
as shown in the gure below
Mark the length to the cut o (prole loss will occur during cutting by about
the thickness of the blade), and please make reservations of prole length
When the wire goes out form the end cap, the length to be cut o is a multiple of the
minimum cutting unit of the strip. See Figure 1
When the wire goes out from the prole bottom and end cap, the length to be cut o
is a multiple of the minimum cutting unit of the strip + wire length going out (8mm).
Multiple of the minimum cutting unit of the strip
The length of wire
Cutting point
Loss
2500
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Applications
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL
