SWITCH MADE LINE G3030C User manual

USER
MANUAL
LINE G3030C(B)
LINE G3030K(B)
LINE G1616C
LINE G1616K
Please read the manual carefully before installation and application, and use the product in the correct way.
Instructions on accessories are included in the manual.
Please properly maintain the manual after reading and understanding it for convenient reference by all users
of the product in the future.
w w w . s w i t c h - m a d e . c o mw w w . s w i t c h - m a d e . c o m
SWITCH MADE

CONTENTS
Installation
Cutting
Surface mounted
02
Components
01
03
Applications
04
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Essential Lighting Source and Power Supply*
* Optional parts
1
2
5
6
3
Flexible strip
Power supply
Prole x1
“C” Diuser×1
End cap x4
4
Clip×8
Others*
7
End cap with hole
7
2
1
5
6
4
3-2
3-1
-1
3
“K” Diuser×1 -1
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Surface mounted
Installation
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Wiring at the installation location (mains supply)
1
Connect the strip wire in the prole with the output line of the power supply,
Fix the prole on the clips
78
Install the power supply at a proper location
2
Do not touch with wet hand or there is risk of electric shock
Place insulation on both ends of the strip and place the strip on the prole3 Mount the diuser on the prole ( C or K diuser to be selected depending
on the application demand)
4
Mount the end caps (with and without hole)5 Make an hole of φ5mm at the mounting position and seal it with a rubber
plug, Fixe the clips on the rubber plug or plate
6
Do not place the power supply in water or remove it
without permission
LED-
LED+
DIM-
DIM+
Driver
GND
AC-N
AC-L
Connect to DIM
End cap
End cap with hole
LED-
LED+
DIM-
DIM+
Driver
GND
AC-N
AC-L
Connect to DIM
-
+
LED
Strips with exposed copper foil on the back shall be insulated
For an end cap without hole, wire goes out from the prole bottom,
while it goes out from an end cap with an hole of φ4.5mm
LINE G1616C/LINE G1616K plug for the tight structure,
no plug screws
The number of clips to be used depends on the prole length (L):
·When L ≤1.2m, 2pcs of clips are recommended
·When 1.2m ＜L ≤2.5m, 4pcs of clips are recommended
Completed
When smoke or the smell of burning is found from the xture,
please immediately turn it o
w w w . s w i t c h - m a d e . c o m
SWITCH MADE USER MANUAL

Cutting
1Mount the diuser on the prole 2Mark the length to the cut o (prole loss will occur during cutting by about
the thickness of the blade), and please make reservations of prole length
When the wire goes out from the prole bottom and end cap, the length to be cut o
is a multiple of the minimum cutting unit of the strip + wire length going out
(For LINE G3030C(B)/LINE G3030K(B) 8mm wire will be led out, and 10mm for
LINE G1616C/LINE G1616K).
Multiple of the minimum cutting unit of the strip
The length of wire
Cutting point
Loss
Prole cutting by a cutting machine
It is recommended to set the speed at 1,000 – 1,200rpm. Too high a speed may cause
damage to the diuser
A light source is not slowed to be placed on the prole during cutting
Please make sure the product is rmly xed during cutting. The break shall be ground
smooth to remove burr after cutting, and metal chips shall be completely removed from
inside the track
34 Cut the strip to match the prole and weld the red and black wire on one
end of the strip
4
5
24V+ 24V+
24V- 24V-
24V+ 24V+
24V- 24V-
24V+ 24V+
24V- 24V-
24V+ 24V+
24V- 24V -
24V+ 24V+
24V- 24V-
24V+ 24V+
24V- 24V-
24V+ 24V+
24V- 24V -
24V+
24V-
24V+
24V-
φ8mm
When the wire goes out from the end cap, it is unnecessary to make an hole
in the prole. When it goes out from the prole bottom, an hole is to be made,
as shown in the gure below
