Sylvania SDVD8730 User manual

SDVD8730

1
Safety Precaution
Warning: To reduce therisk of fireor electric shock,do not exposethis apparatus torain
or moisture.
1) Please readthe instruction manualcarefully and followall the requirementsof safe
operation to operatethe device.
2) Do notuse this unitnear water.Do not placeover the unitany container withliquid
inside.
3) Do notinstall near anyheat sources suchas radiators, heatregisters, stoves, orother
apparatus (including amplifiers)that produce heat.
4) Unplug thisunit during lightningstorms or whenunused for longtime.
5) AboutCleaning: Unplug thesystem, use onlywet cloth toclean. Do notuse liquid
detergent or aerosol.
6) Only useaccessories specified bythe manufacturer.
7) Refer allservicing to qualifiedservice personnel, servicingis required whenthe unit
has been damagedin any way, such as power supply cord or plug is damaged, liquid
has been spilledor objects havefallen into theunit, exposed tomoisture, does not
operate normally.Don't try torepair the machineby yourself becauseof the dangerof
high voltage andelectric shock.
8) Do notuse irregular shapeddiscs such asheart or star-shapeddiscs as theymay
cause the unitto malfunction.
Thank you forchoosing our portableDVD player.It includes a7” wide screen anda DVD
player. Theunit applies thelatest state ofart electronics andis designed foruse at home,
in hotels andin offices etcfor relaxation. Thecompact size makescarrying easier as
well as installation.Please read themanual carefully prior to use and keep it well for later
consultation.
Table Of Contents
Safety Precaution 1
Package 2
Main Features 2
Main Unit Controls 3
System Connection 4
The Remote Control 7
Basic operation 9
System Setup 14
Specification 17
Troubleshooting 18
Straps Installation Guide 19

2
Main Features
High brightness color7”LCD screen
Compatible with discof DVD, VCD,MP3, MP4, CD,JPEG, etc.
Built-in stereo speaker
Support PALor NTSC system
Support Multi-language OSD,speed forward/backward, repeatfunction
Zoom in/out function
Main Unit Controls
1
1
1
1
1
1
2
Remote Control withbattery
Audio/Video Cable
AC/DC Power Adapter
Cigarette LighterAdapter
User Manual
Earphone
Package
7 '' LCDMonitor & DVD Player
1
DC+Audio/Video Cable
PLAY/
PAUSE
MODE
SETUP
MENU
OFF/ON
DCOUT
DC IN 9-12V
AVOUT
1. Open knob
2. Earphone jack
3. Volumeknob
4. Power ON/OFFswitch
5.Play/Pause
6.SETUP button
7. MENU button
8. MODE button
9.
10.OK button
11. DCIN 9-12V
12.DC OUT
13. AV OUT
14. USB Port
15.SD card slot
1
2
3
4
5
6
7
8
9
10
9
11
12
13
14 15
Monitor View
1
2
3
4
5
6
1. Power ON/OFF
2. Volumeknob
3. Earphone jack
4. AV i n
5. DC IN9-12V
6. Brightness knob
3
Carrybag
Mounting straps
1
2

Notice:
1.Car cigarettelighter adaptor can'tbe used torecharge the battery.
2.Car cigarettelighter adaptor isavailable to useonly when thecarpower supply is9-12V.
Powering and installation
Plug one endof theAC/DC power adaptorinto the DCIN 9-12V jackon the right of the
machine, then plugthe other endinto theAC power receptacle. Please refer tothe
following illustration
If using carcigarette lighter adaptorto connect tothe power:
Plug one endof the cigarettelighter adaptor intothe DC IN9-12V jack onthe unit, plug
the other endinto the carcigarette lighter socket.See illustration below.
System Connection
5
4
DC OUT
DC IN 9-12V
AV OU T
DC OUT
DC IN 9-12V
AV OU T
Connecting to the monitor
The unit canalso be connectedto the externalLCD monitor.
Connect the unitto power byAC/DC adapteror cigarette lighteradapter.
Then connect theunit DC OUT jack to DC IN 9-12V Jack of the LCD Monitor by a DC/AV
cable. Alsouse this DC/AV cable to connect the AV OUTjack of theunit toAV IN
jack of theMonitor.
Please refer tothe illustration below.
Note: You're advised tosupply both unitsthe power bythe cigarette lighteradapter
only. The AC/DC adapter is used to supply power of one unit only.
ON/OFF
DC OUT
DC IN 9-12V
AV OU T
Using SD/MMC card
Upon using anSD or MMCcard, insert itinto the correspondingslot flatly withthe label
side frontward untilyou hear aclick.
Using USB
Upon using anUSB, insert itinto the USBslot directly.

76
1. Number button
2. TITLE (To display title information)
3. AUDIO(Toselect audio language)
4. SETUP (To go toor exit setup menu)
5. Previous/Next button(Togo to
previous/next chapter orscene during
playing)
6. Fast forward/backwardbutton (To
scan forward/backward at2, 4, 8,16,
or 32 times)
7.OSD ( To display discinformation
during playing suchas elapsed and
remaining time)
8. Play/pause
9. Stop (press once tostop playback, then
press to resumeplayback from the
point where youstopped; press stop
button twice tostop playback completely)
10. MODE (To select thesource)
The Remote Control
11. ZOOM(To zoom in/outthe image during
the playback)
12. Menu (To enter orexit menu root)
13. Subtitle (To select subtitlelanguage
when playing DVDdisc)
14. Angle(Tochange viewing anglewhen
playing disc withmulti-angle)
15. A-B(Repeat a specificportion from
point Ato B, pressit again tocancel
repeat playing)
16. Repeat (To repeat playingtitle,
chapter or track)
17. Return (To return tothe main menu)
18. MUTE(To turn tomute)
19. VOL +/- (To adjust thevolume)
20: Enter (Toconfirm)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Connecting with externalSpeaker
The unit canbe connected withexternal speaker.Please see thefollowing illustration
AMPLIFIER
TV
SUBWOOFER
Left front speaker Right front speaker
Center speaker
Left rear speaker Right rear speaker
Notice:There is no 5.1channel in the unit,however, after connectingto APM itis available to
output audio in5.1 channel
AUDIO IN
VIDEO IN
AV CABLE
Not supplied
DC OUT
DC IN 9-12V
AV OU T

8
Playing disc ofDVD, MPEG4, SVCD, VCD, CD, MP3, Xvid
1. Afterconnecting power to the unit, turn on the unitby sliding the ON/OFF
switch to ON,
2. Open thedisc door and insert a disc into the doorwith the label side facing
up.
3. Close thedisc door. The unit will load thedisc and start playing.
4. Press toonce to stop playback; then press to resume playbackfrom
the point whereyou stoped; press twice to stopplayback completely).
5. During playback,press to pause; press it again to resume playback.
6. When theplaying is finished,please turn off the powerby sliding ON/OFF
switch to OFF.
7. For someDVD disc with Title or Chapter menu, press “ MENU” button to
enter menu page,and use to select. Press ENTER to confirm.
the source menuwill be displayed on the screen:
Basic Operation
Press to enterDVD mode or Media mode and press OK button to confirm.
When selecting “Media”,ensure to insert USB or SD/MMC card properly
play/pause
DVD MPEG4 SVCD VCD CD MP3 Xvid
DVD
MEDIA
Cursor button
ENTER
Title Menu
9
Note: Please donot disconnect USB devices or plug out SD/MMC cards
while they areworking with the unit. Functional failure may occur in
case of wrongoperations.
1
2
CR2025 CR2025
0
30
0
30
Please put thebattery into theremote control asper below illustration
When using remotecontrol, make surethe
infrared window ispointed to infraredreceiving
window of themachine. The distancebetween
machine and remotecontrol must bewithin 3
metres. Please referto the followingillustration
Notice
1.To avoid fallingoff or placenear damp environment.
2.To avoid infraredreceiving window of the unit being under direct sunlight
3.Please usea new batteryto replace old one if the remote control doesn't work.
The Use ofRemote Control
PLAY/
PAUSE
MODE
SETUP
MENU

10
DVD MPEG4 SVCD VCD CD
2X 4X
8X16X32X
2X 4X
8X16X32X
DVD MPEG4 SVCD VCD CD
Search forward
Fast forward andfast backward
When playing discof DVD, MPEG4,SVCD,VCD, CD, theunit can searchforward or
backward.
1. Press ,the unit willsearch forward. Pressit repeatedly ,theunit will playat 2, 4,8, 16,
32 times ofspeed.
2. Press ,the unit willsearch backward. Pressit repeatedly ,
the unit willplay at 2,4, 8, 16,32 times ofspeed.
Repeat playing
When playing discof DVD, MPEG4,SVCD, VCD, CD, user can repeatplaying one
chapter, titleor all thewhole disc.
For DVD disc,press “repeat” button, user can repeat playing one Chapter; press it
again to repeatplaying Title;press it thethird time torepeat playing thewhole disc.
For MP3 disc,press “repeat” to repeat playing present file; press it again to repeat
playing the folder;press it thethird time tocancel repeat playing.
Search backward
Chapter Title All
Repeat off
Repeat one Repeat folder
Repeat off
When playing discof DVD, MPEG4,SVCD, VCD, CD,Mp3, user canrepeatedly
play a specificsection.
During playback, press“A-B” button at apoint A,then press
this button againin point B,the unit will automatically repeat
playing the partbetween A-B
Press it thethird time, theunit will returnto normal playback.
1 /4
2 /4
3 /4
4 /4
AB
A
Number
Angle
During playing DVDdisc with multi-angle,press “Angle”
button, the followingswill be displayedon screen:
Press number buttonsto select theangle you desire
Toreturn to normalplaying, please press“Angle” .
The unit willplay the discin the defaultangle.
Notice
The function isavailable only fordiscs with multi-angle.
Angle
A-B
11
Repeat playing offavorite scene
MP3CDVCD
SVCD
MPEG4
DVD

DVD MPEG4 SVCD VCD
2X
3X
4X
1 /2X
1 /3X
1 /4X
Zoom in/out
12
Zoom in/ out
When playing discof DVD, MPEG4,SVCD, VCD,
user can zoomin or zoomout the image.
During playback, press“Zoom ” button, the image will be
enlarged; press itagain the imagewill be enlargedagain;
press it fourthtime, the imagewill zoom out,press it
repeatedly and theimage will returnto normal status.
When the imageis enlarged, usercan press tomove
the image
13
Playing JPG file
1. Place aJPG disc intothe tray,the unit will start reading and play.
2. Press “MENU” to browse JPG files.
3. Press to select aJPG file andpress “ OK” button to confirm.
Note: you canpress MENU toreturn to thefolder list. Press or “ OK ” to preview
the file selected
4. Torotate the picturecounter-clockwise, press “ “;Press “ “to rotate thepicture
clockwise
5. Press OSD buttonwhen viewing pictures,you can selectdifferent refresh modeas
follows:
. from topto bottom
. from bottomto top
. from leftside to rightside
. from rightside to leftside
. from lefttop to rightbottom
. from righttop to left bottom
. from leftbottom to righttop
. from rightbottom to lefttop
. from horizontalcenter to both sides
. from verticalcenter to both sides
from top andbottom to center.
. from rightand left to center.
. from fourwindow's top sideto bottom side.
. from fourwindow's left sideto right side.
. from 4edges to center.
6. During viewingfiles, “ “ may appear when pressing or "Subtitle"or "Audio"
or "A-B" or"Title" etc; in this situation these options are unavailable to operate.
7. When viewingJPG files, press" " ,pictures will bedisplayed in thumbnailmode,
press or “OK" button to selectone picture toview
Playing MP3 files
1.Place MP3disc into thedisc door or insert USB disk, SD card to USB port or SD card slot.
Press “ ” or “OK” button to choose a MP3 file; Press “ ” or “ OK ” button to play the
file selected.
00 36 03 43
Dir 001
\Ctyy\
......
Mp3 TRACK01
Mp3 TRACK02
Mp3 TRACK03
Mp3 TRACK04
Mp3 TRACK05
"Angle”
/

14 15

Specification
17
16
Compatible disc: DVD/VCD/CD/Mp3/MPEG4
Signal system: PAL/NTSC
Panel size: 7inch
Frequency response: 20Hz to 20 kHz
Video output: 1 Vp-p/75 Ohm, unbalanced
Audio output:1.4Vrms/10kOhm
Audio S/N:Better than 80 dB
Dynamic range: Betterthan 85 dB
Laser: Semiconductor Laser, Wave Length: 650 nm/795 nm
Power source: DC9-12V
Power consumption: 10W
Operating temperature: 0~40°C
Weight( ): 0.42/0.7kg
Dimensions ( (W x Dx H): /255x 146x 36mm
Monitor/DVD Player
Monitor/DVD Player) 255x146x26

18
Troubleshooting
PROBLEM SOLUTION
No sound or
distorted sound
Make sure themachine is connectedproperly.
Make sure allcables are securelyinserted into
the appropriate jacks.
The icon
appears on
screen
Can't advance
through a movie
Picture is distorted
No forward or
reverse scan
You can't advance through the opening credits
and warning informationthat appears atthe
beginning of moviesbecause the discis
programmed to prohibitthat action.
The feature oraction cannot becompleted at
this time because:
1. The disc'ssoftware restricts it.
2. The disc'ssoftware doesn't support the
feature (e.g., angles)
3. The featureis not available at the moment.
4. You've requested a title or chapter number
that is outof range.
Some discs havesections that prohibitrapid
scanning or chapterskip;
If you tryto skip throughthe warning information
and credits atthe beginning ofa movie, you
won't be ableto. This partof the movie is often
programmed to prohibitskipping through it.
The disc mightbe damaged. Try another disc;
It is normalfor some distortionto appear during
forward or reversescan.
Owing to continuous improvement, no prior notice will be given regarding changes on above
feature and spec.
19
PLAY/
PAUSE
MODE
SETUP
MENU
PLAY/
PAUSE
MODE
SETUP
MENU
