Sym e-Virid User manual

Periodical Maintenance Chart
Item First
month
Every
month
Every 3
months
Every 6
months
Every 1
year Note
1
Motor I
2
Motor Controller I
5
Battery I I
6
Charger I I
7
DC to DC Converter I I
8
Tire I I
9
Tire Pressure I I
10
Brake Clearance I I A
11
Light / Electrical System / Meter I I
12
Electric Throttle Operation I
13
Steering Handlebar I
14
Bolt / Screw / Nut Tightness I I
15
Main Stand / Spring I
16
Suspension / Oil Leakage I
17
Frame Parts Lubrication L
18
Transmission Belt I
19
Transmission Oil
R Replace every 4 months or 2000km
I-Inspection A-Adjustment R-Replace C-Clean L-Lubrication

Maintenance Record
1st month 2nd month 3rd month 4th month 5th month 6th month
Kilometer
km
km
km
km
km
km
Date / /
/ /
/ /
/ /
/ /
/ /
Distributor
7th month 8th month 9th month 10th month 11th month 12th month
Kilometer
km
km
km
km
km
km
Date / /
/ /
/ /
/ /
/ /
/ /
Distributor
13th month 14th month 15th month 16th month 17th month 18th month
Kilometer
km
km
km
km
km
km
Date / /
/ /
/ /
/ /
/ /
/ /
Distributor
19th month 20th month 21st month 22nd month
23rd month 24th month
Kilometer
km
km
km
km
km
km
Date / /
/ /
/ /
/ /
/ /
/ /
Distributor

25th month 26th month 27th month 28th month 29th month 30th month
Kilometer
km
km
km
km
km
km
Date / /
/ /
/ /
/ /
/ /
/ /
Distributor
31st month 32nd month
33rd month 34th month 35th month 36th month
Kilometer
km
km
km
km
km
km
Date / /
/ /
/ /
/ /
/ /
/ /
Distributor
37th month 38th month 39th month 40th month 41st month 42nd month
Kilometer
km
km
km
km
km
km
Date / /
/ /
/ /
/ /
/ /
/ /
Distributor
43rd month 44th month 45th month 46th month 47th month 48th month
Kilometer
km
km
km
km
km
km
Date / /
/ /
/ /
/ /
/ /
/ /
Distributor
Note:1. Bring this maintenance record while maintaining and repairing your scooter.
2. Expendable replacement items and abnormal usage are not applicable to the warranty.
Please read the warranty procedure.
3. Please carry out maintenance in accordance with the Maintenance Record.
4. Whlie running out of the Maintenance Record, please copy and add it to the original.

This manual describes the correct usage of this vehicle including safe riding, simple inspection methods
and so on.
For a more comfortable and safer riding, please read this manual carefully.
For your benefit, please ask your SYM dealer the operating manual and read the following:
Correct usage of the vehicle.
Pre-delivery inspection and maintenance.
Usage of warranty, warrant contents, and warranty period.
In case the vehicle’s specifications and construction are modified and different from the photos and
diagrams on the owner’s manual / catalogues, the specifications and construction of the actual vehicle shall
prevail.
◎
◎◎
◎Safety Suggestion◎
◎◎
◎
We concern the safety of both you and your scooter, thus, in this manual we provide safety suggestions
of the scooter usage. Please read carefully and follow the safety suggestions. These safety
suggestions indicate some potential dangers which may cause injury; each safety suggestion has specific
warning mark, symbol, or notation illustrated below:
Warning
Disobeying of this mark may lead to serious injury or even death.
Caution
Disobeying of this mark may lead to hurt or even serious injury.
Attention
Disobeying of this mark may lead to hurt.
◎Every safety suggestion has notation telling you what danger may happen and how to avoid or reduce
the risk.
◎In addition to the three safety suggestions mentioned before, there is also another important mark in
this manual—Note ; disobeying this mark may result malfunction of your scooter.

1
1. Contents
1. Contents ......................................................................................................................... 1
2. Control Location ............................................................................................................ 2
3. Warranty Method ........................................................................................................... 3
4. Correct Riding Method .................................................................................................. 4
Use Genuine Spare Parts .................................................................................................... 4
Safe Riding ....................................................................................................................... 4
Riding Method ................................................................................................................... 5
5. Use of Each Component ............................................................................................... 7
Gauges ............................................................................................................................. 7
Main Switch / Handlebar Lock Operation ............................................................................. 11
Button Operation .............................................................................................................. 12
Seat Lock ........................................................................................................................ 12
Note on Starting to Ride .................................................................................................... 13
Brake .............................................................................................................................. 13
Parking / Shutting Off ........................................................................................................ 13
Electric Throttle Instruction ................................................................................................ 14
Battery Charging Instruction .............................................................................................. 14
Battery Charging Procedure .............................................................................................. 15
Battery Usage Instruction .................................................................................................. 16
Battery Charger Usage Method .......................................................................................... 17
6. Inspection and Maintenance before Riding ............................................................... 19
Tire Inspection ................................................................................................................. 19
Steering Handlebar Inspection ........................................................................................... 19
Brake Lever Free Play Inspection & Adjustment ................................................................... 20
Transmission Oil Replacement .......................................................................................... 20
Maintenance ................................................................................................................... 21
Motor Usage Notes .......................................................................................................... 21
Motor Controller Usage Notes ............................................................................................ 21
7. Troubleshooting .......................................................................................................... 22
8. Specification ................................................................................................................ 23
9. SYM Electric Scooter Q & A ........................................................................................ 24

2
2. Control Location
Battery
Front Brake
Lever
Rear Brake
Lever
Luggage Box
Luggage Box
Lock
Headlight / Starter
/Horn Switch
Front Position
Light
Headlight
Taillight
Main Switch
Rear Turn
Signal Light
Motor
Motor Controller
Frame
Number
Main Stand
Side Stand
Turn signal light
Horn switch
Winker /

3
3. Before Riding
This manual describes the correct usage of this vehicle including safe riding, simple inspection methods
and so on.
For a more comfortable and safer riding, please read this manual carefully.
For your benefit, please ask your SYM dealer the operating manual and read the following:
Correct usage of the vehicle.
Pre-delivery inspection and maintenance.
In case the vehicle’s specifications and construction are modified and different from the photos and
diagrams on the owner’s manual / catalogues, the specifications and construction of the actual vehicle
shall prevail.
SAFE RIDING
It is very important to be relaxed and wear properly while riding, observe traffic regulations, do not rush,
always ride carefully and relaxed.
Usually, most people would ride their newly bought vehicle very carefully, but after they become familiar
with their vehicle, they tend to become reckless which may result in an accident.
To remind you:
Please wear a helmet, and properly tighten the helmet belt when riding.
Clothes with open or loose cuffs may be blown by wind and cause the cuffs caught on the steering
handlebar and thus affects riding safety. So put on clothes with tight sleeves.
Hold the steering handlebar by both hands when riding. Never ride with only one hand.
Observe the speed limit.
Wear suitable low-heel shoes.
Perform periodical maintenance and inspection in accordance with the schedule.
CAUTION:
Modified vehicle will affect its structure or performance, and cause poor engine operation or exhaust
noise, which will result in shorter vehicle service life.
Besides, modification is illegal and does not conform to the original design and specifications.
A modified vehicle will not be covered by warranty. Therefore, do not modify your vehicle at will.
Tire and rim modifications will make it unsafe to ride and may cause severe injury or death.

4
4. Riding
Keep your body such as shoulders, arms, palms, and waist relaxed and ride with the most comfortable
posture in order to react quickly when necessary.
Riding posture will greatly affect riding safety. Always keep your body’s gravity in the center of the
seat. If your body’s gravity is on the rear part of seat, the front wheel load will be reduced, and this
will cause the steering handlebar shaking. It is dangerous to ride a vehicle with an unstable
handlebar.
It will be much easier to make a turn when the rider inclines his body inward. On the contrary, the
rider will feel unstable if his body and the vehicle do not incline when making a turn.
The vehicle is hard to control on a bumpy, unleveled, unpaved road. Try to know the road
conditions in advance, slow down and use your shoulder’s force to control the handlebar.
Suggestion: Do not load unnecessary objects on the front floor panel; avoid affecting the riding
safety and the operation of steering handlebar.
CAUTION:
The rider’s feeling on the handlebar is slightly different with or without a load.
Overload may cause the handlebar to swing and affect the riding safety.
Therefore, do not overload your vehicle.
Overload will cause the vehicle become unstable and hard to control, it may cause serious damage to
the tires and rims; it may also change the center of gravity, which could result in an accident that could
cause injury or death. Do not exceed the maximum authorized load.
USE GENUINE SPARE PARTS
To maintain the vehicle’s best performance, each part’s quality, material, and machined precision must
conform to the design requirements.
“SYM Genuine Spare Parts” are made from the same high quality materials used for the original vehicle.
No parts would be sold to the market until they could meet the designed specifications through
sophisticated engineering and stringent quality control.
Therefore, it is necessary to purchase “SYM Genuine Spare Parts” from “SYM Authorized Dealers or
Franchised Dealers” when replacing spare parts.
If you buy the cheap or fake substitute parts from the market, neither quality nor durability will be
guaranteed.
Also, it may result in unexpected troubles and reduce the vehicle’s performance.
Always use SYM Genuine Spare Parts to ensure its long service life.

5
5. Use of Each Component
Basic Controls of SYM e-Virid
GAUGES
Speedometer
This shows the speed in kilometers per hour (km/h).
Odometer
This odometer shows the total kilometers this motor has been driven.
Turn Signal Indicator
The left or right Indicator will be flashing according to the operated directions of turn
signal light switch when it is turned on.
High Beam Indicator:
This indicator comes on when the high beam headlight switch is turned on.
Charging Indicator
When the battery is being charged, the charging indicator is on.
Battery Quantity Indicator
When the main switch is turned to with the battery quantity gauge pointing to
〝 〞, the battery is fully charged;when consuming the power, the battery quantity
indicator will go down, each section indicates around 10% battery quantity.
Speedometer
Odometer
Battery Volume
Status Indicator
Turn Signal
Indicator
High Beam
Indicator
Charging Indictor
Automatic on & off
headlight /
UV Sensing Window
Energy-saving
Mode
Driving Mode
Vehicle Lock Signal
Abnormal
Indicator
SET Button MODE Button

6
5. Use of Each Component
Adjustment of SET / MODE Button
When key switch is turned to “ ”, Press “MODE” button to change between “TOTAL” and ”TRIP”
modes. Under TRIP mode, press “SET” button continuously to reset the TRIP kilometer readings.
Mode Button
SET Button

7
5. Use of Each Component
Driving Mode
Pull the brake lever then press〝 〞,vehicle lock signal〝 〞will go off, at the mean time you
can switch:〝 〞(normal mode),〝 〞(economic mode),〝 〞(hill-climbing mode).
〝 〞Vehicle Lock Signal
When the main switch is turned to〝 〞, pull the brake lever and press〝 〞, Vehicle Lock
Signal will go off, then you can ride the scooter.
CAUTION:
After unlocking the vehicle, it will automatically transfer to lock condition if the vehicle is not
operated (without turning throttle) in 5 minutes. It is needed to pull the brake lever and press
〝 〞, to activate to vehicle again.
In the situation of unlocking the vehicle while the main stand is applied, turn the throttle and the
rear wheel go unloaded, the vehicle will go idling protection, and there will be no power output.
If the side stand is applied, the vehicle lock signal will be on, and it is unable to activate the
vehicle.
〝 〞Normal Mode
The scooter operates at its max efficiency. The max speed is around 50km/h on level road
condition.
〝 〞Economic Mode
The scooter operates at its most economic efficiency to carry out the best durability. The max
speed is around 30km/h.
〝 〞Hill-climbing Mode
Hill-climbing Mode will increase the motor torsion to enhance hill-climbing ability. After 30
seconds of applying this mode, the scooter will automatically transfer to normal mode.
While used on flat road, the scooter will increase its motor torsion and increase its acceleration.
CAUTION:
If the hill-climbing mode is continuously used on flat road or gentle slope, the scooter will not transfer
to normal mode and maintain at hill-climbing mode.
While changing lanes or making a turn, do not switch the modes.
〝 〞Energy-saving Mode
When riding on flat road condition, 〝 〞indicates the scooter is operated at the most
energy-saving state.
Driving Mode
Vehicle Lock Signal
Energy-saving
Mode

8
5. Use of Each Component
Battery Volume Status Indicator
Turn the main switch to〝 〞
Battery Volume Status Remaining power Condition
90~100% Shows the remaining power is full and at its
best durability.
40~50% Show the remaining power is 40-50%. Avoid
long distance riding.
20~30%
Shows the remaining power is 1/3, and the
system will be compelled to 〝 〞economic
mode; the max speed is 30km/h.
+ 10% The two signals flash shows the remaining
power is low, the durability is around 4km;
please charge the battery immediately.
+ + 5% The three signals flash show the remaining
power is extra low, the durability is around 2km;
please charge the battery immediately.
Note: It is suggested that to charge the battery to its full capacity after each riding.
CAUTION:
When the battery volume indicator shows the remaining power less than 1/3, the system will be
transferred to economic mode to keep the best durability and cannot be switched to other modes; at
the mean time the top speed is less than 30km/h.
Battery Volume
Status Indicator

9
5. Use of Each Component
Operation of Main Switch
MAGNETIC KEY:
::
:
•Align magnetic key and magnetic keyhole and turn right to open the main switch keyhole.
•Align magnetic key and magnetic keyhole and turn left to shut the main switch keyhole.
Main Switch
“ON” position
The motor is on in this position. After unlocking, the scooter is ready for use. The key cannot be
removed.
“OFF” position
The motor is off in this position. The key can be removed.
“steering handle lock” position
Turn the steering handle to left and press the key down and then lightly turn it to lock.
The key can be removed.
When unlocking. Simply turn the key from “lock” to “off.”
Turn signal switch
Horn switch
High/Low Beam Switch
Starting Button/
Mode Switch
Light switch
IGNITION SWITCH
Main switch
keyhole
Magnetic key
keyhole
Ignition switch key
Magnetic key
Seat open switch

10
5. Use of Each Component
Use of Buttons
Light Switches
When the switch is turned to this position, all lights will go off.
When the switch is turned to this position, headlight, position light, rear light, and panel light will
automatically be on or off according to the environment.
When the switch is turned to this position, position light, rear light, and panel light will come on.
When the switch is turned to this position, headlight, position light, rear light, and panel light will
come on.
Starting Button
To activate the motor, press this button.
Turn the main switch to “ ”position, pull brake lever after gauge checking system, then press
this button to activate the motor.
Turn Light Switch
Turn the main switch to “ ”position, turn the turn light switch, and the turn light will flash.
When using turn light, the turn light signal will flash in accordance with the turn you make.
Horn Switch
Turn the main switch to “ ”position, press this button, and the horn will sound.
Seat Lock
•Unlocking method: 1. Insert the key to the keyhole on left side panel, then turn the key right
to open the seat.
2. Press “ ” to open the seat.
Lock:Press the saddle down and it will be locked automatically.

11
5. Use of Each Component
The Best Method to Start
Before start, you should turn on the turn signal, watch the rear side to make sure no vehicle is coming,
and then you can start.
Braking
Avoid unnecessary sudden braking.
Use front and rear wheel brakes simultaneously when braking.
Slow down and brake early when riding in rainy days on slippery roads. Never apply the brakes
suddenly to prevent skidding and falling.
Avoid brake continuously for a long period of time because that may overheat the brakes and reduce its
braking efficiency.
CAUTION:
Using only the front brake or the rear brake increases the risk of falling because the scooter tends to
pull to one side.
When the front or rear brake is operated, speed controller will cut off the power. Be careful when
riding the vehicle.
Parking / Shutting Off
1. Turn on the turn signal in advance to warn the vehicles behind. Decelerate and ride to the right side.
Reverse the electric throttle and pull front and rear brake levers slowly.
2. Push back the turn signal switch and rotate the main switch key to 〝 〞 to cut motor power off.
CAUTION:
Do not rotate the main switch key when riding the vehicle to avoid an accident.
To avoid children from injury and theft, lock the steering handle and removing the key after parking.
3. Park the vehicle on level ground with the main stand.
4. Lock the steering handlebar and remove the key after parking to avoid being stolen.
ELECTRIC THROTTLE INSTRUCTION
Accelerate:
::
:Increase riding speed.
If brake lever is pulled, the electric throttle will be cut
off power.
Decelerate:
::
:Decrease riding speed.
For Front WheelFor Rear Wheel
Decelerate
Accelerate

12
5. Use of Each Component
BATTERY CHARGING INSTRUCTION
Steps for charging battery on vehicle:
1. Open the saddle
2. Insert the power cable of the charger to socket (100V-240V)
3. Connect output cable of the charger and the charging terminal of the vehicle
4. Turn the charger on to charge the battery
Steps for removing the charger:
Reverse the steps of charging.
CAUTION:
Power remaining more than 50%, continuous 14 days without operating, the battery will
automatically be in hibernation mode.
Power remaining 15%-50%, continuous 7 days without operating, the battery will automatically be in
hibernation mode.
Power remaining less than 15%, continuous 2 days without operating, the battery will automatically
be in hibernation mode.
If the battery is in hibernation mode, you have to charge and reactivate the battery before using.
If the vehicle will not be operated for a long period of time, it is recommended to fully charge the
battery to maintain the best efficiency and life service.
WARNING:
Please turn off the power and remove the key before charging to avoid children from injury.
Do not remove the battery from the vehicle and then charge.
Please charge the battery at a cool place. Keep the battery from high temperature, sun ray, heat,
fire, and water.
Please use SYM authorized charger for charging, or the battery may result in electrolyte leakage,
heat, and explosion.
Battery
Charging Terminal
Charging Terminal

13
5. Use of Each Component
STEPS FOR CHARGING THE BATTERY
1. Turn off main switch 2. Keep charger switch on “OFF”
position 3. Open luggage box
4. Open charging cover 5. Connect charging terminal
(Note: Be aware the direction of
the charging terminal)
6. Connect the charger to
AC100V-240V
7.Turn the charger switch to “ON”
position. 8.The charger will show orange
light (charging) or green light
(fully charged).
9.The gauge will show the
battery power while charging.
Note: If the charger shows no light or flashes red light, please check the charging terminal and turn on
the switch again. If the charger light still shows no light or flashes red light, please contact your
SYM dealer.

14
5. Use of Each Component
INSTRUCTION OF BATTERY USAGE
Specification:
::
:Size
Type Voltage
(V) Capacity
(Ah) Length
(mm) Width
(mm) Height
(mm)
Weight
(kg)
Li(Ni Co Mn) O2
48 20 393 246 417 10.2
Usage Method:
::
:
Turn off main switch before charging.
Fully charge the battery before the first ride.
Charge the battery after each ride.
Charge at least once every 3 months, if the vehicle does not operate for a long period of time.
Charge the battery on the vehicle. Do not remove the battery.
CAUTION:
Please use the SYM authorized battery. For the safety of electrical parts, do not use unauthorized
battery.
Keep the battery clean.
Keep children away while charging.
WARNING:
When deformation, leakage or corrosion occurs to the battery case, stop using the battery immediately
and contact your SYM dealer for help.
Do not disassemble, restructure or destroy the battery.
Do not dispose the battery or throw it into fire; recycle it at recycle plants or local dealers.
Factors that affect the life span of the battery:
::
:
(1) Over Discharge:
a. Not in use for long period of time without charging.
b. The battery is not recharged when it is empty.
(2) High-Rate Discharge:
a. Frequent riding at max. speed.
b. Frequent riding on the slope.
c. Frequent riding on the rugged road.
d. Over-loaded.
(3) Others:
a. Vehicle parts worn out.
b. Charger malfunction.

15
5. Use of Each Component
BATTERY CHARGER USAGE NOTES
Usage Method:
::
:
1. Insert the charger output plug into the charging terminal on the battery.
2. Connect charger cable plug “A” to AC power, and connect charger cable “B” to the charger.
3. Turn on charger power switch.
4. Check LED status indicator.
5. When the battery is fully charged, the green light is on.
CAUTION:
Make sure the power switch on “OFF” position while connecting and removing charger cable.
Use the battery charger indoors; avoid hot, humid or dusty environment.
WARNING:
Prevent the charger from striking, pressing, and falling.
Use the charger indoors. Do not place the charger in the luggage box to avoid shocking and moisture.
Do not place the charger in the luggage box while charging to avoid heat.
Keep children away while charging.
Please park the vehicle along the wall or in the corner while charging to avoid tripping people.
LED Indicator
LED Orange Green Red Flash No Light
Mode Charging Fully Charged Abnormal Cable disconnect or power
switch off
LED Red Flash:
Low input voltage, fan malfunction, over-heat protection, battery disconnection, battery low voltage,
charger over voltage protection, overtime charging, battery malfunction
Status Indicator
Charger
Power Switch
Power Input
Socket
Charger Cable
B
A

16
6. Inspection and Maintenance before Riding
Troubleshooting
Detection Item Possible causes Countermeasures
Charger power switch off Turn power switch to “ON”
Not using SYM authorized
battery Using SYM authorized batteryUnable to charge
Low input voltage Power input 100V~240V
Long time charging without
green light on Battery deterioration or
malfunction Replace battery
If problems cannot be eliminated, please contact your SYM dealer.
CHARGER USAGE INSTRUCTION
Specification:
Model Input Voltage Output Voltage
Charging Time Battery Type
48V 10A 100~240 VAC 48 VDC 2~3 hour LiFe Battery (20Ah)
Charger Usage Instruction:
Keep power switch on “OFF” position before charging
Connect charger output cable and battery first, then connect power cable and 100V-240V socket.
Orange light shows the battery is being charged; green light means charging finished, the battery is fully
charged, please stop charging.
Please use SYM authorized charger.
CAUTION:
While connecting or removing cables, please make sure the power switch on “OFF” position.
Please charge the battery indoors, avoid sun ray, moisture, and dust.
Prevent rain, liquid, foreign metal material from falling into the charger to avoid short circuit or burnout.
After charging, please remove the cables from the socket to avoid power consuming.
Do not charge battery of other form and brand with the charger to ensure the life span and safety of the
charger and battery.
CAUTION:
The AC pug is 3P mode; do not modify it to 2P mode to prevent electric shock.
In normal temperature, the battery can be fully charged in 2-3 hours; however, if the ambient
temperature or battery temperature is too high (over 55℃) or too low (under 0℃), to prevent
deterioration, the charger will prolong the charging time to 4-5 hours.
When the charger indicator light does not come on, red light flashes, or the battery cannot be fully
charger, please shut off the charger for 5 seconds, then turn on the charger again to correct the
situation. If this situation still cannot be solved, please contact your SYM dealer.
WARNING:
Use independent socket for the charger, do not share the socket with electric equipment to avoid danger
and fire.
When charging, the fan will make louder noise, which is a normal phenomenon.
Do not disassemble or strike the charger. Warranty will not be applicable if consumers disassemble
the charger or there is obvious damage on the charger.
Table of contents
Other Sym Motorcycle manuals

Sym
Sym MAXSYM 400i User manual

Sym
Sym JET 14 XC05W1-EU Series User manual

Sym
Sym VS150 User manual

Sym
Sym Wolf Classic 150 User manual

Sym
Sym CRUiSYM 300i User manual

Sym
Sym Fiddle III 50i CC User manual

Sym
Sym MMBCU User manual

Sym
Sym Symba 110 MB10A7 Series User manual

Sym
Sym Fiddle II 50 SYM Series User manual

Sym
Sym HD 125 User manual
