Symbol LS 2104 Operating instructions

LS 2104-I007 Special Operating Instructions
(73-32820-007)
Revision A: November 1998
Special Operating
Instructions

LS 2104-I007 Special Operating Instructions
(73-32820-007)
Revision A: November 1998
2-4
The LS2104-I007 differs from the standard in
the following ways:
• New parameters are added for ignor-
ing commands from an IBM 46xx reg-
ister.
• I 2 of 5 range decoding is supported.
• The custom default settings below are
supported.
Custom Defaults
Parameter Default
Ignore IBM 46xx
Beep directives: Enable
Ignore IBM 46xx
Decode directives: Enable
Ignore IBM 46xx
Code Type/
Length directives: Enable
Decode I 2 of 5: 2 discrete lengths -
8 & 14
Host Type: Port 5B for STI30-
xxxx Synapse cables
UPC-A: Disable
UPC-E: Disable
EAN-8: Disable
EAN-13: Disable
Code 128: Disable
Code 39: Disable
UCC/EAN 128: Disable

LS 2104-I007 Special Operating Instructions
(73-32820-007)
Revision A: November 1998
3-4
Interleaved 2 of 5 Lengths
To decode I 2 of 5 bar codes of any length or
within a range, scan the appropriate bar code
below.
Scan four numeric bar codes from the LS 2104
Product Reference Guide when setting up the
scanner to decode a range of I 2 of 5 bar codes.
Beep Directives
Scan a bar code below to ignore or process
beep directives.
I 2 OF 5 ANY LENGTH
I 2 OF 5 LENGTHWITHIN RANGE
IGNORE IBM 46XX BEEP DIRECTIVES
PROCESS IBM 46XX BEEP DIRECTIVES

LS 2104-I007 Special Operating Instructions
(73-32820-007)
Revision A: November 1998
4-4
Decode Directives
Scan a bar code below to ignore or process de-
code directives.
CodeType/Length Directives
Scan a bar code below to ignore or process
code type/length directives.
IGNORE IBM 46XX DECODE DIRECTIVES
PROCESS IBM 46XX DECODE DIRECTIVES
IGNORE IBM 46XX CODETYPE/LENGTH
DIRECTIVES
PROCESS IBM 46XX CODETYPE/LENGTH
DIRECTIVES
