The LS 4071 is a high performance scanner that lets you scan a
bar code and transmit it to a base station up to 10 feet (3 meters)
away, without a physical cable to limit your movement. Instead,
the scanner communicates with the base station through a low
power radio transmission.
Scanning Made Easy
To install the scanner or change the different programmable
parameters of the LS 4071, see the Product Reference Guide .
Ifyou areusing a Synapse cable, selectthe host type byscanning
the appropriate bar code packed with the cable. If you are not
using a Synapse cable, scan one of the bar codes beginning on
page 6.
If you need assistance, contact the technical person in charge of
scanning at your site, or Symbol Technologies.

Quick Reference
2
Ready, Test, Scan
Ready
Make sure connections are secure, and the battery pack is
charged. The battery must be charged before the scanner’s
initial use, and after each day’s use. Placing the scanner in its
base station between uses will help maintain the battery’s
charge.
Be sure the scanner is “paired” to the base station by
scanning the Pairing bar code on the base.
Test
Aim the scanner away from you and press the trigger.
When you press the trigger, the scanning beam is energized
for approximately 3.0 seconds (default).
Scan
Make sure the symbol you want to scan is within the
scanning range. See the LS4071 ProductReferenceGuide .
Also, be certain the scanner is within range of the base
station: 10 feet (3 meters).
The scanner has read the symbol when:
• The yellow LED on the rear of the scanner turns green
for a short period of time after the scanning beam turns
off.
The data has been successfully sent to the base station when:
• You hear a short, high tone beep from the base (if
default beeper settings are selected).
• The yellow LED on the base blinks.

3
Aiming
Scan the Entire Symbol
• Your scan beam must cross every bar and space on the
symbol.
• The larger the symbol, the farther away you should
hold the scanner.
• Hold the scanner closer for symbols with bars that are
close together.
• Ashort, high tone beep from the base indicates a good
decode.
Right Wrong
0123456789 0123456789

Quick Reference
4
Hold at an angle
Do not hold the scanner directly over the bar code. Laser light
reflecting directly back into the scanner from the bar code is
known as specular reflection. This strong light can “blind” the
scanner and make decoding difficult. The area where specular
reflection occurs is known as a “dead zone”.
You can tilt the scanner up to 65 ° forward or back and still
achieve a successful decode. Simple practice quickly shows
what tolerances to work within.
65°
Max
Shaded area represents
dead zone (±2°)
Bar Code
Scan
Beam
Scan
Beam
65°
Max

5
What Does The Beep Mean?
When you hear 1 beep (short high tone) it means data has been
decoded successfully. If any other beeps are heard, contact the
technical person in charge of scanning.
What If...
If the scanner is not operating according to your needs,
contact the technical person in charge of scanning. If there is
no one in charge of scanning, call the Symbol Support Center
at 1-800-653-5350.

Quick Reference
6
Host Types
When using an RL475 system, select one of the bar codes below
to communicate with an IBM 468X/9X host.
Port 5B
Port 9B
Port 17
Note: To properly communicate with 468X/9X
terminals, the driver corresponding to the
port being used must be loaded and
enabled when you are configuring your
terminal system. See your terminal’s
operating manual for details.

7
Host Types
RS-232C Host Types
Three RS-232C hosts are set up with their own parameter
default settings. Selecting the ICL, Fujitsu or Nixdorf RS-232C
terminal sets the defaults listed on the following page. These
defaults take precedence over Standard RS-232 defaults. So,
if you’ve selected Fujitsu RS-232C, then select the Standard
RS-232 defaults, the Fujitsu defaults still take precedence. To
return to the factory set defaults, scan the SET ALL
DEFAULTS bar code below. See the table on the following
page for terminal specific defaults.
SET ALL DEFAULTS

Quick Reference
8
Host Types
Parameter Standard ICL FUJITSU NIXDORF
Mode A/
Mode B
Transmit
Code ID
No Yes Yes Yes
Data
Transmission
Format
Data as is Data/Suffix Data/Suffix Data/Suffix
Suffix CR/LF CR CR CR
Baud Rate 9600 9600 9600 9600
Parity None Even None Odd
Hardware
Handshaking
None RTS/CTS
Option 3 None RTS/CTS Option 3
Software
Handshaking
None None None None
Serial
Response
Time-out
2 Sec. 9.9 Sec. 2 Sec. 9.9 Sec.
Stop Bit
Select
One One One One
ASCII Format 8-Bit 8-Bit 8-Bit 8-Bit
Beep On
<BEL>
Disabled Disabled Disabled Disabled
RTS Line
State
Low High Low *Low = No
data to send
*In the Nixdorf Mode B, if CTS is Low, transmission of scan data is
disabled. When CTS is High, bar code data is transmitted to the host.

9
Host Types
When using an RL474 system, select one of the bar codes below
to communicate with an RS-232C host.
STANDARD RS-232C
ICL RS-232C
NIXDORF RS-232C Mode A
NIXDORF RS-232C Mode B
FUJITSU RS-232C

Quick Reference
10
Regulatory Information
Scanner Labeling
COMPLIES WITH US DHHS 21CFR1040. 10 SUBCHAPTER J AND IEC 825-1 : 1993/EN60825-1 1994
VORSICHT! LASERSTRAHLUNG TRITT AUS, WENN DECKEL (CODER KLAPPE) GEDEFFNET IST! MICHT IN DEN
STRAHL BLICKEN!
ATTENTION - LUMIÈRE LASER EN CAS D'OUVERTURE. EXPOSITION DANGEREUSE AU FAISCEAU
DANGER - LASER LIGHT WHEN OPEN. AVOID DIRECT EYE EXPOSURE
LASER LIGHT -
DO NOT STARE INTO BEAM
680 nm LASER
1.0 MILLIWATT MAX OUTPUT
CLASS II LASER PRODUCT
PATENT NO. XXXXXXXXXXXXXXXXXXX
C A U T I O N
ACHTUNG LASERSTRAHL LASERKLASSE 2 NICHT IN DEN STRAHL
BLICKEN,. LUMIERE LASER NE PAS REGARDER DANS LE FAISCEAU
APPARIEL A LASER DE CLASSE 2. CAUTION - LASER LIGHT. DO NOT
STARE INTO BEAM. IEC CLASS 2 LASER PRODUCT 680 nm, 1.0 mw
LASER
COMPLIES WITH US DHHS 21CFR1040. 10 SUBCHAPTER J AND IEC 825-1 : 1993/EN60825-1:1994
CAUTION – LASER LIGHT WHEN OPEN. DO NOT STARE INTO BEAM
ATTENTION – LUMIÈRE LASER EN CAS D'OUVERTURE. NE PAS REGARDER DANS LE FAISCEAU
IE C C L A S S 1 L A S E R P R O D U C T
T I M E B A S I S : 1 0 0 S
A P P A R I E L L A S E R D E C L A S S E I
B A S E D E T E M P S : 1 0 0 S
K L A S S E 1 L A S E R G E R A T E
Z E I T B A S I S : 1 0 0 S
PATENT NO. XXXXXXXXXXXXXXXXXXX
or

11
Regulatory Information
Class I
Symbol U.S. Federal (FDA)/IEC825/EN60825 Class 1 laser
productsuselowpower visible or IR lasers.Class 1 laser devices
are not considered to be hazardous when used for their
intended purpose. To comply with U. S. Federal and
International regulations, the following statement is required:
Caution
Use of controls, adjustments, or performance of procedures
other than those specified herein may result in hazardous
visible or invisible laser light exposure.
This advisory statement also applies to all other FDA/IEC825/
EN60825 classes of laser products.

Quick Reference
12
Regulatory Information
In accordance with Clause 5, IEC 0825 and EN60825, the follow-
ing information is provided to the user:
ENGLISH
CLASS 1 CLASS 1 LASER PRODUCT
CLASS 2 LASER LIGHT
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
DANISH
KLASSE 1 KLASSE 1 LASERPRODUKT
KLASSE 2 LASERLYF
SE IKKE IND I STRÅLEN
KLASSE 2 LASERPRODUKT
DUTCH
KLASSE 1 KLASSE-1 LASERPRODUKT
KLASSE 2 LASERLICHT
NIET IN STRAAL STAREN
KLASSE-2 LASERPRODUKT
FINNISH
LUOKKA 1 LUOKKA 1 LASERTUOTE
LUOKKA 2 LASERVALO
ÄLÄ TUIJOTA SÄDETTÄ
LUOKKA 2 LASERTUOTE
FRENCH
CLASSE 1 PRODUIT LASER DE CLASSE 1
CLASSE 2 LUMIERE LASER
NE PAS REGARDER LE RAYON FIXEMENT
PRODUIT LASER DE CLASSE 2

13
Regulatory Information
GERMAN
KLASSE 1 LASERPRODUKT DER KLASSE 1
KLASSE 2 LASERSTRAHLEN
NICHT DIREKT IN DEN LASERSTRAHL SCHAUEN
LASERPRODUKT DER KLASSE 2
HEBREW
ITALIAN
CLASSE 1 PRODOTTO AL LASER DI CLASSE 1
CLASSE 2 LUCE LASER
NON FISSARE IL RAGGIOPRODOTTO AL LASER DI CLASSE 2
NORWEGIAN
KLASSE 1 LASERPRODUKT, KLASSE 1
KLASSE 2 LASERLYS IKKE STIRR INN I LYSSTRÅLEN
LASERPRODUKT, KLASSE 2
PORTUGUESE
CLASSE 1 PRODUTO LASER DA CLASSE 1
CLASSE 2 LUZ DE LASER NÃO FIXAR O RAIO LUMINOSO
PRODUTO LASER DACLASSE 2
SPANISH
CLASE 1 PRODUCTO LASER DE LA CLASE 1
CLASE 2 LUZ LASER
NO MIRE FIJAMENTE EL HAZ
PRODUCTO LASER DE LACLASE 2
SWEDISH
KLASS 1 LASERPRODUKT KLASS 1
KLASS 2 LASERLJUS STIRRA INTE MOT STRÅLEN
LASERPRODUKT KLASS 2
RNV 1 numr khhzr rnv 1
rnv 2 tur khhzr
thi kvchy tk ,ul vzro
numr khhzr rnv 2

Warranty Information
For Warranty & Service Information, Call:
1-800-653-5350
Outside North America, contact you local Symbol
representative
Symbolproductsarewarrantedagainstdefectsinworkmanship
and materials for a period of one year (unless specified
otherwise) from the date of shipment, provided that the product
remains unmodified and is operated under normal and proper
conditions.
This warranty is limited to repair or replacement at Symbol’s
option, with reasonable promptness after being returned to
Symbol by a carrier selected and paid for by the customer. These
provisions do not prolong the original warranty term for any
product which has been repaired or replaced by Symbol.
This warranty applies to the original owner and does not extend
to any product which has been subject to misuse, neglect,
accidental damage, unauthorized repair or tampering.
Preventive maintenance activities are not covered by warranty.
70-19478-01
Revision B - February 1997
