Symmetry Javelin S884 Guide

Mount the backplate using countersunk headed screws adjacent to the opening edge
of the door.
If fixing hole ’A’ is used then the breakout must be removed and the screw must not
protrude.
Feed the required cables through the backplate:
·The cable from the controller.
If wall tamper function is to be used then breakout ‘B’ must be removed and an
appropriate wall screw fitted through the hole to actuate the tamper lever.
2
1Mount the Backplate
Reader Connections
The S884-OSDP reader is a
keypad. The reader is configured for RS485 / OSDP communications.
This reader is for indoor Use Only.
The S884-OSDP reader will read smartMAX encoded MIFARE cards and card
serial numbers from most ISO 14443A smart cards which have a 4-byte UID (User
Identification).
For additional information regarding the installation, configuration and proper use of
this product:
SMS User Guide, P/N 9600-0429,
M2150 Access Control Design Guide, P/N 9600-0420,
M2150 Intrusion Guide, P/N 9600-0540,
M4000 Commissioning Guide
contactless smart-card reader, with Graphic LCD and
, P/N 9600-0698
The securing screws ‘C’ are integral to the backplate and are unscrewed via
the small holes in the enclosure so that the screw heads locate in the
counterbored holes on the inside of the enclosure.
You should find
that the
backplate has
holes for
connection to
most standard
electrical
backboxes.
C
AB
Installation and User Instructions for S884 OSDP Readers
0V
Rx+
Rx-
12V
Controller
0V
0s
+V
RS485 (OSDP)
1s
Reader
TB1
Connect shield at
controller end only.
Slide the ferrite sleeve onto cable before wiring terminal block. Ferrite to be placed 50mm (2") up cable and held in place
with cable ties.
Note: The FERRITE must be fitted!
Note:
1). Consult local AHJ (Authority Having Jurisdiction) when installing access control readers and locking mechanisms to any
portal in an egress path.
2). The use of Fail Closed / secure configuration shall be determined by local building codes and the local AHJ.
3). Wiring methods shall be in accordance with NEC (National Electrical Code) ANSI/NFPA 70.
225ft (75m) max with Belden 9503 or
450ft (150m) by doubling power cores
with Belden 9536.
If termination is required use Lk5 to set
(see over).
Twisted
pairs

Present the card face-on to the reader until you hear a "bleep". The reader is now working properly. Cards can be
presented in rapid succession; there is no need, for example, to wait for "UNLOCKED" to disappear before presenting
another.
If the reader has been enabled for user-code mode at the controller, you can gain access by pressing the Okey, entering
your card number, then pressing the Pkey.
The reader, by default, retain the formats from the first two cards used.
In addition to the card format retention, the readers allow the first two card formats learnt by the reader to be locked.
Instructions to 'Lock' the formats:
·Ensure that the reader has learnt the two required formats.
·Navigate through the setup menu to 'Card Learning'.
·Set the 'Card Types Locked' to yes 'Y' and Exit.
A Setup menu can be displayed by pressing the Oand Pkeys simultaneously while power is applied. You can use the menu
to change the contrast and language used for the LCD (default English). Use the four function keys to navigate around the
menu.
Please refer to M2150 Intrusion Guide, 9600-0540 for IDS Arm / Disarm procedure.
9600-0725. S884 OSDP Installation and User Instructions
Issue 1.2 © AMAG Technology, 2019.
FCC Notice: This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Any unauthorized modification to this device may void the authority of
the user to operate it. All trademarks acknowledged.
FCC ID: OE5S884O
LED Status Indicator
GREEN –The lock is released and you may open the door.
RED –No access rights to gain entry, or the reader did not read your card properly. Present a card again.
YELLOW –Enter your PIN. If you make a mistake, the message INVALID PIN is momentarily displayed, followed by
ENTER PIN, to prompt you to try again.
Specifications
Input voltage: 12-13Vdc.
(Voltage Source is Class 2 Power Limited)
Input current: 320mA max
Operating temperature: 32 to 120°F (0 to 49°C)
Operating humidity: 15 to 90%, non-condensing.
Maximum read range: 4" (100mm).
Approvals
En302291 & EN301489
4Using / Testing the Reader
For OSDP the links should be configured as below.:
LK3 S (USER Keypad audio feedback) to 1 for sound ON, or 0 for sound OFF.
LK5 Fit
et
link to Pin 2 and 3 to add comms termination (120R). Fit link to Pin1 and 2 for no termination.
3Reader Links
