Symmons 1003-ACP-24 Reference guide

Model Numbers
1003-ACP-24
Installation Brief
Must be mounted to studs or blocking
blocking
2 mm
1
2
3
4
Quick Install Guide Accessory Panel, 1003-ACP-24
(right mount installation shown)
2 mm
wrench
(6) 2" #10-32 screws
Accessory Panel, 1003-ACP-24
 Need Help?
Contact Symmons customer service at
[phone], [phone]
Email: [email protected]
Monday - Friday 7:30 am - 7:00 pm EST
Please check Symmons website
for technical help, the latest product
information and warranty policy.
www.symmons.com/service
Tools Required
Hardware Included
Accessory panel for 24 inch
towel bar and two robe hooks
For left mount installation
ip back plate and panel
so robe hooks are on left side

Note: Dimensions subject to change without notice.
3-9/16" (90 mm)
3/4" (19 mm) dia
6"
(152 mm)
40" (1016 mm)
Must be mounted to studs or blocking
Not for use as a grab bar
3" (76 mm)
1-1/8" dia
(29 mm)
1-1/2" (38 mm)
24" (610 mm)
1-1/2" (38 mm)
1/4" (6 mm)
thickness
3"
(76 mm)
30-1/2" (775 mm)
34-1/2" (876 mm) 2-15/16" (74 mm)
38-1/2" (978 mm)
1/8" (3 mm)
thickness
■ ACCESSORY PANEL (right mount installation shown)
■ MOUNTING PLATE (right mount installation shown)
3/4" (19 mm) 3/4" (19 mm)
1" (25 mm)
1" (25 mm)
1-7/16" (37 mm)
16" (406 mm)
3-1/4" (83 mm) 3-1/4" (83 mm)
24" (610 mm)
30-1/2" (775 mm)
Dimensions Accessory Panel, 1003-ACP-24
For left mount installation ip back plate and panel so robe hooks are on left side.
