Symmons Dia 353TB-18 User manual

Dia
Drill
RECOMMENDED
TOOLS AND MATERIALS
Flathead Screwdriver,
Phillips Screwdriver
Allen Wrench
Tape Measure
All specifications subject to change without
prior notice.
353TB-18 Towel bar
353TB-24 Towel bar
353DTB-18 Towel bar
353DTB-24 Towel bar
353TS-22 Towel shelf
353TR Towel ring
353RH Robe hook
353DRH Double robe hook
353TH Toothbrush holder
353TP Paper holder
353SD Soap dish
353TB-18 & 353TB-24
353DTB-18 & 353DTB-24
353TS-22
353TR 353RH
353TPC
353SD
353TP
353TH
353TB-18
353DTB-18
353TS-22
18.03
18.03
22.05
MODEL NO.LENGTH X=inch
TM
Feature Highlights
▪Metal construction
▪Standard finish is polished chrome
Finish Options
Append appropriate-suffix to model number.
▪STN Satin nickel finish
Warranty
▪Limited Lifetime - to the original end purchaser
in residential/consumer installations
▪5 years - for commercial installations
353DRH
353TB-24 23.62
353DTB-24
23.62
MEASUREMENT
BEFORE INSTALLATION
1
2
3
Measure and mark holes as listed in the above table.
Drill screw mounting holes using a size 5/16" drill bit
-IMPORTANT: Ensure that the holes you have drilled for
installation are level.
use size
5/16" drill bit
X
After securing your mounting hardware to the wall, place
the mounting end of your accessory onto the mounting
hardware as is shown in the picture above. Affix your
accessory to the mounting hardware using the Allen
wrench that shipped with the product.
Accessory Installation Instructions
Toilet
Toilet Paper holder
353TPC
REPLACEMENT PARTS
RA-017Mounting
Hardware Kit
MODEL NO.DESCRIPTION
353-SD2
Soap basket
353-SD2
Affix your mounting hardware to the wall using your
mounting screws. For plaster walls 1/2” thick or less,
insert toggle tool into toggle anchor to secure behind
wall prior to installing accessory trim.
353-SD2 Only:
For California Residents
WARNING: This product contains chemicals known
to the State of California to cause cancer, birth
defects, or other reproductive harm.

ACCESSORY INSTALLATION INSTRUCTIONS
DIMENSIONS
353TR
353TH
353DRH
353TPC
353SD
353TP
353TB-18 & 353TB-24
353TS-22
353DTB-18 & 353DTB-24 353RH
To ensure that your Symmons product will continue to
look as beautiful as the day it was installed,
please follow these simple cleaning instructions.
1. To clean the finish on your Symmons product, rinse
with clean water, wipe with a soft damp cloth
and blot dry with a soft cotton cloth or towel.
2. If heavy cleaning is required start by cleaning as
described in Step 1. Use a mild liquid soap or liquid
glass cleaner to remove any remaining surface buildup.
Rinse product with clean water to remove any
remaining cleaning solution and blot a soft
cotton cloth or towel.
Do not use cleaning products containing abrasives, acids,
alcohol, bleach or foaming compounds. If any
unintentional splashing or overspray of these types of
cleaning products comes in contact with your
Symmons product, immediately rinse it with clean water
and blot a clean soft cotton cloth or towel.
IMPORTANT CLEANING
INSTRUCTIONS
Symmons Industries, Inc. 31 Brooks Drive Braintree, MA 02184
[phone], [phone] Fax [phone] www.symmons.com
[email protected]
■■
■ ■
■©
dry with
dry with
2016 Symmons Industries,Inc ■ZV-1098 REV F 101216
353-SD2
244
[9.62”]
62
[2.43”]
147
[5.80”]
10
[0.39”]
61
[2.40”]
304.8
[12”] 457.2 [18”] 609.6 [24”]
457.2
[18”] 609.6 [24”]
