Symphony Conductor VMS 43 Series User manual

Bailey Hartmann & Braun
TM
Instruction
Conductor
Conductor VMS
Series 43 Auxiliary Terminal

WBPEEUI220772A0
Preface
This instruction provides specific hardware installation, trou-
bleshooting, maintenance, and repair and replacement proce-
dures information necessary for the Conductor VMS Series 43
Auxiliary Terminal. There are additional instructions that
explain how to set up and use the auxiliary terminal. Refer to
the table of reference documents in Section 1 for more informa-
tion on these instructions.
This instruction can be used as a guide by system engineers. It
is not a tutorial and assumes the reader has a general knowl-
edge of installing and maintaining process control systems.
Some sections of this instruction have been prepared in proce-
dure format. There is a sequence flowchart that follows the
introduction to the section and any nonprocedural informa-
tion. This flowchart directs personnel to the appropriate proce-
dure located in the back of this instruction. By treating each
task as a separate entity, the procedures provide an easy
method for finding the information needed to perform each
task. The procedures can be removed and placed in separate
folders or notebooks, or carried to the job site.
The procedures have check boxes in the margin by each step.
When performing a procedure, check each box as each step is
completed.
Do not perform any procedures related to installation, mainte-
nance or repair until reading and understanding this
instruction.
Throughout this instruction a question mark (?) is used to
indicate revision levels in part numbers and variables in
nomenclature positions. In most cases, if a variable is at the
end of a nomenclature item the question mark will not be
included.
This instruction covers C-I-CV43C auxiliary terminals.

WBPEEUI220772A0
List of Effective Pages
NOTE: Changed text or tables are indicated by a vertical bar adjacent to the changed area. Changed fig-
ures are indicated by a vertical bar next to the figure caption. The date appears beside the page number.
Total number of pages in this instruction is 151, consisting of the following:
Page No. Change Date Page No. Change Date
Preface Original
List of Effective Pages Original
iii through xi Original
1-1 through 1-9 Original
2-1 through 2-2 Original
3-1 through 3-8 Original
4-1 through 4-3 Original
5-1 through 5-2 Original
6-1 through 6-7 Original
7-1 Original
A-1 through A-7 Original
B-1 through B-3 Original
C-1 through C-12 Original
PR1-1 Original
PR2-1 through PR2-2 Original
PR3-1 through PR3-2 Original
PR4-1 through PR4-2 Original
PR5-1 through PR5-2 Original
PR6-1 through PR6-4 Original
PR7-1 through PR7-2 Original
PR8-1 through PR8-3 Original
PR9-1 through PR9-2 Original
PR10-1 through PR10-2 Original
PR11-1 through PR11-2 Original
PR12-1 through PR12-3 Original
PR13-1 through PR13-2 Original
PR14-1 through PR14-2 Original
PR15-1 Original
PR16-1 through PR16-2 Original
PR17-1 through PR17-2 Original
PR18-1 through PR18-2 Original
PR19-1 Original
PR20-1 through PR20-3 Original
PR21-1 Original
PR22-1 Original
PR23-1 through PR23-2 Original
PR24-1 Original
PR25-1 through PR25-2 Original
PR26-1 through PR26-2 Original
PR27-1 through PR27-2 Original
PR28-1 through PR28-4 Original
PR29-1 through PR29-2 Original
PR30-1 through PR30-2 Original
PR31-1 through PR31-2 Original
PR32-1 through PR32-2 Original
PR33-1 through PR33-3 Original
PR34-1 Original
PR35-1 through PR35-2 Original
PR36-1 through PR36-2 Original
PR37-1 Original
PR38-1 through PR38-2 Original
PR39-1 through PR39-2 Original
PR40-1 through PR40-2 Original
PR41-1 through PR41-2 Original
PR42-1 Original
Index-1 through Index-3 Original

WBPEEUI220772A0 iii
Table of Contents
Section 1 Introduction ..................................................................................................1-1
Overview .................................................................................................................. 1-1
Intended User .......................................................................................................... 1-1
Description .............................................................................................................. 1-1
Central Processing Unit (CPU) .............................................................................. 1-3
Hardware ............................................................................................................. 1-4
Instruction Content.................................................................................................. 1-4
How to Use this Instruction ...................................................................................... 1-5
Document Conventions ............................................................................................ 1-5
Reference Documents............................................................................................... 1-6
Nomenclature .......................................................................................................... 1-7
Specifications........................................................................................................... 1-7
Accessories .............................................................................................................. 1-9
Section 2 Description and Operation .........................................................................2-1
Introduction............................................................................................................. 2-1
Functional Operation ............................................................................................... 2-1
Section 3 Installation ....................................................................................................3-1
Introduction............................................................................................................. 3-1
Special Handling ...................................................................................................... 3-1
Unpacking and Inspection........................................................................................ 3-2
Safety Considerations .............................................................................................. 3-3
Wiring Considerations.............................................................................................. 3-3
AC Power Wiring................................................................................................... 3-4
Access .............................................................................................................. 3-5
Connections ..................................................................................................... 3-5
Communications Wiring ....................................................................................... 3-6
Access .............................................................................................................. 3-6
Connections ..................................................................................................... 3-6
Grounding............................................................................................................ 3-6
Software Installation and Start-up............................................................................ 3-6
Installation Sequence ............................................................................................... 3-6
Section 4 Troubleshooting ..........................................................................................4-1
Introduction............................................................................................................. 4-1
Troubleshooting ....................................................................................................... 4-1
Troubleshooting Sequence ....................................................................................... 4-2

iv WBPEEUI220772A0
Table of Contents
(continued)
Section 5 Maintenance .................................................................................................5-1
Introduction .............................................................................................................5-1
Preventive Maintenance Schedule .............................................................................5-2
Section 6 Repair and Replacement .............................................................................6-1
Introduction .............................................................................................................6-1
Repair and Replacement Sequence ...........................................................................6-1
Section 7 Replacement and Spare Parts ....................................................................7-1
Spare Parts...............................................................................................................7-1
Appendix A Dimension Drawings ..............................................................................A-1
Introduction ............................................................................................................ A-1
Appendix B Factory Cabling ...................................................................................... B-1
Introduction ............................................................................................................ B-1
Appendix C Quick Reference .....................................................................................C-1
Introduction ............................................................................................................ C-1
List of Procedures
No. Title
PR1 Cover Removal
PR2 Anchoring
PR3 Work Surface Installation
PR4 Connecting Console Components
PR5 Wedge Table Installation
PR6 Power Wiring
PR7 Module Removal
PR8 IIMKM02A Module Settings
PR9 Module Installation
PR10 CPU Removal
PR11 CPU Halt Switch Setting
PR12 CPU Installation
PR13 Keyboard Interface Device Installation

WBPEEUI220772A0 v
List of Procedures
(continued)
No. Title
PR14 Ethernet Wiring
PR15 Printer Installation
PR16 AC Power Test
PR17 DC Power Test
PR18 Checking Connections
PR19 Monitor Cleaning
PR20 Printed Circuit Board Cleaning
PR21 Keyboard Cleaning
PR22 PEP Checking and Inspection
PR23 Multibus Card Cage Removal
PR24 Fan Replacement
PR25 Multibus Card Cage Installation
PR26 Power Supply Removal
PR27 Power Supply Installation
PR28 PEP Replacement
PR29 Graphics Card Settings
PR30 Hard Drive Settings
PR31 CD ROM Drive Settings
PR32 Keyboard Interface Device Removal
PR33 IIADP02 Replacement
PR34 Keyboard Interface Assembly Replacement
PR35 Upper Monitor Removal
PR36 Lower Monitor Removal
PR37 Touchscreen Removal
PR38 Touchscreen Installation
PR39 Touchscreen Controller Card Replacement
PR40 Upper Monitor Installation
PR41 Lower Monitor Installation
PR42 Cover Installation
List of Figures
No. Title Page
1-1. Auxiliary Terminal Components - Front View............................................. 1-2
1-2. Auxiliary Terminal Components - Rear View .............................................. 1-3
2-1. Block Diagram .......................................................................................... 2-2
3-1. Installation Sequence Flowchart................................................................ 3-8
4-1. Troubleshooting Sequence ........................................................................ 4-3
6-1. Repair and Replacement Sequence Flowchart ............................................ 6-2

vi WBPEEUI220772A0
List of Figures
(continued)
No. Title Pg.
6-2. Multibus Card Cage...................................................................................6-3
6-3. Power Supply and PEP ...............................................................................6-4
6-4. CPU...........................................................................................................6-5
6-5. Operator Interface .....................................................................................6-6
6-6. Monitors and Touchscreen ........................................................................6-7
A-1. Auxiliary Terminal Installation Drawing .................................................... A-2
A-2. Anchoring Dimensions.............................................................................. A-2
A-3. Anchoring Scheme (Typical) ...................................................................... A-3
A-4. Cable Entry Cutouts ................................................................................. A-3
A-5. Array Installation Drawing (Typical) .......................................................... A-4
A-6. IICPI01 15° Wedge Installation Drawing .................................................... A-5
A-7. IICPI02 45° Wedge Installation Drawing .................................................... A-5
A-8. IICWS01 Work and Printer Surface Installation Drawing ........................... A-6
A-9. IICUC01 Utility Console Installation Drawing ............................................ A-7
B-1. Factory Cabling ........................................................................................ B-3
C-1. Auxiliary Terminal Components - Front View ............................................ C-2
C-2. Auxiliary Terminal Components - Rear View ............................................. C-3
C-3. IIMKM02A Module .................................................................................... C-4
C-4. Touchscreen Controller Card .................................................................... C-5
C-5. Multibus Card Cage Backplane................................................................. C-5
C-6. CPU Halt Switch Settings.......................................................................... C-6
C-7. Graphics Card Settings............................................................................. C-6
C-8. Hard Disk Drive Settings .......................................................................... C-7
C-9. CD ROM Drive Settings............................................................................. C-7
C-10. Keyboard Interface Assembly .................................................................... C-8
C-11. IIADP01 Panel .......................................................................................... C-9
C-12. IIADP02 Panel ........................................................................................ C-10
C-13. PEP ........................................................................................................ C-11
C-14. Monitor .................................................................................................. C-12
PR2-1. Anchoring Dimensions.......................................................................... PR2-2
PR2-2. Anchoring Scheme (Typical) .................................................................. PR2-2
PR3-1. Work Surface Installation ..................................................................... PR3-1
PR4-1. Connecting Console Components.......................................................... PR4-1
PR5-1. Wedge Table Installation ....................................................................... PR5-2
PR6-1. Cable Entry Cutouts ............................................................................. PR6-3
PR6-2. Power Wiring ........................................................................................ PR6-3
PR6-3. CPU Input Voltage ................................................................................ PR6-4
PR7-1. Module Location ................................................................................... PR7-2
PR8-1. IIMKM02A Module ................................................................................ PR8-3
PR9-1. Module Location ................................................................................... PR9-1
PR10-1. CPU Removal...................................................................................... PR10-2
PR11-1. HALT Switch Setting ........................................................................... PR11-2
PR12-1. Input Voltage Switch........................................................................... PR12-2

WBPEEUI220772A0 vii
List of Figures
(continued)
No. Title Pg.
PR12-2. CPU Installation.................................................................................. PR12-3
PR13-1. Keyboard Interface Assembly .............................................................. PR13-2
PR13-2. IIADP01 Installation............................................................................ PR13-2
PR14-1. Cable Entry Cutouts ........................................................................... PR14-2
PR16-1. PEP..................................................................................................... PR16-2
PR17-1. DC Power Test .................................................................................... PR17-2
PR23-1. Multibus Card Cage Removal .............................................................. PR23-2
PR25-1. Multibus Card Cage ............................................................................ PR25-2
PR26-1. Power Supply Removal ........................................................................ PR26-2
PR27-1. Power Supply Installation.................................................................... PR27-2
PR28-1. PEP..................................................................................................... PR28-3
PR28-2. PEP Replacement ................................................................................ PR28-4
PR29-1. Graphics Card Settings ....................................................................... PR29-2
PR30-1. Hard Disk Drive Settings ..................................................................... PR30-1
PR31-1. CD ROM Drive Settings ....................................................................... PR31-2
PR32-1. Keyboard Interface Assembly .............................................................. PR32-1
PR33-1. IIADP02 Replacement.......................................................................... PR33-2
PR33-2. IIADP02 Bezel Removal ....................................................................... PR33-3
PR39-1. Touchscreen Controller Card Installation ............................................ PR39-2
PR40-1. Monitor Connections and Adjustments ................................................ PR40-2
PR41-1. Monitor Connections and Adjustments ................................................ PR41-2
List of Tables
No. Title Page
1-1. Reference Documents................................................................................ 1-6
1-2. Nomenclature ........................................................................................... 1-7
1-3. Specifications............................................................................................ 1-7
1-4. Accessories ............................................................................................... 1-9
3-1. Wiring Color Code ..................................................................................... 3-4
4-1. Troubleshooting Guide .............................................................................. 4-1
5-1. Preventive Maintenance Schedule.............................................................. 5-2
7-1. Spare Parts (Recommended) ...................................................................... 7-1
A-1. Installation and Dimension Drawings ........................................................A-1
B-1. Factory Cabling.........................................................................................B-1
C-1. Quick Reference Figures ...........................................................................C-1
PR8-1. IIMKM02A Module Jumper Settings ......................................................PR8-1
PR15-1. Printers............................................................................................... PR15-1

viii WBPEEUI220772A0
Safety Summary
GENERAL
WARNINGS Equipment Environment
All components, whether in transportation, operation or storage,
must be in a noncorrosive environment.
Electrical Shock Hazard During Maintenance
Disconnect power or take precautions to insure that contact with
energized parts is avoided when servicing.
SPECIFIC
WARNINGS There are exposed AC and DC connections inside the cabinet.
These exposed electrical connections present a shock hazard that
can cause injury or death. (p. PR7-1, PR9-1, PR10-1, PR12-1,
PR16-1, PR17-1, PR26-1, PR27-1, PR28-1, PR33-1, PR34-1,
PR35-1, PR36-1, PR40-1, PR41-1)
Disconnect power before attempting these procedures. Failure to do
so could result in severe or fatal shock, or equipment damage. (p.
PR18-1, PR20-1, PR22-1, PR23-1, PR25-1)
Disconnect the AC line cord or power lines from the operating
branch circuit coming from the source before attempting electrical
connections. Instruments powered by AC line voltage constitute a
potential for personnel injury due to electric shock. (p. PR6-1,
PR18-1, PR22-1, PR28-1)
Wear eye protection whenever working with cleaning solvents.
When removing solvents from printed circuit boards using com-
pressed air, injury to the eyes could result from splashing solvent as
it is blown off the printed circuit board. (p. PR20-1)
The monitor will slide out by itself when the mounting hardware is
removed. The monitor weighs approximately 27 kilograms (60
pounds) and can cause bodily injury if it is allowed to slide out by
itself. Support the monitor before removing the hardware. (p.
PR35-1, PR36-1, PR40-1, PR41-1)

WBPEEUI220772A0 ix
Safety Summary
(continued)
SPECIFIC
CAUTIONS Make sure that all voltage labels and voltage switch settings on the
peripheral devices, power supply, and power entry panel show the
correct operating voltage. Equipment damage may result if the
incorrect voltage is connected. Make sure the console main power
circuit breaker is off before changing operating voltage settings or
equipment damage may result. (p. PR6-1, PR12-1)

xWBPEEUI220772A0
Support Services
Elsag Bailey will provide assistance in the operation and repair
of its products. Requests for sales or application services
should be made to your nearest sales or service office. Elsag
Bailey can also provide installation, repair and maintenance
contract services.
When ordering parts, use nomenclature or part numbers and
part descriptions from equipment manuals. Parts without a
description must be ordered from the nearest sales or service
office. Recommended spare parts lists, including prices are
available though the nearest sales or service office.
Elsag Bailey has modern training facilities available for train-
ing your personnel. On-site training is also available. Contact
your nearest Elsag Bailey sales office for specific information
and scheduling.
Additional copies of this instruction, or other instructions, can
be obtained from the nearest Elsag Bailey sales office at a rea-
sonable charge.

WBPEEUI220772A0 xi
Trademarks and Registrations
Registrations and trademarks used in this document include:
™ AlphaStation Trademark of Digital Equipment Corporation.
™ DEC Trademark of Digital Equipment Corporation.
™ DECnet Trademark of Digital Equipment Corporation.
® Eberhard Faber Registered trademark of Eberhard Faber Incorporated.
® Elsag Bailey Registered trademark of Elsag Bailey Process Automation.
™ Ethernet Trademark of Xerox Corporation.
® HP Registered trademark of Hewlett-Packard Company.
® INFI-NET Registered trademark of Elsag Bailey Process Automation.
™ Lexmark Trademark of Lexmark International, Inc.
® Mylar Registered trademark of E.I. DuPont de Nemours Company, Incorporated.
® Pink Pearl Registered trademark of Eberhard Faber Incorporated.
™ VMS Trademark of Digital Equipment Corporation.

WBPEEUI220772A0

WBPEEUI220772A0 1 - 1
Section 1
Introduction
Overview
The Conductor VMS™ Series 43 Auxiliary Terminal is a remote
dual monitor and keyboard interface that connects to a main
workstation. The main workstation connects to the INFI-NET ®
communication highway.
In this document, auxiliary terminal refers to a C-I-CV43C
auxiliary terminal and main workstation refers to a
C-I-CV43S-X1, C-I-CV43S-X2, or C-I-CV43S-X3 console; or a
C-I-CV43S-XA or C-I-CV43S-XD driver cabinet. Refer to Table
1-1 for the C-I-CV43S instruction number.
This instruction contains information and procedures neces-
sary to install, maintain and repair the Conductor VMS Series
43 Auxiliary Terminal.
Intended User
This instruction is intended for use by technical personnel
responsible for the installation, maintenance and repair of the
auxiliary terminal.
System engineers and technicians with a background in pro-
cess control systems should read this instruction thoroughly
before installing and using the system. Do not put the terminal
into operation until reading and understanding this instruc-
tion. It is a reference for installers with installation and main-
tenance experience on process control equipment. It is not a
tutorial.
Description
These units are auxiliary terminals for the main workstation.
They provide a remote operator interface for displaying graph-
ics, alarm summaries, Symphony Enterprise Management and
Control System status and for logging, trending and process
control. The auxiliary terminal allows more than one operator
to use a single main workstation.

1 - 2 WBPEEUI220772A0
Description
An Ethernet™ network cable connects the auxiliary terminal to
the main workstation. Figures 1-1 and 1-2 show the main com-
ponents of the auxiliary terminal. Both figures show the unit
with doors open.
Figure 1-1. Auxiliary Terminal Components - Front View
T01441A
FRONT VIEW
MULTIBUS
CARD CAGE
PEP
IIMKM02A MODULE
CD-ROM DRIVE
KEYBOARD
INTERFACE
ASSEMBLY
LOWER
MONITOR
UPPER
MONITOR
ADP
KEYBOARD
CPU

Description
WBPEEUI220772A0 1 - 3
Central Processing Unit (CPU)
The CPU described in this instruction is a DEC™ AlphaSta-
tion™ 255, Model 233. Specifications for the CPU are listed in
the DEC User Information manual shipped with the auxiliary
terminal.
Figure 1-2. Auxiliary Terminal Components - Rear View
T01442A
REAR VIEW
POWER SUPPLY
PEP
DC DISTRIBUTION
BOARD
KEYBOARD
INTERFACE
ASSEMBLY
ADP
MULTIBUS
CARD CAGE
UPPER
MONITOR
CPU

1 - 4 WBPEEUI220772A0
Instruction Content
Hardware
The auxiliary terminal hardware is very similar to that of a
dual monitor main workstation. The auxiliary terminal has dif-
ferent hardware in the CPU (one hard disk drive) and has only
one module in the multibus card cage. The monitors, annunci-
ator display panel (ADP) and keyboard interface assembly are
in the upper half of the auxiliary terminal. The lower half con-
tains the power supply, CPU, power entry panel (PEP) with
cable connector panel and multibus card cage.
The auxiliary terminal has front and rear doors with individual
locks. The front door has slotted openings for air intake to cool
the inside of the auxiliary terminal. It has a stabilizer, which
must be fastened to the front when it is not secured to the
floor. A 63.5-millimeter (2.5-inch) diameter cable entry is
located at the rear of the auxiliary terminal.
Instruction Content
This instruction contains information on C-I-CV43C auxiliary
terminals. It is organized into seven sections, three appendices
and a set of procedures. After becoming completely familiar
with it and the auxiliary terminal, it may be used as a
reference.
Introduction
Presents an overview of the auxiliary terminal and related
hardware. It also provides a complete list of system
specifications.
Description and
Operation
Describes the theory of operation of the auxiliary terminal and
related hardware.
Installation
Provides an introduction into the procedures involved in plac-
ing the auxiliary terminal into operation. Provides an installa-
tion sequence flowchart that directs installation personnel to
the appropriate procedures.
Troubleshooting
Contains a table of error messages and corrective action, and a
troubleshooting sequence flowchart that guides troubleshoot-
ing personnel to the appropriate procedures.
Maintenance
Provides an introduction into the routine maintenance of the
auxiliary terminal. Includes a preventive maintenance sched-
ule that includes references to applicable procedures.

How to Use this Instruction
WBPEEUI220772A0 1 - 5
Repair and
Replacement
Provides an introduction into the procedures involved in
replacing auxiliary terminal components. Includes repair and
replacement sequence flowcharts that direct repair personnel
to the appropriate procedures.
Replacement and Spare
Parts
Includes a spare parts list.
Appendix A - Dimension
Drawings
Contains dimensions drawings for various components.
Appendix B - Factory
Wiring
Contains a factory wiring diagram and table.
Appendix C - Quick
Reference
Provides useful information including circuit board drawings
showing the locations of specific components and switch and
jumper settings.
Procedures PR1
through PR42
Provide procedures for each task.
How to Use this Instruction
Read this entire instruction through in sequence before
attempting to install, maintain or repair the auxiliary terminal.
After gaining a complete understanding of this instruction and
the auxiliary terminal, it can be used as a reference.
Some sections of this instruction have been prepared in proce-
dure format. There are flowcharts that follow the introduction
to the section and any nonprocedural information. These flow-
charts direct personnel to the appropriate procedure. By treat-
ing each task as a separate entity, the procedures provide an
easy method for finding the information needed to perform
each task. The procedures can be removed and placed into
separate folders or notebooks, or carried to the job site.
Each procedure lists the recommended tools to perform that
procedure. Specific tool sizes are listed when required, such as
Allen wrench size, socket size, wrench size, etc. Screwdrivers
are listed as long or short when necessary.
Document Conventions
This document uses standard text conventions to represent
keys, display items and user data inputs:

1 - 6 WBPEEUI220772A0
Reference Documents
Key
Identifies a keyboard key.
Example:
Press .
Display item
Any item displayed on a screen appears as italic text.
Example:
Running
User data input
Bold - Identifies any part of a command line that is not
optional or variable and must be entered exactly as shown.
Italic - Identifies a variable parameter entered in a command
line.
[ ] - Indicates an optional parameter; text within the brackets
follows the previously described conventions.
Examples:
ei 108,87
,key1,key2,x-coord,y-coord
ELE
volume filename.exe
Reference Documents
Table 1-1 lists Elsag Bailey instructions referenced in this
instruction.
ENTER
Table 1-1. Reference Documents
Number Document
I-E96-500 Site Planning and Preparation
WBPEEUI220770A0 Conductor VMS Series 43 Workstation
WBPEEUI220773A0 Operation, Conductor VMS
WBPEEUI220774A0 Configuration, Conductor VMS
WBPEEUI220775A0 File Utilities, Conductor VMS
WBPEEUI220776A0 Display Builder Reference
WBPEEUI220777A0 Introduction and Installation

Nomenclature
WBPEEUI220772A0 1 - 7
Nomenclature
Table 1-2 contains the nomenclature used in this instruction.
The nomenclature presented only includes the positions neces-
sary to adequately identify and describe the auxiliary terminal.
Specifications
Table 1-3 contains the specifications for the C-I-CV43C auxil-
iary terminals.
Table 1-2. Nomenclature
Nomenclature Description
C-I-CV43C-3 Auxiliary terminal with monitor in both upper and lower
positions
Table 1-3. Specifications
Property Characteristic/Value
Power
Line voltage
Line frequency
Circuit breaker size
240 VAC nominal (180 VAC to 264 VAC RMS)
120 VAC nominal (90 VAC to 132 VAC RMS)
Overvoltage category: III
47 to 63 Hz
20 A
Power consumption
Power characteristics
Power supply +5 VDC at 20 A, +12 VDC at 4 A, -12 VDC at 4 A
Keyboards 1 Mylar®(operator)
1 Engineering (QWERTY)
Annunciator display
panels 4 (per IIMKM02A module) 32 pushbuttons and 64 LEDs per panel
Voltage Typical
Amps Maximum Amps Typical Watts Maximum Watts
120 3.79 5.04 323 429.6
240 2.61 3.47 3.21 426.9
Voltage Inrush Current
Amps (Typical) Crest Factor Power Factor
(Typical)
120 53.3 2.49 0.704
240 64.8 4.66 0.510
