Synergy S800 Series Manual

No.4
Backcheck
No.1 Closing
No.2 Latching
90°
1 2 3
4
Fast Slow
Adjusting the force
No.3 Delayed Action
(OPTIONAL)
Using the templates provided, mark and
drill pilot holes into the door and frame.
Connect the armset ensuring the pre-loading
requirement has been completed.
Using the templates provided, fix the mechanism to the door
as well as the armset and any necessary brackets.
Operate door closer in order to check operation.
No.2 No.1 No.3
No.4
65°
Regular Fixing
Installation and Maintenance Instructions:
Maintenance
1.Once the unit has been correctly
fitted it is recommended that
periodic checks (every six
months) are carried out to ensure
all fixings are tight and the door
closes freely and positively into
the frame, without slamming.
2.A light oil lubricant (non-graphite)
should be applied to the moving
joints and exposed pivot points.
After Installation
1.When the closer operates to close
the door from its maximum opening
position, it should ensure the lock
latchbolt and any seals are overcome
and the leaf returned into its frame.
2.When the door is slightly open and
the latch bolt resting against the
strike, release the door to ensure the
leaf fully closes into its frame.
Warning
1.Please note the minimum power size requirement for fire / smoke
door assemblies is 3 as required by Approved Document B.
2.Do not install mechanical hold open devices on fire / smoke door
assemblies.
3.Take care not to exceed the maximum opening angle as detailed
above.
4.Care and attention must be taken when adjusting any of the units
control valves to avoid damage through over adjustment.
5.All Synergy Door Closer units are sealed for life and the internal
components assembled under high load, therefore, tampering
with the mechanism is to be strictly avoided.
Installation Instructions: Please refer to actual size template for exact fitting dimensions
Fixing in Fig.1 / Fig.61
Pre-Loading of Arm
For the unit to provide the optimum performance and overcome any resistance
upon closing it is recommended that the armset is “pre-loaded” To pre-load,
reposition the fixing angle of the arm onto the mechanism so that the end of the
closing cycle would be past the stop position, as indicated below.
Adjustment Details
This unit is a power adjustable mechanism. Power / force adjustment is carried
out by a single adjustment valve in the end of the mechanism. The unit is
pre-set in the factory at EN size 3. Please see table below for adjustment
details for each power size.
The following adjustment valves have a maximum adjustment of 1 full turn per
valve. PLEASE NOTE over adjustment will damage the mechanism and/or the
performance of the door closer and invalidate its guarantee.
Adjust Backcheck (valve #4) and the optional Delayed Action (valve #3) before
adjusting the Closing Speed (valve #1) and Latching Action (valve #2).
90° 90°
Before After 3
Max.
Door width Max. Door weight
950mm 60Kg
Power
size
180°
180°
Door opening
Max.
41100mm 80Kg
5 1250mm 100Kg 180°
0
7CW
Number of turns
7CW
Factory preset
CW:Clockwise CCW:Counterclockwise
2180°
850mm 40Kg 8CCW
ISSUE 07:12/20
10912 ZINS-F979-3S
Fixing Instructions for :
S800 Series
Door Closer
Power Adjustable EN 2-5
www.synergyhardware.co.uk
APPROVED
PRODUCT
CF5294
CPR
AD5196
2812
15
BS EN1154:1997+ A1:2002
485
2114
Backcheck Adjustment
To increase the backcheck action, turn the valve clockwise. To decrease, or to turn
off backcheck, turn the valve counter clockwise.
Adjust the Closing & Latching speed.
1.The door closer can control two different speeds.
2.The No.1 speed-adjusting valve controls the Closing speed, and the No.2 speed
adjusting valve controls the Latching speed.
Delayed Action (optional)
To delay the closing action of the unit adjust valve No.3
This product falls outside of its CE & Certifire approval when this feature is activated.
