SY120SA SINGLE DOOR CONTROLLER
- 1 -
contents
1.Login/Logout Procedure........................................................................................................................- 2 -
2.Add card operation procedurethis function need to operate under login status............................- 3 -
3.Delete Card Operation Procedurethis function needs to operate under login status.....................- 3 -
4.Modify Card Operation Procedurethis function nees to operate under login status......................- 4 -
5. System DI Function Setupthis function needs to operate under login status...............................- 5 -
6. System DO Function Setupthis function needs to operate under login status..............................- 6 -
7. System Group and Timer Control Function Operation this function needs to operate under login
status.....................................................................................................................................................- 6 -
8. Set up card number and password open door way ...............................................................................- 8 -
this function nneds tooperateunder login status................................................................................- 8 -
9. System default ......................................................................................................................................- 9 -
10. Steal Alarm System Function Setup ...................................................................................................- 9 -
11. Anti-Force Function Setup................................................................................................................- 10 -
12. Expand Function Set up....................................................................................................................- 10 -
13. System Communication Identify Number Setup..............................................................................- 10 -
14.SY120SA and Other SY120SA Wiring Diagram ..............................................................................- 11 -
15. SY120SA and MD120EXT-1S Wiring Diagram..............................................................................- 11 -
16.SY120SA and SYRDK5 Wiring Diagram.........................................................................................- 12 -
17. Advanced Features............................................................................................................................- 13 -

SY120SA SINGLE DOOR CONTROLLER
- 2 -
1.Login/Logout Procedure
1-1 System login
Enter FUN + + EN , the “OK” pilot lamp flashes and wait for enter password.
Enter password(preset1234) + EN, and CALL key flashes, it means login success.
Examplelogin procedure
FUN + + EN + + EN 
1-2 System logout
Repeat enter FUN + + EN after setup procedure to logout
1-3 Alter the Login Password
The login password preset three set, the beginning value are all set to 1234, suggest alter the three
set password before using and avoid the unconcerned personnel to login system, the password
alter method as following :
Use preset password(1234) login and enter FUN + + NNNN+NNNN+ EN 
(NNNNnew password , enter second time as confirm action)
Then enter FUN + + EN to logout system to complete the first group password wetting.
The second and third password as the above procedure, repeat use preset password 1234 to login
then modify three times as modify three groups password, please use new password to login after
alter.
Exampleuse preset password to login
FUN + + EN + + EN
modify password to 5678
FUN+ + +  + EN
logout
FUN + + EN

SY120SA SINGLE DOOR CONTROLLER
- 3 -
2.Add card operation procedure【this function need to operate under login status】
2-1 Add One Card
Enter FUN + + NNNN+G+ EN then proximity to one card.
NNNNAssign add card number, range: 0001~2000
GAssign card group number, range : 1~4
Example add one card sequent number0001, and set to group
FUN+ + + + EN , proximity one un-use card.
2-2 Add Multi Cards
EnterFUN+ + NNNN+G+ EN and proximity card one by one.
 NNNNassign card serial numbers from 0001~2000
Gassign card group number, range : 1~4
Exampleadd five card from sequent number 0002 and set to group
FUN+ + + + EN , proximity five un-use cards
 The sequent number will automatically edit 0002 to 0006, the group all set to1.
3.Delete Card Operation Procedure【this function needs to operate under login status】
3-1 Delete One Card
EnterFUN+ + NNNN+ EN
NNNNassign the card number which wants to delete, range : 0001~2000
Exampledelete one card of sequent number 0001
FUN+ + + EN

SY120SA SINGLE DOOR CONTROLLER
- 4 -
3-2 Delete Multi Cards
Enter FUN + + NNNN+EEEE+ EN
NNNNassign the begin card number which wants to delete, range : 0001~2000
EEEEassign the end card number which want to delete, range 0001~2000
Exampledelete cards of sequent number from 0002~0006
FUN+ + + + EN
4.Modify Card Operation Procedure【this function nees to operate under login status】
4-1 Modify One CardGroup
Enter FUN+ NNNN+ G+ EN
NNNNassign card number which wants to modify in the card group, range :0001~2000
Gassign the new group number to card, range: 1~4
Example modify the original card sequent number 0001 in group 1 to group 2
FUN+ + + EN
4-2 Modify One Card
Enter FUN+ NNNN+ S+ EN
NNNNassign the card number which want to modify the card status; rnage:00012000
SS = 1 set up card enableS = 0 set up card disable
Exampledisable the sequent number 0002 card
FUN + + + EN
restart the sequent number 0002 card
FUN + + + EN
4-3 Modify Multi Card Group
EnterFUN+ + NNNN+ EEEE+ G+ EN 
NNNNassign the begin card number of card group which wants to modify; range :00012000
EEEEassign the end card number of card group which wants to modify; range : 00012000
Gassign the new group number of card; range : 14
Examplemodify the original sequent number 0003~0006 cards of group 1 to group 2
FUN+ + + + + EN 

SY120SA SINGLE DOOR CONTROLLER
- 5 -
4-4 Modify Multi Cards
Enter FUN + +NNNN+ EEEE+ S+ EN
NNNNassign the begin card number of card status which wants to modify; range:00012000
EEEEassign the end number of card status which wants to modify; range: 00012000
SS = 1 set up card enableS = 0 set up card disable
Exampledisable the sequent number 0003~0006 cards
FUN+ + + + + EN
5. System DI Function Setup【this function needs to operate under login status】
Enter FUN + + K+ F+ J+ EN 
Kthe DI sequent number which wants to set up, range: 18
K = 5 as SY120SA CALL key K = 6 as expandkeypad reader CALL key
K = 7 as expandDI#1K = 8 as expandDI#2
FDI purpose number, please refer the below DI purpose table.
J0 for set to NOdefault, 1 for set to NC
DI Purpose Table
Number Purpose Notation
0 Not use
1 Door detect (DI1 preset)
2 Open door button (DI2 preset)
3 Emergency open door button Open door and send out alarm until relief
4 Steal alarm set up status
detect Detect if complete deploy
5 Doorbell DI (CALL key preset)
6 Emergency call button Send out alarm until relief
7 One area alarm detect Send out alarm until relief（deploy status）
8 Two area alarm detect Send out alarm until relief（deploy status）
9 Anti- force detect Send out alarm until relief

SY120SA SINGLE DOOR CONTROLLER
- 6 -
6. System DO Function Setup【this function needs to operate under login status】
Enter FUN + + K+ F+ TTT+ EN 
KThe DO sequent number which wants to set up;
K = 1 as electric lock DO,
K = 2 as relay DO,
K = 3 as expand relay DO,
K = 4 as pre-save DO
FDO purpose number, please refer the below DO purpose table.
TTTDO action time set up, range: 000255, unit: second; default electric lock DO for 5 seconds,
relay DO for 2seconds.
DO Purpose Table
Numbe
r Purpose Notation
0 Not use
1 Open door control (electric lock DO preset)
2 Doorbell contact output (relay DO preset)
3 Burglar alarm output Deploy and withdraw controlled
4 Alarm contact output Use withdraw to cancel alarm
5 Anti-force contact output Use[FUN][4][4]to cancel anti-force
alarm
Action time set “0” for keeps action until relief
Exampleset up expand open door button, action time 3seconds (set up DI and DO together)
DI FUN + + + + + EN
DOFUN + + + + + EN
7. System Group and Timer Control Function Operation
【this function needs to operate under login status】

SY120SA SINGLE DOOR CONTROLLER
- 7 -
7-1 System Ttime Setup
Enter FUN + +YYYY+MM+DD+hh+mm+ss+ EN
YYYYyear, range: 20002199MMmonth, range: 0112
DDday, range: 0131
hhhour, range: 0023
mmminute, range: 0059
sssecond, range: 0059
Partly week automatically count by controller
Example:set up April/15/2004 time: 16:30
FUN+ + + + + + + + EN
7-2 Timer Setup
Enter FUN + + HHMM+ hhmm+ EN
HHMMthe time setting of timer begin; hour/mintue; default 0700
hhmmtime setting of timer end; hour/mintue; default 1900
Exampleset up timer from 8am to 6pm
FUN+ + 0800+ 1800+ EN
7-3 group timer set uo ( passage way setup )
Enter FUN + +G+D+N+A+ EN
Ggroup number ( 1 ~ 4 )
Din timer ( 0 ~ 3 )
Nout of timer ( 0 ~ 3 )
Adoor passage, 1= pass enablepreset, 0= pass disable
In and out of timer function table
0Can not pass
1Card or password
2Card system default
3Card and password
ExampleSet up group 1 to use “ card and password” for passage in the timer and can not pass out of timer
FUN + + + + + + EN
7-4 Holiday Setup
Enter FUN + + HH+ MMDD+ EN
HHholiday sequent number, range: 0130, if set to “00” is for clear all holiday setting.
MMDDThe holiday date which wants to assign to the sequent number
Exampleset up holiday sequent number 01 define new year
FUN+ + + + EN

SY120SA SINGLE DOOR CONTROLLER
- 8 -
7-5 group weekly plan
EnterFUN+ + G+ WWWWWWW+ H+ EN
WWWWWWWweekly plan from Sunday to satruday, 1= can passdefault, 0= can not pass
Ggroup number; range: 14
Hholiday control, 1= can passdefault, 0= can not pass
Exampleset up group 1 normal passage from Monday to Friday, Staturday, Sunday and
holidaycan not pass
FUN+ + + + + EN
8. Set up card number and password open door way
【this function nneds tooperateunder login status】
8-1 Use card number plus password to open the door or password only to open the door
need to set up group for card or passage way (for the set up method please refer to 8-3)
EnterFUN+ + P+ EN 
PP = 1 as use card number and password(default)P = 0 as direct password open door.
Example if already set up card or password opne door then st up card number and password
opendoor
FUN+ + + EN
now, before use password to open the door, it requires to enter the card number with password.
For example: first, enter the user’s card number, then enter the default password number to
open the door
+ + EN
8-2 alter user preset passworddefault define 0000
Enter FUN + +nnnnnnnn+ EN
nnnnnew password, enter twice to confirm
ExampleFUN + + + + EN
alter one card password setting(no need to login, can operate under normal status )
The situation of group set up open door mode as card and password
Proximity the card which wants to set up or modify, the card reader will displays wait for
password enter status and stop read card function,
Enter pppp+nnnn+nnnn+ EN
ppppthoe original old password or system first set up password; default deifne 0000
nnnnnew password, enter twice to confirm.

SY120SA SINGLE DOOR CONTROLLER
- 9 -
Examplecard password alter from 0000 to 5678
After proximity card then enter+ + + EN
The card password change from 0000 to 5678
group set up open door mode to password open door mode
Enter NNNN+pppp+nnnn+nnnn+ EN, the system will decide correct or
not, and will response correct status and modify the old password to new password.
NNNNeffective card number, 00012000
ppppthe orginal password or system preset password (default password is 0000)
nnnnnew password, enter twice to confirm.
Examplethe password of card number 0001change from 5678 to 2468
Enter+ + + + EN
The card passowrd change from 6578 to 2468
9. System default
9-1 Clear all setting and restore to default (including card data, parameters, and I/O data…etc.)
Under login status, enter FUN + + EN, it will response the correct status if correct;
thenenterFUN+ + EN again and wait for ten seconds to clear all setting and restore
to default.
10. Steal Alarm System Function Setup
10-1 Steal Alarm system reliefwithdraw
EnterFUN+ + EN, the OK pilot lamp flash once, the warning light go out after
proximity card then burglarproof system complete relief.
10-2 Start Steal Alarm Systemdeploy
Enter FUN + + EN, the pilot lamp flash once, after proximty card the warning light
flashes, the burlgarproof system start operating complete.

SY120SA SINGLE DOOR CONTROLLER
- 10 -
11. Anti-Force Function Setup
11-1 anti-force password start using
Enter FUN + + + EN
G: anti-force password group, range: 1~4
PPPP: enter anti-force password.
system default 1-4 groups all define 5555. If personal password the same with anti-force
password, it will take as presonal password.
11-2 Set up anti-force alarm
Enter FUN + + + EN
 execute anti-force alarm cancel anti-force alarmdefault
Exampleenter anti-force password to start the DO which we choose(relay DO default) 
Anti-force password start using FUN + + + EN
Execute anti-force alarmFUN + + + EN
DOFUN + + + + + EN
12. Expand Function Set up
12-1 Expand module Setup
 EnterFUN+ + + EN
has external expand moduleno external expand moduledefault
12-2 Expand Card Reader Setup
 EnterFUN+ + + EN
standard card reader keypad card readerdefault
13. System Communication Identify Number Setup
Enter FUN + + + EN
controller identify , range: preset 

SY120SA SINGLE DOOR CONTROLLER
- 11 -
14.SY120SA and Other SY120SA Wiring Diagram
15. SY120SA and MD120EXT-1S Wiring Diagram

SY120SA SINGLE DOOR CONTROLLER
- 12 -
16.SY120SA and SYRDK5 Wiring Diagram

E-Lock󰇞󰞺
Reader Power
and
Reader Network
DI 1 Brown
DI 2 Orange󰕉
DI 3 Yellow󰀴
DI 4 Green󰋙
GND Black󰀶
+8 ~ 15V Red
GND Black󰀶
SYRIS New Version
SYRDS1 , SYRDS5
SYRDK5 , SYRDL5
SYRDF5
4R+ 4R- 0V +V
M6
M4
M5
M2
M7
NO NC
GND I4 I3 I2 I1
LED BE D1 D0 0V +V- LOCK +NO1 C1 NC1
+5V LED
RS485 LED
+12V LED
LOCK LED
RELAY LED
BATTERY
CR2032
RELAY
JP1
TAMPER SW
BEEPER
CPU
M7
M2
LED Orange󰕉
BEEPER Yellow󰀴
D1 White
+V Red
GND Black󰀶
D0 Green󰋙
D0 White
D1 Brown
BEEPER Violet
LED Green󰋙
Lock + Brown
Lock- Orange󰕉
NC Green󰋙
COM Blue󰞕
NO Violet
4R-Green󰋙
+8~15VRed
GND Black󰀶
4R+Yellow󰀴
M5
M4
M6
Ex: Door Sensor
Ex: Push Button󰀓󰀉
NO NC
JP1 E-Lock Setting
FAIL - SECURE
󰇞󰀓 FAIL - SAFE 󰝑󰇞󰀓
NO NC
RELAY󰢪󰇞󰔕
POWER & RS485
󰇞󰃎󰋷󰋜󰆢
Connect to
RS485 Convert
󰞰󰔕
Connect to DC Power
󰇞󰃎
GNDBlack󰀶
4R-Green󰋙
4R+Yellow󰀴
M9
TAMPER SW
(反破壞開關)
M9
NO Orange(橙色)
COM Gray(灰色)
PQRS
GHI
4
7
CLR
SYRIS
DEF
FUN
ABC
6
9
WXYZ
MNO
EN MENU
TUV
JKL
5
8
0
1 2 3
CALL


SY120SA SINGLE DOOR CONTROLLER
- 13 -
17. Advanced Features
17-1 System setting function
Code Function Code Function Code Function
0 Remove security 42 Setup Master card 58 Setup I/O data mode
1 To deploy security 43 Setup Anti-duress password 59 Setup extern reader
2 Login / Logout 44 Remove Anti-duress alarm
45 Enabled or Disable Door Forced 61 Configure Input point setting
31 Add single card 46 Enabled or Disable Door Time-Out
32 Delete single card 48 Encryption Card setting 71 Configure Output point setting
33 Modify single card group data 49 Restore to Default setting
34 Modify single card group status 51 Access with password 81 Setup system time
35 Add multiple card 52 Change default password 82 Setup time period
36 Delete multiple card 53 Setup error password lockdown 83 Setup Group
37 Modify multiple cards group data 54 Setup alarm source 84 Setup Weekly Group schedule
38 Modify multiple cards group status 55 Setup alarm enabled 85 Setup Holiday access limit
56 Setup doorbell enabled 86 Automatic door Setting
41 Modify Master card password 57 Setup extend module 91 Setup controller ID
17-2 Reader LED status list
Show light & sound Footnote
code Status description OK LED
(SY120SA)
Power LED
(SY120SA)
Error LED
(error)
BEEPER
(voice)
0 Normal status off LED Red LED Orange no action
1 Correct status LED Green LED Red off short beep(0.5sec) Return to original status
2 Error status off LED Red LED Orange 2 short beep Return to original status
3 Armed status off LED Red twinkling long beep(2sec) Work until remove guard
4 Login status off twinkling off long beep(1sec) Work until login out
5 Alarm status off LED Red twinkling keep rapid beep Work until remove guard
6 Finishing setting status LED Green LED Red off long beep(1sec) Return to original status
7 Activate alarm delay status twinkling LED Red off keep short beep Work until finish guard
8 Waiting input status twinkling LED Red off short beep(0.5sec) Work until finish guard or delay
9 Lockdown status twinkling LED Red twinkling No action Return to original status

SY120SA SINGLE DOOR CONTROLLER
- 14 -
17-3 Usage of Master card (Maximum 3 Master cards)
1. Follow the sequence of [FUN][4][2](K)(D)[EN], if correct and response normal ststus and
see (K)to decide back to original ststus or waiting setting card response.
2. If K = 1 and enter proximity card modeand waiting setting card response.Correct response
back to correct status and original status.
(K):K = 1 use to set card;K = 0 use to cancel card
(D):Set or cancel setting card number, Range:1~3
* if use any setting card(1-3) , the other card password need to operate with setting card
password.
17-4 Enabled or Disable Door Forced(V2.8)
Enter[FUN][4][5](E)[EN]
(E):E = 1 enabled door forced alarm;
E = 0 cancel door forced (default)
17-5 Enabled or Disable Door Time-Out(V2.9)
Enter[FUN][4][6](E) (TT) [EN]
(E): E=0 cancel door time-out (default) ; E=1 enabled door time-out alarm
(TT): Time-Out time setting, Range:01~99; default :20,unit:sec
17-6 Enabled or Disable Encryption Card (V3.0)
Enter[FUN][4][8](E) [EN]
(E): E=0 EM/TEMIC Card (default); E=1 Use SYRIS Encryption Card;
E=2 Use Security Encryption Card
17-7 Error psaaword keylock setting
Enter[FUN][5][3](K)(L)(A)[EN]
(K):setting acceptable error times,range:1~9;default :6
(L):enter lock time setting,range:1~9,unit: min;default :3
(A):enter lock time and show alarm setting status;
A = 1 start,
A = 0 close(default)
17-8 Activate guard and indicate source, delay time
Enter[FUN][5][4](R)(TT)[EN]
(R):R = 0 set inside delay,time us TT to set.It’s default
R = 1 seting inport enter,please follow:system inport setting function
(TT): Activate guard delay time setting, Range:01~99; default :05,unit:sec
17-9 Setting alarm enabled
Enter[FUN][5][5](B)[EN]
(B):B = 0 close alarm voice output,
B = 1 allow alarm voice output(default)
17-10 Setting doorbell enabled
Enter[FUN][5][6](B)[EN]

SY120SA SINGLE DOOR CONTROLLER
- 15 -
(B):B = 0 close doorbell voice output,
B = 1 allow doorbell voice output(default)
17-11 Configure Input/Output Data(V2.0)
Enter[FUN][5][8](M)[EN]
(M):M = 0 only in out data mode
M = 1 all in out data mode(default)
17-12 Automatic door Setting
Enter[FUN] [8] [6]NHHMMhhmm[EN]
N Group Number (1 to 4)
(HHMM): Set start time;HH = hour , MM = minute;
(hhmm): Set end time ;hh = hour , mm = minute;
17-13 Access without Prox. card.
1. Access with card’s password or card number and card password:
Enter (pppp)[EN]or (NNNN)(pppp)[EN], system will confirm correct or error, if correct will
response correct status and control open automatic.
(NNNN):valid card number: 0001~2000
(pppp): Card’s password; default: 0000
2.Access with card number and anti-duress password:
Enter (NNNN)(pppp) [EN], and wait for confirmation from controller, if correct will back to
normal ststus and anti-duress alarm will be initiated automatically.
(NNNN): valid card number are in the range between 0001~2000
(pppp): anti-duress password (The password is four digit)
* If anti-duress password & personal password are the same, the personal password will be the
first priority to be checked and the alarm won’t be triggered.
17-14 Notice:
1. While change Master cards password, one needs to change 3 cards at same time. if
one uses Master card to login then system will make it (itAccess with Master card’s passwrod)
as invalid.
2. SY120SA controller(system) and reader needs to be connected the GND. Please use
parallel cable while using parallel cable with 0.75mm shield cover cable, it can connect up to
100 meter long. While useing normal phone line the distance limits is within 20 meters.
3. The voltage output limits is 5A current. If one needs higher electric current, then please
add another relay.
4. Relay output can only accept up to 1A current. if one needs to increase the limits, then
please add another relay.
