Syscall ST-5020 Series Instruction manual

1
QUICK USER GUIDE –ST-5020/ SR-A Series
1. Installation
[ST-5020 –Transmitter]
1) Plug the power adapter and insert the connector into the port next to the antenna.
2) Turn on the power switch on the right side of the transmitter.
3) Set Channel Number & Group Number to connect with the receiver.
Channel Number Setting [Pn] (Range: 1~15)
Group Number Setting [Gn] (Range: 1~99)

2
[SR-A Series –Receiver]
1) Plug the power adapter and insert the connector into the jack on the back.
2) Turn on the power switch on the right side of the receiver.
3) Set the same Channel Number & Group Number to connect with the transmitter.
Channel Number Setting [E5]
Group Number Setting [E2]
1~15

3
2. Keypad Description
Functions
Default
Range
Channel Number Setting
Pn
1
1~15
Group Number Setting
Gn
1
1~99
The Number of Digits Displayed Setting
N1
5
2~5
RF Output Power Control
RP
2
1~2
Beep Sound Setting
SC
1(ON)
0-OFF, 1-ON
Haptic Feedback Setting
VC
1(ON)
0-OFF, 1-ON
3. Function Setting
3-1. The Number of Digits Displayed Setting [N1]
* Set the number of digits displayed according to your receiver type.
ex) SR-A2003 → ‘2’, SR-A330 → ‘3’, SR-A440 → ‘4’
‘N1’

4
3-2. RF Output Power Control [RP]
3-3. Beep [SC] & Haptic Feedback Setting [VC]
