Syscom Video HICB355H User manual

INSTRUCTION MANUAL
DSP COLOR CAMERA
1/3" INTERLINE TRANSFER CCD
STANDARD RESOLUTION
HIGH RESOLUTION
Please read this manual thoroughly before use, and keep it handy for future reference.
