Syscom Video HD SDI DVR User manual

HD SDI DVR
USER’S MANUAL
RoHS

- 2 -
FCC COMPLIANCE STATEMENT
CE COMPLIANCE STATEMENT
FCC INFORMATION : This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the
interference at his own expense.
CAUTION :
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
WARNING: This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate
measures.

- 3 -

- 4 -
Features
This HD SDI(serial digital interface) DVR allows users to have HD level of video surveillance with 720P &
1080P resolution both in live and playback. Unlike megapixel IP cameras and NVR, it doesn’t require IP
related expertise and can be installed under coaxial cabling.
HD SDI DVR with H.264 compression
HD video over coaxial cable : No latency & no loss of frame
120fps(PAL: 100fps) real time @ 720P, 60fps(PAL:50fps) @ 1080P
HDMI, VGA and BNC video outputs
1 internal SATA HDD and E-SATA for external storage
Individual channel setup for recording & network stream (resolution/frame rate)
Event text + image notification to FTP server and E-mail address
Easy network : UPNP (Universal plug & play) support
User control : Up to 20 users can be generated with various access authority
Calendar search, Time search, Event search & Thumbnail search
CMS for multi sites monitoring
Web view monitoring via various browser (IE, Safari, Firefox and more)
Smart phone application (Live, PTZ, Search)

- 5 -
CONTENTS
1. Product Overview
1.1 Packing Contents ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 8
1.2 Front ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 9
1.3 Rear ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 10
2. Installing Product
2.1 Installing HDD ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 13
2.2 Connecting Camera and Audio Device ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 14
2.3 Connecting Monitor ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 14
2.4 Connecting Optional Device ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 15
2.5 Connecting Network ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 15
2.6 Connecting Power Supply ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 15
3.Controlling DVR
3.1 Remote control –basic description ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙
3.2 Remote control –additional description ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙
3.3 Mouse ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙
16
17
18
4. Operation
4.1 Turning On∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 20
4.2 Initial Screen ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 20
4.3 Screen Layout ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 20
5. MENU
5.1 Access to menu ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 23
5.2 Setup Menu ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 23
5.2.1 Display ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 24
5.2.2 Camera ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 25
5.2.3 Record ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 27

- 6 -
5.2.4 Event ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 30
5.2.5 Storage ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 34
5.2.6 Network ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 36
5.2.7 System ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 40
5.3 Search ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙
5.3.1 Search by Time ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 45
5.3.2 Search by Event ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 45
5.3.3 Thumbnail Search ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 45
5.3.4 Backup ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 46
5.3.3 Search mode ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 47
5.4 Other function ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 48
5.4.1 PTZ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 48
5.4.2 Audio ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 49
5.4.3 Log View ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 49
5.5 OSD OFF ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 50
5.6 REC ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 50
5.7 Log Out Control ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 50
Specification ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 51
Trouble shooting ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 52

- 7 -
1. Product Overview

- 8 -
1.1 Packing Contents
When you first open the product, please check out whether there are all contents as follows.
If any of these items is missing or damaged, contact your supplier immediately before using the product.
DVR product Remote control & Battery
Power adaptor and cable Software CD
USB mouse Screws
User’s Manual HDD power cable & SATA cable

- 9 -
1.2 Front
Number Name Function
USB port Connect USB device (mouse or USB stick/HDD)
LED indicator
PWR : Light on when power is on
REC : Light on when DVR is recording
NET : Light on when a user is connected via network
Mode Change screen split mode
Menu Access to main menu
Direction &
Selection keys
Select directions in menu
Play, FF(fast-forward), RW(rewind), stop/pause buttons
ZOOM Access directly to digital zoom mode (in live & playback)
SEARCH Access directly to search menu
1
2
4
5
6
7
3

- 10 -
1.3 REAR –4channel
Number Name Function
DC 12V Connect power adaptor provided with the product
SENSOR Sensor input port
ALARM Alarm output port
RS-485 PTZ camera control by RS-485 communication
AUDIO IN/OUT Connect audio in or out device (such microphone or speaker)
VIDEO OUT Composite video out (BNC type)
VGA VGA output
HDMI HDMI ouput
E-SATA E-SATA port
USB Connect USB device (mouse or USB stick/HDD)
ETHERNET ETHERNET port
HD SDI HD SDI video input
1
2
3 5
4 6
7
8
9
10
1
3
4
5
6
7
8
10
2
9

- 11 -
1.3 REAR –8 channel
Number Name Function
DC 12V Connect power adaptor provided with the product
SENSOR Sensor input port
ALARM Alarm output port
RS-485 PTZ camera control by RS-485 communication
AUDIO IN/OUT Connect audio in or out device (such microphone or speaker)
VIDEO OUT Composite video out (BNC type)
VGA VGA output
HDMI HDMI ouput
E-SATA E-SATA port
USB Connect USB device (mouse or USB stick/HDD)
ETHERNET ETHERNET port
HD SDI HD SDI video input
1
1
2
3
4
5
6
7
8
9
10
2
3
4
5 6 7
8
9
10
0

- 12 -
2. Installing Product
HD SDI 4ch DVR
SYSTEM CONFIGURATION

- 13 -
2.1. Installing HDD
1 internal HDD can be installed inside the product.
If HDD was not installed in the product, please install HDD first as follows.
Be careful not to be harmed by sharp edges of the product.
(1) Loosen screws on both sides and back to
detach the product cover.
(2) Lift the end of top cover and pull out from
product.
(2) Lift the end of top cover and pull out from
product.
(3) In order to install HDD, you need to upside
down the unit and position HDD onto thebottom
and fix it with provided screws as below.
(4) After connecting HDD onto the bottom of
the unit then connect SATA HDD and power
cable between HDD and main board.
(5) Insert top cover to product as side picture
Them, tighten screws again.

- 14 -
2.2. Connecting camera and audio device
Connect coaxial cable (BNC type) into VIDEO IN port on rear of the product.
HD SDI cabling specification: SMPTE 292M standard, 5C-HFBT or above
Connect RCA cable from microphone into AUDIO IN port on rear of the product.
Connect RCA cable into AUDIO OUT port on rear of the product and into audio device.
2.3. Connecting monitor
Connect monitors into the video out ports of the product according to interface.
Audio OUT
Audio IN
HD SDI video input
1 x HDMI OUT
1 x VGA OUT
1 x Composite out (BNC)
*Composite out doesn’t provide OSD or menu GUI on screen.
It is recommened to use composite out just for check video.

- 15 -
2.4. Connecting Optional device
You can connect and control the PTZ device supporting RS-485 communication.
2.5. Connecting Network
Connect LAN cable (RJ45) to Ethernet port on rear of the product.
2.6. Connecting power supply
Connect provided power cable to AC-DC adaptor.
Connect the adaptor to DC power port on rear of the product.
Connect AC power plug to the plug socket.
LAN cable (RJ45)

- 16 -
3.Controlling DVR
3.1. Remote control – Basic description
1) REC : Instant record button
2) DVR ID
3) Number button : Input channel number
4) AUDIO : Audio ON / Mute
5) BACKUP : Access directly to backup menu
6) MENU : Access to main menu
7) OSD : Show or Hide OSD
8) PTZ : Control Pan/Tilt/Zoom camera.
9) Z/F: Access to digital zoom mode
10) Direction (▲,▼,◀,▶) & ENTER
11) SEARCH : Search recorded video
12) LOG : Show running status of DVR system
13) ◀◀ : Reverse play
14) ▶I : Play or Pause during playback
15) ▶▶ : Fast forward play
16) ■: Stop playback and go to Live mode
17) SPOT : Not Operated in this model
18) PIP : Go to PIP mode
19) POP : Enlarge specific channel in Live mode
20) SEQ : Show each camera rotation
21) Full screen mode
22) Quad screen mode
23) 9 Division screen mode
Operated only for 8ch or 16 channels
24) 16 Division screen mode
Operated only for 16 channels
1
3
4
7
6
8
10
11
9
13
12
14
17
22
19
16
15
2
5
21
23
24
18
20

- 17 -
3.2. Remote control –Additional descriptions
3.2.1. Full screen mode
- Press button. Whenever pressing button, screen will go to next screen.
- Press desired numeric button of remote controller.
3.2.2. Quad screen mode
- To see quad screen mode, press button.
3.2.3. OSD Hide or Show
- Press OSD button of remote controller to appear or disappear OSD.
3.2.4. Sequence mode
- If you press SEQ button in Full screen split, screen will rotate automatically.
- Default value of cannel rotating interval is 2 or 3 seconds.
- User can select changing interval value from 1 to 99 seconds.
- User can select desired channel to display

- 18 -
3.2.5. Digital-ZOOM
DVR supports up to 10 times (x10) digital zoom
Select ZOOM icon or ZOOM button on remote control
Using mouse, drag certain area to enlarge image
To disable to digital zoom mode, mouse right-click
3.3. MOUSE
System supports USB MOUSE
Just Insert USB mouse into the product, then DVR will detect it automatically.
Inquire your supplier if certain USB mouse doesn’t work properly.
3.3.1. Change screen mode
Mouse left-click is for selecting an item on menu. Right-click in live goes to main menu.
Double left-click on a specific channel, screen will change into full screen mode.
With double-click in full screen mode, screen will go back to previous mode.
Normal mode Digital zoom mode x10

- 19 -
4. Operation
