syscomtec SCT-IPKVM-CX User manual

distributed by
Version: V1.0.0
User Manual
SCT-IPKVM-CX
IP Control Box

distributed by
Important Safety Instructions
Note
In case of any content change, we are sorry for no further notice.
Warning
To reduce the risk of fire, electric shock or product damage:
1. Do not expose this apparatus
to rain, moisture, dripping or
splashing and that no objects
filled with liquids, such as vases,
shall be placed on the apparatus.
6. Clean this apparatus
only with dry cloth.
2. Do not install or place this unit
in a bookcase, built-in cabinet or
in another confined space.
Ensure the unit is well ventilated.
3. To prevent risk of electric
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
5. Do not place sources of naked
flames, such as lighted candles,
on the unit.
7. Unplug this apparatus
during lightning storms or
when unused for long
periods of time.
8. Protect the power cord
from being walked on or
pinched particularly at
plugs.
9. Only use attachments /
accessories specified by
the manufacturer.
10. Refer all servicing to
qualified service
personnel.

distributed by
1
Table of Contents
Introduction....................................................................................................4
Overview...................................................................................................4
Features ...................................................................................................5
Package Contents ....................................................................................5
Specifications............................................................................................6
Panel ........................................................................................................8
Hardware Installation...................................................................................10
Access the Device ....................................................................................... 11
Web........................................................................................................11
Telnet......................................................................................................12
Web Configuration.......................................................................................14
Home Screen..........................................................................................14
Matrix......................................................................................................15
TX/RX Settings.......................................................................................16
IP Setup...........................................................................................16
Alias.................................................................................................17
Commands......................................................................................17
System Settings......................................................................................18
IP Setup (TX and RX communication).............................................18
IP Setup (Telnet /browser communication)......................................19
Web Password ................................................................................19
Debug Log.......................................................................................19
Commands......................................................................................20
FAQ ...............................................................................................................21
Access the Device .......................................................................................24
Web........................................................................................................24
Telnet......................................................................................................25
API Command Table....................................................................................28

distributed by
2
API Command Sets......................................................................................32
Configure Set Parameter........................................................................32
Set IPAddress.................................................................................32
Set IPAddress 2..............................................................................32
Set Password for Web.....................................................................33
Reset IP Control Box.......................................................................33
Shutdown IP Control Box.................................................................34
Reboot IP Control Box.....................................................................34
Enable/Disable Debug log...............................................................34
Set Alias ..........................................................................................35
Remove Device's Record................................................................35
Set IPAddress Mode.......................................................................36
Reboot Device.................................................................................37
Reset Device...................................................................................37
Set Device Info................................................................................38
Set Device Standby.........................................................................38
Set Device Onetouchplay................................................................39
Configure Get Parameter........................................................................39
Get Version......................................................................................39
Get Device List................................................................................40
Get IP Setting..................................................................................40
Get IP Setting 2...............................................................................41
Get Alias..........................................................................................41
Get Device Info................................................................................41
Get Device Json Info.......................................................................43
Matrix Parameter....................................................................................47
Set Matrix ........................................................................................47
Get Matrix........................................................................................47
Video-Wall ..............................................................................................48
Create Video Wall Configuration......................................................48

distributed by
3
Remove Video Wall Configuration...................................................49
Configure Video Wall.......................................................................49
Create a Video Wall Layout.............................................................50
Change the Source of a Certain RX................................................50
Change the Source of All RX...........................................................51
Set the Size of TV Frame ................................................................51
Set the Image Shift..........................................................................52
Get Video Wall Info..........................................................................52
Multiple View...........................................................................................53
Get Multiple View Info......................................................................53
Set Multiple View.............................................................................54
Scene .....................................................................................................54
Get Scene........................................................................................54
Active a Scene.................................................................................55
Change the Source of a Certain RX................................................55
Serial ......................................................................................................56
Device Json Info Description..................................................................57
Product Service ...........................................................................................60
Maintenance...........................................................................................60
Provided Service.....................................................................................60
Mail-In Service.................................................................................60
Warranty..........................................................................................61
Warranty Limits and Exclusions.......................................................61
Glossary .......................................................................................................63

distributed by
4
Introduction
Overview
SCT-IPKVM-CX is an Audio/Video control device to manage TX/RX detected
on the local area network. It can automatically search and display TX/RX,
perform operations on TX/RX, such as switching between multiple input
sources, setting Video wall. This device can be controlled by web browser, a
telnet client or a third- party control system.

distributed by
5
Features
ŸProvides built-in web server and Telnet API (used in a third-party
controller)
ŸDetect TX/RX automatically
ŸSupports matrix switching between TX and RX
ŸSupports Video Wall
ŸStandards and protocols: HTTP, TCP/IP, Multicast
Package Contents
Ÿ1 x TK-N006-000
Ÿ1 x 5V/2A Power Supply
Ÿ1 x Serial Port Cable
Ÿ5 x Label

distributed by
6
Specifications
Technical
I/O Connections 1 x RJ45 Port
1 x RS232
LED Power LED,
Work LED
Button 1 x Reset Button
Power Supply 5V/2A DC, 5.5mm
Power Consumption 1.4Watts
Control Method
Web;
Telnet;
A Third-party Control System.
System Requirements RS232 Cables
Industry Standard CAT5e/6/7 Cables
Supported TX/RX SCT-IPKVM-TX131,
SCT-IPKVM-RX141
Operating Temperature
32°F to 95°F (0°C to 35°C)
10% to 90%, non-condensing
Storage Temperature -4°F to 140°F (-20°C to 70°C)
10% to 90%, non-condensing
ESD Protection
Human Body Model:
±8kV (air-gap discharge)
±4kV (contact discharge)
Surge Protection
Voltage: ±1000 V
(Tested ten times respectively for the positive
and negative voltages)
General

distributed by
7
Dimension
Device: 141mmW×115mmD×26mmH
/5.6’’W×4.5’’D×1’’H
Gift box: 390mmW×220mmD×92mmH
/15.4’’W×8.7’’D×3.6’’H
Weight 0.42kg (without accessories)
Certification CE, FCC, RoHS

distributed by
8
Panel
Front Panel
ID
Name Description
1 Power
This LED glows steady red when the device is powered on.
2 WORK
This LED glows steady blue when the device is working
properly. If red, that means the device is rebooting.
3 RESET
When the device is powered on, press and hold this button
4
3
1
2

distributed by
9
ID
Name Description
for 5 seconds, it automatically restores to factory default
settings.
4 Label Write down the IP address of the device on the label comes
with the device, then insert the label into the device.
Rear Panel
ID
Name Description
5 ETHERNET RJ45 Port
6 RS232 Debug
7 Power 5V / 2A DC power supply input
7
6
5

distributed by
10
Hardware Installation
1. Connect PC, SCT-IPKVM-CX, and TX/RX to a Switch via CAT5e/6
cables.
2. Connect HDMI Source (such as Apple TV, Xbox or PS3) to TX.
3. Connect HDMI Sink (such as a plasma TV) to RX.
4. Power on all the devices.
5. Use Telnet or Web browser to manage SCT-IPKVM-CX.
tv
Apple TV Xbox
TX
TVTV
RX
PC
Switch
HDMI
Ethernet
TX RX
IP Control Box

distributed by
11
Access the Device
Users can access the device through Web, Telnet or a Third-party controller.
Web
To access the device through Web Management Page, follow these steps.
Step 1. Enter 192.168.11.243 into a browser. We recommend you use,
Firefox, Opera, Safari, Internet Explorer 11 or Chrome.
Step 2. Enter a password (admin by default), click Login to access the
device.
Note:
žThe IP address of the computer and IP Control Box should be in the
same network subnet. For example, if the IP address of IP Control Box
is 192.168.11.243, then the computer should be 192.168.11.X.
žThe IP address of the IP Control Box can be changed through Web
Management Page or Telnet.
žIf the Web Management Page cannot be displayed, please refer to FAQ.

distributed by
12
Telnet
To access the device through Telnet, follow these steps (here take Window 7
as an example).
Step 1. Click Start menu, go to Run. Input cmd, click OK.
Step 2. Input telnet 192.168.11.243, press Enter.

distributed by
13
Then you can see this window comes up.
Note:
žThe IP address of the computer and IP Control Box should be in the
same network subnet. For example, if the IP address of IP Control Box
is 192.168.11.243, then the computer should be 192.168.11.X.
žIf you use a third-party controller, you can access the device refer to the
document API Command.

distributed by
14
Web Configuration
The Web Management Page is designed to perform the functions to control
the device in a user-friendly interface.
Home Screen
Open your browser, enter 192.168.11.243 in the address bar, and input the
password (admin by default), click Login.
The home screen comes up.
It includes three parts: Matrix,TX/RX Settings and System Settings.

distributed by
15
Matrix
Click Load Matrix button, a table comes up.
The first row shows TX, the first column shows RX.
Icon Description
The device is online.
The device is offline.
The green bar represents correspondence TX and RX are
linked. Click the green bar; it changes into blank, which
means the correspondence TX and RX are disconnected.
The red bar represents TX/RX connecting is in processing.
The white bar represents correspondence TX and RX are
not linked. You can link them by clicking this white bar.

distributed by
16
TX/RX Settings
Click TX/RX Settings tab, TX/RX Settings page comes up. Select a device
you want to configure.
IP Setup
GUI Element Description
Auto IP Obtain the IP address automatically.
DHCP The IP address is assigned by a DHCP server.
Static The IP address is manually configured.
IP Address The IP address of the TX/RX.
Subnet Mask The subnet mask of the TX/RX.
Default Gateway
The default gateway of the TX/RX.

distributed by
17
Alias
GUI Element Description
Alias Give the TX/RX a different name which would be easier to
remember.
Note:
Alias cannot contain ',' ';' '_' '@', '*', '&', 'EX131', 'EX363', 'EX373',
'EX383', 'EX393', 'TX', 'EX141', 'EX403', 'RX'.
Commands
GUI Element Description
Factory Default Restore the TX/RX to factory default settings.
Reboot Reboot the TX/RX.

distributed by
18
System Settings
Click System Settings tab, System Settings page comes up. In this page,
you can configure the IP Control Box.
IP Setup (TX and RX communication)
GUI Element Description
IP Address The IP address for TX and RX communication.
Subnet Mask The subnet mask for TX and RX communication.
Default Gateway
The default gateway for TX and RX communication.
