GEM eSyLite 629 User manual

GEMÜ 629 eSyLite
Motorized diaphragm valve
Operating instructions
EN
TYPE EL
CLASS I
AUGUST 2021
further information
webcode: GW-629

All rights including copyrights or industrial property rights are expressly reserved.
Keep the document for future reference.
© GEMÜ Gebr. Müller Apparatebau GmbH & Co. KG
02.11.2023
www.gemu-group.com2 / 45GEMÜ 629 eSyLite

Contents
1 General information ............................................. 4
1.1 Information .................................................... 4
1.2 Symbols used ................................................ 4
1.3 Definition of terms ........................................ 4
1.4 Warning notes ............................................... 4
2 Safety information ............................................... 5
3 Product description ............................................. 5
3.1 Construction .................................................. 5
3.2 Description ..................................................... 6
3.3 Function ......................................................... 6
3.4 Product label ................................................. 6
4 GEMÜ CONEXO .................................................... 6
5 Correct use .......................................................... 6
6 Order data ........................................................... 7
6.1 Order codes ................................................... 7
6.1.11 Special version ................................. 8
6.2 Order example ............................................... 9
7 Technical data ..................................................... 10
7.1 Medium .......................................................... 10
7.2 Temperature .................................................. 10
7.3 Pressure ......................................................... 10
7.4 Product compliance ...................................... 11
7.5 Mechanical data ............................................ 12
7.6 Actuator duty cycle and service life ............. 13
8 Electrical connection ........................................... 14
9 Dimensions .......................................................... 16
9.1 Actuator dimensions ..................................... 16
9.2 Actuator dimensions with distance piece ... 17
9.3 Actuator dimensions with GEMÜ 1215 posi-
tion indicator .................................................. 18
9.4 Actuator dimensions with GEMÜ 1235 posi-
tion indicator .................................................. 19
9.5 Body dimensions ........................................... 20
9.5.9 Flange JIS (code 34) ........................ 29
10 Manufacturer's information .................................. 33
10.1 Delivery .......................................................... 33
10.2 Transport ....................................................... 33
10.3 Storage ........................................................... 33
11 Installation in piping ............................................ 33
11.1 Preparing for installation .............................. 33
11.2 Installation position ....................................... 34
11.3 Installation with clamp connections ............ 34
11.4 Installation with butt weld spigots ............... 34
11.5 Installation with threaded sockets ............... 34
11.6 Installation with threaded spigots ................ 34
11.7 Installation with flanged connection ............ 35
12 Operation ............................................................. 35
12.1 Manual override ............................................. 35
14 Inspection and maintenance ................................ 38
14.1 Spare parts .................................................... 38
14.2 Removing the actuator .................................. 38
14.3 Removing the diaphragm .............................. 38
14.4 Mounting the compressor ............................ 39
14.5 Mounting the diaphragm .............................. 39
14.6 Mounting the actuator .................................. 40
15 Removal from piping ............................................ 40
16 Returns ................................................................ 40
17 EU Declaration of Incorporation according to the
EC Machinery Directive 2006/42/EC, Annex II B ... 41
18 EU Declaration of Conformity in accordance with
2014/68/EU (Pressure Equipment Directive) ........ 42
19 EU Declaration of Conformity in accordance with
2014/30/EU (EMC Directive) ................................ 43
20 EU Declaration of Conformity In accordance with
2011/65/EU (RoHS Directive) ............................... 44
GEMÜ 629 eSyLitewww.gemu-group.com 3 / 45

www.gemu-group.com4 / 45GEMÜ 629 eSyLite
1 General information
1 General information
1.1 Information
- The descriptions and instructions apply to the standard ver-
sions. For special versions not described in this document
the basic information contained herein applies in combina-
tion with any additional special documentation.
- Correct installation, operation, maintenance and repair work
ensure faultless operation of the product.
- Should there be any doubts or misunderstandings, the Ger-
man version is the authoritative document.
- Contact us at the address on the last page for staff training
information.
1.2 Symbols used
The following symbols are used in this document:
Symbol Meaning
Tasks to be performed
Response(s) to tasks
– Lists
1.3 Definition of terms
Working medium
The medium that flows through the GEMÜ product.
Diaphragm size
Uniform seat size of GEMÜ diaphragm valves for different
nominal sizes.
1.4 Warning notes
Wherever possible, warning notes are organised according to
the following scheme:
SIGNAL WORD
Type and source of the danger
Possible
symbol for the
specific
danger
Possible consequences of non-observance.
Measures for avoiding danger.
Warning notes are always marked with a signal word and
sometimes also with a symbol for the specific danger.
The following signal words and danger levels are used:
DANGER
Imminent danger!
▶Non-observance can cause death or
severe injury.
WARNING
Potentially dangerous situation!
▶Non-observance can cause death or
severe injury.
CAUTION
Potentially dangerous situation!
▶Non-observance can cause moderate
to light injury.
NOTICE
Potentially dangerous situation!
▶Non-observance can cause damage to
property.
The following symbols for the specific dangers can be used
within a warning note:
Symbol Meaning
Danger of explosion!
Corrosive chemicals!
Hot plant components!
Damage to the product!

www.gemu-group.com 5 / 45 GEMÜ 629 eSyLite
2 Safety information
The safety information in this document refers only to an indi-
vidual product. Potentially dangerous conditions can arise in
combination with other plant components, which need to be
considered on the basis of a risk analysis. The operator is re-
sponsible for the production of the risk analysis and for com-
pliance with the resulting precautionary measures and re-
gional safety regulations.
The document contains fundamental safety information that
must be observed during commissioning, operation and main-
tenance. Non-compliance with these instructions may cause:
- Personal hazard due to electrical, mechanical and chemical
effects.
- Hazard to nearby equipment.
- Failure of important functions.
- Hazard to the environment due to the leakage of dangerous
substances.
The safety information does not take into account:
- Unexpected incidents and events, which may occur during
installation, operation and maintenance.
- Local safety regulations which must be adhered to by the
operator and by any additional installation personnel.
Prior to commissioning:
1. Transport and store the product correctly.
2. Do not paint the bolts and plastic parts of the product.
3. Carry out installation and commissioning using trained
personnel.
4. Provide adequate training for installation and operating
personnel.
5. Ensure that the contents of the document have been fully
understood by the responsible personnel.
6. Define the areas of responsibility.
7. Observe the safety data sheets.
8. Observe the safety regulations for the media used.
During operation:
9. Keep this document available at the place of use.
10. Observe the safety information.
11. Operate the product in accordance with this document.
12. Operate the product in accordance with the specifications.
13. Maintain the product correctly.
14. Do not carry out any maintenance work and repairs not de-
scribed in this document without consulting the manufac-
turer first.
In cases of uncertainty:
15. Consult the nearest GEMÜ sales office.
3 Product description
3.1 Construction
1
2
3
5
4
6
7
8
9
Item Name Materials
1 Optical position in-
dicator
PA 12
2 Manual override
3 Motorized actu-
ator
Reinforced polyamide
4 CONEXO actuator
RFID chip
5 Diaphragm CR, EPDM, FKM, NBR, PTFE/EPDM
6 CONEXO dia-
phragm RFID chip
7 CONEXO body
RFID chip
8 Valve body EN-GJS-400-18-LT (GGG 40.3)
EN-GJS-400-18-LT (GGG 40.3), PFA
lined
EN-GJS-400-18-LT (GGG 40.3), PP
lined
EN-GJS-400-18-LT (GGG 40.3),
hard rubber lined
1.4408, investment casting
1.4408, PFA lined
1.4435 (F316L), forged body
1.4435 (BN2), forged body, Δ Fe <
0.5 %
1.4435, investment casting
1.4539, forged body
CW614N, CW617N (brass)
9 Electrical connec-
tion
3 Product description

www.gemu-group.com6 / 45GEMÜ 629 eSyLite
4 GEMÜ CONEXO
3.2 Description
The GEMÜ 629 eSyLite 2/2-way diaphragm valve is motorized.
It is available as an Open/Close version. An integrated optical
position indicator is standard. The self-locking actuator holds
its position in a stable manner in the event of power supply
failure.
3.3 Function
The product controls a flowing medium by being closed or
opened by a motorised actuator. The product is designed as
an OPEN/CLOSED valve and is not intended for control applic-
ations.
The product has an optical position indicator as standard. The
optical position indicator indicates the OPEN and CLOSED po-
sitions.
3.4 Product label
The product label is located on the actuator. Product label
data (example):
Design in accordance with order data
Device-specific data
Year of manufacture
Item number Traceability number Consecutive number
The month of manufacture is encoded in the traceability num-
ber and can be obtained from GEMÜ. The product was manu-
factured in Germany.
The operating pressure stated on the product label applies to
a media temperature of 20 °C. The product can be used up to
the maximum stated media temperature. You can find the
pressure/temperature correlation in the technical data.
4 GEMÜ CONEXO
The interaction of valve components that are equipped with
RFID chips and an associated IT infrastructure actively in-
crease process reliability.
Thanks to serialization, every valve and every relevant valve
component such as the body, actuator or diaphragm, and
even automation components, can be clearly traced and read
using the CONEXO pen RFID reader. The CONEXO app, which
can be installed on mobile devices, not only facilitates and im-
proves the "installation qualification" process, but also makes
the maintenance process much more transparent and easier
to document. The app actively guides the maintenance techni-
cian through the maintenance schedule and directly provides
him with all the information assigned to the valve, such as
test reports, testing documentation and maintenance histor-
ies. The CONEXO portal acts as a central element, helping to
collect, manage and process all data.
For further information on GEMÜ CONEXO please visit:
www.gemu-group.com/conexo
5 Correct use
DANGER
Danger of explosion!
▶Risk of death or severe injury
●Do not use the product in potentially
explosive zones.
WARNING
Improper use of the product!
▶Risk of severe injury or death
▶Manufacturer liability and guarantee will be void.
●Only use the product in accordance with the operating
conditions specified in the contract documentation and in
this document.
The product is designed for installation in piping systems and
for controlling a working medium.
The product is not intended for use in potentially explosive
areas.
1. Use the product in accordance with the technical data.
2. The product is designed as an OPEN/CLOSED valve and is
not intended for control applications. Due to the minimum
actuation time, sufficiently accurate control is not pos-
sible.

6 Order data
The order data provide an overview of standard configurations.
Please check the availability before ordering. Other configurations available on request.
Order codes
1 Type Code
Diaphragm valve, electrically operated,
stainless steel diaphragm valve
629
2 DN Code
DN 4 4
DN 6 6
DN 8 8
DN 10 10
DN 12 12
DN 15 15
DN 20 20
DN 25 25
DN 32 32
DN 40 40
DN 50 50
DN 65 65
3 Body configuration Code
Tank bottom valve body B
Body configuration code B: Dimensions and designs on
request
2/2-way body D
T body T
Body configuration code T: Dimensions on request
4 Connection type Code
Spigot
Spigot DIN 0
Spigot DIN EN 10357 series B (2014 edition; formerly
DIN 11850 series 1)
16
Spigot EN 10357 series A/DIN 11866 series A
formerly DIN 11850 series 2
17
Spigot DIN 11850 series 3 18
Spigot JIS-G 3447 35
Spigot JIS-G 3459 schedule 10s 36
Spigot SMS 3008 37
Spigot BS 4825, Part 1 55
Spigot ASME BPE/DIN EN 10357 series C (from 2022
edition)/DIN 11866 series C
59
Spigot ISO 1127/DIN EN 10357 series C (2014 edition)/
DIN 11866 series B
60
Spigot ANSI/ASME B36.19M schedule 10s 63
Spigot ANSI/ASME B36.19M schedule 5s 64
Spigot ANSI/ASME B36.19M schedule 40s 65
Threaded connection
Threaded socket DIN ISO 228 1
NPT female thread 31
Threaded spigot DIN 11851 6
Cone spigot and union nut DIN 11851 6K
4 Connection type Code
Flange
Flange EN 1092, PN 16, form B,
face-to-face dimension FTF EN 558 series 1, ISO 5752,
basic series 1,
length only for body configuration D
8
Flange JIS B2220, 10K, RF,
face-to-face dimension FTF EN 558 series 1, ISO 5752,
basic series 1,
length only for body configuration D
34
Flange ANSI Class 150 RF,
face-to-face dimension FTF MSS SP-88,
length only for body configuration D
38
Flange ANSI Class 125/150 RF,
face-to-face dimension FTF EN 558 series 1, ISO 5752,
basic series 1,
length only for body configuration D
39
Clamp
Clamp ASME BPE,
face-to-face dimension FTF ASME BPE,
length only for body configuration D
80
Clamp DIN 32676 series B,
face-to-face dimension FTF EN 558 series 7,
length only for body configuration D
82
Clamp ASME BPE,
for pipe ASME BPE,
face-to-face dimension FTF EN 558 series 7,
length only for body configuration D
88
Clamp DIN 32676 series A,
face-to-face dimension FTF acc. to EN 558 series 7,
length only for body configuration D
8A
Clamp ISO 2852 for pipe ISO 2037,
clamp SMS 3017 for pipe SMS 3008,
face-to-face dimension FTF EN 558 series 7,
length only for body configuration D
8E
Clamp DIN 32676 series C,
face-to-face dimension FTF ASME BPE,
length only for body configuration D
8P
Clamp DIN 32676 series C,
face-to-face dimension FTF EN 558 series 7,
length only for body configuration D
8T
5 Valve body material Code
SG iron material
EN-GJS-400-18-LT (GGG 40.3),
PFA lined
17
EN-GJS-400-18-LT (GGG 40.3),
PP lined
18
EN-GJS-400-18-LT (GGG 40.3),
hard rubber lined
83
EN-GJS-400-18-LT (GGG 40.3) 90
Investment casting material
1.4408, investment casting 37
1.4408, PFA lined 39
6 Order data
www.gemu-group.com 7 / 45 GEMÜ 629 eSyLite

5 Valve body material Code
1.4435, investment casting C3
Forged material
1.4435 (F316L), forged body 40
1.4435 (BN2), forged body, Δ Fe < 0.5% 42
1.4539, forged body F4
Brass
CW614N, CW617N (brass) 12
6 Diaphragm material Code
Elastomer
NBR 2
EPDM 3A
FKM 4
FKM 4A
CR 8
EPDM 13
EPDM 17
EPDM 19
EPDM 28
EPDM 29
EPDM 36
PTFE
PTFE/EPDM one-piece 54
PTFE/EPDM two-piece 5M
Note: The PTFE/EPDM diaphragm (code 5M) is
available from diaphragm size 25.
7 Voltage/Frequency Code
24 V DC C1
8 Control module Code
ON/OFF actuator (economy) A0
ON/OFF actuator (economy)
Emergency power supply module (NC)
A1
ON/OFF actuator (economy)
Emergency power supply module (NO)
A2
OPEN/CLOSE control with mounted GEMÜ 1235
position indicator
Y0
OPEN/CLOSE control with mounted GEMÜ 1235
position indicator
Emergency power supply module (NC)
Y1
OPEN/CLOSE control with mounted GEMÜ 1235
position indicator
Emergency power supply module (NO)
Y2
OPEN/CLOSE control with mounted GEMÜ 1215
position indicator
Z0
OPEN/CLOSE control with mounted GEMÜ 1215
position indicator
Emergency power supply module (NC)
Z1
OPEN/CLOSE control with mounted GEMÜ 1215
position indicator
Emergency power supply module (NO)
Z2
9 Surface Code
Ra ≤ 6.3 μm (250 μin.) for media wetted surfaces,
mechanically polished internal
1500
9 Surface Code
Ra ≤ 0.8 µm (30 µin.) for media wetted surfaces,
in accordance with DIN 11866 H3,
mechanically polished internal
1502
Ra ≤ 0.8 µm (30 µin.) for media wetted surfaces,
in accordance with DIN 11866 HE3,
electropolished internal/external
1503
Ra ≤ 0.6 μm (25 μin.) for media wetted surfaces,
mechanically polished internal
1507
Ra ≤ 0.6 µm (25 µin.) for media wetted surfaces,
electropolished internal/external
1508
Ra ≤ 0.4 µm (15 µin.) for media wetted surfaces,
in accordance with DIN 11866 H4,
mechanically polished internal
1536
Ra ≤ 0.4 µm (15 µin.) for media wetted surfaces,
in accordance with DIN 11866 HE4,
electropolished internal/external
1537
Ra ≤ 0.25 μm (10 µin.) for media wetted surfaces *),
in accordance with DIN 11866 HE5,
electropolished internal/external,
*) for inner pipe diameters < 6 mm, in the spigot Ra ≤
0.38 μm
1516
Ra ≤ 0.25 μm (10 µin.) for media wetted surfaces *),
in accordance with DIN 11866 H5,
mechanically polished internal,
*) for inner pipe diameters < 6 mm, in the spigot Ra ≤
0.38 μm
1527
Ra max. 0.51 µm (20 µin.) for media wetted surfaces,
in accordance with ASME BPE SF1,
mechanically polished internal
SF1
Ra max. 0.64 µm (25 µin.) for media wetted surfaces,
in accordance with ASME BPE SF2,
mechanically polished internal
SF2
Ra max. 0.76 µm (30 µin.) for media wetted surfaces,
in accordance with ASME BPE SF3,
mechanically polished internal
SF3
Ra max. 0.38 µm (15 µin.) for media wetted surfaces,
in accordance with ASME BPE SF4,
electropolished internal/external
SF4
Ra max. 0.51 µm (20 µin.) for media wetted surfaces,
in accordance with ASME BPE SF5,
electropolished internal/external
SF5
Ra max. 0.64 µm (25 µin.) for media wetted surfaces,
in accordance with ASME BPE SF6,
electropolished internal/external
SF6
10 Actuator version Code
Actuator size 1
diaphragm size 8
with distance piece
B1
Actuator size 1
diaphragm size 10
1C
Actuator size 1
diaphragm size 25
1F
Actuator size 3
diaphragm size 40
3H
Actuator size 3
diaphragm size 50
with distance piece
K3
11 Special version Code
Without
6 Order data
www.gemu-group.com8 / 45GEMÜ 629 eSyLite

11 Special version Code
BELGAQUA certification B
12 CONEXO Code
Without
Integrated RFID chip for electronic identification and
traceability
C
Order example
Ordering option Code Description
1 Type 629 Diaphragm valve, electrically operated,
stainless steel diaphragm valve
2 DN 40 DN 40
3 Body configuration D 2/2-way body
4 Connection type 60 Spigot ISO 1127/DIN EN 10357 series C (2014 edition)/DIN 11866
series B
5 Valve body material 40 1.4435 (F316L), forged body
6 Diaphragm material 5M PTFE/EPDM two-piece
7 Voltage/Frequency C1 24 V DC
8 Control module A0 ON/OFF actuator (economy)
9 Surface 1503 Ra ≤ 0.8 µm (30 µin.) for media wetted surfaces,
in accordance with DIN 11866 HE3,
electropolished internal/external
10 Actuator version 3H Actuator size 3
diaphragm size 40
11 CONEXO Without
6 Order data
www.gemu-group.com 9 / 45 GEMÜ 629 eSyLite

7 Technical data
7.1 Medium
Working medium: Corrosive, inert, gaseous and liquid media which have no negative impact on the physical and
chemical properties of the body and diaphragm material.
The valve will seal in both flow directions up to full operating pressure (gauge pressure).
7.2 Temperature
Media temperature: -10 — 80 °C
Ambient temperature: -10 — 50 °C
If the emergency power module is used (control module code A1, A2, Z1, Z2), the maximum ambi-
ent temperature is reduced to 40 °C.
Storage temperature: 0 — 40 °C
7.3 Pressure
Operating pressure: 0 — 6 bar
Pressure rating: PN 16
Leakage rate: Leakage rate A to P11/P12 EN 12266-1
Kv values: MG DN Connection type code
0 16 17 18 37 59 60 1 31
8 4 0.5--------
6- - 1.1 - - - 1.2 - -
8- - 1.3 - - 0.6 2.2 1.4 -
10 - 2.1 2.1 2.1 - 1.3 - - -
15 -----2.0---
10 10 - 2.4 2.4 2.4 - 2.2 3.3 - -
12 -------3.2-
15 3.3 3.8 3.8 3.8 - 2.2 4.0 3.4 -
20 -----3.8---
25 15 4.1 4.7 4.7 4.7 - - 7.4 6.5 6.5
20 6.3 7.0 7.0 7.0 - 4.4 13.2 10.0 10.0
25 13.9 15.0 15.0 15.0 12.6 12.2 16.2 14.0 14.0
40 32 25.3 27.0 27.0 27.0 26.2 - 30.0 26.0 26.0
40 29.3 30.9 30.9 30.9 30.2 29.5 32.8 33.0 33.0
50 50 46.5 48.4 48.4 48.4 51.7 50.6 55.2 60.0 60.0
65 - - - - 62.2 61.8 - - -
MG = diaphragm size
Kv values in m³/h
Kv values determined in accordance with DIN EN 60534 standard, inlet pressure 5 bar, Δp 1 bar, stainless steel
valve body and soft elastomer diaphragm. The Kv values for other product configurations (e.g. other diaphragm
or body materials) may differ. In general, all diaphragms are subject to the influences of pressure, temperature,
the process and their tightening torques. Therefore the Kv values may exceed the tolerance limits of the stand-
ard.
The Kv value curve (Kv value dependent on valve stroke) can vary depending on the diaphragm material and dur-
ation of use.
www.gemu-group.com10 / 45GEMÜ 629 eSyLite
7 Technical data

Kv values: MG DN GGG 40.3
Connection
type
1, 31
GGG 40.3
Connection
type
8, 39
PFA/PP Hard rubber
25 15 8.0 10.0 5.0 6.0
20 11.5 14.0 9.0 11.0
25 11.5 17.0 13.0 15.0
40 32 28.0 36.0 23.0 29.0
40 28.0 40.0 26.0 32.0
50 50 60.0 68.0 47.0 64.0
65 - 68.0 47,0 -
MG = diaphragm size, Kv values in m³/h
Kv values determined in accordance with DIN EN 60534, inlet pressure 5 bar, Δp 1 bar, with connection flange
EN 1092 length EN 558 series 1 (or threaded socket DIN ISO 228 for body material GGG40.3) and soft elastomer
diaphragm. The Kv values for other product configurations (e.g. other diaphragm or body materials) may differ.
In general, all diaphragms are subject to the influences of pressure, temperature, the process and their tighten-
ing torques. Therefore the Kv values may exceed the tolerance limits of the standard.
The Kv value curve (Kv value dependent on valve stroke) can vary depending on the diaphragm material and dur-
ation of use.
7.4 Product compliance
Machinery Directive: 2006/42/EC
Pressure Equipment Dir-
ective:
2014/68/EU
Food: Regulation (EC) No. 1935/2004*
Regulation (EC) No. 10/2011*
FDA*
USP* Class VI
EMC Directive: 2014/30/EU
Drinking water: Belgaqua*
* depending on version and / or operating parameters
RoHS Directive: 2011/65/EU
GEMÜ 629 eSyLitewww.gemu-group.com 11 / 45
7 Technical data

7.5 Mechanical data
Protection class: IP 65 acc. to EN 60529
Actuating speed: Max. 3 mm/s
Flow direction: Optional
Installation position: Optional
Observe the angle of rotation for optimized draining when it comes to installation.
See separate document, "Angle of rotation technical information".
Weight: Actuator
Actuator version B1 1.0 kg
Actuator version 1C 0.8 kg
Actuator version 1F 0.94 kg
Actuator version 3H 1.4 kg
Actuator version K3 2.8 kg
Body
Connection type
Code
0, 16,
17, 18,
35, 36,
37, 55,
59, 60,
63, 64,
65
1 1 1, 31 31 6, 6K 8, 38, 39 80, 82,
88, 8A,
8E, 8P,
8T
Valve body Spigot Threaded socket Threade
d spigot
Flange Clamp
Material code 12 37 90 37
MG DN
8 4 0.09-------
60.09-------
80.09 - 0.09 - - - - 0.15
10 0.09 - - - - 0.21 - 0.18
15 0.09 - - - - - - 0.18
10 10 0.30 - - - - 0.33 - 0.30
12 - 0.17 0.17 - - - - -
15 0.30 0.26 0.26 - - 0.35 - 0.43
20 -------0.43
25 15 0.62 - 0.32 0.50 0.32 0.71 1.50 0.75
20 0.58 - 0.34 0.60 0.34 0.78 2.20 0.71
25 0.55 - 0.39 0.90 0.39 0.79 2.80 0.63
40 32 1.45 - 0.88 1.40 0.88 1.66 3.40 1.62
40 1.32 - 0.93 1.90 0.93 1.62 4.50 1.50
50 50 2.25 - 1.56 2.70 1.56 2.70 6.30 2.50
65 2.20 - - - - - 10.30 2.30
MG = diaphragm size, weight in kg
www.gemu-group.com12 / 45GEMÜ 629 eSyLite
7 Technical data

Mechanical environ-
mental conditions:
Class 4M8 acc. to EN 60721-3-4:1998
Vibration: 5g acc. to IEC 60068-2-6 Test Fc
Shock: 25g acc. to 60068-2-27 Test Ea
7.6 Actuator duty cycle and service life
Service life: Class A acc. to EN 15714-2
Minimum 100,000 switching cycles at room temperature and permissible duty cycle.
Duty cycle: max. 30% duty
7.7 Electrical data
Supply voltage: 24 V DC
Tolerance ± 10 %
Operating time: MG 10: 2.5 s
MG 20: 3.5 s
MG 25: 4.0 s
MG 40: 4.5 s
MG 50: 7.0 s
Close tight current / rated
current:
MG 10: 0.5 A
MG 20: 1.4 A
MG 25: 1.3 A
MG 40: 2.3 A
MG 50: 2.3 A
Starting current / max-
imum current:
MG 10: approx. 2.4 A
MG 20: approx. 2.4 A
MG 25: approx. 2.4 A
MG 40: approx. 4.5 A
MG 50: approx. 4.5 A
Standby current con-
sumption:
approx. 10 mA
7.7.1 Digital input signals
Input voltage: max. 30 V DC
≥ 56 kΩ
High level: ≥ 18 V DC
Low level: ≤ 5 V DC
Minimum actuation dura-
tion:
600 ms
Input current: < 0.6 mA
7.7.2 Emergency power supply module
Charging current: MG 10, MG 20, MG 25: max. 0.16 A
MG 40: 0.32 A
MG 50: not available
Charging time: approx. 13 min
Service life: Guide value at 25 °C ambient temperature, approx. 3 years
GEMÜ 629 eSyLitewww.gemu-group.com 13 / 45
7 Technical data

8 Electrical connection
NOTICE
Appropriate cable socket/appropriate mating connector
▶The appropriate connector is included for X1.
8.1 Position of the connectors
X1
8.2 Electrical connection
Connection X1
13
2
654
7-pin plug, Binder, type 693
Pin Signal name
1 24 V supply voltage
2 GND
3 Digital input OPEN
4 Digital input CLOSED
5 n.c.
6 n.c.
7 n.c.
Preferred direction if both digital inputs are present
for device version 00
(see operating instructions – Product label)
Control module ordering
option
Preferred direction
A0, Y0, Z0 OPEN
A1, Y1, Z1 CLOSED
www.gemu-group.com14 / 45GEMÜ 629 eSyLite
8 Electrical connection

Preferred direction if both digital inputs are present
for device version 00
(see operating instructions – Product label)
A2, Y1, Z2 OPEN
Preferred direction if both digital inputs are present
for device version 01
(see operating instructions – Product label)
Control module ordering
option
Preferred direction
A0, Y0, Z0 OPEN
A1, Y1, Z1 OPEN
A2, Y2, Z2 CLOSED
8.3 Connection diagram
X1
Device side Connections / customer
eSyLite
Uv 24 V DC
Uv GND Power supply
PLC
Digital input 1
Digital input 2
24 V DC
24 V DC
1
2
3
4
5
6
7-pin plug
Binder, type 693
Switch
Consumer
Signal direction
Power supply
=
=
=
=
13
2
654
GEMÜ 629 eSyLitewww.gemu-group.com 15 / 45
8 Electrical connection

9 Dimensions
9.1 Actuator dimensions
B1
B3
B2
A
CT*
A1
B
MG A A1 B B1 B2 B3
8211.0 82.0 59.5 134.5 115.0 82.0
10 192.0 63.0 59.5 134.5 115.0 82.0
25 204.0 75.0 59.5 134.5 115.0 82.0
40 228.0 91.0 80.0 167.0 147.5 94.5
Dimensions in mm
MG = diaphragm size
* CT = A + H1 (see body dimensions)
www.gemu-group.com16 / 45GEMÜ 629 eSyLite
9 Dimensions

9.2 Actuator dimensions with distance piece
A
B3
B1
B2
A1
CT*
B
MG A A1 B B1 B2 B3
50 265.0 128.0 80.0 167.0 147.5 94.5
Dimensions in mm
MG = diaphragm size
* CT = A + H1 (see body dimensions)
MG 50 with metal distance piece
GEMÜ 629 eSyLitewww.gemu-group.com 17 / 45
9 Dimensions

9.3 Actuator dimensions with GEMÜ 1215 position indicator
A
BZ2
AZ1
AZ2
BZ1
MG A AZ1 AZ2 BZ1 BZ2
8256.0 72.0 61.0 30.0 40.0
10 237.0 72.0 61.0 30.0 40.0
25 249.0 72.0 61.0 30.0 40.0
40 273.0 72.0 61.0 30.0 40.0
50 310.0 72.0 61.0 30.0 40.0
Dimensions in mm
MG = diaphragm size
MG 50 with metal distance piece
www.gemu-group.com18 / 45GEMÜ 629 eSyLite
9 Dimensions

9.4 Actuator dimensions with GEMÜ 1235 position indicator
AZ2
AZ1
BZ1
A
BZ2
MG A AZ1 AZ2 Dia. BZ1 BZ2
8276,0 92,0 45,0 60,0 40,5
10 257,0 92,0 45,0 60,0 40,5
25 269,0 92,0 45,0 60,0 40,5
40 293,0 92,0 45,0 60,0 40,5
50 330,0 92,0 45,0 60,0 40,5
Dimensions in mm
MG = diaphragm size
MG 50 with metal distance piece
GEMÜ 629 eSyLitewww.gemu-group.com 19 / 45
9 Dimensions

9.5 Body dimensions
9.5.1 Spigot DIN/EN ISO (code 0, 16, 17, 18, 60)
L
c
ød
s
H1
Connection type spigot DIN/EN/ISO (code 0, 16, 17, 18, 60) 1), forged material (code 40, 42, F4) 2)
MG DN NPS c (min) ød H1 L s
Connection type Connection type
0 16 17 18 60 0 16 17 18 60
8 4 - 20.0 6.0 - - - - 8.5 72.0 1.0 - - - -
6 - 20.0 - - 8.0 - 10.2 8.5 72.0 - - 1.0 - 1.6
8 1/4" 20.0 - - 10.0 - 13.5 8.5 72.0 - - 1.0 - 1.6
10 3/8" 20.0 - 12.0 13.0 14.0 - 8.5 72.0 - 1.0 1.5 2.0 -
10 10 3/8" 25.0 - 12.0 13.0 14.0 17.2 12.5 108.0 - 1.0 1.5 2.0 1.6
15 1/2" 25.0 18.0 18.0 19.0 20.0 21.3 12.5 108.0 1.5 1.0 1.5 2.0 1.6
25 15 1/2" 25.0 18.0 18.0 19.0 20.0 21.3 19.0 120.0 1.5 1.0 1.5 2.0 1.6
20 3/4" 25.0 22.0 22.0 23.0 24.0 26.9 19.0 120.0 1.5 1.0 1.5 2.0 1.6
25 1" 25.0 28.0 28.0 29.0 30.0 33.7 19.0 120.0 1.5 1.0 1.5 2.0 2.0
40 32 1¼" 25.0 34.0 34.0 35.0 36.0 42.4 26.0 153.0 1.5 1.0 1.5 2.0 2.0
40 1½" 30.5 40.0 40.0 41.0 42.0 48.3 26.0 153.0 1.5 1.0 1.5 2.0 2.0
50 50 2" 30.0 52.0 52.0 53.0 54.0 60.3 32.0 173.0 1.5 1.0 1.5 2.0 2.0
Dimensions in mm
MG = diaphragm size
1) Connection type
Code 0: Spigot DIN
Code 16: Spigot DIN EN 10357 series B (2014 edition; formerly DIN 11850 series 1)
Code 17: Spigot EN 10357 series A/DIN 11866 series A formerly DIN 11850 series 2
Code 18: Spigot DIN 11850 series 3
Code 60: Spigot ISO 1127/DIN EN 10357 series C (2014 edition)/DIN 11866 series B
2) Valve body material
Code 40: 1.4435 (F316L), forged body
Code 42: 1.4435 (BN2), forged body, Δ Fe < 0.5%
Code C3: 1.4435, investment casting
Code F4: 1.4539, forged body
www.gemu-group.com20 / 45GEMÜ 629 eSyLite
9 Dimensions
