System air SRC User manual

Installation and user manual
SRC
Smart Remote Control

INSTALLATION INSTRUCTION
NOTICE D’INSTALLATION
INSTALLATIONSHANDBUCH
ISTRUZIONI INSTALLAZIONE
INSTRUCCIONES DE INSTALACIÓN
English
Français
Español
Deutsch
Italiano

2SRC
CONTENTS
1. GENERAL RECOMMENDATIONS ........................................................................................................................................................ 3
1.1. SAFETY DIRECTIONS .......................................................................................................................................................................................................................3
1.2. WARNING .........................................................................................................................................................................................................................................3
1.3. ENVIRONMENT................................................................................................................................................................................................................................3
2. PRESENTATION................................................................................................................................................................................. 4
2.1. INTRODUCTION................................................................................................................................................................................................................................4
2.2. MINI-BMS.........................................................................................................................................................................................................................................4
2.3. REMOTE CONTROL..........................................................................................................................................................................................................................4
2.4. FEATURES .........................................................................................................................................................................................................................................4
2.4.1. CHILLERS AND HOT WATER PRODUCTION UNITS..................................................................................................................................................................................................4
2.4.2. AIR HANDLING UNIT..................................................................................................................................................................................................................................................4
2.4.3. FAN CONVECTOR UNIT..............................................................................................................................................................................................................................................4
2.4.4. HEAT PUMP ON WATER CIRCUIT ..............................................................................................................................................................................................................................4
3. DIMENSIONS AND INSTALLATION..................................................................................................................................................... 5
3.1. POWER AND COMMUNICATION UNIT..........................................................................................................................................................................................5
3.2. SRC REMOTE CONTROL..................................................................................................................................................................................................................6
3.3. WIRING..............................................................................................................................................................................................................................................7
3.3.1. NETWORK PRINCIPLE.................................................................................................................................................................................................................................................7
4. INITIAL SETTINGS ............................................................................................................................................................................. 8
4.1. INTERFACE SETTINGS......................................................................................................................................................................................................................8
4.2. DISPLAY SETTING ............................................................................................................................................................................................................................9
4.3. INTERFACE RESISTOR......................................................................................................................................................................................................................9
5. CONFIGURATION OF THE CONTROL TYPE........................................................................................................................................ 10
5.1. MINI-BMS.......................................................................................................................................................................................................................................10
5.1.1. ADDRESSING IN MINI-BMS MODE........................................................................................................................................................................................................................ 11
5.1.2. FAN CONVECTOR UNIT CONTROL......................................................................................................................................................................................................................... 11
5.1.3. FAN CONVECTOR UNIT CONFIGURATION............................................................................................................................................................................................................. 12
5.1.4. ZONE CREATION ...................................................................................................................................................................................................................................................... 13
5.1.5. NAME ZONES........................................................................................................................................................................................................................................................... 14
5.2. FAN CONVECTOR UNIT ONLY.......................................................................................................................................................................................................14
5.3. FAN CONVECTOR UNIT ZONE ......................................................................................................................................................................................................15
5.4. HEAT PUMP ON WATER CIRCUIT ONLY ......................................................................................................................................................................................16
5.5. HEAT PUMP ON WATER CIRCUIT ONLY ZONE............................................................................................................................................................................17
6. HOURLY PROGRAMMING ............................................................................................................................................................... 18
6.1. GENERAL ........................................................................................................................................................................................................................................18
6.2. FAN CONVECTOR UNIT.................................................................................................................................................................................................................19
6.2.1. FAN CONVECTOR UNIT A........................................................................................................................................................................................................................................ 19
6.2.2. FAN CONVECTOR UNIT B........................................................................................................................................................................................................................................ 20
6.3. CHILLERS AND HOT WATER PRODUCTION UNITS.....................................................................................................................................................................21
6.3.1. CHILLER A ................................................................................................................................................................................................................................................................. 21
6.3.2. CHILLER B ................................................................................................................................................................................................................................................................. 21
6.4. AIR HANDLING UNIT.....................................................................................................................................................................................................................21
6.5. HEAT PUMP ON WATER CIRCUIT.................................................................................................................................................................................................22
7. CONTROL OF DEVICES..................................................................................................................................................................... 23
7.1. FAN CONVECTOR UNIT.................................................................................................................................................................................................................23
7.1.1. FAN CONVECTOR UNIT A........................................................................................................................................................................................................................................ 23
7.1.2. FAN CONVECTOR UNIT B........................................................................................................................................................................................................................................ 24
7.2. CHILLERS AND HOT WATER PRODUCTION UNITS.....................................................................................................................................................................25
7.2.1. CHILLER A ................................................................................................................................................................................................................................................................. 25
7.2.2. CHILLER B ................................................................................................................................................................................................................................................................. 26
7.3. AIR HANDLING UNIT.....................................................................................................................................................................................................................26
7.4. HEAT PUMP ON WATER CIRCUIT.................................................................................................................................................................................................27
8. ALARM........................................................................................................................................................................................... 28
9. PASSWORD CHANGE ...................................................................................................................................................................... 29
10. SRC RESET .................................................................................................................................................................................... 29
11. IN CASE OF WARRANTY - MATERIAL RETURN PROCEDURE ......................................................................................................... 30
12. ORDERING SERVICE AND SPARE PARTS ORDER ........................................................................................................................... 30

3SRC
POWER SUPPLY MUST BE
SWITCHED OFF
BEFORE STARTING WORK IN THE
ELECTRIC CONTROL BOX
1. GENERAL RECOMMENDATIONS
Please read the following safety precautions very carefully before installing the unit.
1.1. SAFETY DIRECTIONS
Cutoff power supply before starting to work on the appliance.
The manufacturer declines any responsibility and the warranty becomes void if these instructions are
not respected.
If you meet a problem, please call the Technical Department of your geographical area.
The information contained in these Instructions are subject to modication without advance notice.
1.2. WARNING
Follow the safety rules in forces when you are working on your appliance.
The installation, commissioning, use and maintenance of these units should be performed by qualied
personnel having a good knowledge of standards and local regulations, as well as experience of this type
of equipment.
This appliance has not been designed for use by persons (including children) with reduced physical, sensorial
or mental faculties or by persons without any experience or knowledge of heating systems, unless they act
under the safety and supervision of a responsible person or have received prior training concerning the use
of the appliance.
Any wiring produced on site must comply with the corresponding national electrical regulations.
Make sure that the power supply and its frequency are adapted to the required electric current of operation,
taking into account specic conditions of the location and the current required for any other appliance
connected to the same circuit.
The unit must be EARTHED to avoid any risks caused by insulation defects.
It is forbidden to start any work on the electrical components if water or high humidity is present on the
installation site.
Climatic conditions
Transport Ambient temperature -20... 70°C
Max. ambient humidity 95% RH, non-condensing
Storage Ambient temperature -20... 70°C
Max. ambient humidity 95% RH, non-condensing
Operation Ambient temperature -20... 50°C
Max. ambient humidity 95% RH, non-condensing
1.3. ENVIRONMENT
This equipment is designed for indoor installation ONLY.

ON
OFF
A
AUTO
A
AUTO
05.02.2020
13:35
AutoAuto
StatutMode
Zone 1
Accueil
ON
OFF
A
AUTO
05.02.2020
13:35
18.5°C
Point de consigne
Haute
ArretFroid
Vitesse
StatutMode
Zone 1
Accueil
MANAUTO
ON
OFF
A
AUTO
05.02.2020
13:35
Occ.18.5°C
Présence
Point de
consigne
AutoArretAuto
VitesseStatutMode
Appareil 1 , Adresse 1
Accueil
MANAUTO
05.02.2020
13:35
Arret
Vitesse
Zone 1
Accueil
4SRC
2. PRESENTATION
2.1. INTRODUCTION
The SRC HMI (Smart Remote Control) is a control interface for control systems. It has the advantage of being
a remote control system. The control can be centralized and is done either individually or by zone (unit
group). It can control up to:
²31 units
²15 separate zones
The SRC is used as a simple remote control. It controls a single type of device, whether alone or several
in a single zone:
²Fan convector unit only
Fan convector unit (featuring SYSLOGIC control)
²Fan convector unit zone (featuring SYSLOGIC control)
²Heat pump on water circuit only (featuring POL423 or POL636 or POL638 control)
²Heat pump zone on water circuit (featuring POL423 or POL636 or POL638 control)
2.2. MINI-BMS
The SRC controls several devices of different types over several zones:
²Chillers and hot water production units
Chiller A (SYSAQUA featuring POL423 or POL636 or POL638 control)
Chiller B (SYSCROLL except SYSCROLL EVO 20-30)
²Air handling units (featuring Access Control)
²Fan convector units
Fan convector unit A (featuring SYSLOGIC control)
Fan convector unit B (featuring TCONTROLPOD control)
The SRC is used to act on the
following:
²operating mode
²unit status
The SRC is used to act on the
following:
²ventilation speed
The SRC is used to act on the
following:
²operating mode
²unit status
²ventilation speed
²ambient setpoint
The SRC is used to act on the
following:
²operating mode
²unit status
²ventilation speed
²ambient setpoint(s)
²in use/not in use
2.3. REMOTE CONTROL
2.4. FEATURES
2.4.1. CHILLERS AND HOT WATER
PRODUCTION UNITS
2.4.2. AIR HANDLING UNIT
2.4.3. FAN CONVECTOR UNIT 2.4.4. HEAT PUMP ON WATER CIRCUIT

143
165
171
198
Ø5
230 V ~ / 50Hz
NL
G
N
D
A
B+
-
MODBUS RTU
GN
D
A
B
+
-
MODBUS RTU
SRC
RJ10
123
Information
the power and communication unit can be installed at the bottom of the wall just above the electrical
ducts. A 1 m connection cable between the unit and the SRC remote control is supplied. It is possible
to use a connection cable of up to 6 m.
5SRC
3. DIMENSIONS AND INSTALLATION
3.1. POWER AND COMMUNICATION UNIT
The power and communication unit contains:
²a 220 V ~/24 V DC transformer
²a Modbus RTU protocol protection card
To install the power and communication unit:
1. Mount 2 screws on the wall, respecting
the dimensions.
2. Hook the unit onto the screws.
Opening the unit
Electrical power supply Communication

34
50
105
105
6SRC
To install the SRC:
1. Mount 2 screws on the wall, respecting the dimensions.
2. Connect the RJ10 cable
3. Attach the SRC remote
control to the screws.
3.2. SRC REMOTE CONTROL
The SRC is designed to be mounted on a wall. There are two
mounting options:
To install the SRC:
1. Fix the back to the wall
2. Connect the RJ10 cable
3. Clip the cover by pressing lightly on it at the clip.
Method 1
Method 2

RS485+ RS485-
GND
RS485+ RS485-
GND
MB2
RS485+ RS485-
GND
RS485+ RS485-
GND
MB2
RS485+ RS485-
GND
RS485+ RS485-
GND
MB2
T5
A+B-
REF
RS485
T5
A+B-
REF
RS485
AB
GND
Max. number of slaves: 31
SRC communication board
SLAVE 5 SLAVE 4 SLAVE 3
SLAVE 2SLAVE 1
MASTER
Information
The transmission is congured in 9600 baud, without parity, with 8 data bits and 1 stop bit.
7SRC
Bus topology Star topology Trunk and branch topology
Prohibited Prohibited Prohibited
Ring topology Linear topology
Prohibited Authorized
3.3. WIRING
The interconnection wires must be a screened twisted pair. The wire impedance shall be between 100 and
130 ohms, and its cross-sectional area between 0.12 and 0.3 mm2(26 to 22 AWG).
Each network is limited to 31 units and a distance of 1,000 meters. However, we recommend using a
repeater well before reaching the limits and in accordance with the geographical constraints.
3.3.1. NETWORK PRINCIPLE

No active alarms
No zones configured
Home 05.02.2020
13:35

i
System preferences
Unit information
Settings
Alarms
Scheduling
Air handling unit
Chiller
Fan coil
Menu
Display settings
HMI termination
None
Clock sync. source
Example 13.00
Use 24 hours time format
05.02.2020 13:35:20
Unit date and time
English
Unit language
System preferences
Italiano
French
Cancel OK
Spanish
German
English
Unit language
System preferences
Display settings
1
2
Display settings
HMI termination
None
Clock sync. source
Example 13.00
Use 24 hours time format
05.02.2020 13:35:20
Unit date and time
English
Unit language
System preferences
2
13513
202025
OKCancel
Unit date and time
MinuteHour
YearMonthDay
Display settings
HMI termination
None
Clock sync. source
Example 13.00
Use 24 hours time format
05.02.2020 13:35:20
Unit date and time
English
Unit language
System preferences
Cancel OK
Air handling unit, Address 5
Chiller B, Address 2
Chiller A, Address 1
Clock sync. source
System preferences
Display settings 2
1
Display settings
HMI termination
Chiller B, Address 2
Clock sync. source
Example 13.00
Use 24 hours time format
05.02.2020 13:35:20
Unit date and time
English
Unit language
System preferences
In the case of heat pump management on water circuits, the SRC’s clock must be synchronized with
that of one of the units.
Caution
8SRC
4. INITIAL SETTINGS
4.1. INTERFACE SETTINGS
Start by conguring the settings for the:
1. language
2. type of time display
3. date and time
When the SRC is used to manage units equipped with an internal clock, it is possible to synchronize the SRC
to one of these units. Synchronization is done automatically (depending on the unit) or at the SRC power-up.

8
Active mode back light
2
Sleep mode back light
10 min
Sleep mode timeout
Display settings
1 ... 60
min10
OKCancel
Sleep mode timeout
Sleep mode timeout
Display settings
2
1
2
OKCancel
Sleep mode back light
Sleep mode timeout
Display settings
2
1
8
OKCancel
Active mode back light
Sleep mode timeout
Display settings
2
1
Display settings
HMI termination
None
Clock sync. source
Example 13.00
Use 24 hours time format
05.02.2020 13:35:20
Unit date and time
English
Unit language
System preferences
Display settings
HMI termination
Chiller B, Address 2
Clock sync. source
Example 13.00
Use 24 hours time format
05.02.2020 13:35:20
Unit date and time
English
Unit language
System preferences
Display settings
HMI termination
Chiller B, Address 2
Clock sync. source
Example 13.00
Use 24 hours time format
05.02.2020 13:35:20
Unit date and time
English
Unit language
System preferences
Information
Setting “0” for standby brightness turns off the SRC screen. Simply tapping on the screen brings the
SRC out of this mode.
9SRC
4.2. DISPLAY SETTING
This menu allows you to manage the screen brightness when it is active or in
standby mode. It is also possible to set the standby time.
4.3. INTERFACE RESISTOR
The SRC is equipped with a 120 ohm terminating resistor. By default, the end of line resistor is activated. It
can be deactivated directly via the “Preferences” screen.


i
System preferences
Unit information
Settings
Alarms
Scheduling
Air handling unit
Chiller
Fan coil
Menu
Factory reset
Change password
Zone devices
Zone name
Configure addresses
DIP Config.
Fan coil A
Fancoil type
µBMS
SRC type
Settings
Factory reset
Settings
Zone of water source heat pump
Single water source heat pump
Cancel OK
Zone of fan coils (A)
Single fan coil (A)
µBMS
SRC type
1
SRC type
2
0
987
654
321
Factory reset
Settings
Enter Service password
Cancel
OK
9201
Fan coil A
Fancoil type
µBMS
SRC type
2
1
Information
To make it easier to identify the elds when using the SRC, it is possible to name each of the zones.
10 SRC
5. CONFIGURATION OF THE CONTROL TYPE
The choice of control system is made in the Parameter menu. Access is password protected (9201 by
default)
With the Mini BMS option, the SRC allows you to group and manage several types of units by zones:
²Chillers and hot water production units
²Air handling units
²Fan convector units
For the other options, the SRC considers the network as a single zone in which only one type of machine is
present:
²Fan convector units featuring SYSLOGIC control
²Heat pump on water circuit
5.1. MINI-BMS
The conguration must be carried out according to the following process:
1. address conguration
2. choice of the control type used on the fan convector units
3. denition of the fan convector unit conguration
Conguration dip switch (SYSLOGIC control)
AC motor (TCONTROLPOD control)
EC motor (TCONTROLPOD control)
4. zone creation

Factory reset
Change password
Zone devices
Zone name
Configure addresses
DIP Config.
Fan coil A
Fancoil type
µBMS
SRC type
Settings
2
Factory reset
Change password
Zone devices
Zone name
Configure addresses
DIP Config.
Fan coil A
Fancoil type
µBMS
SRC type
Settings
1
1/51/5
0
987
654
321
Enter Service password
Cancel
OK
9201
None
Address 7
None
Address 2
None
Address 1
Devices
2
1
1/5
None
Address 7
None
Air handling unit
Chiller B
Cancel OK
Chiller A
Fan coil
None
Configure addresses
1
Devices
2
1/5
None
Address 7
None
Address 6
None
Address 5
None
Address 4
None
Address 3
None
Address 2
Chiller A
Address 1
Devices
1
1/5
None
Address 7
None
Air handling unit
Chiller B
Cancel OK
Chiller A
Fan coil
None
Configure addresses
1
Devices
2
1/5
None
Address 7
None
Address 6
None
Address 5
None
Address 4
None
Address 3
Fan coil
Address 2
Chiller A
Address 1
Devices
1/5
None
Address 7
None
Address 6
None
Address 5
None
Address 4
None
Address 3
Fan coil
Address 2
Chiller A
Address 1
Devices
11
5/5
None
Address 31
None
Address 30
None
Address 29
Devices
Factory reset
Change password
Zone devices
Fancoil type
µBMS
SRC type
Settings
Cancel OK
Fan coil B
Fan coil A
Fancoil type
1
2
Before setting up the SRC, it is important that all slave units are addressed.
²Maximum of 31 units
²Addresses between 1 and 31
Caution
11SRC
5.1.1. ADDRESSING IN MINI-BMS MODE
The correspondence of each address must be
respected.
Up to 31 addresses can be assigned by changing page.
It is always possible to add or remove a machine at
a later date.
This menu is used to dene the type of regulation tted to the fan convector units:
²Fan convector unit A
featuring SYSLOGIC control
²Fan convector unit B
featuring TCONTROLPOD AC control
featuring TCONTROLPOD EC control
5.1.2. FAN CONVECTOR UNIT CONTROL

Factory reset
Change password
Zone devices
Zone name
Configure addresses
DIP Config.
Fan coil A
Fancoil type
µBMS
SRC type
Settings
3
TUs DIP Config.
1
Address 1
1
Address 2
1
1 ... 7
1
TUs DIP Config.
Address 1
OKCancel
DIP Config.
2
1
TUs DIP Config.
1
Address 1
3
Address 2
TUs DIP Config.
1
Address 1
1
Address 2
2
1 ... 7
3
TUs DIP Config.
Address 1
OKCancel
DIP Config.
2
1
Factory reset
Change password
Zone devices
Zone name
Configure addresses
Model
Fan coil B
Fancoil type
µBMS
SRC type
Settings
3
TUs Model
AC
Address 1
AC
Address 2
1
TUs Model
AC
Address 1
Address 2
Cancel OK
EC
AC
Model
1
2
TUs Model
EC
Address 1
AC
Address 2
321
ON
321
ON
321
ON
321
ON
321
ON
321
ON
321
ON
12 SRC
5.1.3. FAN CONVECTOR UNIT CONFIGURATION
5.1.3.1. FAN CONVECTOR UNIT A
5.1.3.2. FAN CONVECTOR UNIT B
The SRC must be set up according to the conguration of the fan convector units.
Type A fan coils are equipped with SYSLOGIC control. This electronic card has a DIP switch to dene the
characteristics of the machine There are 7 possible congurations:
Type B fan convector units feature TCONTROLPOD control. This electronic board is specic according to the
type of motor equipping the unit:
²AC
²EC
1. 2 tubes with valve
Cooling only
2. 2 tubes with valve
Reversible/change over
3. 2 tubes with valve
Heating only
4. 2 tubes without valve
Reversible/change over
5. 4 tubes with valve
Cooling/Heating
6. 2 tubes with valve and electric
heating
Cooling/Heating
7. 2 tubes with valve and electric
heating
Reversible/change over

Cancel OK
Zone 7
Zone 6
Zone 5
Zone 4
Zone 3
Zone 2
Zone 1
Zone
1
2
Factory reset
Change password
Zone devices
Zone name
Configure addresses
DIP Config.
Fan coil A
Fancoil type
µBMS
SRC type
Settings
4+
Zone 1
Fan coil, Address 5
Chiller A, Address 4
Cancel OK
Air handling unit, Address 3
Fan coil, Address 2
Chiller A, Address 1
Zone devices
1
2
+
Zone 1
Release
Chiller A, Address 1
+
Zone 1
Release
Chiller A, Address 1
1
+
+
Zone 1
Release
Chiller A, Address 1
Chiller A, Address 4
Cancel OK
Zone devices
1
2
Zone 1
Release
Chiller A, Address 4
Release
Chiller A, Address 1
Cancel OK
Zone 7
Zone 6
Zone 5
Zone 4
Zone 3
Zone 2
Zone 1
Zone
1
2
+
Zone 1
1
+
Zone 2
1
Zone 2
Fan coil, Address 5
Cancel OK
Air handling unit, Address 3
Fan coil, Address 2
Zone devices
2
+
Zone 2
Release
Fan coil, Address 2
Cancel OK
Zone 7
Zone 6
Zone 5
Zone 4
Zone 3
Zone 2
Zone 1
Zone
1
Each zone can only have one type of device. For fan convector unit zones, the conguration of the
Dips or the motor type must be identical.
Caution
Information
Access to the different zones is done by scrolling vertically. The SRC has 15
zones.
13SRC
5.1.4. ZONE CREATION
After selecting the desired area, add and remove the available devices:
²Chillers
²Terminal units
²Air handling units

Factory reset
Change password
Zone devices
Zone name
Configure addresses
DIP Config.
Fan coil A
Fancoil type
µBMS
SRC type
Settings
1
1/3
Zone 5
Zone 4
Zone 3
Zone 2
Zone 1
Zone name
1
1/3
.123
onbvcxz
lkjhgfdsa
poiuytrewq
Zone 5
Zone 1
Zone name
Zone name
Cancel
OK
1/3
Zone 5
Zone 4
Zone 3
Zone 2
Chiller
Zone 1
Zone name

i
System preferences
Unit information
Settings
Alarms
Scheduling
Air handling unit
Chiller
Fan coil
Menu
Factory reset
Change password
Zone devices
Zone name
Configure addresses
DIP Config.
Fan coil A
Fancoil type
µBMS
SRC type
Settings
Factory reset
Settings
Zone of water source heat pump
Single water source heat pump
Cancel OK
Zone of fan coils (A)
Single fan coil (A)
µBMS
SRC type
1
SRC type
2
0
987
654
321
Factory reset
Settings
Enter Service password
Cancel
OK
9201
Fan coil A
Fancoil type
µBMS
SRC type
2
1
Resets all settings to default
Factory reset
Change password
1
Device addresses
1
DIP Config.
Single fan coil (A)
SRC type
Settings
1
Resets all settings to default
Factory reset
Change password
1
Device addresses
1
DIP Config.
Single fan coil (A)
SRC type
Settings
2
1 ... 7
1
Resets all settings to default
Factory reset
1
SRC type
Settings
OKCancel
DIP Config.
2
1
1 ... 247
1
Resets all settings to default
Factory reset
1
SRC type
Settings
OKCancel
Device address
1
14 SRC
5.1.5. NAME ZONES
Select a zone from the proposed list (zone 1, zone 2, etc.) to name it.
5.2. FAN CONVECTOR UNIT ONLY
In this operating mode the SRC can only control one type A fan conductor unit.
The DIP Cong. corresponds to the technical specications of the fan convector unit (Refer to the §
FAN CONVECTOR UNIT A, page 12). It is imperative that all fan convector units have strictly the same
conguration.
The declared address must be the same as that of the fan convector unit. The address can be between 1
and 247.
The conguration must be carried out according to the following process:
1. denition of the fan convector unit conguration
2. address conguration


i
System preferences
Unit information
Settings
Alarms
Scheduling
Air handling unit
Chiller
Fan coil
Menu
Factory reset
Change password
Zone devices
Zone name
Configure addresses
DIP Config.
Fan coil A
Fancoil type
µBMS
SRC type
Settings
Factory reset
Settings
Zone of water source heat pump
Single water source heat pump
Cancel OK
Zone of fan coils (A)
Single fan coil (A)
µBMS
SRC type
1
SRC type
2
0
987
654
321
Factory reset
Settings
Enter Service password
Cancel
OK
9201
Fan coil A
Fancoil type
µBMS
SRC type
2
1
Resets all settings to default
Factory reset
Change password
Zone devices
1
DIP Config.
Zone of fan coils (A)
SRC type
Settings
11 ... 7
1
Resets all settings to default
Factory reset
1
SRC type
Settings
OKCancel
DIP Config.
2
1
Resets all settings to default
Factory reset
Change password
Zone devices
1
DIP Config.
Zone of fan coils (A)
SRC type
Settings
2
+
Zone devices
Address 1
Device 1
1
+
1 ... 247
36
Zone devices
Device 1
1
OKCancel
Device address
2
1
+
Zone devices
ReleaseAddress 36
Device 2
Address 1
Device 1
1
15SRC
5.3. FAN CONVECTOR UNIT ZONE
The conguration must be carried out according to the following process:
1. denition of the fan convector unit type conguration
2. address conguration
In this operating mode, the SRC can control a maximum of 31 type A fan conductor units.
The DIP Cong. corresponds to the technical specications of the fan convector unit type (Refer to the § FAN
CONVECTOR UNIT B, page 12).
The declared address must be the same as that of the fan convector unit. The address can be between 1
and 247. All addresses must be unique.


i
System preferences
Unit information
Settings
Alarms
Scheduling
Air handling unit
Chiller
Fan coil
Menu
Factory reset
Change password
Zone devices
Zone name
Configure addresses
DIP Config.
Fan coil A
Fancoil type
µBMS
SRC type
Settings
Factory reset
Settings
Zone of water source heat pump
Single water source heat pump
Cancel OK
Zone of fan coils (A)
Single fan coil (A)
µBMS
SRC type
1
SRC type
2
0
987
654
321
Factory reset
Settings
Enter Service password
Cancel
OK
9201
Fan coil A
Fancoil type
µBMS
SRC type
2
1
Resets all settings to default
Factory reset
Change password
Device addresses
1
Single water souce heat pump
SRC type
Settings
11 ... 247
1
SRC type
Settings
OKCancel
Device address
2
1
16 SRC
5.4. HEAT PUMP ON WATER CIRCUIT ONLY
In this operating mode, the SRC can only control one heat pump on water circuit.
The declared address must correspond to that of the heat pump on water circuit. The address can be
between 1 and 247.


i
System preferences
Unit information
Settings
Alarms
Scheduling
Air handling unit
Chiller
Fan coil
Menu
Factory reset
Change password
Zone devices
Zone name
Configure addresses
DIP Config.
Fan coil A
Fancoil type
µBMS
SRC type
Settings
Factory reset
Settings
Zone of water source heat pump
Single water source heat pump
Cancel OK
Zone of fan coils (A)
Single fan coil (A)
µBMS
SRC type
1
SRC type
2
0
987
654
321
Factory reset
Settings
Enter Service password
Cancel
OK
9201
Fan coil A
Fancoil type
µBMS
SRC type
2
1
Resets all settings to default
Factory reset
Change password
Zone devices
Zone of water source heat pump
SRC type
Settings
1
+
Zone devices
Address 1
Device 1
1
+
1 ... 247
36
Zone devices
Device 1
1
OKCancel
Device address
2
1
+
Zone devices
ReleaseAddress 36
Device 2
Address 1
Device 1
1
17SRC
5.5. HEAT PUMP ON WATER CIRCUIT ONLY ZONE
The conguration must be carried out according to the following process:
1. address conguration
In this operating mode, the SRC can control a maximum of 31 heat pumps on water circuit.
The declared address must correspond to that of the heat pump on water circuit. The address can be
between 1 and 247. All addresses must be unique.


i
System preferences
Unit information
Settings
Alarms
Scheduling
Air handling unit
Chiller
Fan coil
Menu
Cancel OK
Zone 7
Zone 6
Zone 5
Zone 4
Zone 3
Zone 2
Zone 1
Zone
1
2
21.0°C
08:00
4321
Copy
Setpoint
Speed
Satus
Mode
Start
Low
OFF
Cooling
Time range active
Time range
Days Week Weekend
Scheduling
Zone 1
21.0°C
08:00
4321
Copy
Setpoint
Speed
Satus
Mode
Start
Low
OFF
Cooling
Time range active
Time range
Days Week Weekend
Scheduling
Zone 1
21.0°C
08:00
4321
Copy
Setpoint
Speed
Satus
Mode
Start
Low
OFF
Cooling
Time range active
Time range
Days Week Weekend
Scheduling
Zone 1
21.0°C
08:00
4321
Copy
Setpoint
Speed
Satus
Mode
Start
Low
OFF
Cooling
Time range active
Time range
Days Week Weekend
Scheduling
Zone 1
21.0°C
08:00
4321
Copy
Setpoint
Speed
Satus
Mode
Start
Low
OFF
Cooling
Time range active
Time range
Days Week Weekend
Scheduling
Zone 1
21.0°C
00:08
Copy
Setpoint
Low
Days Week Weekend
Scheduling
Zone 1
OKCancel
Start
2
1
The time programming of the ranges must be chronological. Otherwise, the SRC will malfunction.
Caution
18 SRC
6. HOURLY PROGRAMMING
The SRC allows the operating parameters to be programmed by zone.
It is possible to program weekdays and weekends differently.
For each programming group, 4 time slots are available.
For each time slot, it is possible to set the time from which the operating
parameters will be applied. It is also necessary to enable or disable this
time slot.
6.1. GENERAL
When creating or modifying a program, the SRC immediately applies the setting of the range that is active
at that time.
Example:
Time: 2:30 PM
T1 active at 8:00 AM
T1 active at 12:00 noon
T3 active at 6:00 PM
T4 active at 10:00 PM
The SRC applies the programming of the T2 range.
Inactive range
Active range
