SS12/24ADA* Series Strobes and

MASS12/24ADA* Series Horn/Strobes

for Fire Protective Signaling Systems

*ULC models add suffix “A”; strobes and sounder/strobes available in 24VDC,

15cd only

INSTALLATION AND MAINTENANCE INSTRUCTIONS

A Division of Pittway

3825 Ohio Avenue, St. Charles, Illinois 60174

1-800-SENSOR2, FAX: 630-377-6495

General Description

The National Fire Protection Association has published

standards and recommended practices for the installation

and use of the listed appliances. It is recommended that the

installer be familiar with these requirements, local codes,

and any special requirements of the local fire authority hav-

ing jurisdiction.

The Multi-Alert sounder and signaling strobe are intended

to be connected to the alarm indicating circuit of a UL-

listed fire alarm control panel. Both are compatible with DC

line supervision. The electronic sounder can be connected

Sound (Hz) Clips on Tabs Current (ma) Output (dBA)

UL (dBA)

( Note 1) DC Regulated/ (Note 3)

Ratings

FWR Unfiltered (Note 4)

12V 24V 30V 12V 24V 12V 24V

Slow Whoop ABC 21/40 38/56 46/72 85 92 79 85

800 Continuous BC 15/24 28/45 35/55 87 93 79 85

800/1000 Alternating AC 17/32 34/46 43/58 85 92 79 85

2400 Interrupted AB 19/23 35/56 43/64 89 90 79 85

2400 Continuous C 21/31 38/59 46/73 85 94 79 85

1200 Interrupted B 13/19 23/33 27/41 85 91 75 82

Swept Frequency A 17/24 34/47 43/60 85 92 79 85

Fast Warble NONE 15/27 30/47 38/59 85 92 79 85

Note 1: See Figure 2 for tab clip removal & storage.

Note 2: All models can be powered using full wave rectified unfiltered

supplies. Under no circumstances can SS24ADA or

MASS24ADA series devices input voltage exceed 33 VDC or be

less than 16 VDC (16-33Vrms for full-wave rectified, unfiltered

supplies). Under no circumstances can the MA12/24D input

Table 1. SS12/24ADA Series electrical ratings:

Model Supply

Voltage

Range

Operating Current from Regulated Supply Operating Current from Full-Wave Rectified Unfiltered

Supply

Average

Operating

Current

Peak

Current

(mA)

20/30V

Peak

Current

(mA)

10.5V/17V

Inrush

Current

(mA in

access of

Peak)

Average

Operating

Current

(mArms)

Peak Current

(mA)

20Vrms/



30Vrms

Peak Current

(mA)

10.5Vrms/

17Vrms

Inrush Current

(Amps in excess

of Peak)

SS24110ADA

SS24110ADAB 20-30V 210 470/500 - 0 245 400/500 - .080

SS2475ADA

SS2475ADAB 20-30V 170 385/400 - 0 200 320/370 - .040

SS2415ADA

SS2415ADAB 20-30V 75 160/180 - 0 90 275/290 - .020

SS1215ADA

SS1215ADAB 10.5-17V 170 - 360/380 0 200 - 330/380 .020

SS241575ADA

SS241575ADAB 20-30V 93 210/220 -- 0 120 275/290 -- 1.0

SS121575ADA

SS121575ADAB 10.5-17V 225 -- 510/560 0 270 -- 500/530 .020



SS2415ADAA 20-30V 175 360/380 -- 0 200 330/380 -- .020

NOTE: Inrush current du-

ration is less than

20 microseconds

(.00002 seconds).

Table 2. Sound Output and Current Ratings for the MA12/24D:

voltage exceed 33 VDC or be less than 9.6 VDC. Under no cir-

cumstances can a SS12ADA or MASS12ADA series device input

voltage exceed 18.7 VDC or be less than 9.6 VDC (9.6 -

18.7Vrms for full-wave rectified, unfiltered supplies).

Note 3: Measured at 10 feet in an anechoic chamber.

Note 4: Measured in a UL reverberant room.

to either 12 or 24 VDC panels. Models SS2415ADA,

SS2475ADA, SS24110ADA, SS241575ADA, and combina-

tion models incorporating these strobes, require 24 volt

panels. Models SS1215ADA, SS121575ADA,

MASS1215ADA , and MASS121575ADA require 12 volt pan-

els. Panels may have full-wave rectified, unfiltered power

supplies. The strobes produce one flash per second (nomi-

nal) with continuous nominal voltage applied.

The MA12/24D is suitable for outdoor applications (-35°to

66°C) when it is used with a WBB Weatherproof Back Box.

The signaling strobe is rated for 0°to 49°C and is NOT

Technical Manuals Online! - http://www.tech-man.com

D900-01-00 2 I56-650-16

suitable for outdoor use.

The rated light output of the SS2415ADA, SS1215ADA,

SS241575ADA, SS121575ADA, MASS2415ADA,

MASS241575ADA, MASS1215ADA, and MASS121575ADA

is 15 cd (See Figure 1).

The rated light output of the SS2475ADA and

MASS2475ADA is 75 cd (See Figure 1).

The rated light output of the SS24110ADA and

MASS24110ADA is 110 cd (See Figure 1).

NOTE: The light output at 0°viewing angle for SS12/

241575ADA and MASS12/241575ADA models is 75

cd (See Figure 1).

Any one of eight sounds can be selected on the electronic

sounder, as indicated in Table 2. The sound selected deter-

mines the maximum current and sound power output per

device. See Table 1 for these values.

Independent Sounder/Strobe Operation

There may be applications where it is desirable to drive the

sounder and strobe as independent devices. The System

Sensor MASS12/24ADA series sounder/strobes are easily

configured for this capability. The terminal connection for

this application is shown in Figure 6. Independent strobe

operation in a coded system requires a separate uncoded

power supply for the strobe.

Installation

A. General:

Slotted head screws are used to attach each device or

combination of devices to the electrical outlet box.

Phillips head screws are used to attach accessories to the

horn. Refer to Figures 3,4,5, and 6 for wiring methods.

Notes: Do not loop wires under the terminal screw. Wires

connecting the device to the panel must be broken

The Sounder and/or Strobe will not work without power. The sounder/

strobe gets its power from the fire/security panel monitoring the alarm

system. If power is cut off for any reason, the sounder/strobe will not pro-

vide the desired audio or visual warning.

The Sounder may not be heard. The loudness of the sounder meets (or

exceeds) current Underwriters Laboratories’ standards. However, the

sounder may not alert a sound sleeper or one who has recently used drugs

or has been drinking alcoholic beverages. The Sounder may not be heard

if it is placed on a different floor from the person in hazard or if placed too

far away to be heard over the ambient noise such as traffic, air condition-

ers, machinery or music appliances that may prevent alert persons from

hearing the alarm. The Sounder may not be heard by persons who are

hearing impaired.

The Signal Strobe may not be seen. The electronic visual warning signal

that flashes at least once every three seconds meets or exceeds current Un-

derwriters Laboratories’ standard 1971 and uses an extremely reliable xe-

non flash tube. The visual warning signal is suitable for direct viewing and

must be installed within an area where it can be seen by building occu-

pants. The strobe must not be installed in direct sunlight or areas of high

light intensity (over 60 foot candles) where the visual flash might be disre-

garded or not seen. The strobe may not be seen by the visually im-

paired.

The signal strobe may cause seizures. Individuals who have a positive

photic response to visual stimuli with seizures, such as epileptics, should

avoid prolonged exposure to environments in which strobe signals, in-

cluding this strobe, are activated.

System Sensor recommends that the Multi-Alert Sounder and Signal

Strobe always be used in combination so that the risks from any of the

above limitations are minimized.

The signal strobe cannot operate from coded power supplies. Coded

power supplies produce interrupted power. The strobe must have an unin-

terrupted source of dc power in order to operate correctly.

WARNING

The Limitations of Sounder/Strobes

at the device terminal connection in order to main-

tain electrical supervision. Strobe and strobe/

horn combination are designed for wall mount-

ing ONLY.

The sounder is 1-1/4"deep. Back boxes must be 4"

square by at least 1-1/2"deep – 2-1/8"deep is

recommended.

All strobes must be mounted so that the top of the lens is

24 inches (61 cm) below ceilings or as required by the

authority having jurisdiction.

B. Sounder mounting:

1. Surface Mount: (See Fig. 7)

2. Semi Flush Mount: (See Fig. 10 and 13)

3. Flush Mount: (See Fig. 12)

C. Sounder/Strobe combination mounting:

1. Surface Mount : (See Fig. 9)

2. Semi Flush Mount: (See Fig. 10 and 13)

Flush mounting requires the use of the deep box (Part #

BB-D) or equivalent. Determine which of the two device

holes will be used to attach the device to the box. Mount

the flush plate to the sounder using the other two holes

with two 1-inch phillips head screws and two square

nuts.

D. Strobe mounting:

1. Surface Mount: (See Fig. 8)

2. Semi Flush Mount: (See Fig. 11)

Installation procedures must conform to all applicable

codes and the requirements of the authority having

jurisdiction.

NOTE: The rated output of the sounder is specified at 10

feet. It cannot be assumed that the output will

meet the NFPA standard of 15 dB over ambient

noise at all locations within a room. Additional

sounders may be needed to ensure sound output

level complies with NFPA requirements.

Technical Manuals Online! - http://www.tech-man.com

D900-01-00 3 I56-650-16

LIGHT

0˚

–45˚

45˚

90˚ –90˚

1. Complete field wiring. (See Fig. 5)

2. Screw sounder to box with screw A.

3. Fill remaining holes with screw B.

Degrees % of Rating

0 100

5 - 25 90

30 - 45 75

50 55

55 45

60 40

65 35

70 35

75 30

80 30

85 25

90 25

From

panel or

previous

device

To Next

Device

or EOL

– VDC

+ VDC

Note: Use uncoded supply only.

(–)

INOUT

STROBE

ONLY

(–)

INOUT (+)

INOUT

STROBE

ONLY

(+)

INOUT

(-)

INOUT

STROBE

ONLY

(-)

INOUT (+)

INOUT

STROBE

ONLY

(+)

INOUT

From

panel or

device

To Next

Device

or EOL

- VDC

+ VDC

MA12/24D

BB-STD

A78-1137-03

A78-1137-29

A78-1137-00

A78-2167-00

Figure 1. Vertical and horizontal light distribution:

CLIP

STORAGE CLIPS REMOVED OR

ADDED TO SELECT

DESIRED TONE.

COVER SLOT

TAB A

TAB B

TAB C

FOR STORING UNUSED CLIPS:

SLIDE COVER BACK TO ALIGN COVER SLOT

WITH CLIP STORAGE POST.

SLIDE COVER

FOR CLIP STORAGE

USE A

SMALL-

BLADED

SCREWDRIVER

TO REMOVE

CLIPS

TONE

SELECTION TABS

Figure 2: Figure 3. Multi-alert sounder:

Figure 4. Strobe: Figure 5. Multi-alert sounder and strobe operating in

tandem:

From

panel or

previous

device

To Next

Device

or EOL

– VDC

+ VDC

– VDC

STROBE

SOUNDER

(–)

INOUT

STROBE

ONLY

(–)

INOUT (+)

INOUT

STROBE

ONLY

(+)

INOUT

Non-

Coded

Supply

Can Be

Coded

Supply

Caution: Break off P.C.B. Tabs

Figure 6. Multi-alert sounder and strobe operating

independently:

A78-1137-01

Figure 7. Sounder surface mount:

Screw types used in figure 9 to 15

A = 8-32x1-7/16" Slot

B = #8 Sheet Metal Phillips

C = 8-32x1" Phillips

D = #8 Sq. Nut

E = 8-32x5/8" Slot

F = 8-32x2-3/4" Slot

G = 6-32x5/8" Slot

Technical Manuals Online! - http://www.tech-man.com

D900-01-00 4 I56-650-16

A78-2514-00 A78-2515-00

A78-2516-00

A78-1137-08

MP-F

MA 12/24D

BB-D

MA 12/24

MP-SF

Plaster

Ring

Standard

Backbox

A78-1137-11

A78-2517-01

1. Complete field wiring.

2. Screw strobe to box with screw A.

3. Fill remaining holes with screw B.

1. Complete field wiring.

2. Screw sounder/strobe to box with screw A.

3. Fill remaining screw holes with screw B

1. Screw plate to box with screw E.

2. Complete field wiring. (See Fig. 3, 4, 5, and 6)

3. Screw sounder or sounder/strobe

to plate with screw A.

4. Fill remaining holes with screw B.

1. Screw strobe to plate with

screw C.

2. Complete field wiring.

3. Screw strobe plate to box with

screw A.

1. Screw sounder to plate.

2. Complete field wiring.

3. Screw plate sounder to box

with screw F.

1. Plaster ring should be properly mounted to electrical box with

screws supplied with box.

2. Screw plate to plaster ring with screw G.

3. Complete field wiring.

4. Screw sounder/strobe to plate with screw A.

5. Fill remaining holes with screw B.

Signal Strobe

Standard

Backbox

TOP

MA-12/24D

Signal Strobe

Standard

Backbox

Figure 8. Strobe surface mount: Figure 9. Sounder/strobe surface mount:

MP-SF

MA-12/24D

STANDARD

BACKBOX

Figure 10. Sounder or sounder/strobe semi-flush

mount:

MP-SF

Signal Strobe

TOP

STANDARD

BACKBOX

Figure 11. Strobe semi-flush mount:

Figure 12. Sounder flush mount (deep box required): Figure 13. Sounder or sounder/strobe semi-flush

mount with plaster ring:

Technical Manuals Online! - http://www.tech-man.com

D400-55-00 1 I56-691-03

SP100ADA Series Dual-transformer

Speaker/Strobes for Fire Protective

Signaling Systems

INSTALLATION AND MAINTENANCE INSTRUCTIONS

A Division of Pittway

3825 Ohio Avenue, St. Charles, Illinois 60174

1-800-SENSOR2, FAX: 630-377-6495

NOTICE: This manual should be left with the owner/user

of this equipment.

General Description

The National Fire Protection Association (NFPA) has pub-

lished standards and recommended practices for the speak-

ers described in this manual. As a result, the installer must

be familiar with these requirements as well as all local

codes and special requirements of the authority having ju-

risdiction.

SP100ADA series speaker/strobes can be operated with dis-

tribution amplifiers having an output voltage of either 25

volts or 70.7 volts.

The speakers operate at any one of six input power levels.

The output sound level is selected at the time of installa-

tion, but can be changed, if necessary.

The speaker is also equipped with a capacitive input to al-

low for DC supervision.

The SP100ADA Series Speaker/Strobe is equipped with an

attached 15, 15/75, 75, or 110 candela (cd), UL 1971 listed

strobe. Although they are shipped as a unit, the strobe and

speaker are electrically independent and require separate

power sources. Strobes can be powered by means of a 24V

regulated or full-wave rectified unfiltered supply.

Installation - For Strobe Replacement See NFPA 72,

Chapter 6

All wiring must be installed in compliance with the Na-

tional Electrical Code and all applicable local codes as well

as any special requirements of the authority having juris-

diction, using the proper wire size. This also includes all

applicable NFPA Standards, ANSI/UL 1480, and NEC 760.

Figure 1. Electrical connections:

Specifications

Mechanical

Input Terminals: 12 to 18 AWG (3.31 to 0.82 mm2)

Speaker Size: 4 inches (101 mm)

Grille Size: 5" (127 mm) square

Electrical (Speaker)

Voltage Input: 25 volts or 70.7 volts (nominal)

Frequency Range: 400 - 4000 Hz

Operating Temperature Range: 32°to 120°F (0°to 49°C)

Electrical

1. Connect the speaker/strobe as shown in Figure 1. Keep

in mind that even though the speaker and strobe are a

single mechanical unit, they are electrically independent

and require separate power sources.

NOTE: Do NOT loop electrical wiring under terminal

screws. Wires connecting the device to the control

panel must be broken at the device terminal con-

nection in order to maintain electrical supervision.

2. Notice that the speaker circuit board is equipped with

two sets of posts and associated electrical jumper wires.

One set of posts is numbered 1 through 6 while the other

is labeled Aand B. Both electrical leads are fitted with a

barrel connector. These two sets of posts and leads en-

able the installer to select any one of six sound pressure

levels with either a 25 volt or 70.7 volt amplifier.

Technical Manuals Online! - http://www.tech-man.com

D400-55-00 2 I56-691-03

For example, Table 1 shows that to select a 1/4 Watt in-

put when a 25 volt amplifier is being used, slide the blue

lead onto post 3and slide the yellow lead onto post B.

Similarly, to select a 4 Watt input with a 70.7 volt ampli-

fier, slide the blue and yellow leads onto posts 2and A,

respectively.

Table 1 also lists the UL reverberant and anechoic output

sound levels for each transformer power tap on the

SP100ADA Series Speaker/Strobes.

CAUTION

Signal levels exceeding 130% rated signal voltage can dam-

age the speaker. Consequently, an incorrect tap connection

may cause speaker damage. This means that if a 25V tap is

selected when a 70.7V amplifier is being used, speaker

damage may result. Therefore, be sure to select the proper

taps for the amplifier voltage/input power level combina-

tion being used.

NEVER connect the yellow jumper to the posts numbered 1

through 6 or the blue jumper to lettered posts Aor B.

Mechanical

Slotted head screws are included for attaching the speaker

to the electrical junction box. Insert the decorative filler

plugs supplied into the remaining two holes in the grille.

Mounting

See Figure 2. The speaker can be flush mounted on a 4" X

4" X 2-1/8" back box with a 1-1/2" extension ring, as fol-

lows:

A. Select the appropriate pair of diagonally opposite

mounting holes in the speaker grille.

B. Use the two 8-32 X 1-3/4" slotted pan head screws, pro-

vided, to attach the speaker/strobe to the back box.

C. Insert the decorative filler plugs (supplied) into the re-

maining two speaker mounting holes.

Table 1:

Figure 2:

1B 1A 2B 2A 3B 4B

2A 3B 4B 5B 6B 6A

90 87 84 81 78 75

93 90 87 84 81 78

4W 2W 1W 1/2 W 1/4 W 1/8 W

25 V

70.7 V

UL Reverberant

Anechoic

(dBA @ 10 ft.)

Technical Manuals Online! - http://www.tech-man.com

D400-55-00 3 I56-691-03

LIGHT

0˚

–45˚

45˚

90˚ –90˚

Figure 3:

Degrees % of Rating

0100

5 - 25 90

30 - 45 75

50 55

55 45

60 40

65 35

70 35

75 30

80 30

85 25

90 25

Table 2. Strobe characteristics:

Model Supply

Voltage

Range

Operating Current from Regulated

Supply Operating Current from Full-Wave Rectified

Unfiltered Supply

Average

Operating

Current

Peak

Current

(mA)

20/30V

Inrush

Current

(mA in

access of

Peak)

Average

Operating

Current

(mArms)

Peak Current

(mA)

20Vrms/30Vrms

Inrush Current

(Amps in excess

of Peak)

SP1R24110ADA

SP1W24110ADA 20-30V 210 470/500 0 245 400/500 0.08

SP1R2475ADA

SP1W2475ADA 20-30V 170 385/400 0 200 320/370 0.04

SP1R2415ADA

SP1W2415ADAB 20-30V 75 160/180 0 90 275/290 0.02

SP1R241575ADA

SP1W241575ADA 20-30V 93 210/220 0 120 275/290 1.0

Note: Inrush current lasts on the order of microseconds

Table 3:

SP100W24MC

LO = 1.5 cd UL 1638 Strobe

M = 15 cd UL 1638 Strobe

24 = 24 VDC Strobe

SP100W = Round Grille, White Speaker

SP101W = Square Grille, White Speaker

SP101R = Square Grille, Red Speaker

C = Ceiling mount

SP1R2415ADA

15 = 15 cd, UL 1971 Strobe

1575 = 15 cd UL 1971 Strobe

75 = 75 cd, UL 1971 Strobe

110 = 110 cd, UL 1971 Strobe

24 = 24 VDC Strobe

SP1R = Square Grille, Red Speaker

SP1W = Square Grille, White Speaker

V4R = V400 Square, Red Speaker

Strobe Light Ratings

The signaling strobe is rated for 0°to 49°C and is not suit-

able for outdoor use.

The rated light output of the SP1*2415ADA and

SP1*241575ADA is 15 cd (See Figure 3).

The rated light output of the SP1*2475ADA is 75 cd (See

Figure 3).

The rated light output of the SP1*24110ADA is 110 cd (See

Figure 3).

NOTE: The light output at 0°viewing angle for

SP1*241575ADA is 75 cd (See Figure 3).

R = Red

W = White

Technical Manuals Online! - http://www.tech-man.com

D400-55-00 4 I56-691-03

If either of the power option jumper wires is not plugged into one of the

appropriate option positions, the speaker will not sound and there will be

no trouble indication at the panel. Always make sure that the individual

speakers are tested after installation per NFPA regulations.

The speaker may not be heard. The loudness of the speaker meets (or

exceeds) the current Underwriters Laboratories standards. However, the

speaker may not attract the attention of a sound sleeper or one who has

recently used drugs or has been drinking alcoholic beverages. The speaker

may not be heard if it is placed on a different floor from the person in haz-

ard or if placed too far away to be heard over the ambient noise. Traffic, air

conditioners, machinery, or music appliances may prevent even alert per-

sons from hearing the alarm. The speaker may not be heard by persons

who are hearing impaired.

The Signal Strobe may not be seen. The electronic visual warning signal

that flashes at least once every three seconds meets or exceeds current

Underwriters Laboratories’ standard 1971 and uses an extremely reliable

xenon flash tube. The visual warning signal is suitable for direct viewing

and must be installed within an area where it can be seen by building oc-

cupants. The strobe must not be installed in direct sunlight or areas of

high light intensity (over 60 foot candles) where the visual flash might be

disregarded or not seen. The strobe may not be seen by the visually im-

paired.

The signal strobe may cause seizures. Individuals who have positive

photic response to visual stimuli with seizures, such as persons with epi-

lepsy, should avoid prolonged exposure to environments in which strobe

signals, including this strobe, are activated.

System Sensor recommends that the speaker and signal strobe always be

used in combination so that the risks from any of the above limitations are

minimized.

WARNING

The Limitations of Speaker/Strobes

Three-Year Limited Warranty

System Sensor warrants its enclosed speaker/strobe to be free from defects

in materials and workmanship under normal use and service for a period

of three years from date of manufacture. System Sensor makes no other

express warranty for this speaker/strobe. No agent, representative, dealer,

or employee of the Company has the authority to increase or alter the obli-

gations or limitations of this Warranty. The Company’s obligation of this

Warranty shall be limited to the repair or replacement of any part of the

speaker/strobe which is found to be defective in materials or workman-

ship under normal use and service during the three year period commenc-

ing with the date of manufacture. After phoning System Sensor’s toll free

number 800-SENSOR2 (736-7672) for a Return Authorization number,

send defective units postage prepaid to: System Sensor, Repair Depart-

ment, RA #__________, 3825 Ohio Avenue, St. Charles, IL 60174. Please

include a note describing the malfunction and suspected cause of failure.

The Company shall not be obligated to repair or replace units which are

found to be defective because of damage, unreasonable use, modifica-

tions, or alterations occurring after the date of manufacture. In no case

shall the Company be liable for any consequential or incidental damages

for breach of this or any other Warranty, expressed or implied whatsoever,

even if the loss or damage is caused by the Company’s negligence or fault.

Some states do not allow the exclusion or limitation of incidental or conse-

quential damages, so the above limitation or exclusion may not apply to

you. This Warranty gives you specific legal rights, and you may also have

other rights which vary from state to state.

Technical Manuals Online! - http://www.tech-man.com

D900-02-00 1 I56-655-03

V4R24ADA Series Speaker/Strobes

for Fire Protective Signaling Systems

INSTALLATION AND MAINTENANCE INSTRUCTIONS

A Division of Pittway

3825 Ohio Avenue, St. Charles, Illinois 60174

1-800-SENSOR2, FAX: 630-377-6495

General

The National Fire Protection Association has published

standards and recommended practices for the installation

and use of the appliances described in these instructions. It

is recommended that the installer become familiar with

these standards and practices, local codes, and any special

requirements of the authority having jurisdiction.

The speakers can operate at any one of four input power

levels at either of two input voltages. The system voltage

and sound power levels are selected at the time of installa-

tion, but can be changed, if necessary.

Strobe

Specifications

Speaker

Frequency Range: 400 Hz to 4000Hz

Supervision: Capacitive input for supervisory DC voltage

Mounting: Standard 4" X 4" electrical box

Surface mount directly to box

Semiflush mount, using model MP-SF or MP-SFB

Model Supply

Voltage

Range

Operating Current from

Regulated Supply Operating Current from Full-Wave 

Rectified Unfiltered Supply

Average

Operating 

Current

Average

Operating 

Current

(mArms)

Peak

Current

(mA)

20Vrms/

30Vrms

Peak

Current

(mA)

20/30V

Inrush

Current

(mA in

access

of Peak)

Inrush

Current

(Amps in

excess

of Peak)

V4R24110ADA

V4R2475ADA

V4R2415ADA

V4R241575ADA

20-30V 210 470/500 0 245 400/500 0.08

20-30V 170 385/400 0 200 320/370 0.04

20-30V 75 160/180 0 90 275/290 0.02

20-30V 93 210/220 0 120 275/290 1.0

NOTE: Inrush current duration is less than 20 microseconds (.00002 seconds).

Input

Voltage

(Vrms)

Power

Tap

(Watts)

Minimum Output (dBA)

Reverberant Anechoic

@ 10 ft.

25 or 70.7 1/4 75 78

25 or 70.7 1/2 78 81

25 or 70.7 1 81 84

25 or 70.7 2 84 87

The speaker is also equipped with a capacitive input to al-

low for DC supervision.

An attached 24 VDC strobe at 110, 75, 15, or 15/75 candela

(cd) is also included with the speaker. Although they are

assembled into a unit, the strobe and speaker are electri-

cally independent and require separate power sources.

Strobes can be powered by means of a full-wave rectified

unfiltered supply.

Technical Manuals Online! - http://www.tech-man.com

D900-02-00 2 I56-655-03

The light output rating of the Model V4R24110ADA is 110

cd; the V4R2475ADA is 75 cd; the V4R2415ADA is 15 cd.

The light output rating of the Model V4R241575ADA is 15

cd (See Figure 1).

NOTE: The light output at 0°viewing angle for

V4R241575ADA is 75 cd (See Figure 1).

Installation - For Strobe Placement See NFPA 72,

Chapter 6

NOTE: Installation procedure must comply with all appli-

cable local codes and any special requirements of

the authority having jurisdiction.

Electrical

All wiring must be installed in compliance with the Na-

tional Electrical Code and all applicable local codes as well

as any special requirements of the authority having juris-

diction, using the proper wire size. This also includes all

applicable NFPA Standards, ANSI/UL 1480, and NEC 760.

1. Connect the speaker and strobe as shown in Figure 2.

Keep in mind that even though the speaker and strobe

are a single mechanical unit, they are electrically inde-

pendent - the strobe must be connected to a DC supply

and the speaker to a 25Vrms or 70.7 Vrms amplifier.

Even though V4R24ADA series speakers can be used

with 25 Vrms or 70.7 Vrms amplifiers, permanent damage

can result if the speaker is improperly connected. There-

fore, be sure to use the COM and 25 terminals when a 25

Vrms amplifier is being used. Similarly, use the COM and

70.7 terminals if a 70.7 Vrms amplifier is in the system.

NOTE: Do NOT loop electrical wiring under terminal

screws. Wires connecting the device to the control

panel must be broken at the device terminal con-

nection to ensure electrical supervision.

Figure 1. Vertical and horizontal light distribution:

Degrees % of Rating

0100

5 - 25 90

30 - 45 75

50 55

55 45

60 40

65 35

70 35

75 30

80 30

85 25

90 25

LIGHT

0˚

–45˚

45˚

90˚ –90˚

2. See Figure 2. The speaker is equipped with five posts

and an associated plug with red and black wires. The

center post is COM (common) while the others are la-

beled 2W, 1/4W, 1/2W, and 1W, respectively.

The installer selects any one of four input power levels

by installing the plug onto COM and the appropriate

power post. When connecting this plug, make sure the

black wire is connected to the COM post and the red

wire to the numbered post. Otherwise, permanent

speaker damage could result.

CAUTION

If the power option plug is not plugged into one of the op-

tion positions, the speaker will not sound and there will be

no trouble indication at the panel. Always make sure that

the individual speakers are tested after installation per

NFPA regulations.

Mounting

A. General

Both slotted head and Phillips head screws are supplied

with the speaker/strobe. Use the slotted head screw to

mount the device or combination of devices on the elec-

trical box. Use the phillips head screws for attaching ac-

cessories to the speaker.

The speaker/strobe must be wall mounted so that the

top of the lens is 24 inches below the ceiling.

B. Surface Wall Mount

See Figure 3. Attach the speaker/strobe to a standard 4-

inch electrical box, using the two 8-32 X 1-7/16" slotted

screws provided. Fill the remaining screws with the

short #8 sheet metal screws, provided.

Technical Manuals Online! - http://www.tech-man.com

D900-02-00 3 I56-655-03

C. Semiflush Wall Mount

(a) System Sensor semiflush mounting plates are

shipped with #8 nuts already installed from the

back.

(b) Attach the semiflush mounting plate to a standard 4-

inch square electrical box using the two 8-32 X 5/8"

slotted screws, provided, at diagonally opposite cor-

ners, as shown in Figure 4.

mount it on the plate using the two 8-32 X 1-7/16"

slotted screws in diagonally opposite corners. Thread

a #8 sheet metal screw into each of the two remaining

holes in the speaker/strobe.

D. Plaster Ring Mount

See Figure 5. Follow the Semiflush Wall Mount proce-

dure, except attach the semiflush plate to the electrical

box, using the two 6-32 X 5/8" screws.

6-32x5/8

V400

8-32x1-7/16

#8 Sht. Mtl.

Signal Strobe

8-32x1-7/16

#8 Sht. Mtl.

6-32x5/8

8-32x5/8

Figure 5. Plaster ring mount:

A78-1799-01

8-32x1-7/16

#8 Sht. Mtl.

8-32x1-7/16

Signal Strobe

V400

Figure 3. Surface wall mount:

A78-1794-02

V400

8-32x1-7/16

#8 Sht. Mtl.

Signal Strobe

8-32x1-7/16

#8 Sht. Mtl.

MP-SF

8-32x5/8

Figure 4. Semiflush wall mount:

A78-1796-02

Figure 2:

1/4W

1/2W

COM 25 70.7

FROM

PANEL OR

PREVIOUS

DEVICE

STROBE

25 OR

70.7V

TO

NEXT

DEVICE

OR

EOL

TO

NEXT

DEVICE

OR

EOL

A78-1792-01

Technical Manuals Online! - http://www.tech-man.com

D900-02-00 4 I56-655-03

If the power option plug is not plugged into one of the option positions,

the speaker will not sound and there will be no trouble indication at the

panel. Always make sure that the individual speakers are tested after in-

stallation per NFPA regulations.

The speaker may not be heard. The loudness of the speaker meets (or

exceeds) the current Underwriters Laboratories standards. However, the

speaker may not attract the attention of a sound sleeper or one who has

recently used drugs or has been drinking alcoholic beverages. The speaker

may not be heard if it is placed on a different floor from the person in haz-

ard or if placed too far away to be heard over the ambient noise, such as

traffic, air conditioners, machinery, or music appliances that may prevent

alert persons from hearing the alarm. The speaker may not be heard by

persons who are hearing impaired.

The signal strobe may not be seen. The electronic visual warning signal

uses an extremely reliable xenon flash tube. It flashes at least once every

second and meets the 1971 Underwriters Laboratories standard for the

hearing impaired. The visual warning signal is suitable for direct viewing

and must be installed within an area where it can be seen by building oc-

cupants. The strobe must not be installed in direct sunlight or areas of

high light intensity (over 60 foot candles) where the visual flash might be

disregarded or not seen. The strobe may not be seen by the visually im-

paired.

The signal strobe may cause seizures. Individuals who have positive

photic response to visual stimuli with seizures, such as persons with epi-

lepsy, should avoid prolonged exposure to environments in which strobe

signals, including this strobe, are activated.

The signal strobe cannot operate from coded power supplies. Coded

power supplies produce interrupted power. The strobe must have an un-

interrupted source of DC power in order to operate correctly.

System Sensor recommends that the speaker and signal strobe always be

used in combination so that the risks from any of the above limitations are

minimized.

WARNING

The Limitations of Speakers and Speaker/Strobes
